Owner Manual
M150 - M350
M150_M350-GD-0515-EN
2041-A, Leonard-de Vinci, Sainte-Julie (Quebec) Canada J3E 1Z2 7
Tel : [phone] Fax : [phone]
Congratulations! You have purchased one of the most sophisticated and reliable power inverters of the industry.
Incorporating the latest technologies, it will deliver years of trouble free operation for your truck, boat, RV or other “OFF Grid”
system.
In order to get the most out of your inverter, it must be installed and used properly. Please thoroughly read this manual
before installing and using your new inverter.
1. INSTALLATION:
M150: Insert the specially designed plug into the cigarette lighter socket of your vehicle. Then push the ON/OFF button
located on the front panel, in order to make it work. A green light will light up to indicate that your inverter is now
ready to provide current. You may now use it.
WARNING! IT IS EXTREMELY INADVISABLE TO INCREASE THE AMPERAGE OF THE “IN-
DASH” FUSE; THIS WOULD OVERHEAT YOUR VEHICLE’S WIRING AND RESULT
IN A FIRE.
M350: Total consumption up to 240W: Most of the vehicle lighter plugs allow a consumption up to 240w (20A @ 12
VDC). Install the specially designed plug to the terminals located on the rear panel of your inverter and insert
the plug into the cigarette lighter socket. Then push the ON/OFF button located on the front panel, in order to
make it work. A green light will light up to indicate that your inverter is now ready to provide current. You may
now use it.
Total consumption up to 350W: In order to use the inverter at its full capacity, you must use the cables with
the alligator clips or by connecting the inverter permanently to one battery using a good quality AWG #8 cable
and a 30A fuse (12 feet of distance maximum).
CAUTION! THIS STEP REQUIRES SKILLS AND CAREFULNESS.
CAUTION! REVERSING THE POLARITY WHEN CONNECTING THE DC CABLES WILL
PERMANENTLY DAMAGE YOUR INVERTER. THIS IS NOT COVERED BY THE
WARRANTY.
2. MAINTENANCE:
An inverter doesn’t require a lot of maintenance to work properly:
1. With a dry cloth, clean the outside of your inverter and its environment periodically in order to prevent dust
accumulation inside its circuits.
2. Your inverter must never be exposed to any liquids. If this occurs, have it inspected by a qualified technician before
use.
3. DC input bolts must be verified periodically and tightened if necessary.
CAUTION! MAKE SURE TO UNPLUG YOUR INVERTER FROM ITS POWER SOURCE BEFORE
DOING ANY KIND OF MAINTENANCE.

Owner Manual
M150 - M350
M150_M350-GD-0515-EN
2041-A, Leonard-de Vinci, Sainte-Julie (Quebec) Canada J3E 1Z2 7
Tel : [phone] Fax : [phone]
3. SPECIFICATIONS
4. WARNINGS
1. The M150 & M350 only work with a 12 volts DC source.
2. When you stop using your inverter, it is strongly recommended to unplug the unit from its power source.
3. The inverter should always be OFF when starting the vehicle.
4. If your consumption is over the inverter capacity, an over load protection will automatically turn off the unit. To restart
the inverter, reduce your consumption. If the inverter doesn’t resume automatically, shut off the unit and restart it
manually using the ON/OFF button located on the front panel.
5. Stop using the inverter if the 12 volts power cord has been damaged or loosen. Have it repaired before using it again.
6. Your inverter could get very hot. Make sure there is no flammable materials near the unit.
7. Keep the inverter away from liquids, snow or any other source of humidity. The electricity produced by the inverter
can create an electric arc in presence of humidity and cause serious injuries or even death.
8. If the inverter has been exposed to rain, moisture, or strong impact, have it inspected by a qualified technician before
use.
9. We stongly recommend using a «pure sine wave» inverter for your sophisticated electronic devices.
Model
M150
M350
Type
Power Inverter
Power Inverter
Grade
Professional
Professional
Part number
TUN112001
TUN112002
Electrical specifications
Continuous output power
150W
350W
Peak output power
300W
700W
Input voltage (nominal)
12 VDC
12 VDC
Operating input voltage
10-15 VDC
10-15 VDC
Output voltage
120 VAC +/- 3%
120 VAC +/- 3%
Output frequency
60 Hz
60 Hz
Output wave form
Modified
Modified
DC efficiency (Peak)
90%
90%
AC efficiency (Peak)
90%
90%
General Specifications
AC outputs
1 x NEMA 5-15R
1 x NEMA 5-15R
Operating temperatures
-30° to 131°F
-30° to 131°F
Cooling fan(s)
Thermostatic
Thermostatic
Construction
Aluminium
Aluminium
DC inputs
Lighter plug
Lighter plug + Alligator clips
Unit dimensions (W x L x H) - English (in.)
6,1 x 3,4 x 2,2
6,9 x 3,4 x 2,2
Unit dimensions (W x L x H) - Metric (cm.)
15,5 x 8,6 x 5,6
17,5 x 8,6 x 5,6
Unit weight (Lbs / kg)
1,1 / 0,5
1,3 / 0,6
Warranty
1 Year
1 Year
