Tulikivi Karelia User manual

Karelia horizontal door
Assembly instruction
OU05852 A02.10.17

OU05624
OU05616
OU05615
OU05624
Tape rope ends to air plates
Glue 10mm rope gasgets to air plates with heat resistant (900 c) glue. 1.
Ensure rope head attachment to air plates with heat resistant tape 2.

Tape rope ends to plate
OU05617
OU05626
Glue 10mm rope gasget to air plate with heat resistant (900 c) glue. 1.
Ensure rope head attachment to air plate with heat resistant tape 2.

Connect ends together
with heat resistant tape
OU05614
OU05625
Glue 6mm rope gasget to door frame with heat resistant (900 c) glue. 1.
Ensure rope attachment to frame with heat resistant tape 2.

Connect ends together
with heat resistant tape
OU05618
OU05622
Glue 10mm rope gasget to door frame with heat resistant (900 c) glue. 1.

Connect ends together
with heat resistent tape
OU05618
OU05622
G
OU05618
OU05621
6
6
NOTE!
Corners!!
Glue 6mm glass gasget to door frame. 1.

P
OU05190
OU04486
Planar surfaces
Saranan pinta samaan tasoon valun pinnan kanssa!
OU05513
OU05614
A
DETAIL A
SCALE 1 : 2
Leave this thread empty!!
DETAIL P
SCALE 1 : 2
OU06194
Attach hinge parts with M6x18 screws (5pc) 1.
Add M6 fixing screws (4pc) to frame 2.
Add door lifting stopper OU06194 with Bn1206 M6x8 screw 3.

B
OU04538
OU04538
OU04582
OU03414
C
DETAIL C
SCALE 1 : 2
Leave this thread empty!!
Attach lock base parts with M6x10 screws (3pc) 1.
Add M6 fixing screws (4pc) to frame 2.

OU04496
OU02985
D
1,50
DETAIL D
SCALE 1 : 2
Attach hinge parts with bn 1206 M6x8 screws (4pc) 1.

E
OU04535
OU02985
OU02985
OU02985
F
2
DETAIL F
SCALE 1 : 2
Attach lock parts with bn 1206 M6x8 screws (4pc) 1.
Attach M6x12 DIN 7991 screws (2pc) to frame 2.

H
R
6mm glass gasget
OU05849
OU05850
OU05850
OU05620
M6x20 DIN7991
6pc
OU06273
OU06273
DETAIL H
SCALE 1 : 1
NOTE!
Corners!
DETAIL R
SCALE 1 : 1
E-glass gasget to
both side of glass holders!
Glue 6mm glass gasgets to both sides of outer glass holders. 1.
Set glass against gasget in frame. 2.
Fix glass to frame with glass holders using T-parts OU06273. 3.

I
OU05847
OU05618
OU06274
M6x8
bn1206
10pc.
OU02985
OU04078
M6x12
DIN7991
2pc
Put outer glass OU05847 against glass holders and add sheet metal 1.
frame.
Fix frame with M6x8 screws 10pc and M6x12 DIN7991 2pc. 2.

OU05626
OU04078
Attach upper spoiler OU05626 to frame OU05614 with M6x12 DIN 7991 1.
screws (4pc)

OU05616
OU05615
OU05534
OU05534
OU05534
OU05534
Attach air plates OU05615 and OU05616 to frame OU05614 with M6x45 1.
DIN7991 screws (4pc)

J
OU05191
OU05045
1.
3.
13
DETAIL J
SCALE 1 : 1
OU04157
OU05045
2.
Attach door stopper part to frame OU05614 and tighten it with M6 nut 1.
Add bn M6x20 screw and Din 934 M6 nut to frame 2.
Add two bn M6x20 screws to frame 3.

3,51
N
1
DETAIL N
SCALE 1 : 2
NOTE!!
Gap between hinge parts!
Check door functions in it's right position 1.

14
13
6
19
20 15 16
OU04816
OU04776
OU04582
OU05045
OU04157
OU05811
OU04469
1. Pack separate parts to polybag and add them to door box

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
A3
Designer
Paino/Weight (kg) ERP/PDM code
Drawer
Inspector
Approver
Pvm/Date Nimi/Name
Info
Materiaali/Material Pinnoite/Coating Liittyy/Depents Toleranssi/Tolerance
Ver.
Nimitys/Description
Ver. Change Date Designer Approver
ISO2768-m
OU05852
02.10.17 KUITJUKK
A 28.37
Horizontal door modern
- Karelia
Osa Osan nimitys Muoto malli mitat MateriaaliNimike-Versio Määrä .Standardi
01 Horizontal door mounting frame EN-GJL 180OU05614-A 1
02 Hinge part EN 10025, S355J2G3OU04486-B 2
03 Door parts for horizontal door - Modern doorOU05851-A 1
04 LockOU04538-C 2
05 Air plate 450 EN-GJL 180OU05615-A 1
06 Kuusiokoloruuvi lieriökanta M6x10 DIN912 kiiltosinkittyOU04582-A 4
07 Kuusiokoloruuvi lieriökanta M6x18 DIN912OU05513-A 5
08 Socket head screw M6x45 DIN7991 Black passivatedOU05534-A 4
09 Set screw M6x8 din 913OU03414-A 8
10 Rope gasget 10mm Culimeta FD3197W Culimeta FD3197WOU05624-A 2
11 Rope gasget 6mm Culimeta FD3197WOU05625-A 1
12 Rope gasget 10mm Culimeta FD3197W Culimeta FD3197WOU05626-A 1
13 Extension spring SF-DFR-3813-LesjoforsOU04469-A 1
14 Hinge fixing plate EN 10025, S235, Pickled/PeitattuOU05190-A 2
15 Door stopperOU05191-A 1
16 Screw bn 1206 m6x20OU05045-A 3
17 Kuusiomutteri matala Din 439B M6OU04157-A 1
18 Upper spoiler EN-GJL 180 SiCrOU05617-A 1
19 Hexagon socket screw M6 L12 DIN 7991 black passivatedOU04078-A 4
20 Pystykahva Musta - Karelia vaakaluukkuOU05853-A 1
21 Fix part EN 10025, S235, Pickled/PeitattuOU06194-A 1
22 Screw bn 1206 st m6x8OU02985-A 1
23 Air plate 450 EN-GJL 180OU05616-A 1

434
734
87
27kg
Sivu nro.
Pvm Rev.
Dokumentin nimi
Muutos
Hyväksyjä
Tekijä
Ver.
Pvm.
19
OU05852 A
KUITJUKK
02.10.17
