U.S. Solid USS-DBS01 Series User manual

Instruction Manual
U.S. Solid Mobile-controlled
Analytical Balance

1
Table of Contents
Normal Operation
I. Getting Started............................................................................................................ 2
II. Specifications.............................................................................................................5
Technical Parameters:............................................................................................. 5
III. Unit Transformation................................................................................................. 6
IV. Panel Description......................................................................................................7
Panel Explanations.................................................................................................. 7
V. Installation..................................................................................................................8
Choosing the installation location...........................................................................8
Unpacking and inspection....................................................................................... 9
VI. Using the Balance.................................................................................................. 10
Level adjustment................................................................................................... 10
Start....................................................................................................................... 10
Calibration............................................................................................................. 10
Tare function..........................................................................................................11
Weighing unit selection......................................................................................... 11
Counting................................................................................................................ 11
VII. Maintenance and Cleaning................................................................................... 12
Cleaning.................................................................................................................13
Troubleshooting Guide.......................................................................................... 13
Mobile App Operation
Home............................................................................................................................ 16
Connect Device...................................................................................................... 16
1. Discover......................................................................................................16
2. Connected...................................................................................................17
Weight records...................................................................................................... 18
Settings..................................................................................................................18
1. Language.................................................................................................... 18
2. Data Storage............................................................................................... 19
3. Weighing Settings.......................................................................................20
4. Software Version........................................................................................ 21
Functions...................................................................................................................... 22
Basic.......................................................................................................................22
Statistics................................................................................................................ 24
Percent...................................................................................................................27
Density...................................................................................................................28
Multi-device...........................................................................................................31
Settings..................................................................................................................33
1. Sensitivity...................................................................................................33
2. Calibration..................................................................................................33
Tare...............................................................................................................................35
Zero.............................................................................................................................. 35
Switch...........................................................................................................................35

2
I. Getting Started
Thank you for choosing U.S. Solid USS-DBS01 Series Mobile-controlled
Analytical Balance. We hope you enjoy your purchase. Please use and
maintain the equipment according to all instructions within the manual.
The U.S. Solid Mobile-controlled Analytical Balances innovatively enable
app-controlled function on the basis of normal operating mode, which
means you can now connect and control your U.S. Solid analytical
balance with mobile device. We believe this new feature will improve
our users’ experience, with minimum extra cost.
*Note: Please download U.S. Solid Balance app in App Store (IOS) or
Google Play Store (Android) before using.
This product was developed according to CE marking regulations while
emphasizing aesthetics and safety for the user. It has ISO certification,
specifically ISO 9001 The high quality of the product, coupled with
proper user care, should allow you to enjoy the product for years.
Improper use of this equipment can cause accidents, including but not
limited to: electric discharges, circuit breaker malfunctions, fire, etc.
Please read the maintenance section, where this is explained more fully.
For best results and longevity in product efficiency, read through this
manual thoroughly before using the product.
Please bear in mind the following:

3
·This manual should be kept with the analytical balance, so it is
available to all users
·Be careful when handling the balance. Avoid any sudden movements
when in its vicinity. Be sure to not drop the balance, nor drop any
heavy/sharp objects on it. Keep liquids away from the balance to avoid
spills.
·Never take apart the balance to try and fix yourself. This could ruin the
entire balance, and voids the product warranty. There is also risk of
injury when disassembling the balance.
·To prevent fire and electrical issues, avoid dusty or overly dry
environments. In case of electrical issue or fire, unplug the balance
immediately.
·During setup, installation, and use, contact your wholesaler with any
questions that arise.
·This equipment is protected under the Warranties and Consumer
Good Regulation (10/2003)
·Overhaul is not covered by the equipment warranty
·Changes made to the product by non-certified individuals will result in
a loss of the product warranty
·Accessories, including their loss, are not covered by the product
warranty, nor does the warrant cover piece ’ s deterioration over the
course of time.
·Keep your invoice, either for having the right to a warranty, or for
asking for warranty coverage. Manufacturer reserves the right to modify
or improve the manual or equipment.

4
Always make sure you calibrate your scale before using
Features:
·Bluetooth connection function
·Electromagnetic force compensation technology
·Aluminum alloy die cast base and ss platter
·Super bright 5 inch color LCD display with backlight
·Touch screen
·Height-adjustable feet
·RS232 interface
·Full capacity taring
·Overload protection,bubble level adjustment ,under hook
·Different units of measure: g, lb, ct, oz, gn, ozt, dwt, dr, MM, tl. J, tl.T,
tl.H, tola
·Check Weighing

5
II. Specifications
Technical Parameters:
MODEL
USS- DBS01002
USS- DBS01003
Max Capacity in
grams
120 g
200 g
Accuracy Class
I
Min. Capacity
10 mg
Division
0.0001 g
Verification Scale
Value
0.001g
Repeatability
±0.0002 g
Linearity
±0.0003 g
Stabilization Time
≤8 Seconds
Operating
Temperature
17.5°C- 22.5°C, with fluctuations of <1°C/Hour
63.5°F- 72.5°F with fluctuations of <1.8°F/ Hour
Relative Humidity
50%-75%
Pan size
Ф90 mm
Windshield
225 x 220 x 265 mm (L*W*H)
Total dimensions
355 x 230 x 350 mm(L*W*H)
Net weight
7.2 kg
Power
AC 110 - 240 V 50 Hz/60 Hz
DC 9 V-2.2 A by using the universal adapter

6
III. Unit Transformation
Unit
Conversion
Rate
Digit after
Decimal Point
g
1
4
mg
1000
1
lb
0.0022046
6
ct
5
3
oz
0.035274
5
gn
15.4323584
3
ozt
0.0321507
5
dwt
0.6430149
4
dr
0.5643834
4
MM
0.266666951
4
tl.J
0.02671725
5
tl.T
0.026666702
5
tl.H
0.026455464
5

7
IV. Panel Description
Panel Explanations
1. Language: Switch between Chinese and English
2. Time:Set time
3. INT: Press ”+”or “-”to choose the speed
INT-0 Highest Speed
INT-1 High Speed
INT-2 Normal Speed
INT-3 Low Speed
4. PCS: Press it to enter the piece counting mode
5. ASD: Press ”+” or “-” to choose the sensitivity to match the
environment
ASD-0 The highest sensitivity
ASD-1 The high sensitivity

8
ASD-2 The normal sensitivity
ASD-3 The poor sensitivity for bad environment
6. Print: Press”+”or “-”to choose the print
mode
PRN-0 Output by Pressing
PRN-1 Timing output for every 30s
PRN-2 Timing output for every 60s
PRN-3 Timing output for every 120s
PRN-4 Continuous output
7. EXT CAL:Calibration key
V. Installation
Choosing the installation location
When analytical balances are used in routine lab or industrial
measurement environments, the weighing speed will be much
quicker, and the results more accurate. The location should meet the
following conditions:
1. Work room should be clean and dry
2. Balance should be placed on a solid, stable, plain flat surface
3. Avoid locations in which the balance could be exposed to any of the
following:

9
a. Airflow from air conditioners, fans, doors, or windows
b. Vibrations from surrounding or nearby equipment
c. Direct sunlight or radiation
4. Do not use the balance anywhere exposed to explosive,
combustible, or corrosive gases.
5. Do not use the balance in areas with high humidity or high levels of
dust
6. When moving from a cooler to a warmer place, the accuracy and
reliability of the scale will be influenced by the moisture
condensation inside the balance. In order to eliminate this
influence, it is best to leave the scale unplugged in its new location
for at least two hours before next use.
7. Keep the balance clean.
8. Do not leave material on the balance when not in use.
Unpacking and inspection
Check that all of the items indicated below are included in the package
and that nothing has been damaged:
·Balance
·Pan
·Power Cable
·External Calibration weight
·Manual
In case the balance or any component is damaged during transport,
tell your transportation agent immediately in order to process claims
within the proper time frame.

10
VI. Using the Balance
Level adjustment
Once the balance is placed at its location, check the bubble level; if
bubble is not well-centered, turn the adjustable feet so the bubble
moves to the center and the balance is properly leveled.
Start
1. Connect the balance to the power supply and press ON key on the
panel. Wait 30 minutes after powering on for best performance.
2. After warming up, calibrate the balance.
3. After calibration, the balance will enter weighing mode
4. To turn the balance off, press the OFF key on the panel and the
display will shut off. If the balance will be unused for an extended
period of time, disconnect it from the power supply.
Calibration
1. Press EXT CAL key; the value of the necessary weight will flash on
display
2. Put the calibration weight on the pan. Wait until the value of the
calibration weight stops flashing and is fixed on the display (e.g.
100.0000 g, 200.0000g, etc., depending on the model)
3. Remove the weight from the pan
4. The balance will enter weighing mode and will display 0.0000g

11
Note: Each balance includes the necessary weight to complete
external calibration
Tare function
1. Put the receptacle on the weighing pan; its weight will be displayed
2. Press “→T←” or “→0←” key and the reading on the display will
automatically be set to 0.0000g; tare is complete
3. If the receptacle is removed from the pan, the corresponding
weight, with negative value will be displayed
4. Press the “→T←” or “→0←” key again and the value on display
will be set to zero again
Weighing unit selection
Press UNIT key to select the desired weighing unit from g, lb, ct, oz, gn,
ozt, dwt, dr, MM, tl.j, tl.T, tl.H, tola
Counting
1. Press “PCS” to enter the piece counting mode
2. Prepare the sample, for example, prepare 10pcs samples and put
them on the pan gently
3. Press 10, and until the display shows 10pcs. Then remove the
samples gently. And it can work
4. Press to get back

12
VII. Maintenance and Cleaning
To get the best results and for product longevity, be sure to follow the
suggestions below.
Note: All of the suggestions and guidelines mentioned below and
throughout this manual will only be effective with continuous and
careful maintenance of the equipment
·Follow all processes outlined in the manual
·Make the manual available to all users of the equipment
·Prevent the balance from any sudden movements or falls, as well as
from direct sunlight or air flow. The balance is a precision instrument
and must be handled carefully.
·Balance must be plugged into a grounded electrical outlet and the
socket should be easily accessible to unplug in case of emergency
·Never unplug the balance by pulling on the wire, do so from the base
·Never use the balance in a wedged-in location, such as a shelf
·Never use other objects such as pens, pencils, etc. to press the
buttons on the control panel; use only your fingers.
·Never place anything on the pan heavier than the maximum capacity
of the balance, or the sensor could be damaged
·Do not submerge the balance, nor spill any liquids on it
·If any liquid does come into contact with the electrical parts of the
balance, immediately disconnect it and send it in for service to be

13
checked and adjusted if necessary
·Always use only original components and supplies. Other devices
and parts may appear similar, but can damage the equipment.
Cleaning
·Never use scourers or substances that can grate to clean metallic
parts. This include, but is not limited to, stainless steel, aluminum,
coatings, etc.. These can damage the balance and lead to early
erosion of effectiveness of the balance.
·Use a lint-free cloth, dampened with soapy water, that does not
contain any abrasive surfaces, nor corrosive materials
Troubleshooting Guide
Problem
Cause
Solution
Display not
working
No power
supply
Plug in the adapter
Fuse Damaged
Replace fuse
Damaged
Transformer
Replace the power transformer.
If problem persists, send to
Technical Services for repair.
Unstable Display
Poor working
conditions
Seek somewhere with less
vibration and/or airflow
Wind or drafts
Check to make sure draft shield
ATTENTION!! If equipment is not properly cleaned and cared for,
technical service will be unable to fix or repair issues.

14
affecting
readings
is closed tightly
Scale pan
unsteady
Remove the pan and clean the
surface of the balance well,
making sure there are no
lingering items
Power exceeds
permissible
value
Connect balance to power
supply 110-220 V AC
Displayed mass
is not the same
as true mass
Balance has not
been calibrated
Double check calibration,
internal and/or external
Receptacle not
being
considered
Make sure the receptacle
has been tared out
Uneven surface
Make sure balance is on
a flat, even surface
Note: According to the applicable legislation regarding “Non-automatic
weighing instruments”in which balances are included, by means of writ
dating from the 22nd of October, 1994 (BOE 1/3rd/95), these balances
must not be used for:
·Commercial transactions
·Calculating taxes, tariffs, rates, indemnities, and other
similar canons
·Judicial surveys
·Pharmaceutical medicine preparations, as well as analysis

15
made in medical or pharmaceutical laboratories
·Determining the price or total amount in sale price or in pre-
packaged preparations
Instructions on environmental protection:
At the end of its life cycle, please do not dispose of this
equipment by throwing it in the usual garbage. Instead, hand it over at a
collection point for the recycling of electrical and electronic appliances.
It does not contain dangerous nor toxic products for humans, but
inadequate disposal could still damage the environment. The materials
are recyclable as mentioned. By recycling material or through other
forms or repurposing old appliances, you are making an important
contribution to the protection of our environment. Please inquire with
your local community authorities for the proper disposal location.

16
Mobile APP Operation
Home
Open the U.S Solid Balance app or click the [HOME]menu item on the
lower navigation menu to view the HOME screen.
Connect Device
1. Discover
Find your U.S. Solid Balance in the list of discovered devices. Click on its
[PAIR] button to connect your mobile device to your balance. Once
connected, the app will automatically advance to the CONNECTED
screen.

17
2. Connected
Select the [Connected] tab to view any connected balance. The app will
navigate to the FUNCTION screen by clicking on it from the list.

18
Weight records
Click on the [BASIC WEIGHING], [PIECE COUNTING] or [DENSITY
WEIGHING] menu items to check their corresponding records.
Settings
Click the [SETTINGS] menu item to view the app’s system settings.
1. Language
Choose the [LANGUAGE] menu item to select your preferred language.
You can choose Auto, Simplified Chinese, or English.

19
2. Data Storage
Enable/Disable the saving of the stable weight only by switching the
[Save stable weight only] switch on or off.
