User instructions
Valet 10 – V10
Commercial vacuum cleaner
CAUTION - READ THESE INSTRUCTIONS BEFORE USING THE MACHINE
03-8132-0000 Iss.1 05/07

2
Contents
Page
1 Product information ..................................................................... 3
1.1 Important safety advice .................................................................... 3
1.2 Guidelines for the operator .............................................................. 3
1.3 Transporting the machine ................................................................ 3
2 Preparing for use ........................................................................... 4
2.1 Electrical connection ........................................................................ 4
3 Controls ............................................................................................. 4
4 Operation ......................................................................................... 4
5 Storage ............................................................................................... 4
6 Maintenance ...................................................................................... 5
7 After sales service .......................................................................... 5
8 Guarantee ......................................................................................... 5
9 Waste Electrical and Electronic Equipment ........................ 5
10 Technical specification ............................................................... 6
11 Accessories ..................................................................................... 6
12 Fault diagnosis ............................................................................... 6
13 Declaration of conformity .......................................................... 7

3
IMPORTANT
READ THESE INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE REFERENCE
1 Product information
This commercial tub vacuum cleaner is designed
for the collection of dust in indoor areas. It should
not be used in outdoor areas.
The following instructions contain important
information about the machines and safety advice
for the operator.
Equipment must be operated, serviced and
maintained in accordance with the manufacturer’s
instructions.
If in doubt contact the supplier of your
machine.
These instructions are valid for the following
models:
Valet 10 – V10
1.1 Important Safety Advice
When using electrical equipment basic safety
precautions should be followed including the
following.
•Read all instructions carefully before use.
•Keep children and unauthorised persons away
from the machine when in use.
•Do not leave the machine connected to the
electricity supply. When not in use, always
remove the plug from the socket-outlet.
•Do not operate switches or touch the mains
plug with wet hands as this may cause electric
shock.
•Switch off the machine before removing the
plug.
•When unplugging, pull the plug not the supply
cord.
•Do not operate the machine with a damaged
supply cord or plug, or after the machine
malfunctions or is damaged in any way. Contact
an authorised Service Agent for repair or
adjustment.
•The plug of the power supply cord must be
removed from the socket-outlet before
commencing cleaning of the machine or
undertaking maintenance operations.
•The power supply cord must be regularly
inspected for signs of damage. If the power
supply cord is damaged, it has to be replaced.
•Do not put any objects into openings. Do not
use with any opening blocked. Keep free of
dust, lint, hair and anything that may reduce
airflow.
•This vacuum cleaner creates suction. Keep
hair, loose clothing, fingers and all parts of body
away from openings.
•Do not use without dust bag in place.
•Do not use without main filter in place.
•Do not use to pick up moisture or any liquids.
•Do not use where hazardous dust is present.
•Do not use in an explosive atmosphere.
•Do not pick up oil or other flammable material.
•Take care when using a machine near the top
of stairs to avoid overbalancing.
•Do not vacuum up hard or sharp objects, as
they may damage the hose, vacuum bag or the
vacuum motor.
•Do not drop the vacuum on the floor.
•If the vacuum falls on its side switch off the
power immediately and stand it upright before
re-using.
•Do not wash or launder the cloth filter. This
could impair the filtration capability of the fabric.
•Do not kink or twist the power cord.
•Do not attempt to service the vacuum yourself.
Repair by anyone other than an authorised
repair or service centre may void the warranty.
1.2 Guidelines for the operator
•Only use the machine on firm level surfaces.
•Operators must be fully trained in the use of the
machine in accordance with these instructions,
able to perform user maintenance and the
correct selection of accessories, i.e. bags,
filters, hoses etc.
•Do not leave machine running unattended.
•Operators should be physically capable to
manoeuvre, transport and operate the
machines.
•Operators should be able to recognise unusual
operation of the machine and report any
problems.
•Wear suitable footwear to avoid slipping.
•Wear suitable clothing to keep dry and
warm.
•Where possible implement job rotation and
adequate rest periods to avoid continuous
use of the same muscles.
•Do not smoke when using the machine.
•CAUTION – This machine is for indoors use
only and should not be used or stored
outdoors or in wet conditions.
1.3 Transporting the machine
When transporting a machine ensure that all
components, accessories and removable parts
are securely fastened and that the supply cord and
plug are not trailing.

4
2 Preparing for use
2.1 Electrical connection
Before connecting the machine to the power
supply, check that your supply voltage
corresponds with that marked on the rating label
on the underside of the motor head.
The power supply cord plus any extension leads
should not exceed 30m in total. The cross-section
of any extension cable wiring must be at least 2,5
mm ².
UK only
The supply cord for 230v models is fitted with a
plug containing a 13 amp fuse. Should the fuse
require replacement it must only be replaced by a
13 amp fuse conforming to BS1362, and the fuse
cover must be refitted. If the fuse cover is lost the
plug must not be used until the correct
replacement cover is fitted.
IMPORTANT - If the supply cord is damaged, it
must only be replaced by a suitable cord available
from the manufacturer or an authorised service
agent.
3 Controls
1. To turn the vacuum on, push the switch located
on the top of the vacuum to the (I) position.
2. To turn the vacuum off, push the switch to the
(0) position.
4 Operation
Please read the following operating instructions
carefully. They will help you to get the best
performance from this professional quality vacuum
cleaner and to maintain it in optimum condition.
1. Check the vacuum bag
Always ensure that the vacuum bag is empty
before vacuuming.
Remove the motor head by releasing the two
catches on the side of the vacuum. Lift out the
white main filter. Check that vacuum bag is in
place. If bag is full, remove and replace.
Replace main filter and motor head and secure
catches.
2. Push vacuum hose into machine inlet.
3. Plug the cord into a suitable power outlet.
Always unwind the cord completely before
vacuuming. It is important to maintain the
power cord in good condition. Use care when
pulling the cord around sharp edges and
through doorways
Never operate the Valet 10 if the power cord
is damaged in any way.
4. Attach the extension wand to the hose and fit
the floor tool or any of the other vacuuming
accessories on the wand.
5. Turn the vacuum on.
Your Valet 10 vacuum is fitted with a thermal
overload to protect the motor against damage
should the airflow be blocked for extended
periods. This may occur if the vacuum bag is
overfull or if the vacuum hose is blocked. The
vacuum motor will stop before it can get too hot. If
this happens, replace the vacuum bag or free any
blockage and ensure that adequate airflow is
restored. The motor will automatically restart after
it has cooled to a safe operating temperature.
5 Storage
•After use check the bag. If full, replace the bag.
•Coil the supply cord and loop over machine
ensuring that the plug is not trailing on the floor.
Alternatively wrap supply cord around the
machine.
•Store the machine in a dry indoor area only.

5
6 Maintenance
WARNING - Before undertaking maintenance
operations or adjustments switch off machine
and unplug from the electricity supply.
The machine requires minimum maintenance
apart from the following checks by the operator.
•Supply cord – Regularly inspect sheath, plug
and cord anchorage for damage or loose
connection.
•Body of the machine – Clean with a damp
cloth.
•Clean the cloth filter regularly – After emptying
the vacuum bag, shake any dust out of the
fabric. Always use a paper vacuum bag.
•Ensure that the vacuum hose, the extension
wand and the vacuum accessories are not
blocked.
IMPORTANT – Should the machine fail to operate
contact Truvox Customer Service Department for
rapid attention.
7 After sales service
Truvox machines are high quality machines that
have been tested for safety by authorised
technicians. It is always apparent that after longer
working periods, electrical and mechanical
components will show signs of wear and tear or
ageing.
To maintain operational safety and reliability the
following service interval has been defined: Every
year.
Under extreme or specialised conditions and/or
insufficient maintenance, shorter maintenance
intervals are necessary. Use only original Truvox
spare parts. Use of other spare parts will
invalidate all warranty and liability claims.
Should you require after sales service please
contact the supplier from whom you purchased the
machine, who will arrange service. Repairs and
servicing of Truvox products should only be
performed by trained staff. Improper repairs can
cause considerable dangers to the user.
Enquire about the Truvox low cost and efficient
Maintenance Contract.
8 Guarantee
Your product is guaranteed for one year from the
date of original purchase, or hire purchase,
against defects in materials or workmanship
during manufacture. Within the guarantee period
we undertake at our discretion, to repair or replace
free of charge to the purchaser, any part found to
be defective, subject to the following conditions.
CONDITIONS
1. Claims made under the terms of the guarantee
must be supported by the original invoice/bill of
sale issued at the time of sale, or the machine
Serial No.
2. For claims under this guarantee contact the
supplier from whom you purchased the product
who will arrange the appropriate action. Do not
initially return the product as this could result in
transit damage.
3. Neither Truvox nor its distributor shall be liable
for any incidental or consequential loss.
4. This guarantee is governed by the laws of
England.
5. This guarantee does not cover any of the
following:
- Periodic maintenance, and repair or
replacement of parts due to normal wear and
tear.
- Damage caused by accident, misuse or
neglect, or the fitting of other than genuine
Truvox parts.
- Defects in other than genuine Truvox parts, or
repairs, modifications or adjustments
performed by other than a Truvox service
engineer or authorised service agent.
- Costs and risks of transport relating directly or
indirectly to the guarantee of this product.
- Consumable items such as, brushes, drive
discs, filters and vacuum skirts.
This guarantee does not affect your statutory
rights, or your rights against the supplier arising
from their sales or purchase contract.
Truvox International Limited policy is one of
continual product development and we reserve the
right to alter specifications without prior notice
9 Waste Electrical & Electronic Equipment
Do not dispose of this device with unsorted waste.
Improper disposal may be harmful to the
environment and human health.
Please refer to your local waste authority for
information on return and collection systems in
your area.

6
10 Technical specification
Model Valet 10
Ref No V10
Tank material ABS Airflow l/sec
30
Voltage a.c. V 230 Vacuum kPa
25
Frequency Hz 50 / 60
mm/w
g
2426
No. of motors 1 Hose length m 2
Motor rating W 1050 Cable length m 8
Dust bag capacity L 7 Size (l x w x h) cm 37x33x43
Construction class II Weight kg 5.75
Protection IP IP20 Noise Level (see note 1)
dB(A)
68
1 - Noise levels measured at a distance of 1 metre from machine and 1,6 metres above floor,
Measurements recorded using a hand held meter.
11 Accessories
Item Part No. Usage
Dust bags 02-4594-0000 10 dust bags for Valet 10
Hose 20-0104-0000 Hose and connector assembly
Extension tubes 20-0105-0000 Extension tube assemble (2 tubes)
Detail vacuuming
tools
20-0106-0000 Round brush and crevice nozzle
Combination tool 20-0107-0000 Cleaning carpeted or hard floors
Main filter 20-0100-0000 Replacement main filter with frame and gasket
IMPORTANT : Genuine accessories are only available from authorised Service Agents or Truvox Customer
Service Dept.
12 Fault diagnosis
The following simple checks may be performed by the operator.
Trouble Reason Remedy
Machine not working •Lack of voltage/electrical
supply.
•Check fuse *, supply cord, plug and socket outlet.
Loss of suction •Bag full
•Blocked hose or wand
•Motor not working
•Replace bag
•Remove obstruction
•Contact supplier
Motor is not running •Broken switch
•Defective power cord
•Defective motor
•Contact supplier
•Contact supplier
•Contact supplier
* If the fuse blows several times, the machine should be checked by an authorised Service Agent.

7
13 Declaration of conformity
EC Declaration of Conformity
We, Truvox International Ltd.
Of Third Avenue, Millbrook Trading Estate, Southampton SO15 0LE, England
declare that the machinery:
Make : Commercial tub vacuum cleaners
Type : Valet 10
Model : V10
Year of Construction: from 2007
has been manufactured using the following transposed harmonised European Standards and technical
specifications.
BS EN 60335-1 and BS EN 60335-2-69, and is in conformity with:
the Machinery Directive 98/37/EC and subsequent amendments,
the Low Voltage Directive 73/23/EEC and subsequent amendments,
and the EMC Directive 89/336/EEC and subsequent amendments.
Signed in : SOUTHAMPTON, England
on the 1
st
day of April 2007
Signature :
Name : Malcolm Eneas
Position : New Product Development Manager

8
Truvox International Limited, Third Avenue, Millbrook, Southampton, Hampshire SO15 0LE England
Tel: [phone] Fax: [phone]
e-mail: [e-mail] Web: www.truvox.com
A Tacony Company
