U-Line H-6369 User manual

PAGE 1 OF 7 0217 IH-6369
πH-6369, H-6370
DEHUMIDIFIER
1-800-295-5510
uline.com
RECOMMENDED HUMIDITY LEVELS
• Spring/Summer: 35% - 50%
• Fall/Winter: 35% - 40%
WARM AIR EXHAUST IS NORMAL
During operation your dehumidifier will exhaust warm air
from the side of the unit. This is normal operation.
EMPTYING THE BUCKET
The more moisture your dehumidifier removes from
the air, the more often you may have to empty the
bucket (unless you are using the continuous drainage
option). The number of times the bucket will be emptied
depends on the dehumidifier model.
The chart below shows how many pints removed and
how many times to empty bucket in a 24-hour period.
MODEL NO. PINTS REMOVED BUCKETS EMPTIED
H-6369 45 PINTS 6 TIMES
H-6370 70 PINTS 5 TIMES
LESS MOISTURE BEING REMOVED OVER TIME IS
NORMAL
Using a dehumidifier will cause your area to maintain
a more comfortable humidity level. Over time, this
humidity level will become more and more stable. Due
to the stable humidity level in the area, the dehumidifier
will need to remove less and less moisture over time.
Please do not be concerned if the dehumidifier is
removing less moisture from the air or the bucket
is taking longer to fill. This is a direct result of your
dehumidifier creating a more stable humidity level in
your area.
WATER IN THE BUCKET
There might be a small amount of water present in the
bucket before using the dehumidifier for the first time,
which is normal. This is caused by the preliminary testing
done by the factory.
IMPORTANT!
• Always place the unit on a level surface.
• Never use or store gasoline or other flammable
vapor or liquid near this unit unless instructed
by this manual.
• Maintain at least 12-18 inches clearance
space around unit. Do not block or cover air
inlet or outlet grills.
• The unit must be connected to a correctly
grounded power supply.
• Do not start or stop the unit by inserting or
pulling out the power plug.
• Do not use an adapter plug or extension cord.
• Do not use the unit in the immediate
surroundings of a bath, a shower or a
swimming pool.
• Do not insert anything into the air outlet. Do not
obstruct air inlet or outlet grills unless instructed
by this manual.
• Do not let children play near this unit.
• Always inspect the cord for signs of damage
before use. If the power cord is damaged, it
must be replaced by the manufacturer or a
qualified service technician.
• When cleaning the unit, always turn off the unit
and unplug the power cord.
GENERAL INFORMATION

PAGE 2 OF 7 0217 IH-6369
SPECIFICATIONS
CASTER INSTALLATION
CONTROL PANEL
• Noise level is measured at a distance of 3.28 feet
away from the front of the unit.
• Power consumption is measured when the fan runs
at the highest speed setting.
These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
1. Remove casters from the bucket.
2. For H-6369, please check if the casters are under
the lid of the bucket. If so, please remove lid
to access casters, then replace the lid before
operation.
For H-6370, the four casters can be taken out from
the side of the bucket directly.
NOTE: Verify the plastic float on the top of the
bucket is still securely installed and swinging
properly before placing bucket back in the
dehumidifier.
3. Tilt the dehumidifier no more than 45° and forcibly
insert the casters. Make sure the ring around the
caster is flush against the bottom of the dehumidifier.
MODEL NO. H-6369 H-6370
Dehumidifying Capacity 45 Pints per day 70 Pints per day
Power Consumption (Watts) 460 Watts 730 Watts
Air Flow Volume (High/Med/Low) 135/125/105 CFM 205/190/165 CFM
Power Source 115 V/60 Hz 115 V/60 Hz
Rated Current (Amps) 4 A 6.3 A
Sound Pressure Level (High/Med/Low) 53/51/49 dB(A) 53/51/49 dB(A)
Weight 34.2 lbs 47.4 l bs
Dimensions (W x D x H) 13.375" W x 10" D x 19.5" H 15.25" W x 11.25" D x 24.875" H
Energy Star®Yes Yes
Bucket Capacity 8.5 Pints 16.9 Pints
POWER
POWER CLEAN FILTER HIGH
MEDIUM
LOW
SLEEPING SPACE
LIVING SPACE
LOCK BUCKET FULL
TIMER
BASEMENT
FILTER TIMER
FAN SPEED MODE
HUMIDITY %
CONTINUOUS
Power ON
LED Indicator
Clean Filter
LED Indicator
Fan Speed
LED Indicators
MyHome Mode
LED Indicators
Digital
Humidistat
Display
Increase/Decrease Room
Humidity Level
Child-Lock
LED Indicator
Timer
LED Indicator
Bucket Full
LED Indicator

PAGE 3 OF 7 0217 IH-6369
OPERATION
1. When first operating the dehumidifier, run it in
continuous mode for 24 hours.
2. Power On and Off – Press the POWER button once to
manually turn the unit on. Press the POWER button
once more to turn the unit off.
3. Humidity Selection – Press the or buttons
to choose the desired relative humidity in the
room. Each press of the button will change the
desired room humidity by 5%. The room humidity
is selectable from 35%-80% or continuous. The
unit will cycle on and off to maintain the humidity
level chosen on the digital display. If you want the
dehumidifier to operate continuously regardless
of the room humidity, press the MODE button until
you see "CO" on the digital display. This will enable
continuous operation and the "Continuous" indicator
will light up on the control panel.
4. Fan Speed Control – Press the FAN SPEED button
to cycle through the different fan speeds: high,
medium and low. The fan speed can be visually
distinguished by the fan speed indicators on the
control panel.
5. Timer Auto On – To program the unit to automatically
turn on, press the TIMER button when the unit is off.
Press or to increase or decrease the timer in 30
minute increments (.5 hours) up to 10 hours. After 10
hours, each press of the button will increase the
timer in 1 hour increments up to 24 hours. Once the
desired time is reached, the unit will automatically
turn on.
Timer Auto Shut-Off – To program the unit to
automatically turn off, press the TIMER button when
the unit is on. Each press of the or buttons will
change the timer setting in 30 minute increments
(.5 hours) up to 10 hours. After 10 hours, each press of
the or buttons will increase or decrease the timer
in 1 hour increments up to 24 hours. Once the desired
time is over, the unit will automatically power off.
NOTE: Fan will continue to run even when the
compressor is off. This is normal and allows
the unit to circulate air and operate more
efficiently
6. Bucket Full – When the water bucket is full of water,
the unit will automatically shut off, make a beeping
noise and the Bucket Full Indicator will light up. The
dehumidifier will not function until the water bucket
is emptied and placed back inside the unit. The
bucket should be cleaned every few weeks to
prevent the growth of mold, mildew and bacteria.
Use a mild detergent to clean the bucket. Once
clean, completely dry the bucket and place it back
inside the dehumidifier. (See Figure 1)
NOTE: When the bucket is full or removed from
the machine, the compressor will turn off, but
the fan will continue to run for a few minutes. This
is completely normal. The dehumidifier will not
be removing moisture from the air at this time.
NOTE: When removing moisture from the air,
the dehumidifier will exhaust warm air from the
side exhaust vent.
NOTE: Do not place a full bucket on the floor,
because the bottom is uneven.
7. Clean Filter – When the filter needs to be cleaned,
the filter indicator will light up (after 250 hours of use).
Remove the filter from the back of the unit by using
your thumbs to press down on the filter tabs directly
above the filter. (See Figure 2) Clean the filter with
warm, soapy water. Dry thoroughly before replacing
the filter. Once the filter is completely dry, place the
filter back in the unit and press the FILTER button to
reset the filter indicator.
CAUTION! Do not operate the dehumidifier
without the included filter.
Figure 1
Figure 2

PAGE 4 OF 7 0217 IH-6369
OPERATION CONTINUED
8. MyHome Modes – Preset humidity level settings
allow the user to easily move the dehumidifier room-
to-room and select the corresponding mode for
the location in which the dehumidifier is operating
for optimum performance. Press the MODE button
to choose from Sleeping Space, Living Space or
Basement.
9. Child-Lock Mode – To lock the control panel,
press and hold the TIMER button for 3 seconds.
Locking the control panel prevents someone from
accidentally changing the settings. When locked,
the Lock Indicator will light up. Press and hold the
TIMER button for 3 seconds to unlock the control
panel.
CONTINUOUS MODE
GARDEN HOSE INSTALLATION AND SETUP
Water can be automatically emptied by attaching a
hose to the continuous drainage port on the back of the
dehumidifier. This will allow the unit to run continuously
(depending on the selected humidity level) without
having to empty the water bucket. To drain, simply
attach a standard garden hose (not included). The
thread standard for garden hoses in the US and its
territories is known as GHT or "garden hose thread," which
has an outer diameter of 1⁄" and a pitch of 11.5 TPI.
• Place dehumidifier on a level surface.
• Unscrew the cap on the back of the unit to access
the garden hose nozzle
• Thread a garden hose (not supplied) onto the
accessible nozzle, lead to a floor drain and cut to
length.
• Make sure that there are no kinks or knots in the
garden hose. (See Figure 4)
• Turn on the unit and press the MODE button until set
to CONTINUOUS.
NOTE: Placing the dehumidifier on an uneven surface or improper hose installation may result in water
filling the bucket and causing the unit to shut off. Empty bucket if shut-off occurs, then check dehumidifier
location and hose for proper setup. The bucket must be in place and securely seated for the dehumidifier
to operate.
Figure 4

PAGE 5 OF 7 0217 IH-6369
MAINTENANCE
NOTE: Make sure power is off and the power cord
is not plugged into an electrical outlet prior to
performing any maintenance on the unit.
CLEAN OR REPLACE FILTER
Refer to page 3 Clean Filter section.
CLEAN THE UNIT HOUSING
1. Keep the unit from being exposed directly to the sun
to prevent color fading.
2. Clean the surface with a damp cloth and dry it with
a soft towel.
END OF SEASON STORAGE/TRANSPORTING THE UNIT
1. Clean or replace filter. Refer to page 3 Clean Filter
section.
2. Unplug the unit and secure the power cord to the
back of the unit.
3. Remove bucket and empty all water.
4. The unit should be stored in a cool, dry place.
LOCATION
• A dehumidifier operating in a basement will have
little or no effect in drying out an adjacent enclosed
storage area, such as a closet, unless there is
adequate circulation of air in and out of the area.
• Do not use outdoors.
• This dehumidifier is intended for indoor use only.
Place the dehumidifier on a smooth, level floor
surface that is strong enough to support the unit with
a full bucket of water.
• Allow at least 12"-18" of air flow on all sides.
(See Figure 3)
• Place the dehumidifier in an area where the
temperature will not fall below 41°F. The coils can
become covered with frost at temperatures below
41°F, which may reduce performance. (See Figure 3)
• Use the dehumidifier in cooking, laundry, bathing
and dishwashing areas that have excessive moisture.
NOTE: Place the dehumidifier away from a
clothes dryer.
• Use the dehumidifier to prevent moisture damage
anywhere books or valuables are stored.
• Use the dehumidifier in a basement to help prevent
moisture damage.
• The dehumidifier must be operated in an enclosed
area to be most effective.
• Close all doors, windows and other outside openings
to the room.
AUTOMATIC DEFROST
When frost builds up on the evaporator coils, the
compressor will cycle off and the fan will continue to run
until the frost disappears. When the coils are completely
defrosted, the compressor or fan (depending on the
model) will automatically restart and dehumidification
will resume.
Above
41ºF
(5ºC)
Below
41ºF
(5ºC)
YES NO
18 inches
18 inches
Figure 3

PAGE 6 OF 7 0217 IH-6369
OPERATING ISSUE CAUSES RECOMMENDATIONS
Dehumidifier does not start. The dehumidifier is unplugged.
The fuse is blown/circuit breaker is
tripped.
Dehumidifier has reached its preset
level or the bucket is full.
Bucket is not in the proper position.
Power Failure.
Make sure the dehumidifier's plug is pushed
completely into the outlet.
Check the fuse/circuit breaker box and replace fuse
or reset breaker.
The dehumidifier automatically turns off when either
condition occurs. Change to a lower setting or
empty the water bucket and replace properly.
The bucket must be in place and securely seated for
the dehumidifier to operate.
There is a protective time delay (up to 3 minutes) to
prevent tripping of the compressor overload. For this
reason, the unit may not start normal dehumidification
for 3 minutes after it is powered back on .
Dehumidifier does not dry the
air as it should. Not enough time allowed for unit to
remove moisture.
Airflow is restricted.
Dirty filter.
The humidity control may not be set low
enough.
Doors and windows may not be closed
tightly.
Clothes dryer may be blowing moist air
into the room.
Room temperature is too low.
When first installed, allow at least 24 hours to
maintain the desired dryness.
Make sure there are no curtains, blinds or furniture
blocking the front or back of the dehumidifier. See
the Location section on Page 5.
See the Clean Filter section on Page 3.
For drier air, press the button to lower the
percent humidity desired in the room, or set the
dehumidifier to CO for maximum dehumidification.
Check that all doors, windows and other openings
are securely closed.
Install the dehumidifier away from the dryer. The
dryer should be vented outside.
Moisture removal is best at higher room
temperatures. Lower room temperatures will
reduce the moisture removal rate. This model is
designed to operate at temperatures above 41°F.
Dehumidifier runs too much. The area to be dehumidified is too
large.
Doors and windows are open.
The capacity of your dehumidifier may not be
adequate for the room size.
Close all doors and windows to the outside.
Frost appears on the coils. The dehumidifier has recently been
turned on or the room temperature is
below 41° F.
This is normal. Frost will usually disappear within 60
minutes.
Controls cannot be set. The compressor will turn off and the
fan will automatically continue to run
for approximately 3 minutes at a fixed
setting.
This is normal. Wait approximately 3 minutes and
set the fan speed at the desired level.
Fan noise present. Air is moving through the unit. This is normal.
TROUBLESHOOTING

PAGE 7 OF 7 0217 IH-6369
TROUBLESHOOTING CONTINUED
SELF-DIAGNOSING CODES
OPERATING ISSUE CAUSES RECOMMENDATIONS
Water present on floor. Hose connection may be loose.
Hose is attached, but not draining into
a drain.
End of Season drain plug is loose.
The fuse is blown/circuit breaker is
tripped.
Dehumidifier has reached its preset
level or the bucket is full.
Bucket is not in the proper position.
Power Failure.
Check the hose connection. See the Continuous
Mode garden hose installation and set up section
on page 4.
Disconnect the hose if using the bucket or place
the hose near a drain.
Check inside the bucket cavity on the unit and
be sure that the rubber drain plug is completely
inserted.
Check the house fuse/circuit breaker box and
replace fuse or reset breaker.
The dehumidifier automatically turns off when
either condition occurs. Change to a lower setting
or empty the water bucket and replace properly.
The bucket must be in place and securely seated
for the dehumidifier to operate.
There is a protective time delay (up to 3 minutes)
to prevent tripping of the compressor overload.
For this reason, the unit may not start normal
dehumidification for 3 minutes after it is powered
back on.
Continuous Mode on, but
water is draining in bucket. Incorrect drain hose is installed.
Dehumidifier on uneven surface.
Garden hose must be used while operating in
continuous mode.
Make sure that the unit is placed on a flat, level
surface.
SELF-DIAGNOSING
CODE DESCRIPTION RESOLUTION
E1 Compressor Overheat Protection Call Uline Customer Service for
assistance at 1-800-295-5510.
E2 Condenser Overheat Protection Call Uline Customer Service for
assistance at 1-800-295-5510.
EH Humidity Sensor Malfunction Call Uline Customer Service for
assistance at 1-800-295-5510.
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
