TVS Rockz User manual

Owners Manual
© PT TVS Motor Company Indonesia
TAKE THE LEAD
RE 00001

ALWAYS USE TVS GENUINE PARTS

OWNER’S IDENTITY
Customer Name :
Address :
Customer HP / Phone No. :
Frame No. :
Engine No. :
Type :
Color :
Purchase Date :
Signature and
dealer stamp
Owner signature

Preface
1. Specifications.......................................................... 1
New vehicle delivery certificate............................... 6
Pre-delivery check................................................... 7
2. Important information............................................. 10
3. Know about your Rockz........................................... 14
4. Integrated Music System......................................... 30
5. Features & benefits................................................. 38
6. Maintenance........................................................... 45
CONTENTS
CONTENTS

PREFACE
Dear Rockz Owner,
Congratulations!
Welcome to the family of millions of satisfied TVS Customers across the world by choosing TVS
Rockz.
This manual explains about the features and benefits of your bebek. Please thoroughly
familiarise this manual before you start driving your bike.
Maintenance is extremely important to let your Rockz deliver the maximum performance to
you. Please get your Rockz maintained from any TVS Authorised Dealer / PGM/ Service Outlets.
We are delightful to welcome you into our ever expanding happy family.
Wish you all the very best. Thank you for choosing TVS Rockz.
Happy riding,
PT TVS Motor Company Indonesia

SPECIFICATIONS
SPECIFICATIONS
1
OVERALL DIMENSIONS
Overall length 1940 mm
Overall width (Handle bar) 665 mm
Overall height (With mirror) 1078 mm
Seat height 767 mm
Ground Clearance 150 mm
0
Grade ability 17
Wheel base 1260 mm
Dry Mass 107 Kg
Pay load 130 Kg
ENGINE
Type Single cylinder 4 stroke air
cooled engine
Bore x Stroke 57.0 x 48.8 mm
Piston displacement 124.5 cc
1

SPECIFICATIONS
Compression ration 9.3:1
Carburettor VM 17 UCAL
Air Filter Paper filter
Starting System Electric start / kick start
Lubrication System Trochoid Oil Pump
Engine oil grade SAE 20W40 TVS Tru4 Premium Engine Oil
Maximum power (in kW) 9.8 BHP @ 7500 rpm
Maximum torque (in Nm) 9.8 Nm @ 5500 rpm
Engine idling rpm 1300 ± 50 rpm
Spark plug BOSCH - UR5DC
Spark plug gap 0.6 mm
TRANSMISSION
Clutch Centrifugal clutch - Auto,
Auto with Manual Override (Rockz - CW)
Transmission Constant mesh 4 speed gear box
Primary reduction (61/18) 3.388
2

SPECIFICATIONS
Final reduction (39/15) 2.60
Gear ratios:
1st gear (35/12) 2.916
2nd gear (26/14) 1.857
3rd gear (24/18) 1.333
4th gear (Top gear) (21/20) 1.050
Overall reduction (Top gear) 9.25
CHASSIS
Frame type Underbone
0
Caster angle 26
Trail 74 mm
0
Steering angle 90
Brakes front and rear
Rockz - SW Front: Disc 220 mm Rear : Drum :110 mm Dia
Rockz - CW Front: Disc 220 mm Rear : Drum :130 mm Dia
3

SPECIFICATIONS
00
Tyre size
Front 2.50 x 17“
Rear 2.75 x 17”
Tyre pressure kg/cm2 (PSI)
2
Front 2.00 kg/cm (29 PSI)
2
Rear 2.25 kg/cm (32 PSI)
Suspension
Front Telescopic shock absorbers
Rear Swing arm with triple rated, 3 step adjustable, monotube
gas filled canister shock absorbers (Rockz CW).
ELECTRICAL
Ignition system Digital CDI
Battery type 12V 4Ah Sealed MF
Generator AC 90W Magneto
Head Lamp 30 /30 W (Halogen)
Tail/Brake Lamp 12V 5W/18W
Turn signal Lamp 12V 2W LED
4

SPECIFICATIONS
Speedometer Lamp 12V 0.25W LED (Rockz - CW)
Fuel gauge Lamp 12V 0.25W LED (Rockz - CW)
Turn signal indicator Lamp 12V 0.25W LED (Rockz - CW)
High beam indicator Lamp 12V 0.25W LED (Rockz - CW)
Iecono mode indicator 12V 0.25W LED (Rockz - CW)
Engine warm up indicator 12V 0.25W LED (Rockz - CW)
Gear position indicators (1 - 4) 12V 0.25W LED (4 nos.)
Horn 12V DC - 2A
Position Lamp 12V 1.7W
CAPACITIES
Fuel tank capacity 4 litres
Engine oil quantity
For oil change 1000 ml
For overhaul 1200 ml
Front fork oil quantity 55 ± 2 ml
5

NEW VEHICLE DELIVERY CERTIFICATE
Herewith we certify that this vehicle has been checked before delivery by dealer through standard procedure which has been
specified by PT TVS MOTOR COMPANY INDONESIA to guarantee performance, vehicle appearance to achieve customer
satisfaction. Details of bike are as follows :
Customer Name :
Frame No. :
Engine No. :
Type :
Color : Telephone / HP
Purchase Date :
Warranty is valid for vehicle that always avail service periodically in TVS authorized outlet that is Regional Distributor /
Dealer / PGM and always using TVS Genuine Parts and recommended engine oil.
Thank you very much for showing trust and choosing our product.
Cordially yours,
 Note : To be sent to PT TVS MOTOR COMPANY INDONESIA
Signature and
dealer stamp
Owner signature
6

PRE DELIVERY CHECK
Explain to customer about the following:
1. Integrated Music System
(FM/MP3/Speakers)
2.
3.
4.
5.
6. Explain to customer about installation:
7. Fuel tank capacity
8. Engine oil quantity - 1000 ml
Please make sure that Pre Delivery Check (PDC) is carried out in your
presence before taking delivery of TVS Rockz.
The check consisting of:The check is consisting of:
1. Clean and check condition of physical vehicle
2. Check tyre air pressure
3. Check engine oil level
4. Check throttle, clutch, brake cable play and adjustment
5. Check drive chain slackness
6. Check Battery/Electricals / Music system (FM/MP3/Speakers)
7. Start the vehicle and check acceleration
8. Check handle bar freeness
9. Check smoothness of throttle grip
10. Rear view mirror fitment
11. Tightens bolts and nuts
Date:
Mechanic signature
Customer signature
7

NEW VEHICLE DELIVERY CERTIFICATE
Herewith we certify that this vehicle has been checked before delivery by dealer through standard procedure which has been
specified by PT TVS MOTOR COMPANY INDONESIA to guarantee performance, vehicle appearance to achieve customer
satisfaction. Details of bike are as follows :
Customer Name :
Frame No. :
Engine No. :
Type :
Color : Telephone / HP
Purchase Date :
Warranty is valid for vehicle that always avail service periodically in TVS authorized outlet that is Regional Distributor /
Dealer / PGM and always using TVS Genuine Parts and recommended engine oil.
Thank you very much for showing trust and choosing our product.
Cordially yours,
 Note : To be sent to REGIONAL DISTRIBUTOR
Signature and
dealer stamp
Owner signature
8

PRE DELIVERY CHECK
Explain to customer about the following:
1. Integrated Music System
(FM/MP3/Speakers)
2.
3.
4.
5.
6. Explain to customer about installation:
7. Fuel tank capacity
8. Engine oil quantity - 1000 ml
Please make sure that Pre Delivery Check (PDC) is carried out in your
presence before taking delivery of TVS Rockz.
The check consisting of:The check is consisting of:
1. Clean and check condition of physical vehicle
2. Check tyre air pressure
3. Check engine oil level
4. Check throttle, clutch, brake cable play and adjustment
5. Check drive chain slackness
6. Check Battery/Electricals / Music system (FM/MP3/Speakers)
7. Start the vehicle and check acceleration
8. Check handle bar freeness
9. Check smoothness of throttle grip
10. Rear view mirror fitment
11. Tightens bolts and nuts
Date:
Mechanic signature
Customer signature
9

IMPORTANT INFORMATION
IMPORTANT
INFORMATION
2
Usage
This bike is designed to use only on road. It is recommended to
use only good quality gasoline for your Rockz.
Loading
This bike is intended to transport you and one pillion. The
designed capacity is :
It is strictly recommended not to overload by means of
additional pillion passenger, or any extra cargo into the bike.
Unlimited loading will affect your bike stability and reduce
performance significantly.
Modification
We have designed this bike with greater care which will
Maximum load of 130 kg
10

IMPORTANT INFORMATION
deliver optimum performance to you.
Modifying your bike is not recommended.
Any kind of modification in this bike will
affect the performance and may overrule
statutory requirements by the government
and violate warranty terms and conditions
also.
Know the controls
Before you start driving your bike, we
recommend to read this manual carefully.
This will give you a very good understanding
about your bike and controls and other
instruments so that you never make any
mistake while driving. Once you read out the
manual, habituate yourself to the controls of
your bike.
Accessories
While fitting the accessories in your bike we
recommend to consult your friendly TVS
authorized service outlets who can guide you
to select the suitable accessory according to
the requirement. Unsuitable accessories
which will affect the bike performance is
strictly prohibited.
11

IMPORTANT INFORMATION
Item check list
Please check that all the following items
have been included in your bike. If
anything is missing please contact your
friendly TVS service outlets:
Item Qty
Control key 2q
Owners’ manual 1q
Rear view mirror 2q
Tool kit 1q
Date :
Pre delivery check
Please make sure that Pre Delivery Check (PDC) is carried
out in your presence before taking delivery of TVS Rockz.
The check is consisting of :
1. Clean and check condition of physical vehicle
2. Check tyre air pressure
3. Check engine oil level
4. Check throttle, brake cable play and adjustment
5. Check drive chain slackness
6. Check battery/electricals/Integrated Music System
(FM/MP3/Speakers)
7. Start the vehicle and check acceleration
8. Check handle bar freeness
9. Check smoothness of throttle grip
10. Rear view mirror fitment
11. Tighten bolts and nuts
Customer signature Mechanic signature
12

IMPORTANT INFORMATION
In this manual, the following symbols are read as follows:
WARNING - Disregarding the message might result in serious injury to the rider
CAUTION - This message indicates special procedures or precautions to be
followed to avoid damage to the vehicle
NOTE - This provides further clarification for cleaner understanding of any
particular information
Important Information
We recommend you to carefully read this manual to get clear understanding of your Rockz.
This manual is applicable for all the Rockz models. Though most of the basic information is
common across all variants, differentiation will help in better understanding of both. So please
read the information with :
- for Rockz Basic model (Spoke Wheel/SW)
- for Rockz Plus model (Casting Wheel/CW)
!
G

13

KNOW ABOUT YOUR ROCKZ
KNOW ABOUT
YOUR ROCKZ
3
Frame Number
Frame number is located in
the rear side of the frame,
between pillion handle and
fuel tank. To read the frame
number clearly, remove the
pillion handle by loosening
mounting bolts (4 nos.).
Engine Number
Engine number is engraved
on the left side crankcase of
engine as shown in fig.
VEHICLE IDENTIFICATION NUMBER (VIN)
14

KNOW ABOUT YOUR ROCKZ
LOCATION OF PARTS - HANDLE BAR Description:
1. Integrated Music System
2. Speaker R
3. Ignition lock
4. Electric starter switch
5. Head lamp ON / OFF switch
6. Front brake lever
7. Rear view mirror R
8. Instrument cluster
9. Rear view mirror L
10. High / low beam switch & pass by switch
11. Clutch lever
12. Turn signal lamp switch
13. Horn switch
14. Choke lever
15. USB socket
16. Head phone socket 2 nos.
17. Charger handphone
18. Speaker L
3
2
45
6
7
8
10
9
11
12 13
14 15
16 17
18
1
15
