TABLE OF CONTENTS
Display Symbols ......................................2
Analyzer Overview ....................................3
Getting Started........................................4
Safety Notes.......................................4
Warnings .........................................4
Menu / Setup .........................................4
Set Time ..........................................4
Set Date ..........................................4
Set Auxiliary Screen .................................5
Adjust Screen Contrast...............................5
Customizeable Header (on print-outs) ...................6
Set Language ......................................6
Viewing and Printing Reports..........................7
Print Setup ........................................7
Basic Fast Start (Operation) ............................8
Power On .........................................8
Select Fuel ........................................8
Connect Probe......................................8
Select Parameter to View / Log / Print ..................8
Status............................................8
Aux ..............................................8
Eff- X Air .........................................9
O2 CO Air Free ....................................9
CO2 CO...........................................9
Temp ............................................9
Fuel..............................................9
Date Time ........................................9
Where To Test ....................................10-11
What Results Are Generally Acceptable ................11
General Maintenance.................................12
Pre Test Checklist .................................12
Setting Inlet Temperature ...........................12
Analyzer Connections ..............................12
Emptying, Cleaning Water Trap ......................12
Changing Particle Filter .............................12
Replacing Batteries ................................13
Post Test ........................................13
Periodic Service ...................................13
Analyzer Re-Certification ............................13
Cleaning .........................................13
Other Important Factors Related To Combustion .........14
Combustion Measurement Terms ......................14
Specifications .......................................15
Electromagnetic Compatibility .........................15
Limited Warranty.....................................16
DISPLAY SYMBOLS
Excess Air Theoretical amount of air in excess of
level needed to completely burn fuel
Efficiency Calculated combustion
efficiency based on net
temperature, oxygen and fuel
selected
Losses Losses calculated from oxygen and
type of fuel
Total NOx Calculated total Oxides of
Nitrogen
Ratio CO to CO2 Ratio. Used to indicate the
general condition of the combustion
process
Draft Pressure Units can be changed:
InH2O, mbar, mmH2O, Pa,
kPa, PSI, mmHg, hPa.
Carbon
Monoxide
Carbon Monoxide measure in parts
per million ppm
CO - Air Free Undiluted concentration of
CO in combustion gases.
Carbon Dioxide Carbon Dioxide measured in percent-
age%
Nitrogen Oxide Nitrogen oxide in PPM
Oxygen Oxygen calculated Flue
Temperature (˚F)
Units can be changed: F˚/ C˚
Pressure Units can be changed: InH2O, mbar,
mmH2O, Pa, kPa, PSI, mmHg, hPa.
Inlet
Temperature (˚F)
Units can be changed: F˚/ C˚
Battery Level Delta T (˚F) Differential temperature
