Ultra-tow 40511 User manual

Page 1 of 8
18 WATT AMBER MINI LIGHTBAR
OWNER’S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and
other basic safety precautions may result in serious personal injury.
Item# 40511

Page 2 of 8
Thank you very much for choosing an Ultra-Tow product! For future reference, please
complete the owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire
manual to become familiar with this product before you begin using it.
This lightbar is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this lightbar not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the lightbar until you have first contacted the
distributor to determine if it can or should be performed on the product.
For technical questions please call 1-800-222-5381.
INTENDED USE
The 18W LED amber lightbar features 13 selectable flash patterns to mach your situation. It
includes 36 LEDs that provide superior performance warning light in any conditions. Durable
high-impact polycarbonate housing stands up to the weather. Magnetic mount features rubber
housing to prevent marring or scratching of the vehicle. The 2-in-1 mounting system allows for
magnetic and permanent mounting.
TECHNICAL SPECIFICATIONS
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this lightbar until they have
read this manual and have developed a thorough understanding of how the lightbar works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
Item
Description
Bulb Type
LED
Volts
DC 12V
Watts
18 Watt
Flash patterns
13
Power cord (ft.)
15
Product Size
14in.L x 8.3in.W x 2.8in.H

Page 3 of 8
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built
into this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY CONSIDERATIONS
•If mounting this product requires drilling holes, the installer MUST be sure that no
vehicle components or other vital parts could be damaged by the drilling process.
Check both sides of the mounting surface before drilling begins. Also de-burr any
holes and remove any metal shards or remnants. Install grommets into all wire
passage holes.
•WARNING: The vehicle should never be driven at high speeds if the lighbar is
magnetically mounted. If intended to be used at high speeds, user must permanently
mount the lightbar.
•If this product is mounted with magnets, clean the mounting surface and dry it
thoroughly before installation.
•Do not install this product or route any wires in the deployment area of your air bag.
Equipment mounted or located in the air bag deployment area will damage or reduce
the effectiveness of the air bag, or become a projectile that could cause serious
personal injury or death. Refer to your vehicle owner’s manual for the air bag
deployment area. The User/Installer assumes full responsibility to determine proper
mounting location, ensuring safety to all passengers inside the vehicle.
•Use only soap and water to clean the outer lens. Inspect and operate this product
regularly to confirm its proper operation and mounting condition.
LIGHTBAR USE AND CARE
•It is strongly recommended to only plug 12V plug into 12V power port, as
cigarette outlets can become contaminated and not create a good connection.
•Do not modify the lightbar in any way. Unauthorized modification may impair the
function and/or safety and could affect the life of the product.
•Always check damaged or worn out parts before using the lightbar. Broken parts
will affect the lightbar operation. Replace or repair damaged or worn parts
immediately.

Page 4 of 8
INSTALL THE LIGHTBAR
Magnetic mounting
1. The magnetic lightbar should be positioned on the vehicle’s roof where the magnets will
safely secure the lightbar. Before mount the lightbar to the roof, be sure the surface is
clean and clear of dirt, grease and debris.
2. Locate the desired location where you wish to mount the lightbar. For best results you
should make sure the lens is unobstructed, so that the light can be seen 360 degrees.
3. If you need to move the lightbar, hold one side securely, then lift the other side of the
lightbar from the room and move; repeat procedure to move the other side.
Permanent mounting
1. Upside down the lamp, take off the rubber boots. Remove the M6x20 screw (6), which in
the center of magnetic bases. The magnetic base (5), sleeve gasket (4), spring (3) pulled
away from the light body (1). (See Figure 1)
2. Drill a mounting hole for M6x45 Hex bolt (10) on the mounting surface. Insert M6x45 Hex
bolt (10) to the spring washer (9), flat washer (8), mounting surface, rubber gasket (7),
and mounting hole of lightbar. Then tighten the M6 bolts. (See Figure 2)

Page 5 of 8
OPERATION
1. To turn on the lightbar, insert the 12V plug into the vehicles power outlet.
Press the on/off button on the back on the 12V plug. When the lightbar is operating, the
LED on the plug’s switch will illuminate.
2. To change the pattern, press the button beside to the on/off button. Memory function
keeps same pattern selected, even when the lightbar is turned off.
3. To turn off the lightbar, remove the 12V plug from the vehicle’s power socket or position
the on/off switch to off.
The 12V plug has a built-in fuse to protect the lightbar and the vehicle. If the lightbar does not
turn on when the plug is inserted into the vehicle power socket, check the fuse built into the
power plug by the following method: The tip of the power plug has a chrome push-in contact
which is secured by a black nut. Unscrew the nut which will give you access to the fuse. If the
fuse needs to be replaced, use a 5-Amp fuse. Follow the reverse procedure to re-assemble
fuse back into power-plug. (See Figure 3)
MAINTENANCE
•It is recommended that the general condition of the lightbar be examined before it is
used. Keep your lightbar in good repair by adopting a program of conscientious repair
and maintenance. Have necessary repairs made by qualified service personnel.
•Clean the surface of lightbar lens frequently to keep its brightness.
•When any malfunction occurs, stop using and repair it immediately as soon as
possible. Please operate your lightbar according to the proper operation procedures.

Page 6 of 8
PARTS DIAGRAM & PARTS LIST
mounting
surface
Part#
Description
Qty.
1
Light Body
1
2
12V plug
1
3
Spring
4
4
Sleeve gasket
4
5
Magnetic base
4
6
M6 x 20 screw
4
7
Rubber gasket
4
8
Flat washer
4
9
Spring washer
4
10
M6x45 Hex bolt
4
For replacement parts and technical questions please call 1-800-222-5381.

Page 7 of 8

Page 8 of 8
WARRANTY
3-year limited warranty
Distributed by:
Northern Tool + Equipment Co., Inc.
Burnsville, Minnesota 55306
NorthernTool.com
Made in China
