TDD-1-S
TDD-1-S
*Height does not include 141/4" (362 mm) for draft arm. ▲Plug type varies by country.
Direct Draw Beer Dispenser:
Stainless Steel Solid Door
4/06
True’s direct draw beer
dispensers are designed with
enduring quality and value. Our
commitment to using the highest
quality materials and oversized
refrigeration assures colder
product temperatures and years
of trouble free service.
Oversized, factory balanced,
refrigeration system holds 33°F to
38°F (.5°C to 3.3°C).
Exterior - stainless steel door,
front and sides. Matching
aluminum back. All stainless steel
counter top.
Interior - 300 series stainless steel
floor with 1/2" (13 mm) reinforced
lip and heavy gauge galvanized
steel walls. NSF approved for pre-
packaged and bottled product.
3" (77 mm) diameter stainless
steel insulated beer column. Cold
air is directed into beer column
to reduce foaming and maximize
draft beer profits.
Anodized aluminum glass rail
provides convenient storage for
glasses on top.
Entire cabinet structure and
solid door are foamed-in-place
using high density, CFC free,
polyurethane insulation.
Model Doors
Capacity
1/2
Barrels
Cabinet Dimensions
(inches)
(mm)
LDH
*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TDD-1-S 1 1 231/2
597
311/4
794
393/4
1010
1/5
1/4
115/60/1
230-240/50/1
4.4
2.5
5-15P
▲
7
2.1
175
80
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
KCL
Model Elevation Right Plan 3D
PLAN VIEW
TDD-1-S TFHY04E TFHY04S TFHY04P TFHY043
Direct Draw Beer Dispenser:
Stainless Steel Solid Door
TDD-1-S
DESIGN
• True’s direct draw beer dispensers
are designed with enduring quality
and value. Our commitment to using
the highest quality materials and
oversized refrigeration assures colder
product temperatures and years of
trouble free service.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains
cabinet temperatures of 33°F to 38°F
(.5°C to 3.3°C).
• Sealed, cast iron, self-lubricating
evaporator fan motor and larger
fan blades give True beer dispensers
a more efficient low velocity, high
volume airflow design. This unique
design insures faster temperature
pull down of warm product, colder
holding temperatures and faster
recovery in high use situations.
• Condensing unit accessed from
rear of unit for easy cleaning and
maintenance.
CABINET CONSTRUCTION
• Exterior - stainless steel door, front
and sides. Matching aluminum back.
All stainless steel counter top.
• Interior - 300 series stainless steel floor
with 1/2" (13 mm) reinforced lip and
heavy gauge galvanized steel walls.
• Insulation - entire cabinet structure
and solid door are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• 4" (102 mm) diameter castors (legs
not available).
• 3" (77 mm) diameter stainless steel
insulated beer column. Cold air is
directed into beer column to reduce
foaming and maximize draft beer
profits.
• Anodized aluminum glass rail.
DOOR
• Stainless steel exterior with heavy
gauge galvanized steel liner.
• Door fitted with 12" (305 mm) long
recessed handle that is foamed-in-
place with a sheet metal interlock to
insure permanent attachment.
• Magnetic door gasket of one piece
construction, removable without tools
for ease of cleaning.
• Door lock standard.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Designed to accommodate all types of
beer kegs.
• Listed under NSF-7 for the storage
and/or display of packaged or bottled
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230 - 240V / 50 Hz.
❒Double headed draft column.
❒Two-way manifold.
❒Draft cap.
115/60/1
NEMA-5-15R
ELEVATION PLAN VIEWRIGHT VIEW
237/16"
(596 mm)
141/4"
(362 mm)
343/4"
(883 mm)
54"
(1372 mm)
187/32"
(463 mm)
299/16"
(751 mm)
2011/16"
(526 mm)
5129/32"
(1319 mm)
383/4"
(985 mm)
1123/32"
(298 mm)
5"
(127 mm)
1"
(26 mm)
329/32"
(100 mm)
317/32"
(793 mm)
11/8"
(29 mm)
121/32"
(43 mm)
