VI-2300 FireWire 800 DV PCI Kit
1
UK
Product information
A: Optional power connection (FDD power connector of power supply)
B: 6 pin 1394a Firewire connection
C: 9-pin 1394b Firewire connection
D: PCI-32 connection
E: PCI-64 connection
Installation
1
Computer off
2
Open case
A
B
C
D
E

VI-2300 FireWire 800 DV PCI Kit
2
3
Install PCI card in PC firmly
4
Close case
5
Computer on
Windows 2000/XP: go to 7
6
…
Windows 98SE, assure the latest patch is installed:
http://www.microsoft.com/windows98/downloads/contents
/WURecommended/S_WUFeatured/1394/Default.asp
Windows 98SE/ME:
Follow Windows Hardware Wizard to finish (click
Next…)
Restart system when Windows prompts

VI-2300 FireWire 800 DV PCI Kit
3
UK
7
Windows 2000, assure SP4 is installed
Place CD in CD-ROM
8
Install driver because the default Windows driver
does not support 1394b
Install driver
9
…
Driver installation may be finished without further
prompt
When prompt the driver is not digitally signed, please
click “continue anyway”
10
Check in device manager to assure the 1394B
controller is installed
11
Connect device
Max. 4.5m

VI-2300 FireWire 800 DV PCI Kit
4
Reminders
Click on Install software to install Ulead VideoStudio software
Manual for Ulead software is on CD
Recommended: connect the optional power (A) when use more than 2 FireWire devices
Max. 63 FireWire devices per port
Follow the manual of your Firewire device to connect and use it in your system
Do not disconnect a FireWire device whilst it is still active
Enable write cache of the harddisk for better perfromance
It is recommended to use a 2nd physical hard drive for video editing
For smooth video recordings via FireWire, you must have an Ultra DMA compatible hard disk
The two1394a ports (B)are logically the same port but have two connections. Please connect one at a
time.
If you have any problems, go to www.trust.com/14341 for FAQ, drivers and manuals.
Safety
• Do not repair this device yourself.
• Keep this device away from liquids, such as water.
• This device meets the essential requirements and other relevant conditions of the applicable European
directives. The Declaration of Conformity (DoC) is available at www.trust.com/14341/ce
Warranty & copyright
• This product has a two-year manufacturer's warranty which is effective from the date of purchase. For more
information see www.trust.com/warranty
• Reproduction of this manual or any part of it is prohibited without permission from Trust International B.V.
