Tyent UCE-E13T User manual

MADE IN KOREA
www.tyentusa.com
The user is responsible for improper use of the
products such as use in any manner for which the
product was not originally intended and any
damage that may occur from such improper use.
This product is subject to changes that enhance
its performance without prior notification.
How to Measure pH: Place approximately 2 table-
spoons (30mL) of test water in a container and add 4
drops of pH reagent. Then, mix well and check the
color of the water with the pH chart above (The color
of the water will change according to its pH.)
·
·
·
If the power cord is damaged, it must be replaced by
the manufacturer, or a similarly qualified Tyent repair
person in order to avoid a hazard.
This appliance is not intended for use by persons
(including children) with reduced physical sensory or
mental capabilities or lack of experience and knowl-
edge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
4.02.5 11.5
pH Chart
WATER FOR WELLNESS
This is Home appliance product.
This product is intended for domestic use only.
Keep this User Manual handy for easy reference.
Carefully read this User Manual, particularly “all safety warnings.”
UNDER
COUNTER
EXTREME
BLACK
LABEL
W A T E R I O N I Z E R
User’s Manual

To Our Valued Customers Table of contents
Under Counter Extreme
23
Table of contents
To Our Valued Customers
•
•
•
Intended Use
This device creates functional alkaline, ionized water and water with
molecular hydrogen. It changes the properties of regular tap water
through the use of electrolysis.
Note the following changes that normal tap water undergoes via
this process:
• An increase or decrease in pH level
• Creation of negatively charged hydrogen ions (antioxidants)
• An increase in molecular hydrogen
• Purification through filtration
To Our Valued Customers
Table of Contents
Before Usage
Safety Precautions and Warnings
Installation Diagram
Dispenser Overview
Ionizer Overview
Product Features
Package Contents
Under-Sink Installation
Dispenser Installation
Ionizer Installation
Customer Serviceable Parts
How to Change the Filters
How to Reset the Filter Counters
How to use Cleaning Filter
Touch Screen Operation
Unit Usage
pH Level Adjustment
System Setup Method
Selecting Voice on/off
Cleaning Function
Eco Mode
Turbo Function
Usage Recommendations
Temperature Sensor
Unit Specifications
Troubleshooting
Product Warranty
2
3
4
6
11
12
13
14
18
19
20
22
23
24
25
26
27
31
33
34
40
41
42
43
44
46
47
48
50
Thank you for purchasing the UCE series Water Ionizer.
Please read all safety warnings and this User’s Manual carefully
before using this product to ensure proper product usage. (Keep
themanual handy for easy reference.)
We are not responsible for any accidents and/or malfunctions due to
the improper use of this machine.
Please keep the manual and warranty card in a safe place, so that it’s
easily accessible when you need it.
Please refer to this manual often when you have questions during
usage or when troubleshooting this unit.

Before Usage
Under Counter Extreme
45
Before Usage Safety Precautions and Warnings
Safety precautions are provided for the safe and proper use of this unit and can
prevent danger, bodily harm and/or possible damage due to misuse. Please
make sure you are familiar with all the safety precautions and warnings associ-
ated with this unit.
Do not drink functional water with medication. When taking medication, use
“clean H2O” filtered water thirty minutes prior to taking medication as well as
with medication. You may resume drinking functional water thirty minutes after
taking medication.
Always consult your primary care physician before drinking functional water.
Start off by drinking Level 1 alkaline water for the first four weeks. Starting out
slow is essential because water at higher pH levels is very healthy and cleansing,
and your body needs time to adjust during the detoxification period.
If you notice any negative effects from drinking functional water, stop drinking
the functional water immediately and consult your primary care physician
about changes in your body’s pH level.
If you are currently under the care of a primary care physician for an existing
condition, consult your primary care physician about how changes in pH and
other characteristics of functional water could affect your medical condition.
If you suffer from gastric anacidity, kidney failure or potassium excretion, you
should not drink functional water.
DANGER (Red Warning Sign) indicates an imminent hazard
that could result in serious injury or death. If you see this sign,
stop using this unit immediately.
WARNING (Orange Warning Sign) indicates a potential hazard
that could result in significant bodily harm or damage to the unit. If
you see this sign, stop the use of this unit.
ATTENTION (Yellow Warning Sign) indicates a potential hazard
that could result in minor bodily harm or damage to the unit.
If using groundwater, make sure the water meets drinking water
compliance standards before installation. If not, a pre-filter may be
required. (source water quality greatly affects pH values and filter
performance)
DO NOT use extremely hard water, or water that contains a lot of
sediment, or that has very high TDS level without first consulting
Tyent USA in orfer to determine if a pre-filter is needed.
Use only source water approved as drinking water
by an authorized organization (i.e. tap water).
DO NOT use excessively hard water or saltwater. (may cause
malfunctions and/or shorten the product life)
①
②
③
④
⑤
Verify the pH levels of the functional water dispensed from this unit on a monthly
basis to ensure proper function. This can be done with the supplied reagent
drops and a pH color chart.
When switching from one pH to another, it is good practice to let the water run
for 10-15 seconds before using.
It is common to drink half your body weight in ounces. For example, if you weigh
180 pounds, it may be wise to drink 90 ounces every day of water per day. This
especially applies after you have given your body some time to adjust to the
new pH level.
The recommended drinking level for functional water is 9.5 pH (+-0.3). It is not
recommended to drink functional water above a pH of 10.
If you wish to store functional water, use a glass or other non-leaching material
with an airtight lid and store it in the refrigerator. Functional water will begin to
weaken immediately and will lose most of its benefits after 3 days.
Never run hot water through this unit.
Never drink acidic or turbo water.
⑥
⑦
⑧
⑨
⑩
⑪
⑫

Under Counter Extreme
67
Safety Precautions and Warnings Safety Precautions and Warnings
Safety Precautions and Warnings
To reduce the risk of electric shock, do not remove
the cover; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel.
Removing the cover will void the warranty.
Do not place this unit near heat sources.
Do not place this unit on an uneven surface.
Do not drop or use excessive force on this unit.
Do not connect the water line to a hot water
supply. Please use a new hose to connect to
the water line. (Do not reuse an old hose as it
can cause leakage.)
Do not use unfit raw water in accordance with
the standards of the water service act.
Do not use in areas of high humidity and/or
high temperature.
new hose
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.
Regarding the Power Supply
Only use the unit with the correct voltage.
Do not use if the power cord is damaged or in a
loose power outlet.
Never touch the power cord or the power outlet
with wet hands.
Do not forcibly bend, squeeze, damage or
crush the power cord under heavy objects.
Unplug the power cord during general main-
tenance, repair and inspection and while
replacing parts.
Do not use power surge protectors with this
unit. Use unit with its own dedicated power
source.
Installation

Under Counter Extreme
89
Safety Precautions and Warnings Safety Precautions and Warnings
1-2min
1hour
Do not run the water for longer than 1 hour.
If the unit is not used for a few days, let the
water run for 1-2 minutes before drinking
functional water.
Do not place any objects on top of this unit no
matter how small they are.
If water leaks out of the unit (other than the hoses)
or if the unit is standing in a puddle of water, shut
off the water supply, unplug the power cord and
contact qualified service personnel for service.
It is beneficial for the maintenance of the
machine to run a strong acidic level for
5minute cycles twice weekly. This will help to
maintain a clean chamber.
When you use the Water ionizer in areas
with very hard water, please run Acidic
level 3 for a minute every day.
※
Do not use or store pH reagents near flame.
(There is a risk of fire)
Do not poke or scratch the touch pad or LCD
display with sharp objects.
In areas of hard water (where calcium scaling is
present on faucets), notify your service provider
and install a cell safe anti-scale pre-filter to
protect the ionizer from scale build-up.
Do not use alkaline or acidic water in fish bowls
or aquariums. The sudden change in pH could
be harmful or fatal to some marine life.
It is normal for condensation to be present on
the unit during humid summer months. If
condensation persists despite weather condi-
tions, unplug the power cord and refer servicing
to qualified service personnel.
Replace filters every 6 months to optimize the
purification performance of this unit even if the
replacement indicator light isn’t turned on.
Usage
If the unit won't be used for a long time, shut off
the valve and unplug the power cord.
If you hear strange noises, smell a burning odor or
see smoke, unplug the power cord immediately
and call qualified personnel for service.

Under Counter Extreme
10 11
Installation Diagram Safety Precautions and Warnings
Installation Diagram
Dispenser
Rubber packing
Rubber packing
Fixing nut
Alkaline hose
Union connector
Acid hose
MCU data cable
MCU data
connector
Adapter
Cleaning
benzene
thinner
Do not store the unit near chemicals, food,
metals or medication
Do not spray water on the main unit. Do not
clean the unit with chemicals such as benzene
or thinner, which may leak into the unit. If using
a damp cloth, be very careful not to get the
electronic display wet.
Please clean the inside and outside of the
outlet pipe with a soft brush [If you do not clean
it regularly, scale, such as lime components
(Calcium and Magnesium)] may occur.
In areas with high TDS of water, calcium can
remain the tip of the outlet pipe. Please keep it clean.
Storage
If the original packaging is not available, then
store in a cool dry place where the unit won’t be
scratched.
Carefully remove this unit from its packaging.
Keep the original packaging for future storage
and unit transportation. When not in use, store
the unit in its original packaging, without the
plastic bag, in a cool, dry place.
Remove the filters and turn them upside down to
remove the excess water before storing.
Under CounterExtreme
Nozzle
Ionizer
Tap water hose
Source water valve
Cable tie
Danger: Do not use
benzene or thinner!

Under Counter Extreme
12 13
ionizer Overview Dispenser Overview
IOnizer OverviewDispenser Overview
Front View Front View
Rear View Bottom View
Rear View
Jog Dial
Water Outlet Pipe
Drain Pipe
Fixing Nut
①
②
③
④
⑤
Nozzle
Acidic Outlet
Alkaline Outlet
Front cover
Cable Connector
Front Sheet
①
②
③
④
⑤
⑥
Hanging Groove
Rear Case
Power Cord
Water Inflow
①
②
③
④
Door Case
Front Case
⑦
⑧
29.5cm
11.6inch
17.2cm
6.8inch
3.3cm
1.3inch
13.2cm
5.2inch
11cm
4.3inch
16cm
6.3inch
38.2cm
15inch
SINK
5cm
2inch
%
a
10:30
50
%
50
Under CounterExtreme
1
1
4
2
5
3
4
6
7
8
23
Speaker

Under Counter Extreme
14 15
Product Features Product Features
Product Features
GUI [Graphical User Interface]
Jog Dial & Touch with 2 way Operation Compatibility
Offering both Kitchen Space and Ultimate Beauty
A DESIGN MASTERPIECE
FULL TOUCH LCD – TRANSFORMATION AT YOUR FINGERTIP
JOG DIAL & TOUCH
Light and Screen Indicators for Water Discharge Detection
Excellent MP3 Sound Quality with Guided Support
CAREFUL CONSIDERATION FOR THE USER
Upgraded Power Turbo System
Power SMPS Power Supply System
Electrodes with Solid/Mesh Hybrid Plate Technology
MORE POWERFUL SYSTEM ENGINE !
The TYENT Under Counter Extreme Water Ionizer not only attracts
person’s gaze with its well-differentiated appearance, but also
helps to upgrade your kitchen’s interior decoration with a neat
and luxurious expression.
The upgraded Turbo SMPS Plus Power Supply system produces
strong Turbo acidic and strong Turbo alkaline pH levels for many
uses! See Tyent’s USES guide for more information.
Power SMPS Power Supply System provides the maximum
instantaneous output needed to produce the highly stable electric
power required for each phase of electrolysis.
These Platinum-Coated Titanium Plates are made with highly
stable, durable Solid/Mesh Hybrid technology that enhances the
instantaneous electrolysis efficiency.
Changes to the LCD screen and Jog Dial light can be easily
identified by color to check each selected phase.
Operating functions can be further identified by the voice guided
system.
Multiple Languages Supported
Diversified language guide support is available by selecting the
languages featured from across the world.
The Industry’s First Full Touch Screen Panel
The Full Touch Screen Panel System automatically activates the
unit’s operations through a simple touch to the desired icon
displayed on the screen.
Touch LCD Screen with a Clear Picture Tone
A 262,000 Color Touch LCD Display provides diverse information
in true vivid colors for user convenience.
A Graphical User Interface is designed specifically for ease of use
and operation. Communication between the user and ionizer
has never been this simple!
Choose from either the Jog Dial or the Touch Screen Panel
system–both are available with 2 way operation compatibility and
are easy to use at your convenience.
15:00
%
a
10:30
50
%
50
15:00 15:00
15:00

Under Counter Extreme
16 17
Product Features Product Features
Earth-Friendly Technology when in ECO Mode
True energy saving is accomplished with ultra low power
consumption during periods of non-use.
CARE FOR THE ENVIRONMENT
Temperature Sensor Function for Safe Operation
Water Discharge Nozzle with Directional Control
The water discharge direction may be adjusted to many diverse
angles based on user preference.
Automatic Water Discharge Interruption Function
In order to prevent the overflow of water in case of user
negligence, the water discharge will automatically stop
after 15 minutes of use.
(*TURBO: 5 minutes)
Automatic Electrolysis Tank Cleaning Function
The interior of the Electrolysis Tank is automatically cleaned on a
regular basis, ensuring stable electrolysis operating conditions.
Automatic Memory Function
The last function used by the user is automatically memorized and
displayed on the Standby Screen for fast and convenient operation.
Water Purification Through a Clean Process
FRESH, PURIFIED WATER WITH HEALTHY MINERALS IS A MUST!
Customizable Settings System
Super Simple Filter Replacement System
pH Control Function
Respective alkali, acid & turbo phases can be easily controlled
by the user.
Self Diagnosis Function
When the condition of the source water is not suitable, the water
discharge is automatically suspended, displaying a Warning Sign
on the screen.
Filter Usage Indication and Replacement Time Guide
SELF MAINTENANCE MADE EASY – FROM INSTALLATION TO POST-SERVICE
If the temperature of the source water exceeds 95℉(35℃) then
water will stop flowing and a warning message will appear on the
screen. Perfect, seamless elimination of foreign substances including
residual chlorine, organic & inorganic compounds through the
filtering process using functional UF and ∏ Ceramic materials,
enhancing the alkali water producing condition.
The level of filter usage can be identified through the LCD Screen
on a real time basis. The recommended replacement time is
automatically displayed on the screen with a voice guide.
A simple filter replacement system along with a one-touch Filter
Usage Initialization Setting System makes filter management easy
for anyone.
For your convenience. the LCD screen allows you to easily
customize all of your favorite settings.
under counter extreme

Under Counter Extreme
18 19
Under-Sink Installation Package Contents
Package Contents
Ionizer
Rubber Packing O-Rings
(2EA)
Wrench
pH Testing
Solution Bottle
(Reagent Drops)
User’s Manual
Alkaline hose
(White)
Acid hose
(Orange)
Tap Water
hose
&
Water Outlet Pipe
fixing nut
M
A
N
U
A
L
Stem Elbows
Dispenser
Cable Tie
T-Adapter
Picture of components can be different from the real ones, and some items may be
changed according to advancements in technology.
Under-Sink Installation
T-Adapter
Hose
Cool
water
Do not turn on the main water supply until all hoses are properly
installed to the unit.
The unit and components are subject to change without prior notifi-
cation in order to enhance performance.
Shut off both the hot and the cold water main supply at the pipe under the sink.
Locate the cold water supply line valve.
Disconnect the faucet’s cold water supply line from the main cold water
pipe. Use a towel to catch the small amount of water that may come from
the faucet supply line.
When connecting the T-Adapter to the cold water pipe, be sure to use
plumber’s tape or teflon tape (not included) to prevent leaks.
Reconnect the faucet’s cold water supply line to the T-Adapter (now
secured to the main cold water pipe).
Be sure all connections are secure, but do not overtighten them.
1.
2.
3.
4.
5.
6.
※
※
Under Counter Extreme

Under Counter Extreme
20 21
Dispenser Installation
Place the assembled dispenser into the
drilled hole.
Insert one of the provided rubber O-Rings
in the assembled dispenser.
Tighten the fixing nut underneath the sink.
(do not over-tighten)
Insert the second rubber O-ring in the
assembled dispenser located underneath
the sink.
32mm
Drain Pipe
Water Outlet Pipe
Dispenser Installation
First, unscrew the large nut from the
bottom of the dispenser.
1
Press the outflow pipes into the holes of
the dispenser.
※upper hole: water outlet pipe
-152mm (6inches)
※lower hole : drain pipe
-102mm (4inches)
Connect each hose from the dispenser to
a union connector. Connect each hose
from the ionizer to the union connector.
When you connect the hoses, please
match the hoses by color:
i.e., orange–orange, white–white
If your tower has hoses that are red and
clear instead of orange and white, then
connect the red hose to the orange hose
and the clear hose to the white hose.
from Ionizer
from Dispenser
Use a 32mm(1 / inch) drill bit to drill
a hole.
14
Dispenser Installation
①
⑤
⑥
⑧
⑦
②
③
④
※

Under Counter Extreme
22 23
Customer Serviceable Parts Ionizer Installation
※INTRO Screen appears only when Initial
Power is supplied.
Connect the hose from the tap water
inlet to the cold water supply T-adapter.
Connect the Faucet MCU data cable to
the cable connector.
Connect Alkaline Hose and Acidic Hose
to the Nozzle on the top of the water
ionizer body.
Be sure to connect the hose correctly
as indicated on the Nozzle.
Ionizer Installation
Plug in the power cord and turn on the unit.
1st Filter
2nd Filter
Customer Serviceable Parts
Primary Filter: 1st Filter
ATTENTION: If you do not use the TYENT original filter or parts for replacement, it will
cause product malfunction, and it will void your warranty.
The life of the filter can vary greatly due to use, water pressure, water quality and the
changing of the seasons. Filters may need to be replaced sooner than the scheduled time
due to these reasons, and you may notice reduced water quality or declining water taste.
Recommended filter replacement cycle:
(Every 6 months )
Removes harmful chemicals like chlorine,
compounds such as agrichemicals and
detergents, large suspended matters like rust
and sediments as well as other volatile organic
compounds through an efficient activated
absorption method. It also eliminates bad
smells and any remaining dissolved chlorine.
Secondary Filter: 2nd Filter
Recommended filter replacement cycle:
(Every 6 months )
Fine artificial film filters contaminated materials
including ordinary bacteria while maintaining
essential minerals in the water.
*If you do not use TYENT original filters, the following problems will occur:
- Your warranty will be voided.
- It may cause product malfunction.
- The life of the product is shortened.
- It may cause product leakage.
- Filter performance is significantly reduced.
①
②
③
④
⑤
tap water inlet
acidic
hose
alkaline
hose
Connect the hose from the inflow hole to
the cold water supply at the under-sink
T-Adapter. Make sure all hose connections
are firmly seated in the correct holes,
both on the unit and at the water supply.
※
MCU data cable 연결 전 cable
connector에 결합되어 있는
보호마개를 제거한다.
※
Remove

Under Counter Extreme
24 25
How to Reset the Filter Counters How to Change the Filters
How to Change the Filters How to Reset the Filter Counters
Close
Open
Shut off the water supply to the unit
and unplug the power cord. Open the
door in front of the ionizer that’s
located underneath your sink.
Be sure to keep the ionizer upright while
changing the filters. Do not lay the unit
down!
Put the new filter into the right position
by turning it clockwise.
When installing the filter, the connec-
tion bump of the head and the
connection groove on the top of the
filter should be completely combined.
Close the door, plug the power cord
back in and reengage the water
supply.
ⓐ
ⓑ
ⓒ
After initializing the filter, press the H2O button and run purified water for
3 minutes. It is highly recommended that you follow this process in order
to ensure that your machine functions properly.
If you do not initialize the filter after replacing the filter, the correspond-
ing filter change message will continue to operate.
After initializing the reset, press the H2O button and run purified water
for 3 minutes.
①
②
③
④
⑤
: Filter 1 reset
: Filter 2 reset
%
50 % 50
1. First Filter Reset
① Press the bottom part of the LCD screen.
A menu will appear on the LCD screen.
② To initialize, press the F1 RESET icon 2 times.
The Ionizer with speak and say “First Filter” then
“Initializing was performed” and F1 percentage will go
back to 00%.
① Press the bottom part of the LCD screen.
A menu will appear on the LCD screen.
② To initialize, press the F2 RESET icon 2 times.
The Ionizer with speak and say “Second Filter” then
“Initializing was performed” and F2 percentage will go
back to 00%.
2. Second Filter Reset
Remove old filter:
ⓐ Lift the filter that needs to be replaced.
ⓑ Turn the filter counterclockwise until it
loosens.
ⓒ Pull the filter down and remove it.
※
※
※

Under Counter Extreme
26 27
Operation Touch Screen How to use Cleaning Filter
How to use Cleaning Filter Operation Touch Screen
%
50 % 50
Display line of the set
status
Functional water operation
standby mode
Display line of filter usage
( default : 00% )
Alkaline level 1
Alkaline level 2
Alkaline level 3
Purified water
Turbo water
Acidic level 1
Acidic level 2
Acidic level 3
Icon : description
Set up
Voice on
Voice off
Cleaning
Eco mode on
Eco mode off
Filter 1 usage
Filter 2 usage
1
To prevent any trouble caused by scale build-up in the Electrode
and the water ionizer's internal water piping, please perform a
Citric acid cleaning with a Citric acid filter regularly.
User negligence in regards to hard water is not covered under
warranty.
※TYENT WATER IONIZER CLEANING FILTER is a disposable filter.
When cleaning the machine with a TYENT CLEANING FILTER, be
sure to always use the H2O purified water level only, do not use any
other level while cleaning or damage could occur.
If the unit was subject to hard water conditions, an Anti-Scale filter
should be connected. This filter will prevent scale build-up on plates.
Attention
Remove the existing 2nd filter and install the TYENT Cleaning Filter.
※Connection: clockwise / Separation: counter-clockwise
※Caution: Do not remove the 1st filter when performing
a cleaning.
Run the unit on the H2O cycle only for 30seconds and stop.
Leave the machine sit for 3 hours and don’t use.
After 3 hours, remove the TYENT Cleaning Filter and install the 2nd filer.
Run the unit on the H2O cycle for 5 minutes to wash the inside of the
ionizer and the filter with clean water.
Please check the pH levels of the machine. The flow rate and the pH
levels should return to normal. If not, repeat steps ① through ⑤
①
②
③
④
⑤
⑥
2nd
Filter
2nd
Filter
5min
30sec
※
※

Push the bottom part of LCD Screen. MENU Window appears above
the bottom part of the LCD Screen.
Under Counter Extreme
28 29
Operation Touch Screen Operation Touch Screen
15:00
Selected mode
Auto flow stop
time indicator
LCD Display
Working indicator
3
1 2 3 4
1 2
Menu window
1
Set up mode
2
Voice on/off
3
Cleaning
4
Eco mode on/off
1
Filter 1 reset
2
Filter 2 reset
Use the Filter Initialization Icon only after the filters have
been changed.
Push the upper part of LCD Screen. MENU Window appears below
the upper part of LCD Screen.
CAUTION!
2
DISPLAYS COLORS
The backlight of the LCD display will match the pH level color according to the
water pH level being used after the icon is pressed.
Alkaline Water 1
light Blue Color
15:00
Turbo
Red Color
05:00
(Approx 8.0 pH)
Alkaline Water 2
Dark Blue Color
15:00
(Approx 9.0 pH)
Alkaline Water 3
Purple Color
15:00
(Approx 10.0 pH)
Acidic Water 1
Light Yellow Color
15:00
(Approx 5.5 pH)
Acidic Water 2
Light Orange Color
15:00
(Approx 4.5 pH)
Acidic Water 3
15:00
(Approx 3.5 pH)
Light Pink Color
Clean Water
Green Color
15:00
(Approx 7.0 pH)
%
50 % 50
%
50 % 50

Under Counter Extreme
30 31
Unit usage Operation Touch Screen
00:15
CAUTION: Touch Screen Use
Message Display
4
1.
2.
3.
4.
When the screen above appears (or
pops up), the filter needs to be replaced.
When the inflow water is higher than
95 °F (35 °C), this screen will pop up.
The unit will stop the outflow automati-
cally.
Due to the uniqueness of the TOUCH Screen, TOUCH is not recognized if pushed by
more than one finger. Please push with only one finger and be careful of contamination
to the screen that may cause damage to the TOUCH.
Be careful of electrostatic materials near the TOUCH Screen. Stimulation from such
materials may cause damage to the TOUCH.
The screen may not be seen well under direct sunlight.
Do not push the Screen hard with sharp or pointy objects.
This display means that the water outflow
has been stopped prior because of the
suspension of water supplied to the unit.
15:00
14:39
Unit usage
Press the desired icon on the LCD screen
1
The water outflow will start, and the screen will
display the current level and stop time.
2
Press the screen to stop the flow of water.
3
When done, the screen will move to the last icon
that was used and go into stand-by mode.
4
When using the TOUCH Screen
1
%
50 % 50
%
50 % 50
This warning message
will appear when the
unit reaches the auto-
matic cleaning time.
This cleaning message
will appear when the
unit is being cleaned,
which will happen auto
-matically. You can also
clean the unit manually
if desired or needed.
The water level you choose will be
dispensed through the upper water
outlet tube.

%
50 % 50
%
50 % 50
Color of PH Testing of Each Level
Under Counter Extreme
32 33
H Level Adjustment
Unit usage
pH Level Adjustment
H Level Adjustment
p
1
4
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
2
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
3
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
14:39
15:00
Turn the jog dial in either direction
to select the desired function. The
white highlight signals which
function is selected.
When the screen changes to the
selected color, push the center of
the dial to start the water outflow.
Push the center of the dial to stop
the water outflow.
When finished, the screen will move to the last
icon that was used and go into stand-by mode.
When using the JOG DIAL
2
Alkaline Turbo (dark purple)
Acid Turbo (red)
Alkaline Level 1 Approx. 8.0-8.5 pH (light blue)
Alkaline Level 2 Approx. 9.0 pH (light purple)
Alkaline Level 3 Approx. 9.5 pH (purple)
H2O = Approx. 7.0 pH Purified Water (green)
Acid Level 1 Approx. 6.5-5.5 pH (light greenish yellow)
Acid Level 2 Approx. 5.5-4.0 pH (light orange)
Acid Level 3 Approx . 4.5-3.5 pH (dark orange)
※The pH value indicated for each level is based on standardized test results
which have used average tap water.
p
The water level you choose will be
dispensed through the upper water
outlet tube.
When testing the pH, be sure to allow the unit to run for 1 minute (60
seconds) before taking a sample of the water. If you have to adjust the
percentage, after adjusting, run for an additional 1 minute before taking a
new sample. When testing pH values, we like to use 2 tablespoons (30mL)
of the water being produced and 4 drops of the reagent in a clear glass.
The minimum and maximum Turbo waters produced will depend on the
water source quality. Set Turbo at 99% for maximum pH levels. These
levels can range normally as follows:
4.02.5 11.5
pH Chart

Under Counter Extreme
34 35
System Setup Method System Setup Method
2
: ACD pH level up (08%, 09%, 10%...)
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
: ACD pH level down (06%, 05%, 04%...)
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
Acidic H Level Adjustment
p
1
Press the setup icon.
2
Press the top left corner of the screen. MENU
options will fall below upper part of screen.
5
Press“ACIDIC pH”
3
Press desired level.
4
SYSTEM SETUP METHOD
Press“ALKALI pH”
Press desired level.
3
4
1
Press the setup icon.
2
Press the top left corner of the screen. MENU
options will fall below upper part of screen.
ALKALI pH Level Adjustment
1
: ALK pH level up (09%, 10%, 11%...)
5
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
: ALK pH level down (07%, 06%, 05%...)
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
Push RETURN icon for previous menu screen. Voice says: “Applied”
Push RETURN icon again to complete set up.
Voice says: “Set up was completed”
Backcolor
Orange highlight shows the current position on the menu.
A blue highlight means that changes to that setting are possible.
Turn the Jog Dial clockwise (or counter-clockwise) to
select the desired level. Press the PUSH On/Off button
of the jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
If UP/DOWN Icon is pushed, digital number moves by one step.
Turn the Jog Dial clockwise (or counter- clockwise) to
select “ALKALI pH”. Press the PUSH On/Off button of
the jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Push RETURN icon for previous menu screen. Voice says :“Applied”
Push RETURN icon again to complete set up.
Voice says :“Set up was completed”
Backcolor
Orange highlight shows the current position on the menu.
A blue highlight means that changes to that setting are possible.
Turn the Jog Dial clockwise (or counter-clockwise) to
select the desired level. Press the PUSH On/Off button
of the jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
If UP/DOWN Icon is pushed, digital number moves by one step.
Turn the Jog Dial clockwise (or counter- clockwise) to
select “ACIDIC pH”. Press the PUSH On/Off button of
the jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
%
50 % 50
ALK 1ST :
ALK 2ND :
ALK 3RD :
TURBO :
ALKALI pH
ACIDIC pH
LANGUAGE
VOLUME
ALK 1ST :
ALK 2ND :
ALK 3RD :
TURBO :
4
7
10
99
%
%
%
%
4
7
10
99
%
%
%
%
ALKALI pH
ACIDIC pH
LANGUAGE
VOLUME
ACD 1ST :
ACD 2ND:
ACD 3RD:
25
58
99
%
%
%
ACD 1ST :
ACD 2ND:
ACD 3RD:
25
58
99
%
%
%
%
50 % 50

Under Counter Extreme
36 37
System Setup Method System Setup Method
3
Press“VOLUME”
4
Volume Level Adjustment
4
Press desired language.
4
1
Press the setup icon.
2
Press the top left corner of screen. MENU options
will fall below upper part of the screen.
1
Press the setup icon.
2
Press the top left corner of the screen. MENU
options will fall below upper part of screen.
LANGUAGE MODE
3
3
Press“LANGUAGE”
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Turn the Jog Dial clockwise (or counter-clockwise) to
select your desired language.
: Volume up (0-10 step)
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
: Volume down (0-10 step)
or
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Pressing this icon will let you hear the current volume.
Pressing the Push On/Off button on jog dial will let you
hear the current volume.
Push RETURN icon for previous menu screen. Voice says :“Applied”
Push RETURN icon again to complete set up.
Voice says :“Set up was completed”
If UP/DOWN Icon is pushed, digital number moves by one step.
Turn the Jog Dial clockwise (or counter- clockwise) to
select “LANGUAGE”. Press the PUSH On/Off button of
the jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
When using the Jog Dial
Turn the Jog Dial clockwise (or counter- clockwise) to
select “VOLUME”. Press the PUSH On/Off button of the
jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Push RETURN icon for previous menu screen. Voice says :“Applied”
Push RETURN icon again to complete set up.
Voice says :“Set up was completed”
If UP/DOWN Icon is pushed, digital number moves by one step.
ALKALI pH
ACIDIC pH
LANGUAGE
VOLUME
ALKALI pH
ACIDIC pH
LANGUAGE
VOLUME
5
1. ENGLISH
2. SPANISH
3. CHINESE
4. GERMAN
%
50 % 50
%
50 % 50

Under Counter Extreme
38 39
System Setup Method System Setup Method
Press the top left corner of screen. MENU options
will fall below upper part of the screen.
Press the top left corner of screen. MENU options
will fall below upper part of the screen.
※Do not press with sharp or
pointy objects.
3
Press“TIME”
4
5
Adjustment time and date with the arrows :
: for up
Year
Day
Minute
Month
Hour
ⓑ
ⓓ
ⓐ
ⓒ
ⓔ
Time set up is complete.
1
Press the setup icon.
2
1
Press the setup icon.
2
Each time a crosshair appears on
the screen, touch the center of it
with your finger to complete
calibration.
Setting the TIME
5TOUCH 6
3
Press“TOUCH”
4
5
Once calibration is complete, the display will move
to the setting mode automatically.
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
or
: for down
or
Turn the Jog Dial clockwise (or counter- clockwise) to
select “TIME”. Press the PUSH On/Off button of the jog
dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Turn the Jog Dial clockwise (or counter- clockwise) to
select “TOUCH”. Press the PUSH On/Off button of the
jog dial to make your selection.
When using the Jog Dial
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
◀
J
O
G
D
I
A
L
▶
Push RETURN icon for previous menu screen. Voice says :“Applied”
Push RETURN icon again to complete set up.
Voice says :“Set up was completed”
If UP/DOWN Icon is pushed, digital number moves by one step.
Backcolor
Orange highlight shows current position on menu.
A blue highlight means that changes to that setting are possible.
Year
Month
Day
Hour
Min
ACIDIC pH
LANGUAGE
VOLUME
TIME
LANGUAGE
VOLUME
TIME
TOUCH
LANGUAGE
VOLUME
TIME
TOUCH
Year
Month
Day
Hour
Min
2023
10
23
18
30
2023
10
23
18
30
%
50
%
50
%
50
%
50
Runtime calibration.
please touch the screen
at the center of the ring.
(Upper left position)
Press here
(lower right position)
Press here
