True TMC Series User manual
............ www.truemfg.com ............
TABLE OF CONTENTS
Safety Information
Safety Precautions 1
Proper Disposal 2
Connecting Electricity 3
Adapter Plugs 3
Installation / Operation Instructions
Ownership 4
Required Tools 4
Uncrating 4
Locating & Leveling Cabinet 5
Electrical Instructions 6
Wire Gauge Chart 7
Start-up & Shelf Installation 8
Maintenance, Care & Cleaning
Cleaning Condenser Coil 9-10
Stainless Steel Equipment Care & Cleaning 11-12
Temperature Control Adjustment 13
Warranty (U.S.A. & Canada Only!) 14
INSTALLATION MANUAL FOR
TMC UNITS (MILK COOLERS)
MILK COOLERS
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434
(636)-240-2400 • FAX (636)272-2408 • INT’L FAX (636)272-7546 • (800)325-6152
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471
CONGRATULATIONS!
You have just purchased the finest commercial
refrigerator available. You can expect many years of
trouble-free operation.
TMC-34
TMC-49-S
TMC-58-S-DS
#912629 • WP-51
............ www.truemfg.com ............
True Food Service Equipment, Inc.
............ www.truemfg.com ............
SAFETY INFORMATION
True Food Service Equipment, Inc.
11
-
-
NOTE
We strongly recommend that any
servicing be performed by a qualified
individual.
WARNING!
Use this appliance for its intended purpose as described
in this Owner Manual.
This cabinet contains fluorinated greenhouse gas covered by the Kyoto Protocol
(please refer to cabinet’s inner label for type and volume,
GWP of 134a= 1,300. R404a= 3,800).
How to Maintain Your
Refrigerator to Receive the Most
Efficient and Successful Operation
You have selected one of the finest commercial refrigeration units made. It is manufactured under strict qual-
ity controls with only the best quality materials available. Your TRUE cooler when properly maintained will give
you many years of trouble-free service.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
............ www.truemfg.com ............
True Food Service Equipment, Inc.
SAFETY INFORMATION
2 2
PROPER DISPOSAL OF THE REFRIGERATOR
DANGER!
RISK OF CHILD ENTRAPMENT
USE OF EXTENSION CORDS
NEVER USE AN EXTENSION CORD! TRUE will not warranty any refrigerator that has been
connected to an extension cord.
Before You Throw Away Your Old
Refrigerator or Freezer:
Refrigerant Disposal
REPLACEMENT PARTS
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the ground prong from the power cord.
For personal safety, this appliance must be properly grounded.
WARNING!
USE OF ADAPTER PLUGS
NEVER USE AN ADAPTER PLUG! Because of potential safety hazards under certain conditions, we strongly recommend
against the use of an adapter plug.
............ www.truemfg.com ............
SAFETY INFORMATION
True Food Service Equipment, Inc.
33
North America Use Only!
............ www.truemfg.com ............
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
4 4
TRUE
TRUE
TRUE is not responsible for damage incurred during
shipment.
OWNERSHIP
REQUIRED TOOLS
A.
B.
C.
D.
NOTE
Keys for coolers with door locks are located in warranty
packets.
UNCRATING
INSTALLATION / OPERATION INSTRUCTIONS
REMOTE UNITS
(This section applies to remotes only!)
If you have any questions regarding this
section, please call TRUE at 1-(800)-325-6152.
............ www.truemfg.com ............
INSTALLATION / OPERATION INSTRUCTIONS
True Food Service Equipment, Inc.
55
A.
B.
C.
D.
E.
F.
G.
H.
WARNING
Cabinet warranties are void if OEM power cord is tampered
with. TRUE will not warranty any units that are connected to
an extension cord.
LOCATING
A.
WARNING
Warranty is void if ventilation is insufficient.
B.
C.
LEVELING CASTORS
F°
35°
®
Image 1
LEVELING
Important Safeguard for installation of leg/castor (Images 2-3 demonstrate procedure)
D.
............ www.truemfg.com ............
True Food Service Equipment, Inc.
6 6
A.
B.
TRUE
CAUTION
Voltage drops can occur due to long wire runs from the voltage
source. Consult the wiring chart on page 7 to insure proper
voltage.
WARNING
Compressor warranties are void if compressor burns out due to
low voltage.
WARNING
Power supply cord ground should not be removed!
WARNING
Do not use electrical appliances inside the food storage
compartments of the appliances unless they are of the type
recommended by the manufacturer.
NOTE
To reference wiring diagram - Remove lower rear grill, wiring
diagram is positioned inside on the ballast box.
ELECTRICAL INSTRUCTIONS
LEVELING CASTORS CONTINUED....
INSTALLATION / OPERATION INSTRUCTIONS
Image 3
F°
35°
®
Image 2
............ www.truemfg.com ............
True Food Service Equipment, Inc.
77
INSTALLATION / OPERATION INSTRUCTIONS
115 Volt
Amps 20 30 40 50 60 70 80 90 100 120 140 160
Distance in Feet to Center of Load.
Wire Gauge for 2% Voltage Drop in Supply Circuits
2
3
4
5
6
7
8
9
10
12
14
16
18
20
25
30
35
40
45
50
14
14
14
14
14
14
14
14
14
14
14
14
14
14
12
12
10
10
10
10
14
14
14
14
14
14
14
14
14
14
14
12
12
12
10
10
10
8
8
8
14
14
14
14
14
14
14
14
14
12
12
12
10
10
10
8
8
8
6
6
14
14
14
14
14
14
14
12
12
12
10
10
10
10
8
8
6
6
6
6
14
14
14
14
14
14
12
12
12
10
10
10
8
8
8
6
6
6
6
5
14
14
14
14
14
12
12
12
10
10
10
8
8
8
6
6
6
5
5
4
14
14
14
14
12
12
12
10
10
10
8
8
8
8
6
6
5
5
4
4
14
14
14
12
12
12
10
10
10
8
8
8
8
6
6
6
5
4
4
3
14
14
14
12
12
10
10
10
10
8
8
8
8
6
6
5
4
4
3
3
14
14
12
12
10
10
10
8
8
8
6
6
8
6
5
4
4
3
3
2
14
14
12
10
10
10
8
8
8
8
6
6
8
5
4
4
3
2
2
1
14
12
12
10
10
8
8
8
8
6
6
6
5
5
4
3
2
2
1
1
230Volt
Amps 20 30 40 50 60 70 80 90 100 120 140 160
Distance in Feet to Center of Load.
Wire Gauge for 2% Voltage Drop in Supply Circuits
5
6
7
8
9
10
12
14
16
18
20
25
30
35
40
50
60
70
80
90
100
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
12
12
10
10
10
10
14
14
14
14
14
14
14
14
14
14
14
14
12
12
12
10
10
10
8
8
8
14
14
14
14
14
14
14
14
14
14
14
12
12
10
10
10
8
8
8
6
6
14
14
14
14
14
14
14
14
14
12
12
12
10
10
10
8
6
6
6
6
6
14
14
14
14
14
14
14
14
12
12
10
10
10
10
8
6
6
6
6
5
5
14
14
14
14
14
14
14
12
12
12
10
10
10
8
8
6
6
6
5
5
4
14
14
14
14
14
14
12
12
12
10
10
10
8
8
8
6
6
5
5
4
4
14
14
14
14
14
12
12
12
10
10
10
10
8
8
6
6
6
5
4
4
3
14
14
14
14
12
12
12
10
10
10
10
8
8
8
6
6
5
5
4
3
3
14
14
14
12
12
13
10
10
10
8
8
8
6
6
6
5
4
4
3
3
2
14
14
12
12
12
10
10
10
8
8
8
6
6
6
5
4
4
2
2
1
1
14
12
12
12
10
10
10
8
8
8
8
6
6
5
5
4
3
2
2
1
1
............ www.truemfg.com ............
True Food Service Equipment, Inc.
8 8
INSTALLATION / OPERATION INSTRUCTIONS
A.
B.
C.
D.
NOTE
If the cooler is disconnected or shut off, wait five minutes
before starting again.
RECOMMENDATION
Before loading product we recommend you run your
TRUE unit empty for two to three days. This allows you to
be sure electrical wiring and installation are correct and
no shipping damage has occurred. Every TRUE cooler is
tested in our plants for 24 hours to thoroughly check all
components. Unless they meet our strict standards, they
do not pass our final quality control inspection. Remember,
our factory warranty does not cover product loss!
REPLACEMENT PARTS
TRUE maintains a record of the cabinet serial number for
your cooler. If at any time during the life of your cooler, a
part is needed, you may obtain this part by furnishing the
model number and serial number to the company from
whom you purchased the cooler.
STARTUP
SHELF INSTALLATION
INSTALLATION / OPERATION INSTRUCTIONS
............ www.truemfg.com ............
True Food Service Equipment, Inc.
99
TERMS:
REQUIRED TOOLS
STEP 1
STEP 2
STEP 3
__________ STEP 4 __________
STEP 5
NOTE
Mechanical temperature
controllers are affected when
functioning at high altitude.
The cut-in and cut-out
temperatures will be colder than
when the controller functions closer
to sea level
Danfoss Temperature Control (High Altitude Adjustment Only!)
TEMPERATURE CONTROL ADJUSTMENT FOR
HIGH ALTITUDE ONLY!
MAINTENANCE, CARE & CLEANING
REQUIRED TOOLS:
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 9
Step 10
MAINTENANCE, CARE & CLEANING
CLEANING THE CONDENSER COIL
When using electrical appliances, basic safety precautions should be followed, including the following:
Image 3.
Image 4.
............ www.truemfg.com ............
True Food Service Equipment, Inc.
10 10
............ www.truemfg.com ............
True Food Service Equipment, Inc.
11 11
MAINTENANCE, CARE & CLEANING
Condensing Unit
Airflow
Condenser
IMPORTANT WARRANTY INFORMATION
Condensers accumulate dirt and require cleaning every 30 days. Dirty condensers result in compressor
failure, product loss, and lost sales... which are not covered by warranty.
If you keep the Condenser clean you will minimize your service expense and lower your electrical costs.
The Condenser requires scheduled cleaning every thirty days or as needed.
Air is pulled through the Condenser continuously, along with dust, lint, grease, etc.
A dirty Condenser can result in NON-WARRANTEED part & Compressor Failures, Product Loss, and
Lost Sales.
Proper cleaning involves removing dust from the Condenser. By using a soft brush, or vacuuming the
Condenser with a shop vac, or using CO2, nitrogen, or pressurized air.
If you cannot remove the dirt adequately, please call your refrigeration service company.
On most of the reach-in units the condenser is accessible in the rear of the unit. You must remove the
cabinet grill to expose the Condenser.
The Condenser looks like a group of vertical fins. You need to be able to see through the condenser for
the unit to function at maximum capacity. Do not place filter material in front of condensing coil. This
material blocks air-flow to the coil similar to having a dirty coil.
THE CLEANING OF THE CONDENSER IS NOT
COVERED BY THE WARRANTY!
HOW TO CLEAN THE CONDENSER:
1. Disconnect the electrical power to the unit.
2. Remove the louvered grill.
3. Vacuum or brush the dirt, lint, or debris from the finned condenser coil.
4. If you have a significant dirt build up you can blow out the condenser with compressed air. (CAUTION
MUST BE USED to avoid eye injury. Eye protection is recommended.)
5. When finished be sure to replace the louvered grill. The grill protects the condenser.
6. Reconnect the electrical power to the unit.
If you have any questions, please call TRUE Manufacturing at 636-240-2400 or 800-325-6152 and ask for the
Service Department. Service Department Availability Monday-Friday 7:30 a.m. to 6:00 p.m. and Saturday 8:00 a.m.
to 12:00 p.m. CST.
............ www.truemfg.com ............
True Food Service Equipment, Inc.
12 12
MAINTENANCE, CARE & CLEANING
CAUTION: Do not use any steel wool, abrasive or chlorine based products to clean stainless
steel surfaces.
Stainless Steel Equipment Care and Cleaning
............ www.truemfg.com ............
True Food Service Equipment, Inc.
MAINTENANCE, CARE & CLEANING
13 13
1
Tank Drain
2
NOTE
The use of stainless steel cleaners or other such solvents is not
recommended on plastic parts. Warm soap and water will suffice.
Stainless Steel Equipment Care and Cleaning
14 141414
WARRANTY INFORMATION (U.S.A & CANADA ONLY!)
T
RUE
R
EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
®
THREE YEAR PARTS &LABOR WARRANTY
ADDITIONAL TWO YEAR COMPRESSOR WARRANTY
404A/134A COMPRESSOR WARRANTY
WARRANTY CLAIMS
WHAT IS NOT COVERED BY THIS WARRANTY
TRUE warrants to the original purchaser of every new TRUE refrigerated unit, the cabinet and all parts thereof, to be free from defects in
material or workmanship, under normal and proper use and maintenance service as specified by TRUE and upon proper installation and start-up in
accordance with the instruction packet supplied with each TRUE unit. TRUE’s obligation under this warranty is limited to a period of three (3) years
from the date of original installation or 39 months after shipment date from TRUE, whichever occurs first.
Any part covered under this warranty that are determined by TRUE to have been defective within three (3) years of original installation or
thirty-nine (39) months after shipment date from manufacturer, whichever occurs first, is limited to the repair or replacement, including labor charges,
of defective parts or assemblies. The labor warranty shall include standard straight time labor charges only and reasonable travel time, as determined
by TRUE.
Warranty does not cover standard wear parts which include door gaskets, incandescent bulbs or fluorescent bulbs. Warranty also does
not cover issues caused by improper installation or lack of basic preventative maintenance which includes regular cleaning of condenser coils.
In addition to the Three (3) year warranty stated above, TRUE warrants its hermetically and semi-hermetically sealed compressor to be free
from defects in both material and workmanship under normal and proper use and maintenance service for a period of two (2) additional years from the
date of original installation but not to exceed five (5) years and three (3) months after shipment from the manufacturer.
Compressors determined by TRUE to have been defective within this extended time period will, at TRUE’s option, be either repaired or
replaced with a compressor or compressor parts of similar design and capacity.
The two (2) year extended compressor warranty applies only to hermetically and semi-hermetically sealed parts of the compressor and
does not apply to any other parts or components, including, but not limited to: cabinet, paint finish, temperature control, refrigerant, metering device,
driers, motor starting equipment, fan assembly or any other electrical component, etcetera.
The two year compressor warranty detailed above will be voided if the following procedure is not carefully adhered to:
1. This system contains R404A or R134A refrigerant and polyol ester lubricant. The polyol ester lubricant has rapid moisture absorbing
qualities. If long exposure to the ambient conditions occur, the lubricant must be removed and replaced with new. For oil amounts and specifications
please call TRUE technical service department (800-325-6152). Failure to comply with recommended lubricant specification will void the compressor
warranty.
2. Drier replacement is very important and must be changed when a system is opened for servicing. A drier using XH-7 desiccant or an
exact replacement solid core drier must be used. The new drier must also be the same capacity as the drier being replaced.
3. Micron level vacuums must be achieved to insure low moisture levels in the system. 500 microns or lower must be obtained.
All claims for labor or parts must be made directly through TRUE. All claims should include: model number of the unit, the serial number of
the cabinet, proof of purchase, date of installation, and all pertinent information supporting the existence of the alleged defect.
In case of warranty compressor, the compressor model tag must be returned to TRUE along with above listed information.
Any action or breach of these warranty provisions must be commenced within one (1) year after that cause of action has occurred.
TRUE’s sole obligation under this warranty is limited to either repair or replacement of parts, subject to the additional limitations below. This
warranty neither assumes nor authorizes any person to assume obligations other than those expressly covered by this warranty.
NO CONSEQUENTIAL DAMAGES. TRUE IS NOT RESPONSIBLE FOR ECONOMIC LOSS; PROFIT LOSS; OR SPECIAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOSSES OR DAMAGES ARISING FROM FOOD OR PRODUCT SPOILAGE CLAIMS
WHETHER OR NOT ON ACCOUNT OF REFRIGERATION FAILURE.
WARRANTY IS NOT TRANSFERABLE. This warranty is not assignable and applies only in favor of the original purchaser/user to whom
delivered. ANY SUCH ASSIGNMENT OR TRANSFER SHALL VOID THE WARRANTIES HEREIN MADE AND SHALL VOID ALL WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IMPROPER USAGE. TRUE ASSUMES NO LIABILITY FOR PARTS OR LABOR COVERAGE FOR COMPONENT FAILURE OR OTHER DAMAGES
RESULTING FROM IMPROPER USAGE OR INSTALLATION OR FAILURE TO CLEAN AND/OR MAINTAIN PRODUCT AS SET FORTH IN THE WARRANTY
PACKET PROVIDED WITH THE UNIT.
RESIDENTIAL APPLICATIONS: TRUE assumes no liability for parts or labor coverage for component failure or other damages resulting from
installation in non-commercial or residential applications.
ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD. TRUE
is not responsible for the repair or replacement of any parts that TRUE determines have been subjected after the date of manufacture to alteration,
neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or act of God.
IMPROPER ELECTRICAL CONNECTIONS. TRUE IS NOT RESPONSIBLE FOR THE REPAIR OR REPLACEMENT OF FAILED OR DAMAGED
COMPONENTS RESULTING FROM INCORRECT SUPPLY VOLTAGE, THE USE OF EXTENSION CORDS, LOW VOLTAGE, OR UNSTABLE SUPPLY VOLTAGE.
NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE: THERE ARE NO OTHER WARRANTIES,
EXPRESSED, IMPLIED OR STATUTORY, EXCEPT THE THREE (3) YEAR PARTS &LABOR WARRANTY AND THE ADDITIONAL TWO (2) YEAR COMPRESSOR
WARRANTY AS DESCRIBED ABOVE. THESE WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, INCLUDING IMPLIED
WARRANTY AND MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF.
OUTSIDE U.S/CANADA.: This warranty does not apply to, and TRUE is not responsible for, any warranty claims made on products sold or
used outside the United States or Canada.
THIS WARRANTY ONLY APPLIES TO UNITS SHIPPED FROM TRUE’S MANUFACTURING FACILITIES AFTER JANUARY 1, 2013.
PRODUCT MUST BE PURCHASED IN THE COUNTRY WHERE SERVICE IS REQUESTED.
This manual suits for next models
3
Table of contents
Other True Commercial Food Equipment manuals
True
True Dipping Cabinet TDC-47 User manual
True
True TBR Series User manual
True
True GDM-26-HC-TSL01 User manual
True
True TCGG-72-S-LD User manual
True
True TCGG-36-S-LD User manual
True
True TMC-58-D-DS User manual
True
True THAC-36-LD User manual
True
True GDM-HST02-HC-TSL01 User manual
True
True TDB-24-48-1-G-1 User manual
True
True GDIM Series User manual
