Trust ACM-1000 Build-in Switch User manual

ININ OUT
LN N
ININ OUT
L
N N

ININ OUT
L
N N
ININ OUT
L
N N

ININ OUT
L
N N
ININ OUT
L
N N

ACM-1000 BUILD-IN SWITCH
1
EN
COMPATIBILITY
This receiver works with all Trust SmartHome transmitters.
FUNCTIONALITY
Build-in receiver for switching lights and devices on/o.
R Incandescent lamps
R Eco halogen lamps
R 230 V halogen lamps
R 12 V halogen lamps with electronic transformer
R 12 V halogen lamps with iron-core transformer
R Compact fluorescent lamps
R LED lamps
R Fluorescent tubes with electronic starter
Q Switchstart fluorescent tubes (automatic glow starter)
LIGHTING OVERVIEW (visit www.trustsmarthome.com for more information)
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example, the thin metal coating
in Low-emissivity (Low-E) glass has a negative impact on the range of radio signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this device complies with
local directives.
220-240 VAC 50 Hz
1000 Watt
20 mm 5A (T5A, H250V)
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
0.5 Watt
6
TECHNICAL SPECIFICATIONS
• Power supply input
• Maximum load
• Replaceable fuse
• RF frequency
• RF range
• Standby power consumption
• Memory addresses
Read these simple guidelines. Not following them may be dangerous and faulty installation will invalidate any warranty
that may apply to this product.

ACM-1000 BUILD-IN SWITCH
2
EN
LEGAL INFORMATION
CE: Trust declares this device complies with the Directives as listed in Section 2 of this document.
WEEE: Dispose of the device at a recycling centre. More information: www.trustsmarthome.com
Warranty information: www.trustsmarthome.com/warranty
INSTALLATION
Wire colors may vary per country. Contact an electrician
when in doubt about wiring. This product is not suitable
if the existing light switch is interconnected to other light
switches for multiway switching.
MAXIMUM LOAD
Never connect lights or equipment that exceed the
maximum load of the receiver, as it can result in defects, a
short circuit or fire.
SHOCK HAZARD
Exercise caution when installing a receiver. Voltage may be
present, even when a receiver is switched o.
LIFE-SUPPORT
Never use Trust SmartHome products for life-support
systems or other applications in which equipment
malfunctions can have life-threatening consequences.
INTERFERENCE
All wireless devices may be subject to interference, which
could aect performance. The minimum distance between 2
receivers should be at least 50 cm.
REPAIRING
Do not attempt to repair this product. Only replace the fuse
if necessary.
WATER-RESISTANCE
This product is not water-resistant. Keep it dry. Moisture will
corrode the inner electronics and can result in a short circuit,
defects and shock hazard.
CLEANING
Use a dry cloth to clean this product. Do not use harsh
chemicals, cleaning solvents, or strong detergents.
HANDLING
Do not drop, knock, or shake the device. Rough handling can
break internal circuit boards and fine mechanics.
ENVIRONMENT
Do not expose the product to excessive heat or cold, as it
can damage or shorten the life of electronic circuit boards.
