Ultrak CSC100BU User manual

Rev. A CSMU000835
09/15/03
CSC100xU Series
CSC110xU Series
Covert Cameras
USER MANUAL

Rev. A ii CSMU000835
09/15/03
Rev. Date Description
A September 2003
Initial Release.
©2003 HONEYWELL INTERNATIONAL INC.
ALL RIGHTS RESERVED
HONEYWELL VIDEO SYSTEMS
1305 WATERS RIDGE DRIVE
LEWISVILLE, TX 75057
(800) 796-CCTV
ALL RIGHTS RESERVED. NO PART OF THIS PUBLICATION MAY BE REPRODUCED
BY ANY MEANS WITHOUT WRITTEN PERMISSION FROM HONEYWELL VIDEO
SYSTEMS.
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL
RESPECTS. HOWEVER, HONEYWELL VIDEO SYSTEMS CANNOT ASSUME
RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF.
THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT
NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO
INCORPORATE SUCH CHANGES.

Rev. A iii CSMU000835
09/15/03
WARNING
•TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the presence
of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instruction in the literature
accompanying the product.

Rev. A iv CSMU000835
09/15/03
TABLE OF CONTENTS
SECTION 1: INTRODUCTION ...................................................................... 1
1.1 PRODUCT DESCRIPTION.................................................................. 1
SECTION 2: INSTALLATION........................................................................ 2
2.1 BEFORE INSTALLING ....................................................................... 2
2.2 MOUNTING THE CAMERA............................................................... 2
Setting dip switches............................................................................... 5
2.3 WARM UP TIME ................................................................................. 5
2.4 WALK TESTING THE DETECTOR ................................................... 6
2.5 VOLTAGE REGULATION.................................................................. 6
SECTION 3: SPECIFICATIONS .................................................................... 7
USERS OF THE PRODUCT ARE RESPONSIBLE FOR CHECKING AND
COMPLYING WITH ALL FEDERAL STATE AND LOCAL LAWS AND
STATUTES CONCERNING THE MONITORING AND RECORDING OF
VIDEO AND AUDIO SIGNALS. HONEYWELL VIDEO SYSTEMS
SHALL NOT BE HELD RESPONSIBLE FOR THE USE OF THIS
PRODUCT IN VIOLATION OF CURRENT LAWS AND STATUTES.

Rev. A 1 CSMU000835
09/15/03
SECTION 1:
INTRODUCTION
1.1 PRODUCT DESCRIPTION
The CSC Series covert cameras are designed to blend into
commercial or office settings while providing superior
resolution and low-light capability. Built-in voltage
regulators prevent high voltage from reducing the life of the
camera.
The following models are covered in this manual:
CSC100BU
Covert Camera, Black & White
Standard Resolution,
Non-Functioning PIR
CSC100CU
Covert Camera, Color
Standard Resolution
Non-Functioning PIR
CSC110BU
Covert Camera, Black & White
Standard Resolution
Functioning PIR
CSC110CU
Covert Camera, Color
Standard Resolution
Functioning PIR

Rev. A 2 CSMU000835
09/15/03
SECTION 2:
INSTALLATION
2.1 BEFORE INSTALLING
Select a suitable location for the camera and enclosure.
•Select a location where an intruder is most likely to
cross the range of the detector.
•Do not place the camera in front of windows subject to
direct sunlight.
•Avoid locations which come in direct contact with
radiators, heating/cooling ducts, air conditioners, or
drafts.
•Do not place the camera in front of bulky objects
where camera view will be impaired.
2.2 MOUNTING THE CAMERA
The camera can be mounted directly to a wall or with an
optional mounting bracket for greater maneuverability.
Contact your sales representative for information about
mounting brackets.
To mount the unit directly to a wall:
1. Open the housing by pressing the snap-fit at the bottom
of the unit and gently separating the front and back
sections while avoiding damage to the camera
connections. Do not touch the face of the PYRO
sensor.
2. Remove the electronics board (PCB) screw to access
the rear housing. Refer to Figure 1 or 2, depending on
camera model.

Rev. A 3 CSMU000835
09/15/03
2.2 MOUNTING THE CAMERA, CONTINUED
PCB
Screw Block
Termina
l
CCD
Connector
GND VIDEO GND +Vin
Figure 1: PCB Layout
(CSC100BU/CSC100CU)
Relay
Groundin
g
Jumper
Relay
DIP
Switches
LED
Indicator
CCD
Connector
PCB
Screw
Pyro
Sensor
Figure 2: PCB Layout
(CSC110BU/CSC110CU)

Rev. A 4 CSMU000835
09/15/03
2.2 MOUNTING THE CAMERA, CONTINUED
3. Use the provided knockouts to assist in mounting the
unit. Use the side knockouts to mount the camera at an
angle.
Knock-
outs
Figure 3: Rear Housing Knockouts
4. Reattach the electronics board to the rear housing,
making final wiring additions if needed.

Rev. A 5 CSMU000835
09/15/03
2.2 MOUNTING THE CAMERA, CONTINUED
Setting dip
switches
5. Several operation options and modes are selectable via
DIP switches. (Models CSC110BU/CSC110CU only.)
Option Description
Pulse Counter Controls the amount of pulses (either
1 or 3 pulse mode) that need to be
detected before the detector activates.
LED Indicator Lights LED when movement is
detected. Only disable the LED
indicator after successfully walk
testing the detector.
Relay Operation Selectable to Normally Open (N.O.)
or Normally Closed (N.C.). If one
side of relay grounding is required,
install the relay grounding jumper as
JP1.
Set the switches using the following information:
Option Sw ON OFF
Pulse Counter 1 3 Pulse Mode 1 Pulse Mode
LED Indicator 2 LED ON LED OFF
Relay Operation 3 Relay N.C. Relay N.O.
6. Attach the front cover.
7. Connect the unit to a UL listed power supply or Ultrak
observation system.
2.3 WARM UP TIME
The detector will warm up for the first 90 seconds after
applying power.

Rev. A 6 CSMU000835
09/15/03
2.4 WALK TESTING THE DETECTOR
A walk test is used to determine the lens coverage pattern
of the detector and should be performed weekly.
1. Walk across the scope of the detector according to the
detection pattern selected. Since the pattern is
determined by the lens used in the detector, refer to the
lens range diagram.
2. Confirm that the LED activates, then deactivates after 2
motion-free seconds.
NOTE:
Camera view is wider than
PIR coverage pattern.
Figure 4: Rear Housing Knockouts
2.5 VOLTAGE REGULATION
The detector includes an on-board voltage regulator;
no external voltage regulation is necessary.

Rev. A 7 CSMU000835
09/15/03
SECTION 3:
SPECIFICATIONS
CSC100BU CSC110BU CSC100CU CSC110CU
Image Sensor 1/3” Interline Transfer CCD
CCD Lens 3.6mm pinhole lens 3.7mm pinhole lens
Horizontal Freq. 15.750 KHz (EIA) 15.734KHz (NTSC)
Vertical Freq. 60Hz (EIA) 60Hz (NTSC)
Picture Elements 510(H) x 492(V) (EIA) 510(H) x 492(V) (NTSC)
Scanning System 525 lines, 60 fields/sec (EIA) 525 lines, 60 fields/sec (NTSC
Horiz. Resolution 380 TV Lines 330 TV Lines
Synchronization Internal
Output Signal 1Vp-p Composite Video into 75 Ohms
Light Sensitivity 0.4 Lux at faceplate
S/N Ratio 46dB
Electronic Shutter 1/60 to 1/100,000 sec linear
Gamma Correction 0.45
AGC ON
Geometric Linearity No camera distortion
(picture linearity limited by lens and monitor)
Input Voltage 12.5-16Vdc
Power Draw (max) 100mA 130mA 220mA 220mA
Fire Protection ABS Plastic Housing
Operating Temp. 14°F to 122°F (-10°C to 50°C)
Dimensions 4.5H x 2.75H x 2.13D in (114H x 70H x 54D mm)
Weight 3.6 oz. 4.7 oz. 3.6 oz. 4.7 oz.
PIR MODELS CSC110BU / CSC110CU
Coverage 15m x 15m
Pulse Count 1 or 3 jumper selectable
Pyroelectric Sensor Dual passive infrared element
Alarm Output Dry Contacts (N.O./N.C jumper selectable)
Tamper Switch N.C., Contact Rating 30Vdc, 50mA max
Temp. Compensation Thermistor
Reverse Polarity Diode
LED indicator Jumper Selectable

Rev. A 8 CSMU000835
09/15/03
