Tuni VENUS WA03013 User manual

User Manual
CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Product Code: WA03013
Walker

General Warning
Thank you for purchasing the Tuni Venus walker.
1. DO NOT install or use this walker without first reading and understanding these
instructions. If you are unable to understand the warnings, cautions or instructions in
this manual, please contact a healthcare professional, dealer or technical personnel
before attempting to install this walker – otherwise, injury or damage may occur.
2. Always make sure the handle height on both sides is the same and the knob there is
tightened. Otherwise, it may cause injury.
3. Please do not open this walker with great force as this may cause damage to parts.
4. Do not lean too far over the front of the walker to prevent instability and the risk of
fall.
5. Do not use this walker if the weight of user exceeds the maximum. Weight capacity
of this walker is 136 kg.
6. Always check the condition of parts to ensure safety.
Features for this product
1. The Tuni Venus is modern looking, user-friendly, improves stability, strong and
durable.
2. It folds compact for travel and easy storage.
3. The walker is height adjustable.
4. Front wheels are attached for easier walking.
Specification
Folding size:
Width: 85.5 cm
Depth: 11.5 cm
Height: 85-95 cm
Height adjustable from 85 cm to 95 cm
Weight capacity: 136 kg (21st 5lbs)
1

Assembly
A. Install side frame into foot tubing.
B. The hole on side frame is matched with that on foot tubing (handle height on
both sides is the same) and then tighten the knob.
C. Grasp the handle and open the walker to right position an audible “click” is
heard as shown in figure below.
D. Assemble bag tubing to each side of foot tubing and then hang the shopping
bag.
Instructions
Shopping Bag Foot tubing
Knob
Bag tubing
Side frame
Lever
2

Handle height adjustment
Loosen the knob on both sides and adjust the side frame to desired height, tighten the
knob on condition that the handle height on both sides is the same.
Walking
Grasp handgrip upward with gentle force, push forward and then put down the walker.
Support the body with handgrip and walk forward. Repeat this action to walk forwards,
and keeping balance during usage.
Folding
Grasp the handgrip and pull the lever upward as shown in fig. 1 (Do not use lever during
usage), and fold the handgrip inward as fig. 2 shows.
Maintenance
1. If something goes wrong with the walker, do not disassemble as this may cause
damage to other parts. Please contact dealer or manufacturer.
2. Keep the walker away from acidic substances. Clean the surface with
a mild soap detergent.
Fig. 1
Fig. 2
3
