Trotec Speedy 400 flexx User manual

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 1 of 62
Operation
Manual
Speedy 400 flexx
This documentation with all illustrations is intellectual property of Trotec Laser GmbH.
The entire documentation is given to the user for personal use only. This documentation
must not be reproduced or made available to others without our written permission. Any
breach of law will be prosecuted.

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 2 of 62
Trotec LaserGMBH
Linzer Straße 156
A –4600 Wels
AUSTRIA
Tel.: ++43/7242/239-7000
E-Mail: [email protected]
Troteccannot be held responsible for any direct or indirect damages, which result
from using or working with the products electric circuits or software described
herein. The apparatus must be used only by trained and skilled personnel. Before
use the manual should be read and followed carefully.
Furthermore Trotec reserves the right to change or alter any product described
herein without prior notice.
In case of failure, please check the device first according to section 5.4 Tips for
Troubleshooting. If unsuccessful, please note all data of the device (year of
manufacture, software version, etc.) and call us from a telephone next to the
switched on device.
For queries or technical problems please contact your dealer or Trotec directly at
the above address..

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 3 of 62
TABLE OF CONTENTS
1GENERAL...............................................................................................5
1.1 Operation Manual Use - General Information.........................................................5
1.2 Designated Use..........................................................................................................6
1.3 Disposal remarks.......................................................................................................6
1.4 Technical Data / Device Specification.....................................................................7
1.5 Manufacturer's Label ................................................................................................9
1.6 EU - Declaration of conformity...............................................................................10
2SAFETY................................................................................................11
2.1 General Safety Information.....................................................................................11
2.2 Laser Safety Information ........................................................................................12
2.3 Safety Precautions when Operating the Device...................................................14
2.4 Warning and Information Labels ...........................................................................15
3BEFORE OPERATION.........................................................................17
3.1 Forklift transport......................................................................................................17
3.2 Contents of Delivery................................................................................................18
3.3 Location....................................................................................................................19
3.4 Electrical - Requirements .......................................................................................20
3.5 Exhaust System –Requirements...........................................................................21
3.6 Computer –Requirements .....................................................................................21
3.7 Connections.............................................................................................................22
3.7.1 Connecting the Mains ...........................................................................................22
3.7.2 Connecting the Computer.....................................................................................23
3.7.3 Connecting the Exhaust System...........................................................................24
4OPERATION.........................................................................................25
4.1 Machine view and connections front ....................................................................25

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 4 of 62
4.2 Machine view and connections back ....................................................................26
4.3 ON/OFF Switch ........................................................................................................31
4.4 Keypad......................................................................................................................32
4.1 Tables.......................................................................................................................35
4.1.1 Engraving Table (Standard table).........................................................................35
4.1.2 Vacuum Table.......................................................................................................35
4.1.3 Cutting Table.........................................................................................................35
4.2 First Steps before Marking.....................................................................................36
4.3 First marking Tests .................................................................................................39
4.4 Manually switching Lasersources.........................................................................41
4.5 Tips and Tricks........................................................................................................42
4.5.1 for Laser Engraving...............................................................................................42
4.5.2 for Laser Cutting....................................................................................................44
4.5.3 for the Production of Rubber Dies.........................................................................45
5MAINTENANCE....................................................................................46
5.1 Cleaning the System...............................................................................................46
5.2 Cleaning the Optical Parts......................................................................................47
5.2.1 CLEANING THE LENS.........................................................................................47
5.2.2 CLEANING THE MIRRORS #2, #3 AND #4.........................................................49
5.3 Maintenance Plan....................................................................................................51
6MATERIAL TABLE............ FEHLER! TEXTMARKE NICHT DEFINIERT.
7TIPS FOR TROUBLESHOOTING ........................................................57
8TROTEC FORMS .................................................................................58
8.1 Acceptance report...................................................................................................58
8.2 TRAINING SCHEDULE ............................................................................................59
8.3 Response Form .......................................................................................................60
9HOW TO CREATE A SERVICE FILE...................................................61

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 5 of 62
1 GENERAL
1.1 Operation Manual Use - General Information
Caution:
Please read and follow this Operation Manual carefully, before
installation and operation. Damage to persons and/or material can
result from not following individual points of the Operation Manual!
Operation of the system is only permitted with equipment and spare parts supplied
or listed in the spare parts and consumables lists.
Auxiliary equipment must be adjusted to the base machine (any queries to dealer or
manufacturer).
The following symbols are used for easier understanding of the Operation Manual:
If the Operation Manual is not observed, this area represents a
particular danger for the operating personnel or the personnel
responsible for maintenance.
Caution: This component is under voltage. In these areas strictly
observe the safety instructions regarding electricity. Care is to be
taken in particular during maintenance and repair work
Caution: In this area pay attention to the possible dangers of the laser
beam.
Note or information on individual components of the device, that
simplify the use or make it more understandable.

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 6 of 62
1.2 Designated Use
The TROTEC laser engraver, Speedy 400 flexx, is used for engraving and cutting of
signs, stamps and suchlike.
A wide variety of materials such as rubber, acrylic, coated metal, tin, special steel,
anodized aluminum, cork, cardboard, glass, leather, marble, several plastics and
wood can be processed on the laser.
The working process must only be performed with a perfectly adjusted
machine (see also Section 4 OPERATION).
For cutting applications with 40 W and more the use of the cutting
table is absolutely necessary.
Use of the system in other areas is against the designated use. The
manufacturer does not admit liability for damage to personal and/or
equipment resulting from such use.
The system must only be operated, maintained and repaired, by
personnel that are familiar with the designated field of use and the
dangers of the machine!
Non-observance of the instructions for operation, maintenance and
repair described in this Operation Manual excludes any liability of the
manufacturer if a defect occurs.
Caution when processing conductive materials (carbon fibers,)!
Conductive dust or particles in the ambient air might damage electrical
components and lead to short circuits. Bear in mind that those defects
are NOT warranted.
1.3 Disposal remarks
Do not dispose the machine with domestic waste!
Electronic devices have to be disposed according to the regional
directives on electronic and electric waste disposal. In case of
further questions, please ask your supplier. He might take care of
proper disposal.

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 7 of 62
1.4 Technical Data / Device Specification
Mechanics
Working area
1000 x 610 mm (39 x 24 in)
Loading area
Up to 1090 x 690 mm x 305 mm (42.9 x 27.1 x 12 in) - depending on working
table; up to 1045 x ? x 185 mm (41 x ? x 7.2 in) - depending on working table,
with pass-trough
Max. height of work piece
Up to 305 mm (12 in) depending on table configuration and lens
Work piece table
Flexible table design: engraving, vacuum and cutting table; aluminum grid;
computer controlled and programmable servo z-axis
Speed of motion system
355 cm/sec. (139 in/sec) CO2
200 cm/sec. (78 in/sec) fiber
Acceleration
4 g
Motor
Brushless DC servomotor
Encoder
Increment measuring system
Lenses
2.85" (standard); 1.5", 2.0", 2.5", 3.2", 4.0", 5.0" (optional)
Addressable accuracy
5µm
Repeatability
< 0,015 mm (0.0006 in)
Accuracy to size of parts
According to material an process
Maximum material load
20 kgs (55 lbs) area load over the whole working area
Exhaust
Table exhaust via rear of engraving cabinet
Standard Features
Harsh environment protection kit, Ergonomic access to working area, electro-
optic autofocus, laserpointer (655nm, <0,99mWcw), coaxial air assist (without
pump), 2.85" lens (can be exchanged free of charge with 1.5", 2.0", 2.5", 3.2",
4.0", 5.0" lens), trolley base, one working table of choice (vacuum or cutting
table, black aluminum grid or engraving table), USB connection, JobControl X
Expert software
Options
Pass-through opening (back), rotary attachment, air assist including
compressor, temperature sensor, laser power upgrade, vacuum table, engraving
table, black aluminum grid, cutting table (lamellas), honeycomb table, white
plastic cutting grid
Options
Pass-through opening (back)
Height/width: 185 x 1045 mm (7.2 x 41 in)
maximum material height 185 mm (7.2 in)
Rotary attachment
Cones, roller or combined version; tiltable
JobControl® Vision camera
JobControl® Vision Vision; max. working area: 1000 x 610 mm (39.3 x 24 in)
Engraving via JobControl with camera attached: 975 x 600 mm (38.3 x 23.6 in)
Vacuum table
Vacuum effect for thin or corrugated materials
Honeycomb table
In combination with vacuum table
Black aluminum grid
For reflection-free cutting of small objects
Cutting table
Removable aluminum lamellas
Control System
Software
JobControl X Expert
Laser power
Adjustable 0 - 100%
Interface hardware
USB, RS-232 (RS-232 mandatory for TroCAM and JobControl® Vision)
Interface software
ASCII, HPGL, JobContro

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 8 of 62
Laser Equipment
Laser tube
Sealed off CO2 Laser, maintenance-free,
Laser Power 40 - 120 W, air-cooled
Pulsed fiberlaser, maintenance free
Laserpower: 10W, 20W, 30W, 50W
Wavelength
10,6m CO2, 1064 nm fiber
Dimensions
Width/depth/height
1400 x 950 x 1070 mm / 55 x 37.4 x 42.1 inch
Weight
Approx. 350 kgs / 770 lbs (depending on laser power)
Ambient conditions
Mandatory ambient temperature +15 to +25 C or 59 to 77 F
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
Laser Safety
Laser class
CDRH laser safety; CE tested
Laser class 2 (Laser class 4 when operated with pass-through opening)
Interlock
Duplicate interlock safety system
Loading lid
Front side loading lid
Exhaust
Required
Atmos Duo Plus or equivalent
Electrical Equipment
Power consumption
1,4 kW (60 W laser power)
Subject to change without notice. Errors and omissions excepted. March 2012

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 9 of 62
1.5 Manufacturer's Label
The Manufacturer's Label is located on the backside of the machine (see picture
below).
It is recommended to enter data such as serial number and year of manufacture
data sheet above so that you always have this data handy if you have problems with
your device or require spare parts.

8026 | V5.0_EN (11/2015)
Technical changes reserved
Trotec Laser GmbH
Page 10 of 62
1.6 EU - Declaration of conformity
(Machine directive 2006/42/EG, appendix II A)
Manufacturer:
Trotec Laser GmbH.
Linzer Strae 156,
A-4600 Wels
Authorized person for the compilation of technical documentation:
Gerhard KREMPL, Trotec Laser GmbH., Linzer Strae 156, A-4600 Wels
We hereby certify that
Speedy400 flexx
Model N 8027 Speedy400 flexx
in its conception, construction and form put by us into circulation is in accordance with all the
relevant essential health and safety requirements of the EC machinery directive
2006/42/EEC.
Further valid guidelines/regulations for the product:
2006/95/EG Low Voltage Directive
2004/108/EG EMC Guideline
Applied harmonized standards:
- EN ISO12100 Machine Safety
- EN 60335-1/2007 Safety of Household and similar Appliances
- EN 55011 + A1/2010 Electromagnetic Compatibility
- EN 60204-1 Machine Safety - electr. Equipment
- EN 60825-1/2007, EN 60825-4/2006 and EN 60825-14/2006 Safety of Laser Equipment
- EN 61000-6-2/2005, EN 61000-3-3/2008 and EN 61000-3-2 +A1 +A2/2009 Electromagnetic
Compatibility
Place, Date:
Wels, 02.07.2012
Personal data of the signer:
Stephan FAZENY, Head of Research and Development
Signature:
_______________________________________________
