ULS ULSHIM User manual

ULS Manufacturing
‘ULSHIM’
14 x 15 watt RGBWA+UV
Pix l Map
IP65 RATED
WWW.ULTRALIGHTSOUND.CO.UK

Safety intructions - P ease read this manua carefu y before your intia startup
CAUTION! TAKE CARE USING THIS DEVICE
RISK OF ELECTRIC SHOCK
Each person invo ved with the fitting, maintenance and operation of this device shou d be competent and fo ow
these instructions.
Before Initia start-up check the mains cab e and device for any damage.
Shou d the fuse in the p ug need rep acing ensure a 3amp fuse with a British kite mark is used.
ULS manufacturing wi not accept iabi ity for any damages caused by the non-observance of this manua , or any
modification to this device.
Never remove warning or information abe s.
Do not open this device or modify the equipment
Do not connect this device to a dimmer pack.
Do not switch this device on and off at short interva s.
Make sure the vo tage is between 90 and 240v ac
Make sure the power cab e is never crushed or forced, check the cab e periodica y.
If the equipment has been exposed to drastic temperature change (norma y after transportation), a ow device to
reach room temperature before powering on.
Do not touch this device during a thunderstorm.
If any of the fo owing conditions occur, remove the ac p ug:
Smoke or unusua sme .
Water or foreign objects inside the unit.
Damage to the housing caused by physica damage.
Never pu the power cord, a ways grasp the main body of the p ug top.

Thank you for purchasing our premium Led Batten.
Rugged Design and bui d for out on the road use with a feature set to riva existing products on the market.
Key features
Simp e 2 channe Dmx contro mode or advanced 6, 8, 11, 17, 47, 84 and 86 Dmx channe modes
Pixe mapping abi ity with Dmx contro of each 6 co ours per ed.
On board standa one contro of patterns, chases and fixed co ours. With advance contro of speed and fade times.
Units can be inked together with the integra power and data cab es.
M nu K ys

2 channel Dmx mode - 2ch
Dmx 1 Colour macro
Dmx 2 Speed slow - fast
6 channel Dmx mode - 6 ch
Dmx 1 Red 0 - 100
Dmx 2 Green 0 - 100
Dmx 3 Blue 0 - 100
Dmx 4 White 0 - 100
Dmx 5 Amber 0 - 100
Dmx 6 UV 0 - 100
8 channel Dmx mode - 8 ch
Dmx 1 Master dimmer
Dmx 2 Strobe Open- slow- fast
Dmx 3 Red 0 - 100
Dmx 4 Green 0 - 100
Dmx 5 Blue 0 - 100
Dmx 6 White 0 - 100
Dmx 7 Amber 0 - 100
Dmx 8 UV 0 - 100

11 Channel Dmx Mode
Strobe Speed
background
co our
contro
from
channe 5
contro
of each
co our
avai ab e
from
channe
6 - 11
dmx 1
Master
dimmer
dmx 2 Strobe open - fast
dmx 3 0-005 no function
006-015 user defined chase effect 1
   
016-025 user defined chase effect 2
   
026-035 user defined chase effect 3
   
036-045 user defined chase effect 4
   
046-055 user defined chase effect 5
   
056-065 user defined chase effect 6
   
066-075 user defined chase effect 7
   
076-085 user defined chase effect 8
   
086-095 user defined chase effect 9
   
096-105 user defined chase effect 10
   
106-115 user defined chase effect 11
   
116-125 user defined chase effect 12
   
126-135 user defined chase effect 13
   
136--145 simp e chase effect 1
   
146-155 simp e chase effect 2
   
156-165 simp e chase effect 3
   
166-175 simp e chase effect 4
   
176-185 simp e chase effect 5
   
186-195 simp e chase effect 6
   
196-205 simp e chase effect 7
   
206-215 simp e chase effect 8
   
216-225 cyc e thru simp e chase effects
   
226-235 ye ow - a eds fade in and out
236-245
cyc e thru a co ours - a eds
fade in and out
246-255
Sound contro - interna
microphone
dmx 4 0 -255 s ow - fast chase speed
dmx 5 0 -255
background co ours for some
chases
dmx 6 0 -255 Red
dmx 7 0 -255 Green
dmx 8 0 -255 B ue
dmx 9 0 -255 White
dmx 10 0 -255 Amber
dmx 11 0 -255 UV

17 CHANNEL DMX MODE 17CH
Strobe Speed
background
co our
contro
from
channe 5
contro
of each
co our
avai ab e
from
channe
6 - 11
dmx 1
Master
dimmer
dmx 2 Strobe open - fast
dmx 3 0-005 no function
006-015 user defined chase effect 1
   
016-025 user defined chase effect 2
   
026-035 user defined chase effect 3
   
036-045 user defined chase effect 4
   
046-055 user defined chase effect 5
   
056-065 user definedchase effect 6
   
066-075 user defined chase effect 7
   
076-085 user defined chase effect 8
   
086-095 user defined chase effect 9
   
096-105 user defined chase effect 10
   
106-115 user defined chase effect 11
   
116-125 user defined chase effect 12
   
126-135 user defined chase effect 13
   
136--145 simp e chase effect 1
   
146-155 simp e chase effect 2
   
156-165 simp e chase effect 3
   
166-175 simp e chase effect 4
   
176-185 simp e chase effect 5
   
186-195 simp e chase effect 6
   
196-205 simp e chase effect 7
   
206-215 simp e chase effect 8
   
216-225 cyc e thru simp e chase effects
   
226-235 ye ow - a eds fade in and out
236-245
cyc e thru a co ours - a eds fade in
and out
246-255 Sound contro - interna microphone
dmx 4 0 -255 s ow - fast chase speed
dmx 5 0 -255 background co ours for some chases
dmx 6 0 -255 Red 7 eds eft side
dmx 7 0 -255 Green 7 eds eft side
dmx 8 0 -255 B ue 7 eds eft side
dmx 9 0 -255 White 7 eds eft side
dmx 10 0 -255 Amber 7 eds eft side
dmx 11 0 -255 UV 7 eds eft side
dmx 12 0 -255 Red 7 eds Right side
dmx 13 0 -255 Green 7 eds Right side
dmx 14 0 -255 B ue 7 eds Right side
dmx 15 0 -255 White 7 eds Right side
dmx 16 0 -255 Amber 7 eds Right side
dmx 17 0 -255 UV 7 eds Right side

47 CHANNEL DMX MODE 47CH
Strobe Speed
background
co our
contro
from
channe 5
contro
of each
co our
avai ab e
from
channe
6 - 11
dmx 1
Master
dimmer
dmx 2 Strobe open - fast
dmx 3 0-005 no function
006-015 user defined chase effect 1
   
016-025 user defined chase effect 2
   
026-035 user defined chase effect 3
   
036-045 user defined chase effect 4
   
046-055 user defined chase effect 5
   
056-065 user definedchase effect 6
   
066-075 user defined chase effect 7
   
076-085 user defined chase effect 8
   
086-095 user defined chase effect 9
   
096-105 user defined chase effect 10
   
106-115 user defined chase effect 11
   
116-125 user defined chase effect 12
   
126-135 user defined chase effect 13
   
136--145 simp e chase effect 1
   
146-155 simp e chase effect 2
   
156-165 simp e chase effect 3
   
166-175 simp e chase effect 4
   
176-185 simp e chase effect 5
   
186-195 simp e chase effect 6
   
196-205 simp e chase effect 7
   
206-215 simp e chase effect 8
   
216-225 cyc e thru simp e chase effects
   
226-235 ye ow - a eds fade in and out
236-245
cyc e thru a co ours - a eds fade in
and out
246-255 Sound contro - interna microphone
dmx 4 0 -255 s ow - fast chase speed
dmx 5 0 -255 background co ours for some chases
dmx 6 0 -255 Red 2 eds 1,2
dmx 7 0 -255 Green 2 eds 1,2
dmx 8 0 -255 B ue 2 eds 1,2
dmx 9 0 -255 White 2 eds 1,2
dmx 10 0 -255 Amber 2 eds 1,2
dmx 11 0 -255 UV 2 eds 1,2
dmx 12 0 -255 Red 2 eds 3,4
dmx 13 0 -255 Green 2 eds 3,4
dmx 14 0 -255 B ue 2 eds 3,4
dmx 15 0 -255 White 2 eds 3,4
dmx 16 0 -255 Amber 2 eds 3,4

47 chann l mod continu d
dmx 17 0 -255 UV 2 eds 3,4
dmx 18 0 -255 Red 2 eds 3,4
dmx 19 0 -255 Green 2 eds 3,4
dmx 20 0 -255 B ue 2 eds 3,4
dmx 21 0 -255 White 2 eds 3,4
dmx 22 0 -255 Amber 2 eds 3,4
dmx 23 0 -255 UV 2 eds 3,4
dmx 24 0 -255 Red 2 eds 3,4
dmx 25 0 -255 Green 2 eds 3,4
dmx 26 0 -255 B ue 2 eds 3,4
dmx 27 0 -255 White 2 eds 3,4
dmx 28 0 -255 Amber 2 eds 3,4
dmx 29 0 -255 UV 2 eds 3,4
dmx 30 0 -255 Red 2 eds 3,4
dmx 31 0 -255 Green 2 eds 3,4
dmx 32 0 -255 B ue 2 eds 3,4
dmx 33 0 -255 White 2 eds 3,4
dmx 34 0 -255 Amber 2 eds 3,4
dmx 35 0 -255 UV 2 eds 3,4
dmx 36 0 -255 Red 2 eds 3,4
dmx 37 0 -255 Green 2 eds 3,4
dmx 38 0 -255 B ue 2 eds 3,4
dmx 39 0 -255 White 2 eds 3,4
dmx 40 0 -255 Amber 2 eds 3,4
dmx 41 0 -255 UV 2 eds 3,4
dmx 42 0 -255 Red 2 eds 3,4
dmx 43 0 -255 Green 2 eds 3,4
dmx 44 0 -255 B ue 2 eds 3,4
dmx 45 0 -255 White 2 eds 3,4
dmx 46 0 -255 Amber 2 eds 3,4
dmx 47 0 -255 UV 2 eds 3,4

84 chann
l dmx mod 84 CH
dmx 1 red ed 1 0 - 100%
dmx 2 Green ed 1 0 - 100%
dmx 3 B ue ed 1 0 - 100%
dmx 4 White ed 1 0 - 100%
dmx 5 Amber ed 1 0 - 100%
dmx 6 UV ed 1 0 - 100%
dmx 7 red ed 2 0 - 100%
dmx 8 Green ed 2 0 - 100%
dmx 9 B ue ed 2 0 - 100%
dmx 10 White ed 2 0 - 100%
dmx 11 Amber ed 2 0 - 100%
dmx 12 UV ed 2 0 - 100%
dmx 83 Amber - ed 14 0 - 100%
dmx 84 Uv - 14 0 - 100%
86 chann l dmx mod 86 ch
dmx 1 Master Dimmer
dmx 2 Strobe
dmx 3 Red ed 1 0 - 100%
dmx 4 Green ed 1 0 - 100%
dmx 5 B ue ed 1 0 - 100%
dmx 6 White ed 1 0 - 100%
dmx 7 Amber ed 1 0 - 100%
dmx 8 UV ed 1 0 - 100%
dmx 9 Red ed 2 0 - 100%
dmx 10 Green ed 2 0 - 100%
dmx 11 B ue ed 2 0 - 100%
dmx 12 White ed 2 0 - 100%
dmx 13 Amber ed 2 0 - 100%
Dmx 14 UV ed 2 0 - 100%
Dmx 85 Amber - ed 14 0 - 100%
Dmx 86 Uv - 14 0 - 100%

ULS Manufacturing is a trading name of U tra Light & Sound Limited.
UK based with readi y avai ab e spares and new units in the UK.
This Dmx shutter was designed and manufactured in the UK by ULS Manufacturing.
Our engineers have a detai ed know edge and are ab e to provide technica support both over the te ephone,
emai and at our UK Headquarters.
Our ethos is to be ab e to maintain service and extend product ife and minimise the “beyond economic repair”
approach, he ping reduce waste and saving time, money and the environment.
U tra Light & Sound imited
Te 01173502064
www.U traLightSound.co.uk
info@u tra ightsound.co.uk
WEE D claration
This symbo indicates that this piece of e ectrica equipment must
be disposed of separate y from norma waste at the end of its
operationa ife. P ease dispose of this produced by contacting ULS
manufacturing or taking it to your oca recyc ing or co ection
centre.
