TYAN S7056 User manual

http://www.tyan.com
1
S7056/S7056-HE
Version 1.1b
Copyright
Copyright © 2013 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
TYAN®is a trademark of MiTAC International Corporation.
Intel®is a trademark of Intel®Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2

http://www.tyan.com
3
Contents
Before you begin…....................................................................................4
Chapter 1: Instruction ................................................................................ 5
1.1 Congratulations ................................................................................5
1.2 Hardware Specifications..................................................................5
1.3 Software Specifications..................................................................27
Chapter 2: Board Installation................................................................... 29
2.1 Board Image...................................................................................30
2.2 Block Diagram................................................................................32
2.3 Board Parts, Jumpers and Connectors..........................................33
2.4 Installing the Processor and Heatsink............................................46
2.5 Thermal Interface Material .............................................................49
2.6 Tips on Installing Motherboard in Chassis .....................................50
2.7 Installing the Memory .....................................................................52
2.8 Attaching Drive Cables...................................................................60
2.9 Installing Add-In Cards...................................................................61
2.10 Connecting External Devices.........................................................62
2.11 Installing the Power Supply............................................................63
2.12 Finishing Up....................................................................................64
Chapter 3: BIOS Setup ............................................................................. 65
3.1 About the BIOS...............................................................................65
3.2 Main Menu......................................................................................67
3.3 Advanced Menu..............................................................................68
3.4 Chipset Menu .................................................................................96
3.5 Boot ..............................................................................................106
3.6 Security.........................................................................................111
3.7 Server Management.....................................................................112
3.8 Event Logs....................................................................................115
3.9 Save & Exit...................................................................................116
Chapter 4: Diagnostics........................................................................... 119
4.1 Flash Utility...................................................................................119
4.2 AMIBIOS Post Code (Aptio).........................................................120
Appendix I: Fan and Temp Sensors .....................................................127
Appendix II: RAID OPROM Configuration ............................................131
Glossary................................................................................................... 133
Technical Support ..................................................................................139

http://www.tyan.com
4
Before you begin…
Check the box contents!
The retail motherboard package should contain the following:
1 x S7056 Motherboard
2 x SATA Single Cable
1 x Mini-SAS Cable
1 x IO shielding
1 x S7056 Quick Installation Guide
1 x TYAN®Driver CD
IMPORTANT NOTE:
Sales samples may not come with any of the accessories listed above.
If you have ordered a sales sample and you are missing any of the above items,
please contact your sales representative to help order accessories.
NOTE: The SATA Single Cables, Mini-SAS Cable and IO Shielding are not included
in bulk packing.

http://www.tyan.com
5
Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN® S7056 motherboard, based on the
Intel®Patsburg chipset. The S7056 is designed to support dual Intel®Xeon E5-
2600/E5-2600 v2 Series processors, and up to 512GB RDIMM, 128GB UDIMM
and 512GB LRDIMM DDR3 memory. Leveraging advanced technology from
Intel®, the S7056 is capable of offering scalable 32 and 64-bit computing, high-
bandwidth memory design, and lightning-fast PCI-E bus implementation.
The S7056 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S7056 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN® website at http://www.tyan.com. There you can
find all the information on all TYAN®products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S7056 (S7056GM3NR)
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 95W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600 /
1866 *Speed 1866 only for 1 slot per channel 1.5V
(Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V

http://www.tyan.com
6
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (3) GbE ports
LAN Controller Intel 82574L / Intel I350BT2
Connector (10) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (8) 3.0 Gb/s (2 x mini-SAS
connector)
Storage SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Graphic
Chipset Aspeed AST2300
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
VGA (1) D-Sub 15-pin VGA port
RJ-45 (3) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (2) SATA-III connectors + (2) Mini-SAS (4-in-1)
connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3

http://www.tyan.com
7
/
PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Motherboard (1) S7056 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Package
Contains
Cable SATA (2) SATA signal cables / (1) Mini-SAS cable to 4 x
SATA cables

http://www.tyan.com
8
TYAN S7056 (S7056WGM3NR)
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 95W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602 with upgrade ROM module
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600 /
1866 *Speed 1866 only for 1 slot per channel 1.5V
(Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (3) GbE ports
LAN Controller Intel 82574L / Intel I350BT2
Connector (8) SAS
Controller Intel C602 with TRK-5 upgrade ROM module
Speed 3.0 Gb/s (mini-SAS connector)
SAS
RAID RAID 0/1/10 (Intel Integrated RAID upgrade ROM 5)
Connector (6) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (mini-SAS
connector)
Storage
SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Graphic
Chipset Aspeed AST2300

http://www.tyan.com
9
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (3) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (1) Mini-SAS connector & (2) SATA-III connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/
PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Motherboard (1) S7056 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
Package
Contains
I/O Shield (1) I/O Shield

http://www.tyan.com
10
Cable SATA (2) SATA signal cables / (1) Mini-SAS cable to 4 x
SATA cables

http://www.tyan.com
11
TYAN S7056 (S7056WGM3NR-2T)
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 95W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602 with upgrade ROM module
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600
/ 1866 *Speed 1866 only for 1 slot per channel
1.5V (Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (1) GbE port, (2) 10 GbE ports
LAN Controller Intel 82574L / Intel X540-AT2
Connector (8) SAS
Controller Intel C602 with TRK-5 upgrade ROM module
Speed 3.0 Gb/s (mini-SAS connector)
SAS
RAID RAID 0/1/10 (Intel Integrated RAID upgrade ROM
5)
Connector (6) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (mini-SAS
connector)
Storage
SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Graphic
Resolution Up to 1920x1200

http://www.tyan.com
12
Chipset Aspeed AST2300
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (1) GbE port / (2) 10Gbe Ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (1) Mini-SAS connector & (2) SATA-III connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset &
power supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring / Auto-configurable of hard disk
types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating
System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Package Motherboard (1) S7056 Motherboard

http://www.tyan.com
13
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Contains
Cable SATA (2) SATA signal cables / (1) Mini-SAS cable to 4 x
SATA cables

http://www.tyan.com
14
TYAN S7056 (S7056WGM3NR5 [BTO])
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 95W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602 with upgrade ROM module
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600 /
1866 *Speed 1866 only for 1 slot per channel 1.5V
(Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (3) GbE ports
LAN Controller Intel 82574L / Intel I350BT2
Connector (8) SAS
Controller Intel C602 with TRK-6 upgrade ROM module
Speed 3.0 Gb/s (mini-SAS connector)
SAS
RAID RAID 0/1/10/5 (Intel Integrated RAID upgrade ROM
6)
Connector (6) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (mini-SAS
connector)
Storage
SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Graphic
Chipset Aspeed AST2300

http://www.tyan.com
15
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (3) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (1) Mini-SAS connector & (2) SATA-III connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/
PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Motherboard (1) S7056 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
Package
Contains
I/O Shield (1) I/O Shield

http://www.tyan.com
16
Cable SATA (2) SATA signal cables / (1) Mini-SAS cable to 4 x
SATA cables

http://www.tyan.com
17
TYAN S7056 (S7056GM3NR-HE)
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 150W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600 /
1866 *Speed 1866 only for 1 slot per channel 1.5V
(Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (3) GbE ports
LAN Controller Intel 82574L / Intel I350BT2
Connector (10) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (8) 3.0 Gb/s (2 x mini-SAS
connector)
Storage SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Graphic
Chipset Aspeed AST2300
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
VGA (1) D-Sub 15-pin VGA port
Input /Output
RJ-45 (3) GbE ports

http://www.tyan.com
18
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
SATA (2) SATA-III connectors + (2) Mini-SAS (4-in-1)
connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/
PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Motherboard (1) S7056 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Package
Contains
Cable SATA (2) SATA signal cables / (1) Mini-SAS cable to 4 x
SATA cables

http://www.tyan.com
19
TYAN S7056 (S7056WGM3NR-HE)
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 Series
Socket Type / Q’ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 150W
Processor
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602 with upgrade ROM module
Supported DIMM
Qty (8)+(8) DIMM slots
DIMM Type / Speed UDIMM/RDIMM/LRDIMM ECC 1066 / 1333 / 1600 /
1866 *Speed 1866 only for 1 slot per channel 1.5V
(Blue color DIMM slot )
Capacity up to 128GB UDIMM / 512GB RDIMM / 512GB
LRDIMM
Memory channel 4 Channels per CPU / Support 2 R/LR-DIMMs or 2
UDIMMs per channel
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) sets of the following expansion combination: (1)
PCI-E x16 slot in-lined with / (1) PCI-E x4 slot
(routed to PCI-E x8 bus) recommended to use
TYAN riser card
Expansion Slots
Recommended
TYAN Riser Card M7056-L24-3F, PCI-E x16 2U riser card (left) /
M7056-R24-3F, PCI-E x16 2U riser card (right)
Recommended
Barebone /
Chassis
2U Barebone GN70-B7056
Port Q’ty (3) GbE ports
LAN Controller Intel 82574L / Intel I350BT2
Connector (8) SAS
Controller Intel C602 with TRK-5 upgrade ROM module
Speed 3.0 Gb/s (mini-SAS connector)
SAS
RAID RAID 0/1/10 (Intel Integrated RAID upgrade ROM 5)
Connector (6) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (mini-SAS
connector)
Storage
SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Graphic
Chipset Aspeed AST2300

http://www.tyan.com
20
USB (7) USB2.0 ports (2 at rear, 4 via cable, 1 type A
onboard)
COM (1) header / (1) port (rear)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (3) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / SSI
EEB spec. 2008
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (1) Mini-SAS connector & (2) SATA-III connectors
Chipset Nuvoton 83773G
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
Others Watchdog timer support
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
Server
Management
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s
MAC interface
Brand / ROM size AMI / 8MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/
PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor EATX
Physical
Dimension Board Dimension 12”x13” (305x330mm)
Operating System OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6
Compliant Yes
Motherboard (1) S7056 Motherboard
Manual (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
Package
Contains
I/O Shield (1) I/O Shield
This manual suits for next models
1
Table of contents
Other TYAN Motherboard manuals

TYAN
TYAN S5549 User manual

TYAN
TYAN TITAN TURBO AT User manual

TYAN
TYAN 1.00 User manual

TYAN
TYAN Thunder HEsl S2567 User manual

TYAN
TYAN Tomcat i945GM S3095 User manual

TYAN
TYAN TEMPEST I5000PX User manual

TYAN
TYAN Trinity ATX Motherboard Tyan S1598 User manual

TYAN
TYAN TOMCAT I845 User manual

TYAN
TYAN S8036 User manual

TYAN
TYAN TOMCAT I815EF User manual

TYAN
TYAN TOMCAT I7230B User manual

TYAN
TYAN TAHOE-A ATX User manual

TYAN
TYAN S7055 User manual

TYAN
TYAN TOMCAT I815E User manual

TYAN
TYAN TYAN S1572 ATX User manual

TYAN
TYAN THUNDER K7X User manual

TYAN
TYAN S7063 User manual

TYAN
TYAN THUNDER I7505 User manual

TYAN
TYAN S7105 User manual

TYAN
TYAN TOMCAT H1000S User manual
