U-Boat CLASSICO User manual

CLASSICO
CHRONO

Dear Customer
WE CONGRATULATE YOU ON THE PURCHASE OF THIS U-BOAT WATCH.
IN THIS BOOKLET YOU WILL FIND THE USER INSTRUCTIONS.
WE KINDLY INVITE YOU TO REGISTER YOUR WATCH ON OUR OFFICIAL
WEB SITE IN THE U-CLUB AREA, DEDICATED EXCLUSIVELY TO THE
U-BOAT WATCHES OWNERS, SO TO GET ACCESS TO FURTHER BENEFITS
AND PREVIEWS ON OUR LATEST NEWS, EVENTS AND OFFERS.

24
Representative image.
Some components may be in different positions or not fitted.
WATCH FUNCTIONS
MechanicalAutomaticChrono
MECHANICAL AUTOMATIC CHRONO • CLASSICO
I
7
●CROWN COVER
●CROWN EXTRACTION PUSHER
●CROWN
●CHRONOGRAPH START/STOP PUSHER
●CHRONOGRAPH RESET PUSHER
●HOUR HAND
●MINUTE HAND
●SECONDS HAND
●CHRONOGRAPH SECONDS COUNTER
●CHRONOGRAPH MINUTE COUNTER
●CHRONOGRAPH HOUR COUNTER
●24 HOURS INDICATOR
●DATE
C
F
I
N
O
B
E
H
M
A
D
G
L
●
C
●
B
●
A●
D
●
E
●
F
●
G
●
H
●
I
●
L
●
M
●
N
●
O

24
24
USER INSTRUCTIONS
8
I
CLASSICO • MECHANICAL AUTOMATIC CHRONO MECHANICAL AUTOMATIC CHRONO • CLASSICO
I
9
• POSITION 1
NEUTRAL POSITION
• POSITION 2
FIRST CLICK
• POSITION 3
SECOND CLICK
1. Unscrew the crown cover ●
Ato access the crown ●
C.
POSITION 1
NEUTRAL POSITION
to wind up and start the watch, turn the crown ●
Cclockwise.
POSITION 2
FIRST CLICK
press the pusher ●
Bto bring the crown ●
Cto position 2. Turn the
crown ●
Cclockwise to set the desired date ●
O.
POSITION 3
SECOND CLICK
press the pusher ●
Bagain to bring the crown ●
Cto position 3.
Turn the crown ●
Cclockwise to set the desired time. Consider
the indicator ●
N(24 hours) for the correct click of the date ●
O.
2. Press the crown ●
Call the way down to return it to position 1. Carefully screw
down the crown cover ●
Auntil it locks completely.
●
B
●
B
●
O
●
N
●
N
●
O
POS. 3 POS. 2 POS. 1
●
A
●
C
●
A
●
C

24
*CAUTION IMPORTANT
10
I
CLASSICO • MECHANICAL AUTOMATIC CHRONO MECHANICAL AUTOMATIC CHRONO • CLASSICO
I
11
To avoid misalignment or breakage of the date click wheel when setting the date,
make sure that:
1. When resetting the date ●
Omanually, the hand ●
Fis not positioned between 21
and 03 o'clock (refer to the 24 hours indicator ●
Nif necessary).
2. The day ●
Oindicated by the date window is aligned with the window (see figure
alongside).
3. Bring the crown ●
Cto position 3, position the watch hand ● Fat 3 o'clock, bring the
crown ●
Cto position 2, move the date ●
Oto the desired day paying attention to point 2.
*CAUTION IMPORTANT
INCORRECT POSITION
CORRECT POSITION
3
●
O
●
N
●
F
●
C

24
12
I
CLASSICO • MECHANICAL AUTOMATIC CHRONO MECHANICAL AUTOMATIC CHRONO • CLASSICO
I
13
CHRONOGRAPH FUNCTIONS
Press the (on/off) pusher ●
Dto start the chronograph hand and the hours/minutes
totalizer.
Press the pusher ●
Dagain to stop the chronograph, which will restart by pressing
it again.
After measuring the times, with the chronograph stopped, press the pusher ●
Eto
reset the chronograph and totalizer hands to zero.
●
D
●
E

MECHANICAL AUTOMATIC CHRONO • CLASSICO
I
15
CARE AND MAINTENANCE
• Your watch will keep its performance intact for a long time, with proper care.
• We recommend that you have your watch checked every 3-4 years at one of our
Authorized Dealers/Authorised Service Centres, to carry out ordinary maintenance on
all mechanical parts and water resistance.
• We also recommend contacting an Authorized Dealer/Authorised Service Center to
replace the strap.
• Do not leave the watch in places exposed to extreme temperature changes,
humidity, the sun and strong magnetic fields.
• Make sure the watch is suitable for use in water.
• Always rinse the watch with fresh water after contact with salt water.
AUTOMATIC WATCHES REQUIRE MANUAL WINDING FOLLOWING A LONG PERIOD
OF INACTIVITY.
