True TMC-34-S-DS User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8"(millimeters rounded up to next whole number).
ROUGH-IN DATA
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
TMC-34-S-DS
TMC-34-S-DS
** Length does not include 1/8" (4 mm) each side for lid pins.
†Depth does not include 1" (26 mm) each side for bumpers.
*Height does not include 51/8" (131 mm) for castors.
Milk Cooler:
Dual Sided, Stainless Steel Exterior / White Aluminum Interior
5/07
True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder
product temperatures, and lower
utility costs in an attractive
durable school milk cooler.
Dual sided for convenient access
to product from both sides of unit.
Oversized, forced-air refrigeration
system maintains milk
temperatures of 33°F to 38°F
(.5°C to 3.3°C). Colder holding
temperatures provide better
tasting milk, increased sales and
less product waste.
Exterior - all stainless steel exterior
front, sides, back and top.
All stainless steel self-service doors
feature convenient drop front and
“hold-open” flip-up top. Standard
with door locks.
Interior - attractive, NSF approved,
white aluminum liner with
reinforced, 300 series stainless
steel floor.
Standard with heavy duty floor
racks and convenient clean out
drain.
Designed to hold 8 milk crates.
Entire cabinet structure and
solid doors are foamed-in-place
using high density, CFC free,
polyurethane insulation.
Model Doors
Capacity
Floor
Racks
Cabinet Dimensions
(inches)
(mm)
L** D†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft)
(total m)
Crated
Weight
(lbs.)
(kg)
(Cu. Ft.)
(liters) Crates
TMC-34-S-DS 4 13.8
391
8234
864
333/8
848
411/8
1045
1/3115/60/1 6.7 5-15P 9
2.74
n/a
®
R

STANDARD FEATURES
Model:
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
TMC-34-S-DS
Milk Cooler:
Dual Sided, Stainless Steel Exterior /
White Aluminum Interior
TMC-34-S-DS
DESIGN
• True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder product
temperatures and lower utility costs
in an attractive, durable school milk
cooler.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains milk
temperatures of 33°F to 38°F (.5°C to
3.3°C). Colder holding temperatures
provide better tasting milk, increased
sales and less product waste.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True merchandisers
a more efficient low velocity, high
volume airflow design. This unique
design ensures colder holding
temperatures and faster recovery in
high use situations.
• Condensing unit accessed from
behind back grill, slides out for easy
cleaning and maintenance.
CABINET CONSTRUCTION
• Exterior - all stainless steel front,
sides, back and top.
• Interior - attractive, NSF approved,
white aluminum liner with
reinforced, 300 series stainless steel
floor. Standard with heavy duty floor
racks.
• Insulation - entire cabinet structure
and solid doors are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame
rail dipped in rust inhibiting enamel
paint for corrosion protection inside
and out.
• Frame rail fitted with four (4) easy
roll, 4" (102 mm) diameter swivel
castors (front castors lock in place).
• Designed to hold 8 milk crates.
DOORS
• All stainless steel self-service doors
feature convenient drop front and
“hold-open” flip-up top. Door
support bumpers standard.
• Door locks standard.
• Magnetic door gaskets of one piece
construction, removable without
tools for ease of cleaning.
MODEL FEATURES
• Exterior digital temperature display.
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Convenient clean out drain with 1/2"
(13 mm) NPT-PVC drain plug.
• Listed under NSF-7 for the storage
and/or display of packaged or bottled
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase, 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ A variety of exterior color options
available, see www.truemfg.com for
latest offerings.
❒ 6" (153 mm) standard legs (mounting
plates required).
❒ 6" (153 mm) seismic/flanged legs
(mounting plates required).
❒ Corner bumpers.
❒ See www.truemfg.com for school
milk profit calculator.
❒ Remote cabinets (condensing unit
supplied by others; system comes
standard with 404A expansion valve
and requires R404A refrigerant),
consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
RIGHT VIEW
6315/16"
(1624 mm)
107/16"
(266 mm)
155/16"
(389 mm)
155/16"
(389 mm)
491/2"
(1258 mm)
ELEVATION
35
°F
151/2"
(394 mm)
181/2"
(470 mm)
34"
(864 mm)
347/32"
(870 mm)
301/2"
(775 mm)
239/16"
(599 mm)
461/8"
(1172 mm)
51/16"
(129 mm)
7/64" (3mm)
Lid pin
411/16"
(1043 mm) 335/16"
(847 mm)
355/16"
(897 mm)
1"
(26 mm)
1"
(26 mm)
PLAN VIEW
BACK VIEW
1/2"(13 mm)
NPT PVC
Drain Plug
35
°F
4"
(102 mm)
