USER MANUAL
L238DPH
24" Class Slim HD Widescreen Monitor

TABLE OF CONTENTS
1 Getting Started
Package includes
Installation
2 Control Panel/ Back Panel
Control Panel
Back Panel
3 On Screen Display
4 Technical Specs
5 Care & Maintenance
6 Troubleshooting
No Power
Power on but no screen image
Wrong or Abnormal Colors
7 Safety info & FCC warning

1
GETTING STARTED
Package includes
• AC Power Cord
• VGA Cable
• Audio cable
• Cable holder
• Quick start guide
AC Power Cord VGA Cable Audio cable Cable holder

GETTING STARTED
Installation
1. Slide cable holder onto post 2. Screw base into post
3. Connect video cable, Connect power cord, Connect Audio cable
4. Power on computer and monitor
POWER VGA
DISPLAYPORT
DVI HDMI

CONTROL PANEL/ BACK PANEL
Control Panel
Back Panel
2
OSD Menu On/O
Scroll Down/Decrease
Scroll Up/Increase
Conrm Select
Power On/O
LED Indicator
1 2
Audio Input
Earphone Output
VGA Port
HDMI Port
DVI Port
Display Port
Power Cable

ON SCREEN DISPLAY
31
Display main menu
Exit from OSD menu
2 Manual adjust mode select for VGA, DVI, HDMI, DisplayPort, Auto mode
Select the desired item when in OSD menu
When not in OSD menu, directly enters Contrast/Brightness menu
Select the desired item when in OSD menu
When not in OSD menu, directly enters Picture mode
Recall both of Contrast and Brightness (when not in OSD menu)
Power Lock (when not in OSD menu)
OSD Lock (when not in OSD menu)
Using On Screen Display (OSD) Functions
+
1+
2+
Main Menu


Short Cuts Function from the button(s)
Auto Image Adjust To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. Size) of the screen.
Contrast/Brightness
To manually adjust the Contrast, Brightness, DCR, ECO and OD of screen image.
Contrast: To adjust the foreground white level of screen image.
increase contrast, decrease contrast.
Brightness: To adjust the luminance of the video.
increase brightness, decrease brightness.
DCR: To detect the distribution of the visual signals inputs, and create an optimized contrast. Brightness and ECO adjustment will be
disabled when DCR is active.
ECO: Allows the user to change the ECO mode. Contrast, Brightness and DCR adjustment will be disabled when ECO is active.
OD: Allows the user to change the Over Drive strength. Improve the quality of the motion pictures.


Input Source When Input Select is pressed, change Input signal to VGA, DVI, HDMI, DisplayPort or Auto.


Audio Adjust
To adjust the audio functions.
Volume: To adjust the volume of speaker output.
Mute: To turn the Mute ON/OFF.
Audio input: When in HDMI input, select where the audio source comes from Line-In or HDMI.
When in DisplayPort input, select where the audio source comes from Line-in or DisplayPort.


Color Adjust
To select the color for improving brightness and color saturation between Cool, Normal, Warm and User colour and
Picture mode.
Cool: Adds blue to screen image for cooler white.
Normal: Adds red to screen image for warmer white and richer red.
Warm: Adds green to screen image for a darker color.
User colour: Individual adjustments for red (R), green (G), blue (B).
1. Press button 2to select the desired color.
2. Press or button to adjust selected color.
ON SCREEN DISPLAY

Short Cuts Function from the button(s)
Picture mode: Provides an optimum display environment depending on the contents displayed. It contains 5 user-selectable
presets.
• Standard is for general windows environment and monitor default setting.
• Game optimized for PC game environment
• Video optimized for movie and video environment
• Landscape optimized for displaying outdoor scenery images.
• Text optimized for text editing and viewing in a word processing environment


Information To display the information, regarding the current input signal coming from the graphic card in your computer.
Note: See your graphic card user guide for more information about changing the resolution and refresh rate.
Manual Image
Adjustment
To manually adjust the H. /V. Position, Horizontal size, Fine tune and Sharpness.
H. / V. Position:To adjust the horizontal and vertical position of the video.
H. Position: : move screen to the right, : move screen to the left.
V. Position: : move screen up, : move screen down.
Horizontal Size:To adjust the width of the screen image.
: increase the width of the screen image, : decrease the width of the screen image
Phase: To adjust the delay time of data and clock.
Press or to adjust to your preference.
Sharpness: To adjust the clarity of a non-Full HD Resolution (1920x1080) signal with or button
Video mode adjust: To select the video mode from Aspect Ratio 4:3 or Full Screen.
Aspect Ratio 4:3: To select 4:3 image size.
Full Screen: To select full-screen size image.
Menu Setting
To set up Language select, OSD Position, OSD time out and OSD background.
Language Select: To allow users to choose from available languages
OSD Position: Press or button to select between horizontal and vertical OSD Position Adjustment.
OSD H. Position: To horizontally adjust the OSD Position
: move OSD to the right, : move OSD to the left
OSD V. Position: To vertically adjust the OSD position.
: move OSD up, : move OSD down.
OSD time out: To automatically turn o On Screen Display (OSD) after a preset period of time.
OSD background: Allows the user to turn the OSD background On or O


Memory recall To recall factory settings for Video & Audio controls. Press button 2to select the Memory Recall menu option.
ON SCREEN DISPLAY

TECHNICAL SPECS
4LCD Panel 60.4 cm (23.8”) TFT (with LED back light)
Power
Management
Energy Star
VESA DPMS compatible
O Mode, < 0.5 W
Displayable
Resolution
Full HD 1920 x 1080 max.
Vertical Frequency 60Hz max.
Pixel Dimension 0.2745 x 0.2745 mm
LCD Display Color 16.7M
Tilt -5°~22° (±2°)
Active Display
Area 527.4 mm x 296.46 mm
Temperature Operating: 0°C ~ + 40°C
Storage: -20°C ~ + 60°C
Compliance FCC, CE, Energy Star
Power Input Voltage AC100-240 V
Technical Specication

CARE & MAINTENANCE
5Care
• Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare.
• Put your monitor in a well ventilated area.
• Do not place any heavy things on top of your monitor
• Make certain your monitor is installed in a clean and moisture-free area.
• Keep your monitor away from magnets, motors, transformers, speakers, and TV sets.
Safety Tips
• If smoke, abnormal noise or odor came out from your monitor, caution you should remove the power cord immediately and
call your service center.
• Never remove the rear cover of your monitor cabinet. The display unit inside contains high-voltage parts and may cause
electric shock to human bodies.
• Never try to repair your monitor yourself. Always call your service center or a qualied technician to x it.
