Ultraloq U-Bolt Pro Z-Wave
Installation and User Guide
( )
V1.4
™

• Do not use a power drill for installation.
• Install and test the lock with the door open to avoid being
locked out.
• Please read all the instructions before contacting customer
support.
• Please contact customer support before returning the
product to the store.
• DO NOT install the batteries before installing the lock!
• Follow the instructions in sequential order!
• This lock is designed for the following operating temperatures:
Outside Lock Body: -31°F(-35°C) to 158°F (70°C)
Inside Lock Body: 14°F (-10°C) to 131°F (55°C)
• Please must use AA Alkaline Battery and don't use Lithium Battery
or Rechargeable Battery.
To ensure the best service, please register your account at
www.u-tec.com/register.html
Need Help?
For technical documents and more
Please visit www.u-tec.com/support
Email: [email protected]
Important Notes
Statements
- 1 -
Before using all Ultraloq products, please read all applicable terms,
rules, policies and usage provisions found at
www.u-tec.com/company/privacy. By using your Ultraloq, you
agree to be bound by the U-tec Privacy Policy.
Ultraloq Terms & Policies
Note:The Exterior Assembly of Ultraloq U-Bolt Pro Z-Wave
is waterproof, but the Interior Assembly is not waterproof
at all due to the battery box.

ENGLISH
Interior
Assembly
Exterior
Assembly
Interior Assembly
Mounting Plate
Screw A Screw C
Screw D Screw E
Strike
Screw B
Bolt Spacer
Backup Key
AA Alkaline Batteries
May not be included
for some regions
Screwdriver User Guide Drill Template
Reset Needle
- 2 -
Packing List
UltraloqU-Bolt Pro WiFi
UserGuide
(V1.0)
DrillTemplate
(V1.6)
Faceofthe door Edgeofthe door
Centerline
Backset
2
3
/
4
”
(70mm)
2
3
/
8
” (60mm)
1
3
/
4
”
(44mm)
1
3
/
8
”
(35mm)
Centerline
Backset
2
3
/
4
”
(70mm)
2
3
/
8
” (60mm)
1
3
/
4
”
(44mm)
1
3
/
8
”
(35mm)
Fold
(V1.6)
Plantillade Perforación
Caradela puerta Bordedelapuerta
Eje
Caradela puertaBordedela puerta
Eje
Doblar
Entradade
lacerradura
Entradade
lacerradura
Fold
Doblar
DrillTemplate
(V1.6)
(V1.5)
Plantillade Perforación
Faceofthe doorEdge of the door
2”(50mm)
2”
(50mm)

Please scan this QR code to watch the easy
step by step installation video before
attempting to install Ultraloq .
1”
25 mm
53 mm
21
/
8”
(33 mm ~ 50 mm)
15
/
16”
~ 2 ”
23
/
4”
23
/
8”
(70 mm)
OR
(60 mm)
38 mm
11
/
2
”
Installation Guide
Installation Video
- 3 -
1. Preparing Door
Check the door’s dimensions.
Step 1
Measure to confirm that the door is between 15
/
16”
~ 2 ”
(33 mm-50 mm) thick.
Step 2
Measure to confirm that the diameter of the hole is 21
/
8”
(53 mm)
or
11
/
2”
(38 mm)
Step 3
Measure to confirm that the backset is either 23
/
8” or 23
/
4
”
(60 mm or 70 mm) .
Step 4
Measure to confirm that the diameter of the hole in the door
edge is
1” (25 mm).
Step 5
Measure to confirm the depth of the hole in the frame is at least
1''(25 mm).
If you have a new door, please drill the holes according to Drill
Template.
Or you can also view the webiste directly.
www.u-tec.com/lock/U-bolt_pro_zwave/guide
1''(25 mm)

- 4 -
2. Installing Bolt and Strike
Step 1
Install Bolt into the door. Make sure the UP icon goes up.
Step 2
Note: Bolt is set for 23
/
8”
backset initially. It can be adjusted to 23
/
4”
if needed.
To adjust it please make sure the bolt is retracted, then, press it, twist and pull
it or push it to your desired length.
Install Strike into the door frame.
2
3
/
8
”2
3
/
4
”
Adjust the Bolt
basket length
ENGLISH

- 5 -
Step 1
Keep Bolt retracted and the cylinder tailpiece horizontal.
Install Exterior Assembly. Please do not insert the mechanical
key during installation .
Step 2
Align its two sticks with two holes on Bolt. The cable goes through
the hole below Bolt.
If your door has a
11
/
2”
(38 mm) bore hole, remove the spacer as
shown.
3. Installing Exterior Assembly

- 6 -
Step 1
Route the cable through the hole on Interior Assembly Mounting
Plate.
Step 2
Secure Interior Assembly Mounting Plate to Exterior Assembly
using Screws D.
4. Installing Interior Assembly Mounting Plate
Screw D
ENGLISH

- 7 -
5. Installing Interior Assembly
Step 1
Remove the battery cover of the Interior Assembly.
Step 2
Insert the connector of the cable to the socket on Interior
Assembly. When you plug the connector, please make
sure the white teeth faces up. Press the connector in
firmly until it is completed seated.
Step 3
Rotate the knob and keep it in a vertical position to stay
unlocked.
Step 4
Attach Interior Assembly to Mounting Plate and tighten 2 Screws E.
Unlocked

- 8 -
6. Installing the Batteries and Performing the Door
Handing Process
This step will teach your lock the orientation of your door and is
crucial to lock operation.
Step 1
Rotate the knob and keep it in a horizontal position to stay locked.
Step 2
Insert 4 AA Alkaline Batteries then install the battery cover.
Note: Any fingerprint or code can unlock U-Bolt Pro Z-Wave in Factory Default Mode.
Deadbolt
ENGLISH

- 9 -
Please watch our easy step by step User Guide video before
attempting to use your Ultraloq U-Bolt Pro Z-Wave Smart Lock.
User Guide
1. Product Overview
1.1 Exterior
User Guide Video
Anti-peep Keypad
Used to enter the code and unlock from outside.
Advanced Fingerprint Reader
Used to verify your finger and unlock from the outside.
Backup Key Hole
Used to insert the key to unlock in emergency situations.
Micro USB (5V)
Used to connect power bank to activate the lock when battery
runs out.
Tri-color LED Indicator
Shows you authorized or denied access, Bluetooth connectivity
status, battery status etc.
Ultraloq Button
Used to lock from the outside, illuminate the keypad for code
entry and confirm previous operation etc.
Advanced
Fingerprint Reader
Anti-peep Keypad
Micro USB (5V)
Metal Ring
Tri-color LED
Indicator
Ultraloq Button
Backup Key Hole
Or you can also view the webiste directly.
www.u-tec.com/lock/U-bolt_pro_zwave/guide

- 10 -
Reset Button
Used to reset the lock to Factory Default settings.
If the lock was paired to App, please must click "Delete" to remove
the device from App.
Battery Compartments
Used to insert 4 AA alkaline batteries.
Note:
Lithium batteries may have a longer life, but when they
begin to fail, they fail quickly. We don’t recommend them
because they don’t give you a lot of time to change your
batteries before the lock is completely dead.
Please don't use any Rechargeable Battery.
Battery Cover
Used to cover batteries and product label.
Knob
Used to unlock and lock the door from inside.
LED Indicator
Turns red when door is unlocked.
1.3 Low Battery Alarm
There will be low battery alert on the lock and App when battery
is low. Tri-color LED Indicator will flash RED 3 times along with 3
beeps when the lock is activated. Please replace batteries.
Reset Button
1.2 Interior
Battery
Compartments
Battery Cover
Knob
LED Indicator
RESET
ENGLISH

- 11 -
Step 1
Scan above QR code to download the App, or search “U-tec”in
App Store (iOS) and Google Play (Android).
Step 2
Open the App, register U-tec account and log in the account.
Step 3
Make sure the lock is in Factory Default Mode. Turn on
Bluetooth on your smartphone, stay near the lock (within 10 feet /
3 meters) and search the lock in the App.
Step 4
Pair the lock in the App.
2.2 Adding your lock to a Z-Wave hub
your smart lock can work with U-tec App alone if you haven’t got
any Z-Wave hub yet.
Step1
Follow the instructions of your hub, put your hub into inclusion
mode.
App
2. Lock Setup
Note: Please refer to the guide in U-tec App for more information.
Note: Ultraloq Z-Wave lock must be set up in the U-tec App before
adding it to the Z-Wave hub.
2.1 Register account and add new lock in U-tec App

ENGLISH
- 12 -
Step2
Open the U-tec App and go to Settings, select Z-Wave Control.
The App should state that “Your Ultraloq Smart Lock has not
been added to a Z-Wave hub yet”.
If your lock has been added to a hub already, please follow the
instructions in the FAQ to exclude your lock from the hub first.
Step3
Tap Add to Z-Wave hub,then follow the App instructions to
start the inclusion process. If your Z-Wave hub is Security 2
enabled and requires the Z-Wave QR code or pin code to add the
lock automatically, please find it on the back of the battery cover
of your smart lock.
When U-tec App states that the connection is successful, please
return to your hub interface to complete the setup.
This lock can be operated in any Z-Wave network with other
Z-Wave certified devices from other manufacturers. All
non-battery operated nodes within the network will act as
repeaters regardless of vendor to increase reliability of the
network.
Configuration parameters and association group information can
be found at u-tec.com/Support.
DON’T WANT TO USE THE APP?
Please go to page 17 for programming guide for Standalone Mode.
3. Using Your Lock
• User Code
3.1 Unlock From Outside
Enter 4-8 digit code and press Ultraloq Button to unlock .

• Z-Wave hub interface
Unlock through your hub interface when connected.
- 13 -
• Fingerprint
Place your finger on Fingerprint Reader to unlock.
• U-tec App
Use your U-tec App to unlock. Please refer to more information in
your App.
U-Bolt Pro WiFi
HUB

ENGLISH
1. Pull
- 14 -
3.2 Lock From Outside
Press Ultraloq Button to lock manually.
Enable Auto Lock feature and the lock will relock automatically.
3.3 Unlock From Inside
Rotate the knob to a vertical position to unlock.
3.4 Replace Batteries
Please use 4 high-quality alkaline AA batteries for replacement
when the battery is dead.
3.5 5V Emergency Power
Micro USB interface is used to connect regular 5V power bank to
activate the lock in case the battery is dead.
3.6 Emergency Key Override
Emergency Key Override can be used when the battery is dead.
Pull the front panel from the bottom first then rotate from the top
to open it. You can see Backup Key Hole inside. Insert the key and
rotate to unlock, just like any lock.
3.7 Enable Or Disable Auto Lock
Enable
Please keep Bolt unlocked and press "1" button for 3 seconds
until LED turns green and "1" button blinks.
Disable
Please keep Bolt unlocked and press "0" button for 3 seconds
until LED turns green and "0" button blinks.
This can also be set in U-tec App and Auto Lock timing can be
programmed between 10 seconds to 5 minutes. Factory Default
timing is 30 seconds.
Important Note
Please keep at least one key in secure location outside of
your place.
2. Rotate 3. Insert

- 15 -
3.8 Anti-peep Keypad
The lock supports up to 16-digit Vague Code. Just enter any
16-digit code, as long as a correct code is included in what you
entered, you can open the door.
1:
2:
3:
1 2 3 4 5 6 X X X X X X
1 2 3 4 5 6
X X X X X X
1 2 3 4 5 6
X X X X X X
Example
User Code: 123456
Vague Code
3.9 Place Finger
1. For a higher recognition rate, please try to cover the
Fingerprint Reader completely with your finger, touching the
surrounding metal ring.
2. Make sure that your finger and Fingerprint Reader are clean
and dry. For Fingerprint Reader, use a clean, lint-free cloth to
wipe off any dirt or debris.
3. Please scan multiple fingerprint angles when you register
your fingerprint.
4. While scanning your finger, you shouldn't tap too quickly or
move your finger around.
5. If you have trouble enrolling one finger, try another.
6. U-Bolt Pro Z-Wave fingerprint sensor has self-study
function which the verification rate will be improved after
multiple success .
Bottom View Top View Side View

ENGLISH
- 16 -
4.2 Add User Code in Standalone Mode
Warning
Standalone Mode is NOT available after the lock is registered
in App! Please reset the lock to Factory Default Mode first to
program your lock in Standalone Mode.
Admin Code must be created first prior to any other programming.
Only one Admin Code is available.
4. Standalone Mode Programming Guide
IndicatorOperation
4.1 Add Admin Code in Standalone Mode
Hold for 3 sec 2 beeps with flashing
green light
Enter 4-8 digit Admin Code
and press
1 beep with green light,
then flashing green light
Enter the Admin Code again
and press 2 beeps with green light
Success All lights off
IndicatorOperation
Hold for 3 sec 2 beeps with flashing
blue light
Enter 4-8 digit Admin Code
and press
2 beeps with green light,
then steady blue light
Enter 4-8 digit User Code
and press 1 beep with green light,
then steady blue light
It is recommended to use U-tec App to program your lock. If
you don’t have a smartphone or don’t want to use the App, you
may follow the programming instructions below.

- 17 -
4.3 Add Fingerprint in Standalone Mode
2 beeps with green light
Success All lights off
Enter the User Code again
and press
IndicatorOperation
2 beeps with flashing
blue light
2 beeps with green light,
then steady blue light
Place Your Finger
Hold for 3 sec
Enter 4-8 digit Admin Code
and press
light
Success 2 beeps with green light
Lift and Place Your Finger
Lift and Place Your Finger
Lift and Place Your Finger
Lift and Place Your Finger
Lift and Place Your Finger
#1 and #2 light with beep
#3 and #4 light with beep
#5 and #6 light with beep
#7 and #8 light with beep
#9 and #0 light with beep

ENGLISH
- 18 -
4.4 Delete Admin and User
Please reset the lock to Factory Default Mode to delete Admin
and all Users.
How to reset the lock in Standalone Mode?
Please use a Reset Needle to push the Reset Button (at the
bottom of Interior Assembly) for around 3 seconds until you
hear one long beep and two short beeps.
FAQ
1. How to exclude my lock from a Z-Wave hub?
In the hub interface, find the place to remove the lock or follow
the hub instructions to put the hub into exclusion mode.
Open U-tec App，go to Lock Settings, select Z-Wave Control
，tap Remove my lock from Z-Wave hub, then follow the App
instructions to complete the process.
2. How to reset my Z-Wave lock?
Please note all data will be erased if you reset U-Bolt Pro Z-Wave
to factory default. Use this procedure only when your Z-Wave
hub is missing or otherwise inoperable.
Please note that removing your lock from a Z-Wave network does
not reset your lock. You still need to do the following operations if
a reset is to be done.
If you are using U-tec App as Owner, please click “Delete and
Reset” to remove the lock from your U-tec Account, then use a
Reset Needle to push the Reset Button (at the bottom of Interior
Assembly) for around 3 seconds until you hear one long beep and
two short beeps.
If U-Bolt Pro Z-Wave is working as Standalone Mode, please use a
Reset Needle to push the Reset Button (at the bottom of Interior
Assembly) for around 3 seconds until you hear one long beep and
two short beeps.
3. Can I still use U-tec App when my lock is
connected to a Z-Wave hub?
Yes, Ultraloq Z-Wave lock can be operated from both the Z-Wave
hub interface and U-tec App.
4. What if I lost the paired smartphone?
Please go to www.u-tec.com/myutec.html or login U-tec App
via another smartphone to change your U-tec Account password.

- 19 == -
5. How can I unlock U-Bolt Pro Z-Wave if the battery
runs out?
There will be low battery alert on the lock and App when battery is
low. Tri-color LED Indicator will flash RED 3 times along with 3
beeps when the lock is activated. Please replace batteries.
Solution 1. Use the backup key to unlock.
Solution 2. Connect a 5V power bank to activate the lock
temporarily.
6. What’s the difference between Owner, Admin,
Normal User and Temporary User?
Owner is the person who owns the lock and registers it in U-tec
App originally. Owner has all privileges.
Admin can always unlock via fingerprint, code or App. Admin can
add or delete Admin and Users, control all lock settings and view
logs.
Normal User can always unlock via fingerprint, code or App.
Temporary User has limited access within specific time range.
7. Does U-Bolt Pro Z-Wave work with accessories
such as bolt from third party?
It is recommended to use the original accessories for best
performance and stability.
8. What is the log capacity for U-Bolt Pro Z-Wave?
U-Bolt Pro Z-Wave supports maximum 1,000 logs. The latest log
will replace the oldest one once log is full.
9.What is the user capacity for U-Bolt Pro Z-Wave?
U-Bolt Pro Z-Wave supports maximum 60 users and each user
can register 1 code and 2 fingerprints.
10. Can U-Bolt Pro Z-Wave work with a WiFi
network?
We recommend you remotely control your lock through the
Z-Wave hub. U-Bolt Pro Z-Wave can not work with a WiFi network
directly, However, it can be paired with an Ultraloq WiFi adapter. In
this case, you can remotely control it via U-tec App.
