Trust START-LINE APA3-1500R User manual

2
APA3-1500R STARTER SET WIRELESS SWITCHING
COMPATIBILITY
This set can be combined with all trust smart
home transmitters and receivers.
FUNCTIONALITY
3 Mains socket switches to switch lights or
electronic devices on/o up to 1500 Watt with the
included remote control
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example,
the thin metal coating in Low-emissivity (Low-E) glass has a negative impact on the range of radio
signals.
TECHNICAL SPECIFICATIONS RECEIVER
Power supply input 220-240 VAC 50 Hz
Maximum load 1500 Watt
RF frequency 433,92 MHz
RF range Up to 30m indoor/ 70m outdoor (optimal conditions)
Memory addresses 3
TECHNICAL SPECIFICATIONS TRANSMITTER
Battery 1x 3 V CR2032 lithium
RF frequency 433.92 MHz
RF range Up to 30m indoor/ 70m outdoor (optimal conditions)
Channels 3 + Group o

3
APA3-1500R STARTER SET WIRELESS SWITCHING
Read this manual carefully. Not following them may be dangerous and faulty installation will invalidate
any warranty that may apply to this product.
MAXIMUM LOAD
Never connect lights or equipment that exceed
the maximum load of the receiver, as it can result
in defects.
SHOCK HAZARD
Exercise caution when installing a receiver.
Voltage may be present, even when a receiver is
switched o.
BATTERY
Remove the battery if the product will not
be used for an extended period. Extreme
temperatures reduce the capacity and lifetime of
the battery. Dispose of batteries according to local
regulations. Please recycle when possible.
LIFE-SUPPORT
Never use trust smart home products for life-
support systems or other applications in which
equipment malfunctions can have life-threatening
consequences.
INTERFERENCE
All wireless devices may be subject to
interference, which could aect performance. The
minimum distance between 2 receivers should be
at least 50 cm.
REPAIRING
Do not attempt to repair this product. There are
no user-serviceable parts inside.
WATER-RESISTANCE
This product is not water-resistant. Keep it dry.
Moisture will corrode the inner electronics and
can result in a short circuit, defects and shock
hazard.
CLEANING
Use a dry cloth to clean this product. Do not use
harsh chemicals, cleaning solvents, or strong
detergents.
HANDLING
Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and fine
mechanics.
ENVIRONMENT
Do not expose the product to excessive heat
or cold, as it can damage or shorten the life of
electronic circuit boards.

4
APA3-1500R STARTER SET WIRELESS SWITCHING
Remote control
(1) LED-indicator
(2) ON/OFF buttons*
(3) Group OFF button*
*When using an OFF button or the
group OFF button the connected light(s)/
device(s) is/are switched o and the
receiver is put in stand-by.
1
2
3

5
APA3-1500R STARTER SET WIRELESS SWITCHING
Assigning dierent channels to
dierent receivers
When you would like to control multiple
receivers independently, you can assign a
desired channel to a specific receiver like
depicted above.
Switching multiple receivers to stand-by with the
group OFF function
By using the group OFF function ( ) you can switch the
connected receivers to stand-by. The connected lights and
devices will be switched OFF.
1
2
3
4
1
2
3
and/
or
1
2
3
4
1
2
3
1
2
3
4
1
2
3
1
2
3
etc.
etc.
etc.
and/
or
and/
or
and/
or
and/
or
and/
or

6
1. Connect lamp/device
First check if the lamp or device is turned
on. Then plug the lamp or device into the
receiver. Do not exceed the maximum load:
1500 W
2a. Assign transmitter code
Placing the receiver into a socket will
automatically activate the learn-mode for 5
seconds. The LED-indicator on the receiver
will blink slowly. To reactivate the learn-
mode, remove the receiver from the socket,
wait 10 seconds, then insert the receiver into
the socket again.
APA3-1500R STARTER SET WIRELESS SWITCHING

2x

8
3. Manual operation with a transmitter
1. Send an ON-signal to switch the receiver on.
2. Send an OFF-signal to put the receiver in stand-by.
APA3-1500R STARTER SET WIRELESS SWITCHING

2x

2x

11
Trust International B.V. declares that this product is in compliance with the essential
requirements and other relevant provisions
WEEE: If possible, dispose of this product at a recycling center. Do not dispose of this product
with the household waste.
Warranty
This product is covered by the legal warranty that applies to your country and it begins on the day of
purchase. For additional information, visit: www.trustsmarthome.com/warranty/
Copyright
The contents of this user manual are subject to copyright protection. Without prior written permission,
reproducing or copying is prohibited. Information in these documents is subject to change without
prior notice. Check www.trustsmarthome.com for updates.
