TSi Power UPS-400 User manual

LIMITED WARRANTY
TSi Power warrants this product to be free from defects in materials and
workmanship for two (2) years†from the date of purchase from TSi Power or its
authorized representatives. TSi Power will repair (or at its option, replace) any
defective component(s) during this warranty period.
To make a request or claim for service under this limited warranty, the original
purchaser must return the product, in the original shipping container or equiva-
lent, to TSi Power or its authorized distributor, accompanied by a written receipt
showingthedateof purchase,dealer’sname,and boththe modelname and serial
number of the product.
Warranty does not cover transportation costs. Damage by misuse, accident or
unauthorized tampering of the product is not covered by the warranty. NO
OTHER WARRANTIES ARE EXPRESSED OR IMPLIED. TSI POWER IS NOT
LIABLE FOR CONSEQUENTIAL DAMAGES. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
†Excluding batteries. Battery manufacturer’s warranty applies on batteries.
LIMITATION OF LIABILITY
IN NO EVENT SHALL TSI POWER OR ITS SUPPLIERS BE LIABLE FOR ANY
DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES
FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF
BUSINESS INFORMATION, OR OTHER PECUNIARY LOSS) ARISING OUT OF
THE USE OR INABILITY TO USE THIS TSI POWER PRODUCT, EVEN IF TSI
POWER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
SOME STATES DO NOT ALLOW THE LIMITATION OR EXCLUSION OF
LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
UPS-400 & UPS-600
Operating Instructions
TSi POWER
Uninterruptible Power Supply
AC Input
UPS Output
Power
Conditioning
Low Impedance
Power Condition-
ing (optional)
Efficiency
(Standard Model)
Transfer Times
Battery & Charger
Audible Noise
Safety and
Reliability Features
Size and Weight
Operating
Environment
Warranty
•95V
AC to 135VAC, 47 to 63 Hz, sinusoidal.
•75V
AC to 150VAC, UPS-400LIC & 600LIC.
• 108 to 125 VRMS, 50 or 60 ±3 Hz (user selectable), modified
sine wave.
• UPS-400: 400 VA/240 W maximum.
• UPS-600: 600 VA/400 W maximum.
• Standard models provide 3-way MOV surge suppression
and EMI/RFI noise filtering.
• UPS-400LI & 600LI models include low-impedance
isolation transformers for complete input-to-output line
isolation.
• UPS-400LIC & 600LIC models include line isolation and
wide input voltage range power conditioning.
• 98% or higher during AC operation.
• 90% or higher for LI and LIC options.
• 70% or higher during inverter operation.
• 4 ms. typical between AC and inverter.
• UPS-400 has 84 VAh of battery capacity for about 5
minutes of holdup at full load, 15 minutes at half load.
• UPS-600 has 120 VAh of battery capacity for about 4
minutes of holdup at full load, 13 minutes at half load.
• Optional extended battery models UPS-400X and UPS-
600X have battery capacities of 204 VAh, doubling or
tripling the usual holdup times.
• Less than 40dB at 1.5m, ANSI A scale, during inverter
operation.
• Designed to meet UL/CSA/IEC standards of safety.
• External fuse protects all AC circuits.
• Internal fuse protects all DC circuits.
• Width: 5” (12.7 cm)
• Depth: 16” (40.6 cm)
• Height: 7” (17.8 cm)
• Weight: UPS-400: 18 lbs (8.2 kg)
UPS-600: 20 lbs (9.1 kg)
• Operating Temperature: 0°C to 40°C (32°F to 100°F).
• Relative Humidity: 90%, non-condensing at 25°C.
• Estimated MTBF: 12 years excluding batteries.
• Two years limited warranty, parts and labor (excluding
batteries).
• Extended warranty available.
SPECIFICATIONS
TSi POWER CORP.
1103 West Pierce Avenue
Antigo, Wisconsin 54409, U.S.A.
Phone: [phone] FAX: [phone]
Internet: www.tsipower.com e-mail: [e-mail]
© Copyright—1999 TSi Power Corporation. All rights reserved.
TSi Power’s ongoing product improvement process makes specifications subject to change.
Other company’s product names herein are for identification purposes only and may be trademarks of
their respective companies.

The front panel indicator light monitors the status of the
UPS in the following manner:
1. Continously ON: The UPS is operating on AC power
(normal operation). The buzzer will be off.
2. Blinking slowly: The UPS is operating on battery
power (AC power failed, inverter on). The buzzer will
beep.
3. Blinking rapidly: The UPS is operating on battery power, and the battery is running
low. Only a few minutes of holdup time remains. The buzzer will beep more rapidly.
4. OFF: The UPS is turned off, or has shut down due to low battery.
FRONT PANEL INDICATOR
INTRODUCTION
Your TSi Power uninterruptible power supply model UPS-400 or UPS-600 is
designed to provide continuous AC power to your equipment during power outages,
glitches or brownouts. Normally, the UPS acts as a filter, to reduce the noise and
spikes in the utility voltage that powers your equipment. However, when the utility
voltage fails completely, or when it is too low to reliably hold up your equipment, the
UPS takes over, supplying clean, regulated power—generated from its internal
batteries—to your equipment. In addition, the models equipped with the “LI” or
“LIC” options include true isolation and power conditioning for further protection.
Be sure to mail the enclosed warranty registration card so that we may
better serve you. When you call TSi Power’s customer support (at 1-800-
TSI-3160), please have your unit’s model number and serial number
(located in the rear of the UPS) ready at hand.
SETUP SWITCHES
No Function ON†OFF
2. Audible Alarm ON OFF
3. Switchover Voltage HIGH LOW
4. UPS Output Frequency 60Hz 50Hz
†
ON means the switch is DOWN
Battery
Extension
Connector
Power
Switch
OPERATING INSTRUCTIONS
1. After unpacking the UPS, make sure that the power switch (in the rear of the
UPS) is in the OFF position and plug it into a grounded (3-pronged) 120V
electrical outlet. Do not connect anything yet to the outlets on the UPS.
2. To ensure that your batteries are fully charged, leave the UPS plugged in and
turned on for at least four hours before hooking up any equipment to the UPS.
3. After at least four hours, plug in the equipment you want backed up by the UPS
into the AC outlets in the rear of the UPS. Make sure that your equipment is
initially turned off, and that you don’t exceed the maximum power rating of your
UPS model (240W for UPS-400 and 400W for UPS-600).
NOTE: A typical IBM compatible PC or Macintosh with color monitor
draws 240W or less. Older equipment, file servers and high-end PC
workstations with large monitors usually draw more. Check your
equipment’s specifications for exact figures. Install only essential equip-
ment to your UPS. WARNING: NO LASER PRINTERS EVER!!
4. Turn on the UPS with the rear-panel power switch, and then your equipment.
After they’ve powered up, you may want to test the operation of the UPS by
unplugging the power cord of the UPS from the electrical outlet. Your
equipment should continue operating normally. But now, the green light of the
UPS should blink and the audible alarm should sound, indicating that your
equipment is being supplied with battery power.
6. Plug the power cord back into the outlet. Within several seconds, the audible
alarmwillgooff,andthegreenlightwillremainonwithoutblinking. Onceagain,
your equipment will continue to operate normally.
7. In the event of a real, prolonged power outage, the UPS will continue to operate
on battery power, until the batteries have only a few minutes of reserve power
left. Insuch acase, the audible alarm will beep more rapidly and the front panel
indicator light will blink more rapidly, warning you to save your work and
prepare for a shutdown.
8. Your UPS may be equipped with a port that allows it to communicate with file
servers and workstations for automatic backup & shutdown. Consult the
enclosed “Network Installation Instructions” for more information.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important information for models UPS-
400 and UPS-600 that should be followed during installation
and maintenance of the UPS and batteries.
Nominal voltage of the battery supply inside the UPS is 12
volts.
Maximum Operating Ambient Temperature for the UPS is
40 degrees Celsius.
IMPORTANT NOTICE FOR SERVICING PERSONNEL
A. Servicing of batteries should be performed or supervised
by personnel knowledgeable of batteries and the required
precautions. Keep unauthorized personnel away from
batteries.
B. When replacing batteries, use the same number and the
following type batteries: SEALED LEAD-CALCIUM.
C. CAUTION — Do not dispose of battery or batteries in a
fire. The battery may explode.
D. CAUTION — Do not open or mutilate the battery or
batteries. Released electrolyte is harmful to the skin and
eyes. It may be toxic.
E. CAUTION — A battery can present a risk of high short
circuit current. The following precautions should be
observed when working on batteries:
1. Remove watches, rings or other metal objects.
2. Use tools with insulated handles.
Alarm
Interface
UPS
Output
Sockets
MODEL NO.: SERIAL NO.:
The Power Switch turns the UPS on or off.
The Alarm Interface connects to your network file server (e.g. Novell Netware) or PC
to provide UPS alarm reporting functions. See enclosed instructions for network
installation.
Setup switch No.1 is inactive.
With setup switch No.2 in the OFF position, the audible alarm will sound only when
the reserve battery is running low (as a continuous tone). In the ON position, the
audible alarm will beep when running on
battery power.
switch when the UPS is
transferring to battery
power too often.
Setup switch No.4 deter-
mines the operating fre-
quency of the UPS (50 or
60Hz). Besure toset it to
be the same as your AC
power.
The Battery Extension
Connector plugs into an
EXT-400 for extended
holdup times. Refer to
the installation instruc-
tions enclosed with EXT-
400.
Setting setup switch No.3 to the
OFF position reduces the switch-
overvoltagebyabout10%. Usethis
REAR PANEL CONTROLS
AC Fuse
Power
Cord
Estimated Holdup Time Chart (hours:minutes)
Load 50W 100W 150W 200W 240W 300W 350W 400W
UPS-400 0:38 0:18 0:11 0:07 0:05 n/a n/a n/a
UPS-600 1:00 0:32 0:20 0:13 0:10 0:07 0:05 0:04
