OPERATION MANUAL
8012 Trotec Speedmarker CL
30W, 45W, air cooled
60W, 100W, 200W, water cooled

14/10/2015 Trotec Laser GmbH 2 / 19
Trotec Laser GmbH
Linzer Strasse 156
A –4600 Wels
AUSTRIA
Trotec Laser GmbH
Freilingerstraße 66
A –Marchtrenk
AUSTRIA
Ph.: [phone]
E-Mail: [email protected]
www.troteclaser.com
Trotec Laser GmbH cannot be held responsible for any direct or indirect damages, which result
from using or working with the products electric circuits or software described herein. The
apparatus must be used only by trained and skilled personnel. Before use the manual should be
read and followed carefully.
Furthermore Trotec reserves the right to change or alter any product described herein without prior
notice.
In case of failure, please note all data of the device (year of manufacture, software version, etc.)
and call us from a telephone next to the switched on device.
For queries or technical problems please contact your dealer or Trotec directly at the above
address.
This documentation with all illustrations is intellectual property of Trotec Laser GmbH.
The entire documentation is given to the user for personal use only. This documentation must not
be reproduced or made available to others without our written permission. Any breach of law will
be prosecuted.

8012 Trotec Speedmarker CL
TABLE OF CONTENTS
14/10/2015 Trotec Laser GmbH 3 / 19
TABLE OF CONTENTS
1 GENERAL ........................................................................................................................4
1.1 Operation Manual Use –General Information ........................................................................................ 4
1.2 Designated Use.......................................................................................................................................... 5
1.3 Disposal remarks....................................................................................................................................... 5
1.4 Technical Data / Device Specification ..................................................................................................... 6
1.5 Manufacturer's Label................................................................................................................................. 8
1.6 EU –Declaration of conformity................................................................................................................ 9
2 SAFETY..........................................................................................................................10
2.1 General Safety Information..................................................................................................................... 10
2.2 Laser Safety Information ........................................................................................................................ 12
2.3 Safety precautions during switch-on and operation ........................................................................... 13
2.4 Warning and Information Labels............................................................................................................ 14
3 PRIOR TO COMMISSIONING –SCOPE OD DELIVERY..............................................15
4 OPERATION ..................................................................................................................16
4.1 Machine view and connections.............................................................................................................. 17
5 MAINTENANCE .............................................................................................................18
5.1 Cleaning the System ............................................................................................................................... 18
5.2 Cleaning the Optical Parts...................................................................................................................... 18
5.3 Maintenance Plan .................................................................................................................................... 19

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 4 / 19
1 GENERAL
1.1 Operation Manual Use –General Information
Caution:
Please read and follow this Operation Manual carefully, before installation and operation.
Damage to persons and/or material can result from not following individual points of the
Operation Manual!
Operation of the system is only permitted with equipment and spare parts supplied or
listed in the spare parts and consumables lists.
Auxiliary equipment must be adjusted to the base machine (any queries to dealer or
manufacturer).
The following symbols are used for easier understanding of the Operation Manual:
If the Operation Manual is not observed, this area represents a particular
danger for the operating personnel or the personnel responsible for
maintenance.
Caution: This component is under voltage. In these areas strictly observe
the safety instructions regarding electricity. Care is to be taken in particular
during maintenance and repair work.
Caution: In this area pay attention to the possible dangers of the laser beam.
Note or information on individual components of the device, that simplify
the use or make it more understandable.

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 5 / 19
1.2 Designated Use
The SpeedMarker CL is a laser class IV device.
The Trotec Speedmarker CL, is an industrial apparatus with a high level of security. To
guarantee a safe operation it is necessary to know potential dangers and avoid risks.
The dangers can be classified in two categories:
Dangers caused by the laser beam
Dangers caused by electricity
The SpeedMarker CL is designed for open laser beam operation, and may be
integrated into a production line. In this particular case is the responsibility of
the integrator or end user to guarantee a safe operation via Feberal or Local
guidelines.
Caution when processing conductive materials (carbon fibers,…)! Conductive
dust or particles in the ambient air might damage electrical components and
lead to short circuits. Bear in mind that those defects are NOT warranted.
1.3 Disposal remarks
Do not dispose the machine with domestic waste!
Electronic devices have to be disposed according to the regional directives
on electronic and electric waste disposal.
In case of further questions, please ask your supplier. He might take care of
proper disposal.

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 6 / 19
1.4 Technical Data / Device Specification
Galvo Scanner
Working area
Standard: 140 x 140 mm (50x50mm –850x850mm possible)
Angular repeatability
< 22 µrad
Focal length
Standard: 200 mm (100mm –1200mm possible)
Beam diameter
Standard: 269 µm, 171µm (100mm lens), 1409µm (1200mm
lens)
Distance of object
Standard: 190 mm (distance from lower edge of scanhead to
marking area), ~88mm (100mm lens), ~1210 (1200mm lens)
Resolution
< 4 µm
Marking speed
> 800 cps possible (depending on character height and type)
Options
Laser pointer, marking on the fly, rotary encoder, rackserver-PC,
alternative galvo speeds, power stabilizer
Laser
Laser power
30 to 200 Watts CO2
Wave length
10,6 µm
Laser pointer
wavelength: 650nm, power: <0,99W, laser class II
Computer
Requirements
Windows XP, 256 MB RAM
Free 5V PCI slot, hard disk: min. 600 MB free space
For option Marking on the Fly: dummy slot necessary
Application software
WeldMark
Cooling system
Air cooling system
30W, 45W
Water cooling system
60W, 100, 200W
Electricity
Power requirements
30W: 230V, 50 Hz, 700W, 16A
110V, 60 Hz, 700W, 20A
45W: 230V, 50 Hz, 1000W, 16A
110V, 60 Hz, 1000W, 20A
60W: 230V, 50 Hz, 1300W, 16A
110V, 60 Hz, 1300W, 20A
100W: 230V, 50 Hz, 3000W, 16A
200W: 400V, 50 Hz, 4000W, 16A

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 7 / 19
Dimensions
Dimensions L x W x H [mm]
30W: 832,2 x 278 x 175,5
45W: 832,2 x 278 x 211
For the bending radii of the cables calculate at least
additional 60mm in length.
60W: 1432,5 x 278 x 211
100W: 1182,5 x 280 x 175,5
200W: 1659,8 x 308 x 227,5
For the bending radii of the cables and water hoses calculate at
least additional 100mm in length (60W, 100W & 200W).
Rack: contains power supplies and safety circuits, same
dimensions for all power classes: 706mm x 485mm (19 Zoll
compatible) x 267mm (6 height units)
Weight Laserhead / Rack [kg]
30W: 27 / 26,5
45W: 27 / 28,5
60W: 40 / 30
100W: 45 / 31,5
200W: 55 / 35
Ambient conditions
Ambient conditions
Operating temperature +10 to +30° C, relative humidity up to
max. 80%, non-condensing
Laser Safety
Laser class
CDRH laser safety
Laser Class 4
CE certified
Subject to change without PRIOR notice !

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 8 / 19
1.5 Manufacturer's Label
The manufacturer's label is located on the back of the laser source (see Figure below).
It is recommended to enter data such as serial number and year of manufacture into the
manufacturer's label below so that you always have this data handy if you have problems
with your device or require spare parts.

8012 Trotec Speedmarker CL
GENERAL
14/10/2015 Trotec Laser GmbH 9 / 19
1.6 EU –Declaration of conformity
The manufacturer
Trotec Laser GmbH.
Linzer Strasse 156,
A-4600 Wels, OÖ.,
AUSTRIA
hereby declares that the following product
Trotec 8012 Speedmarker CL
Modell N° 8012 Speedmarker CL 30/45/60/100/200
has demonstrated conformity to the following guidelines:
2006/42/EG Directive for Machines
2006/95/EG Low Voltage Directive
2004/108/EG EMC Guideline
Applied during design and construction of this product:
- EN ISO12100 Machine Safety
- EN 60335-1/2007 Safety of Household and similar Appliances
- EN 55014-1/2006, EN 55014-2/1997 Electromagnetic Compatibility
- EN 60204-1 Machine Safety –electr. Equipment
- EN 60825-1/2007, EN 60825-4/2006 and EN 60825-14/2006
Safety of Laser Equipment
- EN 55022/2008, EN 55024/2003 Electromagnetic Compatibility
Wels, Trotec Laser GmbH

8012 Trotec Speedmarker CL
SAFETY
14/10/2015 Trotec Laser GmbH 10 / 19
2 SAFETY
2.1 General Safety Information
All personnel involved in installation, set-up, operation maintenance and repair of the machine,
must have read and understood the Operation Manual and in particular the "Safety" section. The
user is recommended to generate company-internal instructions considering the professional
qualifications of the personnel employed in each case, and the receipt of the instruction/Operation
Manual or the participation at introduction/training should be acknowledged in writing in each case.
Safety-conscious Working
The machine must only be operated by trained and authorized personnel.
The scopes of competence for the different activities in the scope of operating the machine must
be clearly defined and observed, so that under the aspect of safety no unclear questions of
competence occur. This applies in particular to activities on the electric equipment, which must
only be performed by special experts.
For all activities concerning installation, set-up, start-up, operation, modifications of conditions and
methods of operation, maintenance, inspection and repair, the switch-off procedures that may be
provided in the Operation Manual must be observed.
Safety Information for the User and/or Operating Personnel
No working methods are permitted that affect the safety of the machine.
The operator must also ensure that no unauthorized persons work with the machine (e.g. by
activating equipment without authorization).
It is the duty of the operator, to check the machine before start of work for externally visible
damage and defects, and to immediately report changes that appear (including behavior during
operation) that affect the safety.
The user must provide that the machine is only operated in perfect condition.
The user must guarantee the cleanness and accessibility at and around the machine by
corresponding instructions and controls.
Principally, no safety components may be removed or disabled (already here we emphasize the
imminent dangers, for example severe burns, loss of eye-sight). If the removal of safety
components is required during repair and service, the replacement of the safety components
must be performed immediately after completion of the service and repair activities.
Preparation, retooling, change of work piece, maintenance and repair activities must only
performed with equipment switched off, by trained personnel.
It is forbidden to perform unauthorized modifications and changes to the machine. It is
emphasized, that any unauthorized modifications to the machine are not permitted for safety
reasons.

8012 Trotec Speedmarker CL
SAFETY
14/10/2015 Trotec Laser GmbH 11 / 19
The following safety specifications must be observed:
Processing may only be carried out on a machine that has been properly
installed.
The system may only be used for processing of materials. Using the system in
other areas (e.g. for medical purposes) is absolutely forbidden and is
considered to be improper use. The manufacturer shall not be liable for any
resulting damages to persons or property and the warranty will be voided.
The laser beam may not be shut off by the user. This is to be done exclusively
by specially trained service personnel.
Direct contact of the laser beam with the skin or the eyes could cause serious
injuries.
The system may only be operated, serviced and repaired by personnel that
are familiar with the intended use and with the machine's potential risks.
The non-observance of the operating, maintenance and repair instructions
provided by the manufacturer in this operating manual shall exclude the
manufacturer from any liability in the case of malfunction.
The laser beam could ignite the material to be processed. For this reason, a
fire extinguisher should be placed in the direct vicinity of the SpeedMarker CL.
Flammable materials may not be placed in the direct vicinity of the
SpeedMarker CL.
Because of their low absorption of the laser beam, many materials such as
aluminium, copper, silver and gold may not be processed with the
SpeedMarker CL. Most of the laser beam's energy is reflected. Such materials
should also not be present in the area of the laser beam.
Should you have any additional questions, please contact your integrator or Trotec!

8012 Trotec Speedmarker CL
SAFETY
14/10/2015 Trotec Laser GmbH 12 / 19
2.2 Laser Safety Information
To assess the potential dangers laser systems pose, they are classified into
5 safety classes: 1, 2, 3a, 3b and 4. Speedy 300 is a device of class 4 (USA:
Class IV). The safety is to be guaranteed through the Integrator.
This laser engraving system contains a Class 4 carbon dioxide (CO2) laser
that emits intensive and invisible laser radiation. Without protective gear,
direct radiation, diffusely reflected radiation, or even stray radiation could be
dangerous!
Anyone who is exposed to laser radiation without protective gear is subjected
to the following risks:
Eyes: Burns to the cornea
Skin: Burns
Clothing: Danger of fire
For this reason, never attempt to dismantle or rebuild the laser under any
circumstances, and do not attempt to operate a system that has been
dismantled or rebuilt!
If any operating or calibration devices other than the ones specified
here are used, or any other procedural methods are followed,
dangerous exposure to radiation could occur.
Service technicians are required to wear standard laser-safety goggles for
CO2lasers (wavelength 10.6 µm).

8012 Trotec Speedmarker CL
SAFETY
14/10/2015 Trotec Laser GmbH 13 / 19
2.3 Safety precautions during switch-on and operation
1. Power On/Off switch –main switch1
Using the main switch on the left hand side, switch the SpeedMarker CL on and off.
The key for key switch 2can only be removed while in the 12 o'clock position. The
control circuit is activated in the 3 o'clock position and the laser can be switched on
using button 3.
Button 3must be activated with the first switch-on.
2. Power-On Reset switch –button 3
Press button 3 in order to reset the voltage.
Laser radiation will not be emitted:
1. when the power is turned off and turned back on again (power supply error)
while the main switch is turned on to "position 1"
2. when the circuit for the earthing contact (hard interlock) was open and is closed
again.
The user must push button 3 in order to proceed, i.e. laser emissions are
possible when button 3 is illuminated
Main switch 1 Key switch 2
Button 3
3. During operation, the software shows on the screen that laser radiation is being
emitted. The laser is active!
Should you still have questions regarding safety prior to starting operations, please contact
your supplier or Trotec.

8012 Trotec Speedmarker CL
SAFETY
14/10/2015 Trotec Laser GmbH 14 / 19
2.4 Warning and Information Labels
Warning and information labels have been placed on the machine in every
location that could represent a source of danger prior to start-up or during
operation. Please pay special attention to the instructions on the labels.
Should any of the labels become damaged or lost, please replace them
immediately.
30-watt SpeedMarker CL
Scanner

8012 Trotec Speedmarker CL
Prior to commissioning –Scope od delivery
14/10/2015 Trotec Laser GmbH 15 / 19
3 Prior to commissioning –Scope od delivery
The following basic parts are included:
1. Laser source including scanning unit
2. Rack
3. Cabling
4. SP-ICE interface card
5. WeldMark user software, incl. dongle
1) 2)
3) 4, 5)

8012 Trotec Speedmarker CL
OPERATION
14/10/2015 Trotec Laser GmbH 16 / 19
4 OPERATION
Prior to start-up and operation of the system, this manual is to be carefully read and
the instructions within observed!
The SpeedMarker CL is an industrial laser system with a high standard of safety.
In order to operate the laser system, it is a prerequisite to know the potential dangers and
risks. The dangers and risks can be separated into 2 categories:
Danger from laser beam
Danger from electricity
The SpeedMarker CL is intended for for open beam use when integrated into
a production line.
In this case, it is the responsibility of the integrator or the end user to ensure
its safe operation and any additional certification required.

8012 Trotec Speedmarker CL
OPERATION
14/10/2015 Trotec Laser GmbH 17 / 19
4.1 Machine view and connections
60-watt SpeedMarker CL water-cooled model
Rack
Laser Source
Telescope
Scan head
Laser pointer (optional)

8012 Trotec Speedmarker CL
MAINTENANCE
14/10/2015 Trotec Laser GmbH 18 / 19
5 MAINTENANCE
5.1 Cleaning the System
Caution –use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous laser radiation exposure.
Before starting cleaning and maintenance work always switch off the device
and unplug the mains plug.
You should inspect at least once a day whether any dust has collected on the
focusing lens. Should there be any dust, the lens must be cleaned.
Cleaning intervals will greatly depend on the type of material that you are
working with, and on the length of use of the machine. Remember that a
clean, well maintained unit will provide the best performance and will
minimize service costs. If the laser beam passes through an unclean lens,
the lens can be easily damaged since the dust will most often absorb the
CO2laser's beam. A very dirty housing on an air-cooled laser will lead to
overheating and thus to the laser’s breakdown.
General cleaning:
1. Switch off the machine.
2. Clean the lens on the underside of the scanner.
3. Clean the housing for the laser source.
5.2 Cleaning the Optical Parts
Trotec recommends to use following cleaning material:
Lens tissues Part number 69249
Lens cleaner Part number 69248
The lens is of high quality and will not be damaged when cleaned carefully
and correctly.
Use each cleaning cloth one time only.
Cleaning instructions:
Use oil-free, water-free air pressure in order to remove all particulate from the surface
of the lens.
This guarantees that the lens will not be scratched during the subsequent cleaning with
cleaning cloths and fluid.

8012 Trotec Speedmarker CL
MAINTENANCE
14/10/2015 Trotec Laser GmbH 19 / 19
5.3 Maintenance Plan
Daily
Weekly
Monthly
Annually
Laser system
Lens
Inspect,
clean if
necessary
Housing for laser tubes
and general housing
Cleaning
Entire processing area –
general cleaning
Cleaning
Correct functioning of the
Interlock system
Inspect
Water-cooled system
For water-cooled laser
tubes
Check water
pressure
acc. to
instructions
Extraction system
Filter
Filter matte
See operating manual for the extraction system
Filter for particles
Filter for active carbon
For detailed information on the maintenance activities on exhaust and cooling
systems please refer to the respective manuals.
