Tripp Lite NetDirector B024-H4U16 User manual

1
Owner’s Manual
NetDirector®1U
Rack-Mount 4K/60 Hz
HDMI KVM Switch
with Audio
8-Port Model: B024-H4U08
16-Port Model: B024-H4U16
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Este manual está disponible en español en la página de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty

2
Table of Contents
1. FCC Information 4
2. User Notice 4
3. Package Contents 4
4. Features 5
5. System Requirements 6
5.1 Console 6
5.2 Computers 6
5.3 Cables 6
5.4 Operating Systems 6
5.5 Components 7
6. Important Safety Instructions 10
6.1 General Safety Instructions 10
6.2 Rack-Mounting Safety 11
Instructions
7. Installation 12
7.1 Stacking 12
7.2 Rack Mounting 12
7.2.1 Front Rack-Mounting 12
7.2.2 Rear Rack-Mounting 14
7.3 KVM Switch Installation 16
7.3.1 Single-Stage Installation 16
7.3.2 Two-Stage Cascade Installation 17
7.3.3 Three-Stage Cascade Installation 18
7.3.4 Multi-Display Installation 20
7.3.5 Grouping Ports into Vertical 21
Channels
8. Basic Operation 22
8.1 Hot Plugging 22
8.1.1 Hot Plugging KVM Ports 22
8.1.2 Hot Plugging Console Ports 22
8.2 Port Selection 22
8.3 Port ID Numbering 22
 8.4 PoweringO󰀨andRestarting 23
the KVM
9. OSD Operation 24
9.1 OSD Login 24
9.2 OSD Hotkey 24
9.3 OSD Main Screen 25
9.4 OSD Main Screen Headings 25
9.5 OSD Navigation 26
9.6 OSD Functions 26
9.6.1 F1: Go To 26
9.6.2 F2: List 27
9.6.3 F3: Set 28
9.6.4 F4: Admin 30
9.6.5 F5: SKP 33
9.6.6 F6: BRC 34
9.6.7 F7: Scan 35
9.6.8 F8: Logout 36
10. Hotkey Operation 37
10.1 Hotkey Port Control 37
10.2 Hotkey Setting Mode (HSM) 37
10.3 Select the Active Port 38
10.4 Auto Scan Mode 38
10.5 Skip Mode 39
10.6 Keyboard / Mouse Reset 39
10.7 Hotkey Beeper Control 39
10.8 HSM Hotkey Control 40
10.9 OSD Hotkey Control 40
10.10 Port OS Control 40
10.11 Restore Default Values 04
10.12 EDID Mode 41
10.13 Mouse Emulation Control 41
10.14 HSM Summary Table 41
11. Keyboard Emulation 43
11.1 Mac Keyboard 43
11.2 Sun Keyboard 44

3
Table of Contents
12. RS-232 Operation 45
12.1 Setup 45
12.2 RS-232 Pin Assignments 45
12.3 Console Login: HyperTerminal 46
12.4 RS-232 Commands 47
  12.4.1 Verication 47
12.4.2 Login 47
12.4.3 Logout 48
12.4.4 Open/Close RS-232 Link 48
12.4.5 Set Baud Rate 49
12.4.6 Switch Port 49
12.4.7 Hotkey Setting 50
12.4.8 OSD Hotkey 51
12.4.9 USB Reset 51
12.4.10 Restore Default Settings 52
12.4.11 Firmware Upgrade 52
12.4.12 KVM Status 53
12.4.13 EDID Mode 54
12.4.14 Broadcast Mode 54
13. Firmware Management Utility 55
13.1 Downloading the Firmware 55
13.2 Preparation 55
13.3 Starting the Upgrade 56
13.4 Upgrade Successful 58
13.5 Upgrade Failed 58
13.6 Firmware Upgrade Recovery 58
 13.7 OSDConguration 59
Backup/Restore
13.7.1 Backup 59
13.7.2 Restore 60
14. Appendix 60
14.1 B024-H4U08 and B024-H4U16 60
Connection Tables
14.1.1 B024-H4U08 (First Level) + 60
B024-H4U08 (Second Level)
14.1.2 B024-H4U16 (First Level) + 60
B024-H4U16 (Second Level)
14.1.3 B024-H4U08 (First Level) + 61
B024-H4U08 (Second Level) +
B024-H4U08 (Third Level)
 14.2 Specications 62
14.3 Administrator Login Failure 63
14.4 Factory Default Hotkeys and 63
Settings
15. Warranty and Product 64
Registration

4
1. FCC Information
2. User Notice
3. Package Contents
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense. The user must
useshieldedcablesandconnectorswiththisequipment.Anychangesormodicationstothisequipmentnot
expressly approved by Tripp Lite could void the user’s authority to operate this equipment.
Allinformation,documentation,andspecicationscontainedinthismanualaresubjecttochangewithoutprior
noticationbythemanufacturer.Themanufacturermakesnorepresentationsorwarranties,eitherexpressedor
implied,withrespecttothecontentshereofandspecicallydisclaimsanywarrantiesastomerchantabilityortness
for any particular purpose. Any of the manufacturer’s software described in this manual is sold or licensed “as is.”
Should the programs prove defective following their purchase, the buyer (and not the manufacturer, its distributor, or
its dealer), assumes the entire cost of all necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV interference caused by unauthorized
modicationstothisdevice.Itistheresponsibilityoftheusertocorrectsuchinterference.
The manufacturer is not responsible for any damage incurred in the operation of this system if the correct operational
voltage setting was not selected prior to operation. VERIFY THAT THE VOLTAGE SETTING IS CORRECT
BEFORE USE.
• NetDirector B024-H4U08 / B024-H4U16 Rack-Mount KVM Switch with Audio
• (x2) DisplayPort 1.4 Cables
• (x2) USB 3.0 Cables
• (x2) Audio Cables
• Firmware Upgrade Cable
• Foot Pad Set (4 pc.)
• Power Adapter
• North America Power Cord
• EU Power Cord
• UK Power Cord
• Owner’s Manual
Check to ensure all components are present and in good order. If anything is missing, or was damaged in shipping,
contact your dealer.
Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any damage to the
switch or to any other devices on the installation.

5
4. Features
• One USB console controls up to eight (B024-H4U08) or sixteen (B024-H4U16) DisplayPort interface computers and
two additional USB 3.0 peripheral devices.
• Cascadable to three levels – controls up to 512 computers (B024-H4U08) or to two levels--up to 256 computers
(B024-H4U16).
• Multi-Display feature – stack up to eight units and display video to up to 8 monitors (dual-display/triple-display/quad-
display/multi-display).
• Supports DisplayPort video output and allows you to choose an appropriate video output and deploy console with
exibility.
• Superior video quality – up to 4K DCI (4096 x 2160 @ 60 Hz) resolution.
• Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates.
• Audio enabled – full bass response provides a rich experience for 2.1 channel stereo sound.
• Supports HD audio.
• Computer selection via pushbuttons, hotkeys, OSD, and RS-232 commands.
• Independent switching of KVM and USB peripheral focus.
• Two-level (administrator/user) password authorization for enhanced security protection.
• Broadcast mode – operations can be simultaneously performed on all selected computers, such as software
installation and upgrading, systemwide shutdown, etc.
• Auto Scan Mode for monitoring all computers.
• Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice.
• Multilingual keyboard mapping – supports English (US), English (UK), German (DEUTCH), German (SWISS), French,
Hungarian,Italian,Japanese,Korean,Russian,Spanish,Swedish,TraditionalChinese,andSimpliedChinese.
• Mac/Sun keyboard support and emulation.
• Supports hot-plugging.
• HDMI compliant and HDCP 2.2 compliant.
• Multi-platform support for Windows, Linux, Mac, and Sun operating systems.
• Firmware upgradable.
• Supports multimedia, wireless keyboards and mouse.

6
5. System Requirements
5.1 Console
• HDMI monitor capable of the highest possible resolution in the installation
Note: For multi-display installations, multiple monitors are required. See 7.3.4 Multi-Display Installation for details.
• USB mouse
• USB keyboard
• Speakers (optional)
5.2 Computers
• An HDMI card or built-in HDMI port
Notes:
• The quality of the display is aected by the quality of the HDMI card. For best results, we recommend you purchase a
high-quality product.
• For multi-display installations, multiple monitors are required. See 7.3.4 Multi-Display Installation for details.
• USB-A port
• Audio ports (optional)
5.3 Cables
Note: The quality of the display is aected by the quality and length of the cables.
• For multi-display installations, standard USB-A to USB-B cables and standard HDMI cables are also required
Note: The B024-H4U08 and B024-H4U16 supports speaker ports only. Do not connect the microphone connector from the
KVM cable sets.
5.4 Operating Systems
OS Supported Versions
Windows Windows Server 2008, 2012, 2016, 2019 / Windows 7 SP1 / Windows 8 /
Windows 8.1 / Windows 10
Linux CentOS 7 and higher
OpenSUSE Leap 15.1
Snapshot8
10.26 and higher
Ubuntu 16.0.4 and higher
NeoKylin v7.0
Sun Sun Soloaris 11.3 and higher
Mac 10.6 and higher
Notes:
• Supports Linux Kernel 2.6 and higher.
• The B024-H4U08 and B024-H4U16 have a built-in USB 3.1 hub. They do not support PCs or operating systems that do not support
USB 3.1.

7
5.5 Components
Front View
B024-H4U08
B024-H4U16
No. Component Description
1Port Selection
Pushbuttons
For manual port selection:
• Press a port selection pushbutton for less than two seconds to bring the KVM, USB hub
and audio focus to the computer attached to its corresponding port.
• Press a pushbutton for longer than two seconds to bring the KVM and audio focus to the
computer attached to its corresponding port.
• Press pushbuttons 1 and 2 simultaneously for 2 seconds to perform a keyboard and
mouse reset. See section 10.6 Keyboard / Mouse Reset for details.
• Press pushbuttons 7 and 8 simultaneously for 2 seconds to start Auto Scan Mode.
2Port LEDs The Port LEDs are built into the Port Selection Switches. The left ones are the KVM Port
LEDs; the right ones are the USB LEDs:
KVM
• Lights DIM ORANGE to indicate the computer attached to the corresponding port is up
and running (on line).
•FlashestoindicatethatFirmwareUpgrademodeisine󰀨ect.
• Changes to BRIGHT ORANGE to indicate that the computer attached to its corresponding
port is the one that has the KVM focus (selected).
• Flashes to indicate that the computer attached to its corresponding port is being accessed
under Auto Scan mode.
USB
• Lights GREEN to indicate that the computer attached to its corresponding port is the one
that has access to the USB peripherals.
5. System Requirements
1
1
2
2
3
3
5
5
7
7
4
4
6
6
8
8

8
5. System Requirements
No. Component Description
3Firmware
Upgrade
Recovery Switch
Duringnormaloperationandwhileperformingarmwareupgrade,thisswitchshouldbe
intheNORMALposition.Ifarmwareupgradeoperationdoesnotcompletesuccessfully,
thisswitchisusedtoperformarmwareupgraderecovery.Seesection13.6 Firmware
Upgrade Recovery for details.
4Audio Jack The cables from your main speakers plug in here.
Note: The speakers plugged into the front-panel audio jack have priority over those in the rear panel.
5Firmware
Upgrade Port
Thermwareupgradecablethattransfersthermwareupgradedatafromthe
administrator’s computer to the KVM switch connects to this RJ11 connector.
6USB 3.1 Gen 1
Peripheral Hub
Section
USB 3.1 peripherals (printers, scanners, etc.) plug into this port (this may require an extra
power adapter).
Note: The USB 3.1 hub cannot be accessed through the switch by computers on the second level of a
cascaded installation.
7Reset Button Pressing this switch performs a system reset. When the system resets, the switch beeps
andtheportLEDsashinsuccessionuntiltheresetiscomplete.Aftertheresetiscomplete,
you can login again.
Note: This switch is recessed and must be pushed with a small object, such as the end of a paper clip
or a ballpoint pen.
8Power LED Lights to indicate that the switch is powered up and ready to operate.

9
Rear View
B024-H4U08
B024-H4U16
No. Component Description
1Grounding
Terminal
The grounding wire used to ground the switch attaches here.
2Power Jack The power adapter cable plugs in here.
3Audio Jack The cables from your main speakers plug in here.
Note: The speakers plugged into the front panel audio jack have priority over those plugged in here.
4Console Port
Section
The cables from your console HDMI monitor, USB keyboard, USB mouse and speakers plug
in here. Each connector is marked with an appropriate icon to indicate itself.
5KVM Port
Sections
The cables that link the switch to your computers plug in here. Each KVM port section is
comprised of a speaker jack, a USB-B port, and HDMI connector.
5. System Requirements
1 2 3
4 5
1 2 3
4 5

10
6. Important Safety Instructions
6.1 General Safety Instructions
• Read all of these instructions and save them for future reference.
• Follow all warnings and instructions marked on the device.
• Do not place the device on any unstable surface. If the device falls, serious damage will result.
• Do not use the device near water.
• Do not place the device near or over radiators or heat registers.
• The device cabinet is provided with slots and openings to allow for adequate ventilation. To ensure reliable operation
and protect against overheating, these openings should never be blocked or covered.
• The device should never be placed on a soft surface such as a bed, sofa or rug. Doing so will block the device’s
ventilation openings. Moreover, the device should not be placed in a built-in enclosure unless adequate ventilation has
been provided.
• Never spill liquid of any type on the device.
• Unplug the device from the wall outlet before cleaning. Use a damp cloth for cleaning. Do not use liquid or aerosol
cleaners.
• The device should be operated from the power source indicated on the marking label. If uncertain of the power
available, consult your dealer or local power company.
• The device is designed for IT power distribution systems up to 230V phase-to-phase voltage.
• As an added safety feature, the device is equipped with a 3-wire grounding type plug. If unable to insert the plug into
the outlet, contact an electrician to replace the obsolete outlet. Do not attempt to plug into a two-prong ungrounded
outlet. Always follow local/national wiring codes.
• Do not allow anything to rest on the power cord or cables. Route the power cord and cables to avoid them being
stepped on or tripped over.
• If an extension cord is used with this device, ensure the total ampere ratings of all products used on the extension
cord do not exceed its rated ampere rating. Also ensure all products plugged into the wall outlet do not exceed a total
of 15 amperes.
•Considerationshouldbegiventotheconnectionofequipmentandthesupplycircuit,aswellaswhate󰀨ect
overloading the supply circuit might have on overcurrent protection and supply wiring.
• To help protect the system from unexpected transient increases and decreases in electrical power, use a Tripp Lite
Surge Protector, Line Conditioner, or Uninterruptible Power Supply (UPS).
• Position system cables and power cables carefully so nothing rests on any cables.
• When connecting or disconnecting power to hot pluggable power supplies, observe the following guidelines:
– Install the power supply before connecting the power cable to the power supply.
– Unplug the power cable before removing the power supply.
– If the system has multiple sources of power, disconnect power from the system by unplugging all power cables from
the power supplies.
• Never push objects of any kind into or through cabinet slots. They may touch dangerous voltage points or short out
partsresultinginariskofreorelectricalshock.
•Donotattempttoservicethedevice;referallservicingtoqualiedservicepersonnel.
