FILAC FasTemp*
Thermometer
Where speed and accuracy meet
FILAC FasTemp*
Thermometer
Where speed and accuracy meet

FILAC FasTemp*
Speed or accuracy?
Now be on target with both.
When you are taking a temperature, speed and
accuracy are both critical. You need the quickest
reading possible, but getting it fast doesn’t count if
the temperature is not on target.
With the FILAC FasTemp* Thermometer, you no
longer have to choose, our FasT System allows the
thermometer to “think” on the job like no other
thermometer can. This smart technology allows the
thermometer to target a precise temperature by
enabling it to search for and analyze trends that are
unique to a patient’s individual body site. Accurate
measurement times are as fast as 4 seconds for oral
temperature readings and 10 seconds for axillary
and rectal temperature measurements. Only the
FILAC FasTemp* thermometer takes into account
the patient’s physiological conditions and will report
a reading only when it complies with both ASTM
and CEN standards, a first in the industry. With its
fast PREDICTIVE mode for accurate temperature
measuring and its DIRECT mode for monitoring you
will have the possibility to measure hypothermic
patients as well.
What good is a quick temperature reading if its
accuracy is questionable? Choose the FILAC FasTemp*
Thermometer, where accuracy and speed finally meet.
Direct Mode
FILAC FasTemp* Thermometer normally operates in
fast Predictive mode for accurate temperature
measuring. In certain cases, such as an hypothermic
patient, the thermometer will automatically shift to
Direct (slow) mode and will then act as a temperature
monitor.

Isolation Chambers
Completely separate colour-coded isolation chambers
with individual probes, probe wells and probe cover
holders help reduce the risk of cross-contamination
while facilitating easy change out between two
oral/axillary and rectal temperature modes.
Oversized Backlit LCD
Display with Iconography
Large user-friendly LCD display provides temperature
readings quickly and accurately, day and night, and
features graphic icons for intuitive usage instructions
when language or sight might be a barrier.
Oral/Axillary/Rectal
Temperature Modes
The FILAC FasTemp* Thermometer safely and
efficiently accommodates three different temperature
modes — oral, axillary and rectal — all in one
thermometer.

Stay on target
with FILAC FasTemp*
Fast Temperature Measurement
Accurate measurement times as fast as 4 seconds
for oral temperature readings and 10 seconds for
axillary and rectal temperature measurements.
Self-Calibrating Electronics
Ensures that the thermometer automatically
recalibrates before each use.
Global Iconography
Easy-to-read iconography allows user to use ther-
mometer with precision, confidence, and comfort.
Specifically, it provides non-native English speakers
and users with clear and simple visual temperature
reading instructions.
Probe Covers
The probe cover material protects the probe from
patient handling, biting, bending, and body
solutions. These covers are made for single use only.
When used correctly, these probe covers prevent
cross-contamination.
Biotech OPTIONS SET-UP Mode
The following electronic set-up options can easily be
changed by a qualified biotech technician: Direct
mode, English language icon segments, sounds,
anti-theft system (electronic), back lighting.
Predictive / Direct Mode
The FasTemp thermometer can be used in either
normal or predictive mode allowing the user to
obtain accurate temperatures within 4-10 seconds
(predictive) or within 3-5 minutes in the direct mode
(a turtle icon identifies this mode). This provides the
users with the opportunity to take temperatures with
hypothermic patients as well.
Last Temperature Recall
Stores the last temperature obtained until the next is
taken.
Push Button Probe Cover Removal
Allows the user to discard probe easily without risk
of cross-contamination.
30 Seconds Pulse Timer
Provides a “beep” at 30 seconds to assist pulse
timing.
Temperature Range
The FILAC FasTemp has a 30º C to 43° C
(85° F to 110° F) temperature range.

Why the thinking thermometer
is the better thermometer.
The FILAC FasTemp*Thermometer does not
sacrifice accuracy for speed.
FILAC FasTemp*Action
Display indicates PLACE
PROBE COVER ON animation.
Gives ready “beep.”
Displays patient
temperatures.
Displays final prediction and
beeps.
Clinician Action
Remove probe from probe well.
Place probe cover on probe
and wait for ready “beep”.
Place probe in patient’s
mouth, axilla or rectum.
Wait 4-10 seconds typically
(depending on placement and
patient condition).
FILAC FasTemp*
Advantage
Animation promotes infection
control.
“Beep” indicates that the unit
is checked out and ready to
take a temperature.
Senses patient physiology
by continuously collecting
data and adjusting its data
processing.
“Beep” indicates that the
FILAC FasTemp* quality
metrics (ASTM and CEN)
are met. The temperature
is displayed and saved for
recall.

* FILAC FasTemp is a trademark of Sherwood Services AG.
© 2003 Tyco Healthcare Group LP. All rights reserved. P-TH-FILACFT/GB
07/2003
Wall bracket locking
mechanism
Oral/axillary and rectal
isolation chambers
Probe covers 275 cm oral/axillary and
rectal cord
FILAC FasTemp*Accessories/Probe Covers
FILAC FasTemp*Ordering Information
REF Description Box Quantity
202010 Complete Oral/Axillary System, including Electronic Thermometer,
11 Language Operating Manual, Blue Oral/Axillary Isolation Chamber,
Blue probe with 120 cm Cord, Wall Mountable Base, Mounting Hardware 1
202008 Monitor only 1
202020 Probe covers 5,000/Case
202026 Blue Oral/Axillary Probe with 120 cm Cord 1
202027 Blue Oral/Axillary Probe with 275 cm Cord 1
202028 Blue Oral/Axillary Isolation Chamber 1
202038 Red Rectal Isolation Chamber, Red Rectal Probe with 120 cm Cord,
Wall Mountable Base, Mounting Hardware 1
202036 Red Rectal Isolation Chamber 1
202034 Red Rectal Probe with 120 cm Cord 1
202037 Red Rectal Probe with 275 cm Cord 1
202042 Wall Mountable Base 1
202057 Rolling Stand with Locking Mechanism and Bracket 1
202058 Wall Bracket Locking Mechanism 1
FILAC FasTemp*Specifications
• Separate colour coded isolation chambers
• Self-calibrating
• 4 - 10 second reading (oral, axillary, rectal)
• Predictive/Direct mode
• Large LCD display
• Biotech set up menu
• ± 0.1° C (under normal operating conditions)
• Global iconography
• Celsius/Fahrenheit button
• Last temperature recall
• Electronic anti-theft system
• Temperature range
(30° C – 43° C/85° F – 110° F)
• Ergonomic design and lightweight
(275 grams without base)
• 30 second pulse timer
• Push button probe cover removal
• Battery life indicator
• 9 volt alkaline battery included
• One year warranty
• Temperature out-of-range warning
• Auto on/off function
• ISO 9001 certified manufacturer
• ASTM and CEN compliance
• Electronic anti-theft system
• Action “beep”
• Mountable base (with optional mechanical anti-
theft system) ISO 9001 certified manufacturer
