TW Audio VERA20 User manual

Operation manual VERA20

Operation manual VERA20
2
Introduction
The VERA20 loudspeaker is equipped with two 10” chassis for the low-mid frequencies and
a waveguide with a 1.4” mid-high compression driver. Compared with typical double 8”sys-
tems, the VERA20‘s two 10” drivers are capable of reproducing up to 6dB more output in the
low-mid frequency range with lower distortion.
Thanks to the loudspeaker’s width (only 60 cm / 23.62inches) and height (28cm / 11.02inches),
vertical arrays of up to 24 elements may be constructed.
The newly developed 1.4” compression driver and waveguide provides smooth and accurate
midrange performance for natural vocal and music reproduction. The low frequency crosso-
ver point around 1kHz guarantees precise and uniform coverage even in the sensitive transi-
tion range. The extraordinarily fast transient response ensures that high frequency reproduc-
tion is detailed and crisp.
The VERA20 implements an outstandingly innovative rigging hardware, allowing straightfor-
ward, fast and cost-efficient setup and dismounting by just one technician. A special feature
is logarithmic scaling of the intermediate angles between angles. This allows for angle adjust-
ment of less than one degree to achieve more accurate directivity of upper array elements
over longer distances.
Notes in the user manual
CAUTION
WARNING
WARNING
Thank you for choosing a high-quality product “MADE IN GERMANY” from the brand
TW AUDiO.
If you lend your product to another party, inform that party of the safety-related operating pro-
cedures and hand over this assembly guide. If you require additional copies of this manual,
you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation for persons with a pacemaker. Failure to comply with this safety instruction can lead
to serious injury or even death.
This symbol in combination with the signal word “Caution” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to light or moderate injury.

Operation manual VERA20
3
NOTE
TIP
Notes on the products
Read manual
before use!
Before using the device, carefully read the operating manual and keep it with the
VERA20 loudspeaker.
General information
Operation manual: OM-VERA20
Version 2.0 en, 12/2021
This symbol in combination with the signal word “Note” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
This symbol in combination with the signal word “Tip” identifies additional information or
notes that will simplify working with TWAUDiO products on the basis of practical experience.
© by TWAMBO 2021; all rights reserved.
All information contained in this operating manual was correct to the best of our knowledge
at the time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the technical
specifications, dimensions and weights are not granted by TWAMBO.
TWAMBO also shall not assume liability for any secondary damage (property damage and/or
personal injury) nor for the failure to comply with this operating manual!
TWAMBO reserves the right to update this document based on recent developments.
TWAMBO GmbH
Karl-Hofer-Str. 42
14163 Berlin
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
E-Mail: [email protected]
WWW: www.twaudio.de

Operation manual VERA20
4
Content
1. Safety | Intended Use ..................................................................................................... 5
2. Overview ........................................................................................................................ 7
2.1 Components ........................................................................................................... 7
2.2 VERA20 rear rigging ................................................................................................ 8
2.3 Variants - Horn flanges horizontal coverage 80° / 120° ............................................ 8
3. Technical specifications .................................................................................................. 9
3.1 Data Sheet .............................................................................................................. 9
3.2 Connection Diagram................................................................................................ 9
4. Commissioning............................................................................................................. 10
4.1 Setup .................................................................................................................... 10
4.2 Rigging VERA20.................................................................................................... 10
4.3 Exchanging the horn flanges.................................................................................. 11
4.4 Operation .............................................................................................................. 11
4.5 Connecting cables................................................................................................. 12
5. Transport and Storage.................................................................................................. 13
6. CE Conformity Declaration............................................................................................ 14
7. Disposal ....................................................................................................................... 15

Operation manual VERA20
5
1. Safety | Intended Use
The VERA20 loudspeaker was developed for professional use in sound systems. The loudspe-
aker may only be used by trained and qualified personnel.
WARNING
WARNING
WARNING
NOTE
NOTE
Please adhere to the following safety instructions to avoid risks when operating loudspeakers.
Note the operating modes described in this operating manual. Other uses are not permis-
sible.
Damage caused by improper use is not covered by TWAMBO.
Loudspeakers generate an electromagnetic field. Persons with pacemakers are not permit-
ted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can
cause pacemakers to malfunction.
When working with heavy loads exceeding 20 kg (44 lbs.), use suitable aids (dollies, hoisting
slings, etc.). Multiple persons may be required depending on the situation.
Ensure that the units are in a stable position and are firmly attached. A falling loudspeaker can
result in serious personal injury and property damage.
When using and assembling TW AUDiO loudspeakers, only use materials specified by
TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable
safety regulations.
When setting up loudspeakers, ensure that they are not exposed to the following ambient
conditions:
• Direct sunlight
• Humidity
• Jolting
• Dust
Keep away from the immediate vicinity of loudspeakers that are operated at high sound pres-
sure levels. These loudspeaker systems are capable of endangering your health. Sound levels
beginning as low as approximately 90dBSPL can lead to long-term hearing impairment.
Avoid:
• Feedback
• Distorted signals (clipping) and
• Peaks resulting from switching on devices, plugging in devices or unplugging devices during
operation.
Such signals can lead to loudspeaker overload and ultimately to loudspeaker failure.

Operation manual VERA20
6
WARNING
NOTE
NOTE
Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over-
loads may cause a fire and result in serious personal injury and property damage.
Note that TWAMBO does not provide a warranty for damage that can be attributed to this type
of overload and therefore cannot be held liable for any secondary damage.
A permanent magnetic field is present in the immediate vicinity of loudspeakers. Ensure that
objects which react sensitively to magnetic fields are not located in the immediate vicinity of
the loudspeaker. In particular, this applies to magnetic storage media, magnetic stripe cards
such as debit cards and CRT displays. A distance of approximately one meter is sufficient to
avoid damage.
Check loudspeakers and accessory parts regularly for visible wear. This is essential to ensure
continuing fault-free operation. Worn parts should be replaced immediately. Spare parts are
available from TWAUDiO.

Operation manual VERA20
7
2. Overview
2.1 Components
1. Front grill
2. Multiplex enclosure - Polyurea surface finish
3. Carrying handles (rear, left and right)
4. Rigging track (2 pieces)
5. Locking pins (2 pieces)
6. Carrying handles (left and right)
7. 10“ cone driver
8. Horn flanges (2 pieces)
9. Waveguide with 1,4“ compression driver
10. Type label
11. VERA20 rear rigging (see chapter 2.2)
12. Connection panel with one SpeakON®socket each, top and bottom
Figure 2.1 - Overview
10 11 12 35
1 2
46 5
3
77
9
8 8
6

Operation manual VERA20
8
2.2 VERA20 rear rigging
Figure 2.2 - rear rigging
1. Mounting plate with rails
2. left slider with locking pin
3. Main carrier with hook and spring mechanism
4. right slider with locking pin
5. Quick-locking pin
The VERA20 loudspeaker can optionally be equipped with 80° or 120° horn flanges. The angle
specification refers to horizontal coverage. Check the rear rigging to identify the VERA20 vari-
ant.
The factory installed horn flange type is marked on the VERA20’s rear rigging. Depending on
your application, it may be advantageous to change the horn flange. In this case, the identifi-
cation mark on the rear rigging should also be changed. The factory marking can be removed
using acetone.
2.3 Variants - Horn flanges horizontal coverage 80° / 120°
TIP
Figure 2.3 - VERA20 horn flange variants
34
2
51
80°
120°

Operation manual VERA20
9
3. Technical specifications
3.1 Data Sheet
Variant
VERA20-80 VERA20-120
Drivers 2x 10“ LF / 1x 1,4“ HF
Frequency response 67 - 18000 Hz
Power handling (program/Peak) 1000 / 2000 W
Impedance 8 Ω
Coverage (h x v) 80° x 12° 120° x 12°
Max. SPL / 1m 138 dB
Dimensions (H x B x T) 280 x 600 x 400 mm (11.02 x 23.62 x 15.75 in-
ches)
Weight 24,0 kg (13.67 lbs]
Surface Polyurea coating
3.2 Connection Diagram
Figure 3.2 - Connection diagram

Operation manual VERA20
10
4.1 Setup
The VERA20 loudspeaker has been designed for horizontal operation in stacked and flown
vertical arrays. TW AUDiO provides a wide range of accessories to securely attach the loudspe-
aker.
NOTE
WARNING
4. Commissioning
WARNING
4.2 Rigging VERA20
VERA20 series line arrays can include VERA20 and/or VERAS32 loudspeakers.
WARNING
NOTE
Note that the VERA20 loudspeakers are mechanically connected. This is done via the quick
and easy 3-point rigging.
Also note that the VERA S32 loudspeakers are mechanically connected via 4-point rigging.
Please refer to the VERARF600, SFV20 and GSP20 manuals for operating modes and set-up
options.
EASE Focus simulation software can be used to plan VERA20 line arrays. EASEFocus is avai-
lable as a free download from the TW AUDiO website at www.twaudio.com.
TIP
Make sure that all system structures are located on a firm, level surface and that the surface
can bear the total weight!
Make sure the speakers are securely fastened to prevent personal injury and property damage.
Secure stacked loudspeakers properly so that they can be tipped by 10° in any direction
without toppling.
TW AUDiO recommends using only the accessories specified by TWAUDiO for securing and
mounting loudspeakers.

Operation manual VERA20
11
4.3 Exchanging the horn flanges
Depending on the product version, the loudspeaker is shipped with either 80° or 120° horn
flanges (see chapter 2.2) installed. For applications that require a different horizontal coverage,
it may be advantageous to change the horn flanges. To do so, proceed as follows.
1. Place the VERA20 loudspeaker on its back, with the speaker grille facing up. The rear
rigging lever must be opened. Make sure to place the speaker on a clean, non-slip-
pery surface. To secure the speaker against lifting and slipping, ask a second person for
assistance.
2. To remove the speaker grille a TX25 Torx wrench is required. Use it to remove the four
mounting screws on the left and right side of the speaker enclosure.
3. Loosen the two screws on each horn flange.
4. Carefully pull the horn flanges upwards.
5. Carefully insert the new horn flanges. Screw them to the enclosure.
6. Reattach the front grill and screw it tight.
7. Change the marking of the installed horn flanges on the rear rigging.
NOTE Take care not to damage the chassis with the screws.
4.4 Operation
Operation of the VERA20 loudspeaker requires a DSP-Controller. For this purpose, only pre-
sets developed by TW AUDiO are recommended. The TW AUDiO system racks are ideally
suited for this purpose.
Please note the technical data in section 3.1 on page 9.
NOTE
NOTE
Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that
doesn’t meet the specifications can destroy the loudspeaker.
Before connecting the loudspeaker to the amplifier, ensure that the right preset has been
loaded.
Using a wrong, out dated or a preset not provided by TWAUDiO can lead to destruction of
the speaker.

Operation manual VERA20
12
4.5 Connecting cables
The pin connections of the VERA20 loudspeaker can be found in section 3.2 (“Connection dia-
gram”) on page 9.
The internal wiring of the VERA20 loudspeaker allows for parallel connection of multiple
loudspeaker units.
NOTE
To create a cable connection with an amplifier rack from TW AUDiO, proceed as follows.
Ensure that the cable cross sectional area is sufficient (at least 1.5 mm²) to avoid power losses.
TW AUDiO recommends using the loudspeaker cables available from TW AUDiO.
When connecting the cables to the loudspeaker, ensure that polarity (+/-) and pin assignment
(1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s
sound characteristics and may damage the driver.
Please note that parallel connections will decrease the total impedance of your loudspeaker
configuration.
The total impedance and the resulting power of the speaker configuration must match the
output power of the amplifier.

Operation manual VERA20
13
5. Transport and Storage
To enable a single person to transport up to six VERA20 loudspeakers, TW AUDiO recom-
mends using the VERA DLV20.
NOTE
Due to the VERA20 loudspeaker weighing over 20 kg [44 lbs.], two persons are required to
handle and transport the unit.
• VERA DLV20 (dolly)
• CoverV20 (protective cover)
When transporting and storing the unit, it is important to ensure that the surface and front
grill of the loudspeaker are not damaged. Moisture can penetrate through exposed wood
surfaces and cause the wood to swell. A bent or broken front grill will no longer adequately
protect the sensitive speaker membranes.
In addition, appreciable dust deposits may considerably impair the functionality of a loudspe-
aker membrane. For this reason, the loudspeakers should be transported and stored in a
safe, careful, dry and largely dust-free manner.
The following accessory parts for transport and storage are available from TW AUDiO:
The original packaging is unsuitable as permanent storage and transport packaging.

Operation manual VERA20
14
This declaration applies to the following components
• VERA20-80
• VERA20-120
6. CE Conformity Declaration
Copy and translation of the original CE Conformity Declaration:
We hereby declare that the below-referenced components by virtue of their design and
construction, and in the configuration placed on the market by us, satisfy the safety and
health requirements of the applicable EC directives. This declaration becomes invalid in
case of modifications that have not been approved by us.
as well as all model variants based on these, provided that they correspond to the original
factory models and have not been technically modified in any way.
Applicable directives:
• 2001/95/EG
• 2011/65/EU
Applicable national standards and technical specifications:
• DIN EN 18 800
• DIN EN ISO 12 100
• DGUV Vorschrift 17 und 18
• EN 50581: 2013-02
Berlin, Germany, January 1st, 2021
Bernhard Wüstner

Operation manual VERA20
15
7. Disposal
It is prohibited to dispose of used electrical equipment with household refuse.
All TWAMBOGmbH products are so-called B2B-products. This means that they are sold by
a commercial business to a commercial business. TWAMBO products that bear the trash can
symbol shown here may only be disposed of by TWAMBO.
The loudspeaker owner is legally responsible for proper disposal of used devices that do not
bear this symbol. This pertains to all products delivered prior to March 29, 2010. Nevertheless,
TWAMBO will also be happy to assist you in this case.
If you have any question regarding the disposal of used devices, please contact us under the
following telephone number:
+49 (0) 71 41 - 48 89 89 0
Thus, TWAMBO is in strict compliance with the Waste Electrical and Electronic Equipment
Directive (2012/19/EU) for the protection of our environment.
TWAMBO is registered under the following WEEE-reg.-no. with the German National Register
EAR as a B2B-manufacturer and distributor of electrical devices:
DE93295191
In countries outside of the European Union, comply with local regulations.

Operation manual VERA20
16
TWAMBO GmbH
Karl-Hofer-Str. 42
14163 Berlin
Germany
Phone: + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
E-Mail: [email protected]
WWW: www.twaudio.de
