Turtle Beach Ear force PX11 User manual

User Guide
WIRED
For: PS3™ I Xbox 360®
PC I Mac®
UNIVERSAL STEREO GAMING HEADSET

Congratulations on your purchase of the Ear Force PX11 headset from Turtle Beach. The PX11 works with your
consoles, PC or Mac . Welcome to the Turtle Beach Audio Advantage!
For our Knowledgebase and Technical Support Contact info please visit: http://www.turtlebeach.com/support

Table of Contents
Package Contents P4
Features P5
Amplifier Function Map / Use P6
PS3™ Hardware Setup (HDMI / RCA) P7
Using your PX11 Headset on PS3™ P11
Xbox 360® Hardware Setup (HDMI / RCA) P12
Using your PX11 Headset on Xbox 360® P17
PC / Mac® Hardware Setup P18
PC Setup P19
Mac Setup P20
Specifications P21
Compliance / Conformity P22
Warranty P24

4
Package Contents
Xbox 360
Talkback Cable*
RCA Splitter Cable
EarForce PX11 Headset Inline Amplifier
Turtle Beach Stickers Quick Start Guide
Quick Start Guide
For the full user guide please go to www.turtlebeach.com/products/PX11
#1 IN GAMING AUDIO For: PS3™ I Xbox 360® I PC I Mac®
WIRED
11
11
11
*For best Xbox chat performance, use with official Microsoft Xbox 360 products.

5
Features
Features
11
· Bass Boost: Bumped-up bass guarantees you feel every bone-jarring thud.
· Independent Volume Controls: Adjust incoming chat audio separately from game audio.
· Microphone Monitor: Lets you hear what you’re saying while communicating with others.
· USB Powered: No need for batteries.

6
11
Amplifier Function Map / Use
Inline Amplifier
Mic Switch:
Mic On Mic Mute
Mic Indicator
Green=On Red=Mute
Xbox 360® Talkback
Cable Jack
Game Volume Control
Chat Volume Control

7
11
PS3™ Hardware Setup HDMI / RCA
PS3™ Setup (HDMI)
1
Inline Amplifier
Headset
USB Power
(Green)
RCA Splitter Cable
Green
Audio:
Red / White

8
PS3™ Hardware Setup HDMI / RCA
PS3™ Setup (HDMI)
11
2
Inline Amplifier
RCA Splitter Cable
**HDMI
*PS3 AV Cable
Headset
*PS3 AV cable is included with your console.
**HDMI cable sold separately.
It’s not necessary to connect the PX11 RCA Splitter Cable to the TV itself, since the HDMI
cable carries the audio signal from the PS3 to the TV.
USB Power
(Green)
Audio:
Red / White

9
PS3™ Hardware Setup HDMI / RCA
PS3™ Setup (RCA)
1
11
Inline Amplifier
Green RCA Splitter Cable
Headset
USB Power
(Green) Audio:
Red / White

10
PS3™ Hardware Setup HDMI / RCA
11
Headset
2
PS3™ Setup (RCA)
Inline Amplifier
RCA Splitter Cable
PS3 AV Cable*
*PS3 AV cable is included with your console.
You need to connect
to the TV’s audio and
video input jacks.
(Green)
(Green)
Video: Yellow
Audio:
Red / White
USB Power

11
Using your PX11 Headset on PS3™
HDMI or digital (optical)
Chat Setup
1. Go to Settings
- Choose “Sound Settings”
- Choose “Audio Multi-Output” and set to “On”
1. Go to PS3 Settings
- Choose “Accessory Settings”
- Choose “Audio Device Settings”
- Set “Input Device” to “TURTLE BEACH
PX11 CHAT”
- Set “Output Device” to “TURTLE BEACH
PX11 CHAT”
- Select “OK”
2. Set Microphone Level to 3 or 4
Audio Device Settings
Microphone Level 3
Input Device TURTLE BEACH PX11 CHAT
Output Device TURTLE BEACH PX11 CHAT
Back
X Enter
OK
Audio Output Settings
12/14 12:15 PM
0
On
Sets to output audio through multiple connectors
simultaneously. Audio output to connectors that are
not selected in [Audio Output Settings] is downscaled
to 2 Ch.

12
Xbox 360® Hardware Setup HDMI / RCA
Xbox 360® Setup (HDMI)
11
1
Inline Amplifier
Xbox 360
Talkback Cable
RCA Splitter Cable
Headset
(Black) Audio:
Red / White
USB Power

13
Xbox 360® Hardware Setup HDMI / RCA
Xbox 360® Setup (HDMI)
11
2
Inline Amplifier
Xbox 360
Talkback Cable
RCA Splitter Cable
Headset
(Green)
(Green)
Audio:
Red / White
USB Power
Xbox 360 Audio Adapter*
*All Xbox 360 models require an Xbox 360 Audio Adapter for audio output when used with an HDMI connection available from turtlebeach.com.
Note: If your HDMI TV has a red/white AUDIO OUT RCA Jack, you can use them. (AUDIO IN jacks will not send sound to your headset. AUDIO OUT is
required).

14
Xbox 360® Hardware Setup HDMI / RCA
11
Xbox 360® Setup (HDMI)
3
Inline Amplifier
Xbox 360
Talkback Cable
RCA Splitter Cable
Headset
(Black)
Audio:
Red / White
USB Power
HDMI
Xbox 360 Audio Adapter Cable*
*All Xbox 360 models require an Xbox 360 Audio Adapter for audio output when used with an HDMI connection available from turtlebeach.com.
Note: If your HDMI TV has a red/white AUDIO OUT RCA Jack, you can use them. (AUDIO IN jacks will not send sound to your headset. AUDIO OUT is
required).

15
Xbox 360® Hardware Setup HDMI / RCA
Xbox 360® Setup (RCA)
11
1
Inline Amplifier
Xbox 360
Talkback Cable
RCA Splitter Cable
Headset
(Green) (Green) Audio:
Red / White
USB Power

16
Xbox 360® Hardware Setup HDMI / RCA
Xbox 360® Setup (RCA)
11
2
Inline Amplifier
Xbox 360
Talkback Cable
RCA Splitter Cable
Headset
(Green)
(Green)
Audio:
Red / White
USB Power
RCA plugs need to connect to the HDTV’s input jacks.

17
Using your PX11 Headset on Xbox 360®
Xbox 360® Configuration
Go to Xbox Settings
- Choose “Preferences”
- Choose “Voice”
- Set both Voice Volume and Game Volume to ”10”
- Set “Voice Output” to “Play Through Headset”
Voice Volume 10
Voice
Mute Kinect
Voice Output
Play Through Headset
Play Through Speakers
Play Through Both
Game Volume 10

18
PC / Mac Hardware Setup
PC / Mac Setup
When used as a PC/Mac gaming headset, the PX11 functions as an Amplified USB Stereo Headset. When connected to a
PC or Mac, the PX11 appears in Windows and Mac operating systems as “TURTLE BEACH PX11 CHAT.” This allows the
PX11 microphone to be assigned for chat use in game software as a USB audio device.
The black 3.5mm plug is used for sending the stereo game signal from the computer sound card to the PX11 amplifier,
allowing game sounds, music and other sounds to be heard from the computer.
Note: Both plugs must be connected. Set system volume to maximum and then adjust system volume via the game
volume wheel.
11
Inline Amplifier Headset

19
PC Setup
PLEASE NOTE: Depending on your OS Version, the screens may differ but the steps will remain the same.
1. Right-click the speaker icon in your task bar
and select “Playback Devices”.
2. Right-click on “Speakers” and select “Set as Default
Device”. Next, right-click on “TURTLE BEACH PX11 CHAT”
and select “Set as Default Communication Device”.
3. Click on the “Recording Tab” , then right-click
“TURTLE BEACH PX11 CHAT” and select “Set as
Default Device.” If you speak into the mic you should
see green bars on the right move.
4. Click on the “OK” button at the bottom of the
window to exit.
NOTE: In order to maintain independent volume
controls for chat and game, please make sure to set
“TURTLE BEACH PX11 CHAT” as both the recording
and playback device in the audio setting for your voice
chat application.

20
Mac Setup
PLEASE NOTE: Depending on your OS Version, the screens may differ but the steps will remain the same.
1. Click on the Apple Menu and select System Preferences » Sounds.
2. On Output tab, select “Headphones”.
3. On Input tab, select “TURTLE BEACH PX11 CHAT”.
NOTE: In order to maintain independent volume
controls for chat and game, please make sure to set
“TURTLE BEACH PX11 CHAT” as both the recording
and playback device in the audio setting for your
voice chat application.
