Triton Xerophyte Mixer Unit MUST User manual

WATER-SAVING DIGITAL SHOWER
For a cleaner conscience
USER GUIDE

Content
2
Important Information………………………………………………..
Triton Xerophyte Vision………………………………………………
Innovative Water Conservation………………………………………
Digital Shower Controller…………………………………………….
Display Screen Icons…………………………………………………..
Quick Start……………………………………………………………..
Switching On and Off………………………………………………….
Adjusting the Temperature………………………..…………………
Adjusting the Flow……………………………………………….……
Using the Pause Function………………………………….…………
Settings and Configuration…………………………………………..
Navigate the Configure Menu………………………………………..
Editing Settings…………………………………….………
Maximum Shower Temperature……………………..……
Shower Time……………………………………….………
Default Shower Temperature………………………...……
Circulation Temperature Threshold……………………….
Warm up Flush……………………………………….…….
Default Shower Flow………………………………………
Circulation Time……………………………………………
Inactive Time………………………………….……………
Screen Colour………………………………………………
Water Pressure……………………………………………..
Commissioning………………………………….…………
Software Version………………………………..………….
Factory Reset………………………………………………
Product Care…………………………………………………………..
Cleaning……………………………………………………
Replacing the Batteries……………………………………
Wireless Connectivity……………………………….……..
3
4
5
6
7
8
9
10
11
12
13
13
13
14
14
14
14
15
15
15
15
16
16
16
16
16
17
17
17
18

This book contains all the necessary instructions for
you to operate and enjoy your Water-Saving Digital
Shower. Please read them carefully and keep them
safe for future reference.
The Triton Xerophyte Mixer Unit MUST only be used
with the AC power supply cable provided. If this
supply cable is damaged, it must be replaced by a
qualified person to avoid a hazard.
This appliance should not be used by children under
8 years of age. Children 8 years old and above and
persons with reduced physical, sensory or mental
capabilities or lack of experience or knowledge must
never play with, clean or maintain the appliance and
should not use this appliance until they have been
supervised or instructed on the use of the appliance
safely and warned of and understand the hazards
involved.
ImportantInformation
3

4
TritonXerophyteVision
Our vision is to design and craft aspirational yet
practical water conservation solutions that eliminate
shower water wastage without compromising the
shower experience.
We understand that enjoying a quality shower is an
important part of our daily routine. This experience
should not be marred by ineffective attempts to save
water, or feelings of guilt with your hand under the
shower while watching litres of water being wasted
down the drain until the hot water arrives.
The Triton Xerophyte has been designed to
incorporate innovative water conservation features,
while at the same time delivering outstanding
performance for the best possible shower
experience.

InnovativeWater
Conservation
5
The Triton Xerophyte's innovative digital shower water flow management
technology provides the means to effortlessly and substantially reduce shower
water waste and conserve water without impacting your daily bathroom routine or
sacrificing the luxury and pleasure you derive from spending time showering.
But installing a Triton Xerophyte is not just about removing the need for
ineffective, frustrating and messy manual water conservation interventions to your
showering routine in times of crisis. Even during times of water abundance, every
time you step into a Triton Xerophyte shower you are making a material
contribution toward the protection of our precious and fast depleting water
reserves.
A single press of the START button lets the Triton Xerophyte know you are
preparing to shower. This initiates a water warm-up function, the flow of water
from the showerhead prohibited until the water reaches the optimal shower
temperature. Once at temperature, an audible “beep” announces that your shower
is ready. You are now free to at your convenience step into the shower, press the
controller’s PLAY button to initiate shower water flow and commence showering.
This simple and uncomplicated solution to curtailing the volume of water normally
wasted while waiting for the shower water to warm also saves valuable time. While
the Triton Xerophyte is preparing your shower, you are free to continue with other
personal bathroom routines.
But the Triton Xerophyte’s water conservation features are not just confined to its
pre-shower water warm-up function. While you are showering, the Triton
Xerophyte ensures water flow rates and temperature are maintained at your
selected settings for an uninterrupted and optimal shower. And the Triton
Xerophyte incorporates a water flow timer selector and countdown display with a
mid-session PAUSE/RE-START option to help you adopt a more efficient and
focused water-conserving approach to completing your daily shower routine. A
warning “beep” sounds 30 seconds before the end of your session to prevent you
from being caught unawares when the pre-defined time limit is reached and the
water flow automatically stops.
The Triton Xerophyte - conserving precious water has never been so stylish,
effortless and pleasurable.
.

Triton Xerophyte
Control Unit
6
DisplayScreen
Power Button
FlowDecrease FlowIncrease
Play Button
Pause Button
Temperature
Decrease
Temperature
Increase
Start / Stop

Display Screen Icons
7
Warm Up Display
To cancel the warm-up and
commence a cold shower,
press PLAY. The cold
shower will be ready
to start immediately.
Colour
changesaswater
temperature
Increases.
OperatingIcons
Accept Return
Configure Icons
Full Cold Flow Rate Shower
WARMING UP
The default shower
temperature
has been reached
and your shower is
ready.
Shower water has not
reached the target
temperature during the
warm-up cycle after 120
seconds - check the hot
water source.
Warning Icons
Loss of wireless
connection
Low
Battery
Target Temperature is displayed. The circle colour
changes from blue to red depending on the water
temperature available from the hot water source.
**
**
Hot Water
supply
**
TO START
ºC
TO START
ºC
TO START
ºC
TO START
ºC
(Wireless installation only)
(Wireless installation only)

WARMING UP
The beep sounds when hot
water is available from the
source.
SHOWER TIMER
During the shower, the
remaining time is displayed
on the screen.
AUTOMATIC STOP
To immediately start
another session, press .
30s BEEP
The beep will sound 30
seconds before the end
of the session.
SWITCH ON
Press the Start
Button to activate the
warm-up cycle.
Quick Start
8
123
4 5 6
START SHOWER
Press to start.
The target temperature
is displayed.
WARMING UP
TO START
ºC
ºC
TO START

Switching
On and Off
9
Start Stop
To Stop your Shower
Press the Start/Stop Button ( ) on the Triton Xerophyte Control Unit
and your shower will stop. The display screen will go back to the ready
screen and after 60 seconds the shower will enter into sleep mode.
Note: If the shower has been in sleep mode for 3 minutes, it will restart
using default settings, if enabled (see page 13).
Starting your Shower
To start the Digital Shower, press the Start/Stop Button ( ) the
WARMING UP cycle will then commence. The temperature circle will
change colour as the available water temperature increases.

Adjusting the
Temperature
1
0
You can adjust the temperature at any time during showering. To adjust the
temperature rotate the Temperature Dial: rotate clockwise to increase the
temperature and anti-clockwise to decrease the temperature. The
temperature display will flash, while the temperature is being adjusted until
the target temperature is reached.
+-
*Small changes to the temperature may change quickly and prevent the
temperature readout from flashing.
NOTE: The temperature setting displayed on the Triton Xerophyte Control
Unit is measured within the Triton Xerophyte Mixer Unit. Depending on
your installation this may be 2-3 C higher than the water that is delivered at
the shower outlet accessory.
ºC ºC

You can adjust the flow at any time during showering. The flow rate has a
scale of 1-10.‘1’is its lowest setting and ‘10’is its maximum.
Increasing the Flow Rate
To increase the flow rate of the shower, press the Flow Increase Button ( ).
Decreasing the Flow Rate
To decrease the flow rate of the shower, press the Flow Decrease Button ( ).
The amount of green encircling the flow rate selected will increase or
decrease as the flow rate is, respectively, adjusted upwards or downwards.
12
10
Adjusting
the Flow

Pressing the Pause Button ( ) pauses the shower timer and the
water flow. Pressing the Play Button ( ) will restart the shower
timer and the water flow. The shower can be paused as many times
as is required.
Pause Shower
To pause shower, press the Pause ( ) Button
Restart Shower
To restart the shower, press the Play ( ) Button
PauseFunction
12
PAUSED

The Triton Xerophyte Shower Control Unit provides function and
display re-configuration options to personalize your shower experience.
These can be accessed and activated while you are showering or even
when the Control Unit is in sleep mode. To activate the Configure (or
Configuration) Menu, press and hold the Start/Stop Button ( ) and at
the same time the Flow Decrease Button ( ) for 3 seconds.”
Navigate the Configure Menu
When in the Configure menu, use the
temperature dial to scroll through the menu
options. This icon ( ) will appear next to
the active setting.
Editing Settings
Use the / Buttons to interact with the
display screen icons and .
NOTE: If the shower has been in sleep mode
for 3 minutes, at the next restart, it will use
the configured or default settings.
Outlet Icons
Configure
MaxShowerTemp
MaxShowerTime
Settings and
Configuration
13
Default Shower Temp
Default Shower Flow
Screen Colour
Commissioning

Maximum Shower Temperature
This will limit the showering temperature to a maximum of your
choice up to “47 degrees °C”. Using the Temperature Dial, select
your desired maximum showering temperature, then save your
selection using the Accept Button ( ).
Shower Time
This will set the showering time until your shower will
automatically return to the READY state. Using the Temperature
Dial, select your shower time. Save the setting using the Accept
Button ( ). The default factory setting is 3 minutes.
Default Shower Temperature
This will set the showering temperature from the shower outlet.
This can be set as ‘OFF’ or between 32 °C and the ‘maximum
shower temperature’ setting. If set as ‘Off’ the shower will start at
38 °C. Using the Temperature Dial, select your showering
temperature. Save the setting using the Accept Button ( ).
Circulation Temperature Threshold
This will set the temperature at which the Triton Xerophyte will
terminate the circulation process. The default is 29 °C and is
usually a good indication that hot water has arrived at the
mixer. Using the Temperature Dial, select your desired
threshold. Save the setting using the Accept Button ( ).
Settings and
Configuration
14

Warm-up Flush
With some installations water in the pipe between the Triton
Xerophyte and the showerhead results in the shower starting
with an uncomfortable cold spurt. This function enables flushing
this water when the warm-up is completed. Save the setting
using the Accept Button ( ). The default factory setting is 0 and
the maximum duration is 5 seconds.
Default Shower Flow
This will set the showering flow for the shower outlet. This can be
set as ‘OFF’ or between 1 and 10. If set as ‘Off’ the shower will
start at the last used flow setting. Using the Temperature
Dial, select your flow setting. Save the setting using the Accept
Button ( ). The default factory setting is 10.
Circulation Time
This will set the maximum time the Triton Xerophyte will
circulate if hot water is not detected. Using the Temperature Dial,
select the time setting. Save the setting using the Accept Button
( ). The default factory setting is 120 seconds.
Inactive Limit
This will set the maximum time the Triton Xerophyte will wait
for user input before switching off. Using the Temperature
Dial, select the time setting. Save the setting using the Accept
Button ( ). The default factory setting is 60 seconds.
Settings and
Configuration
15

Screen Colour
This setting enables you to choose the display screen background
colour. This can be set to black or blue. Using the Temperature
Dial, select your background colour. Save the setting using the
Accept Button ( ). The default factory setting is ‘Black’.
Water Pressure
This setting enables you to select between LOW or HIGH-pressure
installations. Selecting the LOW-pressure setting will activate the
pump while showering and increase your water pressure.
Commissioning
This setting returns your Triton Xerophyte Shower Mixer into
commissioning mode. Refer to the Installation guide for further
information.
Factory Reset
The factory reset will return all configuration options and shower
settings to default factory settings. To confirm the change you
must press and hold the Yes Button for 5
seconds. The No Button will cancel the action.
Software Version
The current software version is displayed in dd.mm.yyyy format.
Note: If the hot water source is moved or replaced at a later stage,
a factory reset is required.
Settings and
Configuration
16

Product Care
17
Cleaning
It is recommended that your Triton Xerophyte Shower Control Unit is
cleaned regularly with warm, soapy water using a microfibre cleaning cloth
(eg: E- cloth) or sponge ONLY.
DO NOT use a general-purpose cleaning cloth (eg: J-cloth) dishcloth or
scourer.
DO NOT use abrasive or aggressive chemical cleaning products as this may
affect the product surface finish and invalidate your guarantee.
Replacing the Batteries
Always use Alkaline batteries in your Triton Xerophyte Control Unit for
wireless connection.

Wireless
Connectivity
18
If the Digital Mixer Shower temporarily loses wireless connection, the digital
control panel displays this icon. The Triton Xerophyte Control Unit will
automatically try to re-establish the wireless connection. If the wireless
connection cannot be re-established within 30 seconds the display screen
will show the message ‘Connection Error!’. If the shower is running water
flow will stop automatically.
If the ‘Connection Error!’ message persists, the Triton Xerophyte Control
Unit may need to have its wireless connection reset. To reset the Triton
Xerophyte Control Unit wireless connection follow the procedure below:
Isolate the electricity supply to the Triton Xerophyte Mixer Unit.
After at least 1 minute restore the electricity to the Triton Xerophyte
Mixer Unit.
Within 2 minutes press the Flow Control Buttons together and hold
them down for at least 5 seconds.
Wireless connectivity should now be reset, if this does not resolve the
loss of connection, this process can be repeated. If for any reason the
loss of connection cannot be resolved contact IWSX in South Africa
Customer Service.

Customer Services
South Africa:
[phone]
Email:
[e-mail]
Website:
iwsx.co.za
Brochure enquiries:
[phone]
Triton Showers is a divisionof
Norcros Group (Holdings)
Limited.
Triton Showers, Triton Road, Nuneaton,
Warwickshire CV11 4NR
It is our policy to improve the design and specification of our products and we reserve theright to depart from the
design given without prior notice.
For a cleaner conscience
