Trotec SL800-SET User manual

TRT-BA-SL800-SET-TC2016-21-002-EN
SL800-SET
EN
OPERATING MANUAL
ULTRASONIC DETECTOR

2 EN
ultrasonic detector SL800-SET
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................3
Transport and storage...........................................................5
Operation ...............................................................................5
Errors and faults....................................................................9
Maintenance and repair ......................................................10
Disposal ...............................................................................10
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
SL800-SET
https://hub.trotec.com/?id=43700
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not expose the device to strong vibrations.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Only use the device, if sufficient safety precautions were
taken at the surveyed location (e.g. when performing
measurements along public roads, on building sites etc.).
Otherwise do not use the device.
• Observe the storage and operating conditions (see
Technical data).
• Do not expose the device to directly squirting water.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.

EN 3
ultrasonic detector SL800-SET
Intended use
Only use the device for the detection of irregularities in the
ultrasound spectrum within the measuring range specified in
the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Foreseeable misuse
Do not use the device in potentially explosive atmospheres, for
measurements in liquids and at live parts.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning
Risk of hearing damage!
Ensure sufficient ear protection when there are sources
of loud sound. There is a danger of hearing damage.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The measuring device serves the purpose of detecting the
slightest irregularities in the ultrasound spectrum caused by
e.g.:
• leakages in pressure tanks, vacuum systems, tanks,
compressed-air system lines, valves
• cavitation processes in supply lines for liquids and gases
• electrical discharges due to insulation failure, short
circuits, arcing
• mechanical wear in roller / ball bearings, valves, gears etc.
• leakages in the pneumatic brakes of trucks and trains
• insulation faults at untight door frames, window reveals
and room seals

4 EN
ultrasonic detector SL800-SET
Device depiction
Receiver
OFF
POWER/VOL
RECEIVER
MIN MAX
INTENSITY
1
2
3
4
5
6
No. Designation
1 Locking screw for probes
2 LED bar graph (intensity MIN to MAX via 10LEDs)
3 On/Off thumbwheel and volume control
4 Connection socket for headphones
5 Battery compartment with cover
6 Signal input and connection for probe
SL800T (ultrasonic transmitter)
7
8
9
5
No. Designation
5 Battery compartment with cover
7 Transmitter for ultrasonic signal (40kHz)
8 Operating control lamp
9 On/off switch
Accessories
10
12
14
13
15
11
11
No. Designation
10 Airborne sound probe
11 Adapter
12 Headphones
13 Jack plug
14 Volume control for headphones
15 Structure-borne sound probe

EN 5
ultrasonic detector SL800-SET
Technical data
Parameter Value
Signal input connection Airborne sound probe,
structure-borne sound probe
Display of the ultrasonic
intensity
LED bar graph, 10 levels
Acoustic rendition Soundproof headphones, high
attenuation of ambient sounds
Frequency range 36kHz to 44kHz
Power supply 9 V IEC 6F22
Operating conditions 0 to 40°C, < 75%RH
Dimensions
(lengthx widthx height)
197 x 73 x 33 mm (SL800R) /
203 x 73 x 33 mm (SL800T)
Weight (incl. battery, without
probes)
180 g (SL800R), 160 g
(SL800T)
Scope of delivery
• 1 x Receiver SL800R
• 1 x Transmitter SL800T
• 1 x Headphones
• 1 x Structure-borne sound probe for SL800R
• 1 x Airborne sound probe for SL800R
• 1 x Transport case
• 2x 9V battery
• 1x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device, use the transport case included in
the scope of delivery in order to protect the device from external
influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• For storing the device, use the transport case included in
the scope of delivery in order to protect the device from
external influences.
• the storage temperature complies with the values specified
in the Technical data
• Remove the batteries from the device.
Operation
Inserting the battery
Insert the supplied battery in the SL800R and the SL800T before
first use.
Note
Make sure that the surface of the device is dry and the
device is switched off.
+
-
1. Open the battery compartment at the rear of the device by
sliding down the cover.
2. Use the battery clip to connect the 9V battery with correct
polarity.
3. Place the battery with the battery clip into the battery
compartment.
4. Slide the cover back onto the battery compartment until it
locks in place.
Inserting / exchanging the probe
The SL800R can be equipped with various probes.
The scope of delivery includes a structure-borne and an
airborne sound probe.
The structure-borne sound probe serves the purpose of
detecting material-borne ultrasonic frequencies via direct
contact of the object to be examined (e.g. a ball bearing).
The airborne sound probe serves the purpose of detecting
airborne ultrasonic frequencies even at a distance of up to
several metres.

6 EN
ultrasonic detector SL800-SET
In order to assemble or exchange a probe, please proceed as
follows:
1. Loosen the locking screw(1) at the SL800R.
OFF
POWER/VOL
RECEIVER
MIN MAX
INTENSITY
1
2. If applicable, remove the probe.
3. Put the probe adapter(11) into the holder(6) at the
SL800R.
11
6
4. Retighten the locking screw(1).
OFF
POWER/VOL
RECEIVER
MIN MAX
INTENSITY
1
5. Check the probe for tight fit.
Connecting the headphones
It is recommended to connect the supplied headphones to the
SL800R at all times. Human hearing already perceives very subtle
signal changes with regard to its volume and intensity, so in
addition to the LED indication you are provided with a valuable
acoustic component for a yet more precise detection of ultrasound
sources.
Warning
Risk of hearing damage due to unknown, intense
ultrasound sources.
The sound spectrum perceptible by human ears lies in
the frequency range between 16Hz and 20,000Hz.
Hence, ultrasound is clearly outside of this range. As a
result potential, more or less intense ultrasound sources
in the immediate measuring environment go unnoticed
without technical aids. Nonetheless, they can
inadvertently lead to hearing damage if the auditory
system is suddenly faced with the high-intensity
ultrasound rendered audible by use of these aids.
For that reason always set the volume control at the
headphones to minimum before starting a measurement
(narrow end of the wedge at the volume control).
Increase the volume only slowly.
If necessary, reduce the volume when approaching a
potential ultrasound source.

EN 7
ultrasonic detector SL800-SET
Please proceed as follows to connect the headphones to the
SL800R:
üBoth the SL800T and the SL800R are switched off.
1. Set the volume control(14) at the headphones to the
minimum (narrow end of the wedge at the volume control).
OFF
POWER/VOL
RECEIVER
MIN MAX
INTENSITY
4
13
14
2. Plug the jack plug(13) into the connection socket(4) of the
SL800R.
General information regarding the work with the ultrasonic
detector
Info
Note that moving from a cold area to a warm area can
lead to condensation forming on the devices' circuit
board. This physical and unavoidable effect can falsify
the detection result. In this case, the device emits
either no signals or they are incorrect. Wait for a few
minutes until the devices have become adjusted to the
changed conditions before using the devices.
Info
Please note that the measurement of an ultrasound
source always has to be carried out directly. There
must be no objects or persons located between the
airborne sound probe and the ultrasound source, for
this would hamper the detection process.
Info
In case of very weak ultrasound sources the bar graph
might not indicate a change despite full intensity. If so,
use headphones to work with the acoustic component.
Switching on the SL800R
üA probe is assembled.
üThe headphones are possibly connected.
1. Slowly turn down the thumbwheel(3) until it clicks into
place.
OFF
LOV/REWOP
RECEIVER
MIN MAX
INTENSITY
RECEIVER
OFF
LOV/REWOP
3
ðThe LEDs at the bar graph light up briefly from MAX to
MIN.
ðThe LED next to MIN is permanently illuminated.
ðThe SL800R is switched on.
Using the SL800R with airborne sound probe
The airborne sound probe is suitable for the following fields of
application:
• Leak detection at exposed lines and pipes
• Proving the leakage-related loss at gas-filled supply
networks also during operation
• Leak detection at high-pressure steam installations
• Localization of cracks, poor weld seams or worn flange
connections
• Leak detection at all accessible fittings and connecting
elements where processes take place in a vacuum or at
high pressure
üThe airborne sound probe is assembled.
üThe SL800R is switched on.
üThe volume control at the headphones is set to minimum.
1. Put on the headphones.
2. Test the volume by rubbing the fingertips of thumb and
index finger against one another at a distance of approx.
50cm from the airborne sound probe.

8 EN
ultrasonic detector SL800-SET
3. Carefully increase the intensity via the thumbwheel(3)
until there is a deflection on the bar graph(2).
ðThe receiver is now set to high sensitivity!
4. Carefully increase the volume at the headphones(14) until
you can hear a sound.
5. Now move the airborne sound probe towards the
ultrasound source.
6. Since the intensity of the ultrasound source to be detected
is initially unknown, down-regulate the volume at the
headphones as appropriate when approaching the source
of ultrasound.
7. Whilst approaching the source, the sound grows louder
and the number of illuminated LEDs on the bar graph
increases.
8. If required, adjust the intensity via the thumbwheel(3).
Using the SL800R with structure-borne sound probe
The structure-borne sound probe utilizes structure-borne sound
as bearer of inner states and processes. Hence, the device
combination works like an electronic stethoscope.
The structure-borne sound probe is suitable for the following
fields of application:
• Early detection of wear at ball, roller or slide bearings
• Checking centrifugal pumps for cavitation
• Tightness tests of fittings
• Continuity testing or functional check of steam traps
üThe structure-borne sound probe is assembled.
üThe SL800R is switched on.
üThe volume control at the headphones is set to minimum.
1. Put on the headphones.
2. Hold the probe to the test object.
3. Carefully increase the intensity via the thumbwheel(3)
until there is a deflection on the bar graph(2).
4. Carefully increase the volume at the headphones(14) until
you can hear a sound.
5. Move the probe towards the ultrasound source.
6. Down-regulate the volume at the headphones when
approaching the source of ultrasound.
7. Whilst approaching the source, the sound grows louder
and the number of illuminated LEDs on the bar graph
increases.
8. If required, adjust the intensity via the thumbwheel(3).
Switching on the SL800T
The SL800T emits an acoustic signal in the ultrasonic range
(40kHz) of unvarying intensity.
1. Press the Power button(9).
TRANSMITTER
ðThe operating control lamp(8) is illuminated.
ðThe SL800T is switched on and emits the ultrasonic
signal.
Using the SL800T with SL800R and airborne sound probe
Use the SL800T with the airborne sound probe for the following
fields of application:
• Tightness testing to determine the cause of energetic
defects, e.g. at doors or windows
• Checking containers, housings or climatic chambers for
tightness
• Subjecting tanks or containers to ultrasound so as to test
sealing components
Info
In case of larger rooms the SL800T should be
positioned near potential weak spots so as to make it
easier for them to be detected.
üThe airborne sound probe is mounted to the SL800R.
üThe volume control at the headphones is set to minimum.
1. Position the SL800T at the place to be inspected (e.g.
behind a door or window) or within the object to be
examined (e.g. a tank).
2. Press the Power button(9) on the SL800T.
3. Shut the object properly.
4. Switch on the SL800R using the thumbwheel(3).
5. Put on the headphones.

EN 9
ultrasonic detector SL800-SET
6. Check the surroundings of the object to be examined for
tightness.
7. A leak is indicated by a deflection of the bar graph and by
a changed acoustic signal through the headphones.
TRANSMITTER
OFF
POWER/VOL
RECEIVER
MIN MAX
INTENSITY
Switching off the SL800T
1. Press the Power button(8).
TRANSMITTER
ðThe operating control lamp(8) goes out.
ðThe SL800T is switched off.
Switching off the SL800R
1. Switch the SL800R off by turning the thumbwheel(3)
towards OFF until it clicks into place.
OFF
LOV/REWOP
RECEIVER
MIN MAX
INTENSITY
RECEIVER
OFF
LOV/REWOP
3
ðThe LED(2) at the bar graph goes out.
ðThe SL800R is switched off.
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device is not working:
• The battery might be empty. Replace it with a new one.
Signal from transmitter is not received:
• The battery might be empty. Replace it with a new one.
• Transmitter or receiver are not switched on or the distance
is too large. Reduce the distance from the transmitter that
is not received.
• The ultrasonic locating function of the SL800 strongly
depends on the direction. Check whether the signal input
of the receiver is facing the ultrasonic source or the
potential leak.
• In addition, carefully increase the volume at the receiver (if
necessary).

10 EN
ultrasonic detector SL800-SET
Maintenance and repair
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
The device and its components are not dishwasher-safe.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Battery change
A battery change is required when the battery status indication
flashes or the device can no longer be switched on (see chapter
Inserting the batteries).
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. You can also find out about other return options
that apply for many EU countries on the website
https://hub.trotec.com/?id=45090. Otherwise, please contact an
official recycling centre for electronic and electrical equipment
authorised for your country.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
You are responsible for deleting any personal data stored on the
waste equipment to be disposed of.
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
