unGer Hydro Power DI12 Series Manual

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
ENGLISHDEUTSCH
NEDERLANDS
DI12x DI24x DI48x
1
DI Ion exchange resin filter
DI Ionentauscher-Harzfilter
DI Ionen-uitwisselaar-harsfilter
Status: 03/2016
INSTALLATION & OPERATING INSTRUCTIONS
MONTAGE & BEDIENUNGSANLEITUNG
INSTALLATION OG DRIFTSVEJLEDNING

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
2
HydroPower DI
Table of contents
Introduction ...................................................................................................... 3
1. Safety regulations......................................................................................... 4
1.1 General.............................................................................................................. 4
1.2 Intended use...................................................................................................... 4
1.3 Operating temperatures, pressures and connections ..................................... 4
1.4 Conversions and modifications to the device ................................................... 4
1.5. Attention (General hazards)............................................................................. 5
2. Shipping & Packing ....................................................................................... 6
2.1 Receiving inspection of QuickChange resin bags............................................. 6
2.2 Receiving inspection of entire unit ................................................................... 6
2.3 Claims ............................................................................................................... 6
3. System Overview........................................................................................... 7
4. Installation and start-up ............................................................................... 9
4.1 New Machine Set up ......................................................................................... 9
4.2 Start-up............................................................................................................. 9
4.3 During operation............................................................................................. 10
5. EcoFlo - The Water Flow Optimizer............................................................. 11
6. Resin Change .............................................................................................. 12
6.1 Capacity........................................................................................................... 13
6.2 Resin Change: QuickChange resin bags (recommended).............................. 13
6.3 Resin Change: loose resin .............................................................................. 14
7. Technical Data............................................................................................. 14
7.1 Warnings ......................................................................................................... 14
7.2 Tips.................................................................................................................. 14
8. Spare Parts ................................................................................................. 15

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
ENGLISH
3
HydroPower DI
Introduction
Introduction
When choosing Unger complete desalination as water treatment system,
you have decided in favour of a high-quality product.
Complete desalination is based on the principle of ion exchange.
The minerals responsible for producing hardness and the conductivity (TDS value) are
removed from the water.
The application of this treatment filter has the following advantages:
• A water fed pole and a brush are all that is needed for glass cleaning.
• Prior to system installation and start-up it is essential that you observe
the safety regulations and instructions for installation and maintenance
contained in these instructions.
• The manufacturer is not liable for the function of the device:
• When handling is not in compliance with regular use.
• When used for applications not mentioned in the manual
(use other than intended),
• When failing to comply with safety regulations.
There is a risk of damage to the treatment filter if:
• Operating and installation errors.
• Wrong usage of loose resin (Overfill, expansion of resin)
• Vessel is opened incorrectly
• Replacing spare parts that are not included in the official Unger
spare parts pricelist.
• Performing unauthorised modifications to the design.
• Non-compliance with safety regulations (e.g. anti-freeze protection).
• Use of chemical additives.
• Insufficient maintenance.
All maintenance and repairs are to be performed by a specialist.
Use only original spare parts by Unger (according to spare parts list).
For all inquiries and spare parts orders it is important to provide detailed
information on the device.

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
4
1. Safety regulations
1.1 General
Please observe the applicable rules and regulations, as well as the effective accident
prevention regulations. Unger is not liable for any occurring water damage.
Make sure that the area of application has sufficient water drainage.
Close feed valve in case of prolonged shut-down times (e.g. weekends).
Transportation: Ensure nLite®HydroPowerDI tanks and cart models are properly
secured to trailer, van or truck bed.
The window cleaning contractor shall meet all applicable local, state/provincial, federal
licensing and registration requirements. He also shall strictly adhere to all applicable
local, state/provincial and federal labour laws and safety codes and standards.
1.2 Intended use
This device may cause danger if it is improperly installed, not regularly maintained or
not used as intended. Use this device only for water treatment to reach an optimal water
quality for glass cleaning. Any other use, especially water treatment for food production
(e.g. beverages) is considered as non-intended and not allowed.
When operating with a tap waterIine, it must be assured that the connected watertap is
equipped with a rebound valve to prevent water flowing back into drink water line!
When operating with water other than from drinking water system, e.g. from a well, a
water analysis must be performed prior to application to determine if the water is
suitable. Excess impurities in the water may have an adverse effect on system
performance and cleaning result.
1.3 Operating temperatures, pressures and connections
The system must be protected against frost. The temperatures in the service room must
be at least 4°C. The water temperature may not exceed 30°C, and maximum operating
pressure is 8 bar.
Depending on the composition of the raw water, the treated water is more or less
aggressive. Thus, the parts getting in contact with the treated water must be made of
suitable material.
1.4 Conversions and modifications to the device
Due to safety reasons, unauthorised modifications are not allowed. Original parts and
accessories are specifically designed for this device. Any liability by the manufacturer for
damages resulting from modifications to the device or from using parts other than
original parts is excluded.
HydroPower DI
Safety regulations

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
ENGLISH
5
HydroPower DI
General hazards
Contents under pressure can cause severe
injury or death from tank rupture.
When starting system:
•Checksystemforcracks.
•Besurecoverisinlockedposition.
•Donotexceedpressureof116psi(8Bar).
•Keepdischargelineopenandholdyellowle-
ver down to remove trapped air from system.
•Foruseonlywithdrinkingwater
Before servicing system:
•Shutoffdrinkingwatersupplyandopen
waterfed pole tubing discharge line.
•Disconnectwatersupplyandallowtank
to drain.
DANGER
!
Spilled resin is a slipping hazard.
Clean up spilled resin immediately.
WARNING
!
Resin can cause skin irritation.
Avoid skin contact.
Wash hands thoroughly after use.
Can cause eye irritation.
Avoid eye contact.
Wear safety goggles.
In case of eye contact, immediately
flush eyes thoroughly with clean
water. Consult doctor if symptoms
persist.
CAUTION
!
STORAGE: Do not store
resin in open or unlabelled
containers. Store in a cool
(15°F to 100°F), dry place.
DISPOSAL: Dispose of in
accordance with
applicable federal, state/
provincial, and local
regulations.
All nLite®HydroPower DI
units require the use of
mixed bed ion exchange
resin (commonly referred
to as de-ionizing resin).
This resin will require
replacement and handling.
1.5 Attention (General hazards)
Purified water is delivered to the waterfed pole by flexible hose from the
HydroPowerDI system. This introduces a risk of tripping both to worker and
general public. Identify work area with appropriate signage.
Any surface that becomes wet must be identified with appropriate signage to direct
pedestrians and workers away from work area. During wintertime, it is important to avoid
water pooling, which could freeze, creating a dangerous slip hazard.
General hazards associated with the use of water fed poles and deionization equipment1:
•Triphazardtothegeneralpublicwhenusingtrailinghoses.
•Sliphazardpresentedfromwetpathways.
•Sliphazardforoperatorwhenconcentratingonwork.
•Fallsfromheightwhenworkingonatroofs.
•Electrocutionfrompolescomingintocontactwithoverheadpowersource.
•Injuriestoothersfromfallingpolesorfabricofthebuildingthatmaybedislodged.
•Injurytoothersfromfallingpolescausedbyincorrecthandlingorfailureofpole.
•Injurythroughincorrectmanualhandlingofpolesandotherequipment.
•Spreadoflegionelladiseasethroughpoormaintenanceofsystem.
•Hazardsfromcarryingtanks,systemsandequipmentthatareoverloaded,unstable,
unsecured or incorrectly installed within a vehicle.
1. British Window Cleaning Academy (BWCA): Safety in window cleaning using waterfed pole systems

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
6
2. Shipping & Packing
2.1 Receiving inspection of QuickChange resin bags
Unger QuickChange resin bags are carefully checked and packed prior to dispatch.
However, damages caused by shipment cannot be ruled out.
Check packing for exterior damage while delivering person is still present.
2.2 Receiving inspection of entire unit
• Check device for completeness based on illustration (page 8).
Based on your ordered part number following parts my be optional:
TDS-meter (5), Cart (9), Wheels (10)
• Visual inspection of device for shipping damages.
2.3 Claims
Have delivering person confirm any damages to the packing.
Save packing and shipping carton for possible return.
Reports of shipping damages that have not been confirmed by the transport company cannot
be accepted.
Damage detected only after start-up must be reported to the dealer without undue delay, at
the latest, however, 6 months after purchase.
The dealer‘s invoice is absolutely necessary to confirm the date of purchase.
In addition, the general terms and conditions of Unger apply.
HydroPower DI
Shipping & Packing

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
Pfeil ist falsch,
bei den
herkömmlichen
Systemen ist der
Wassereingang oben
links, Wasser läuft im
Filter runter und auf
der anderen Seite
wieder rauf.
Wasserausgang oben
rechts.
Pfeil ist falsch,
bei den
herkömmlichen
Systemen ist der
Wassereingang oben
links, Wasser läuft im
Filter runter und auf
der anderen Seite
wieder rauf.
Wasserausgang oben
rechts.
ENGLISH
7
3. System Overview
Pure Water is water in its purest form, physically processed to
remove the minerals that would otherwise lead to limescale spots
and streaks. Such impurities are referred to as TDS (Total Dissolved
Solids) and are measured in ppm (parts per million). The water is
considered 100 % demineralised (pure) when its TDS is measured at
0 ppm, whilst the 180 ppm is considered as average water hardness.
The new HydroPower DI offer you a bundle of great
benefits, delivered through innovative features:
Fast Lock Opening
The new HydroPower DI offers an easy & quick opening of the vessel
with a big yellow lever. This includes a pressure valve, so pressure
can be released easily before opening. In one movement you can
press and turn the lid and open the full diameter of the vessel.
QuickChange Resin Bags
Pre-packed resin bags save time and simplify resin change process
- no more time-consuming, inconvenient filling up of narrow vessels
and no more spilled, wasted resin. Resin change process as simple
as coffee pad change in a coffee machine - simple removed the used
bag and insert a new one! Each bag is made from a water-
permeable material and contains a pre-proportioned amount of
Unger High Capacity Premium Grade Virgin Mixed Bed resin.
FloWater Technology
Innovative flow distribution design means that that you produce
much more pure water from a single resin refill compared to
previous generation of DI filters. Reduced operational cost through
less frequent resin replacement. Less waste, less time spent on
changing resin.
Standard DI Filter
(e.g. UNGER DI400)
NEW
HYDRO POWER Filter
HIGHER EFFICIENCY
HydroPower DI
System Overview
FastLock Opening
QuickChange
Resin Bags
FloWater Technology
TDS-Meter
Standard Connector

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
5
2
3
4
1
2
6
7
9
10
8
4 4
8
HydroPower DI
Installation & Start up
1. Water IN connection
2. Water OUT connection
3. FastLock opening lever
to release pressure off the
vessel and to open the vessel
4. Handles to carry and open
the vessel.
5. TDS-Meter
to check the water quality
6. Vessel
7. QuickChange Resin Bag(s)
8. Water IN valve
(packed to box)
9. Cart (optional)
10. Set of wheels (optional for
non-cart versions)

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
ENGLISH
9
4. Installation and start-up
4.1 New Machine Set-Up
• Unpack unit:
Inspect HydroPower DI system and all components. Read warnings and
operating manual.
Inspection & Scope of Delivery: Refer to illustration; perform visual inspection and
take inventory of the following items that should be shipped with the system, then test
system for functionality:
a. TDS Meter functional (powers on/off)
b. Fast Lock lever (yellow) – Depress lever, rotate in clockwise direction and
remove top cap assembly.
c. QuickChange Resin Bag(s) installed in unit.
i. DI120 series – One Bag
ii. DI240 series – Two Bags
iii. DI480 series – Four Bags
d. Trolley, wheels and tank clamp system (optional).
• Water supply connection
• The inflowing water must comply with the applicable local Drinking Water
Ordinance.
• It must be assured that the connected watertap is equipped with a rebound valve
to prevent water flowing back into drink water line.
• Inflowing water temperature max. 30°C
• Temperature on site 4° to 40°C; not in immediate vicinity of heater.
• Do not install in the immediate vicinity of heat sources or in direct sun.
• Depending on the composition of the raw water, the treated water is more or less
aggressive. Thus, the parts getting in contact with the treated water must be
made of suitable material (e.g. glass, plastic or aluminium). Copper and other
non-ferrous metals are not suitable.
4.2 Start-up
1. Locate jobsite drinking water supply.
2. Before window cleaning can begin, the system must be connected to a drinking water
supply (1). If well water system is source, it is recommended water quality analysis be
performed prior to application.
3. Unger recommends testing the onsite water supply for TDS (total dissolved solids) (5)
prior to working. Higher TDS levels reduce the DI system‘s capacity. Conversely, lower
TDS levels will increase the amount of water the system is able to produce.
4. Inspect system – ensure Unger’s QuickChange resin bag(s) (7) are properly
installed, with zip-tie facing up and the sewing in parallel to the vessel ledge.

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
A
B
C
10
HydroPower DI
Start up & Operation
a. NOTE: The performance of HydroPower DI is optimized for the usage with Quick-
Change Resin Bags, but it can also be filled with loose resin.
b. Unger’s pre-measured replacement QuickChange resin bags are designed to allow a
controlled resin expansion within a designed safety limit.
5. Set up system in upright position. Choose a stable onsite location;
best to locate near work area.
6. Connect hoses to system (tap water (1) and waterfed pole tubing (2),
(fig. A).
7. Ensure all waterfed pole on/off valves are in “OPEN” position.
8. Turn on tap water supply slowly.
9. Inspect system as it pressurizes and begins producing pure water.
Keep discharge line open and hold down yellow lever (3) to remove
trapped air from system (fig. B). Use only with drinking water.
10. Turn on TDS meter (5) and inspect pure water quality (fig. C).
For first time use, the TDS meter should read 000.
Stop use when TDS meter reads 010 ppm and change resin.
Adjust flow at waterfed pole brush head by:
a. Tap water valve or
b. Waterfed pole control (on/off) valve.
11. You are ready to start cleaning.
4.3 During operation
1. Periodically inspect the HydroPower DI system during use. Ensure hoses are proper-
ly attached. Inspect system for leaks and proper fit of top cap assembly.
2. Take care when working to ensure there is enough slack in waterfed pole tubing.
This tubing is connected to the top of the unit, and excessive tugging may cause the
system to tip over.
3. Drinking water flows into the system’s lower connection port via tap pressure and
flows upwards through the HydroPower DI vessel. Pure Water exits through the top
connection. When plumbing line pressures fall below 3 bar (44psi),
a reduction in flow rates will be noticeable.
4. Use the included water valve on Water IN valve (8) to regulate the water stream
inside the HydroPower DI.

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
ENGLISH
11
HydroPower DI
EcoFlo-Water Flow Optimizer
5. EcoFlo - Water Flow Optimizer
Depending on the pressure of the incoming water supply, using the HydroPower EcoFlo
insert allows you to restrict the water flow to an optimum level of between 120 – 150 L per
hour, which is ideal for regular glass cleaning. Optimising the water flow in this way allows
you to use less pure water, extending the lifetime and performance of a single resin refill in
the HydroPower DI Filters by at least 20%, without compromising the quality of your work.
• Automatically reduces the water flow – see table below for details.
• Fits any industry standard valves.
• Can be fitted, removed or replaced inside the water flow valve in seconds – simple.
• Compatible with all HydroPower DI Filters, regardless of size.
• NOTE: By reducing the flow it will take longer to fill a pure water
vessel / storage tank when using EcoFlo.
To speed up the filling process you should
remove the EcoFlo insert from the valve.
HOW TO FIT THE ECOFLO:
12 3
4 5 6
!
O-Ring must
be positioned
AFTER the
EcoFlo!
ATTENTION:
EcoFlo must be inserted into the Incoming
Water Valve (Inlet) only, located at the
bottom of the filter.
Inserting EcoFlo into the Outgoing Water Valve
(Outlet) may result in a build up of pressure inside the
filter vessel, potentially causing damage to the unit.
Do not use the EcoFlo when then pressure of
the incoming water is below 3 Bar.
Order your free EcoFlo:
PRESSURE
Bar
Output* with EcoFlo
6180 L/hour
5150 L/hour
4120 L/hour
3
Do not use EcoFlo!
* Pure Water Output at the brush
with EcoFlo and with Pole
Hose, 25 m
EU: www.ungerglobal.com/ecoflo
UK: www.ungerglobal.com/uk/free-ecoflo

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
D
E
F
F2
G
H
12
HydroPower DI
Resin Change
6. Resin Change
6.1 Capacity
Since the DI resin filter is used at different filling points with various degrees of
hardness, the available quantity of completely desalinated water differs.
The conductivity measurement is used to monitor water quality.
If a conductivity measurement indicates a value of > 10 ppm, the resin is depleted.
The QuickChange resin bag or the loose resin must be replaced.
Raw water quality can be determined in various ways.
a) Information from responsible water works (indication of overall hardness).
b) By measuring the mineral content with Unger TDS-Meter (5).
6.2 Resin Change - QuickChange resin bags
Unger’s pre-measured replacement QuickChange resin bags are designed
to allow a controlled resin expansion within a designed safety limit.
1. SHUT OFF TAP WATER SUPPLY VALVE
a. Shut off tap water supply and open pole tubing discharge line.
b. Disconnect feed tap water line and allow system to drain.
2. REMOVE TOP CAP ASSEMBLY:
a. Press yellow FastLock Opening lever (3) (fig. D) to to get pressure
out of the vessel, fix the base unit with your feet, press the top cap
slightly down and use a counter-clockwise 1/8 turn to release top cap
assembly; remove and set aside (fig. E).
b. Open all valves to facilitate the removal of the bags.
c. Reach into housing and remove exhausted resin bag(s) by hand (fig. F);
discard according to local regulations.
3. REPLACE RESIN BAG
a. Install new resin bag(s) by hand (fig. F) – be sure to seat bags with
zip-tie facing up and sewing in parallel to vessel ledge (fig. F2).
Otherwise resin capacity will not completely be used and ppm value is
too high.
b. Inspect system head assembly: O-ring and FloWater distribution
filter are in good condition. Re-coat o-ring with silicone lubricant only.
c. Re-install DI System head assembly, press it slightly, then turn it 1/8
clockwise while fixing the base unit with your feet.
d. System is ready to be operated.
4. RECONNECT WATERFED POLE TUBING (fig. G)
a. Turn “ON“ water supply at tap.
b. Inspect system as it pressurizes.
c. Keep discharge line open and hold down yellow lever (3) to remove
trapped air from system.
5. TEST SYSTEM TDS (fig. H)

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
I
J
K
L
M
ENGLISH
13
6.3 Resin Change - loose resin
NOTE: Pay attention to not overfill the vessel. Only use new, saturated wet resin. Never use
dry resin as this will expand a lot and can damage the system.
1. SHUT OFF TAP WATER SUPPLY VALVE
a. Shut off tap water supply and open pole tubing discharge line.
b. Disconnect feeding tap water line and allow system to drain.
2. REMOVE TOP CAP ASSEMBLY:
a. Press yellow FastLock Opening lever (3) to get pressure out of the vessel,
(fig. I) fix the base unit with your feet, press the top cap
slightly down and use a counter-clockwise 1/8 turn to release top cap
assembly; remove and set aside (fig. J).
b. Empty the resin out of the vessel by tipping it over or by using a small
shovel; discard according to local regulations.
3. REPLACE RESIN
a. Fill with new resin out of a bag (fig. K). Pay attention to not overfill the vessel.
Only use new, saturated wet resin. Never use dry resin as this will expand
a lot and can damage the system.
b. Only fill with the following quantities into the vessel:
Small system: max. 6,25l wet resin
Medium system: max.12,5l wet resin
Big system: max. 25l wet resin
1 cm from the top of the resin to the ledge of the vessel
must stay unfilled to prevent damage.
c. Inspect system head assembly: O-ring and FloWater distribution
filter are in good condition. Re-coat O-ring with silicone lubricant only.
Pay attention that no resin beads are in the screwing mechanism.
d. Re-install DI System head assembly, press it slightly, then turn it 1/8
clockwise while fixing the base unit with your feet.
e. System is ready to be operated.
4. RECONNECT WATERFED POLE TUBING (fig. L)
a. Turn “ON“ water supply at tap.
b. Inspect system as it pressurizes.
c. Keep discharge line open and hold down yellow lever (3) to remove
trapped air from system.
5. TEST SYSTEM TDS (fig. M)
ATTENTION: Spilled resin is a slipping hazard. Clean up spilled resin immediately.
HydroPower DI
Resin Change

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
14
HydroPower DI
Technical Data
7. Technical Data
* These values are based on the „DIxxT“ variation, including resin bags, TDS-meter, excluding wheels
or cart. For variation „C“ with cart please consider following values:
Size incl. wheels (WxDxH): 55 x 108 x 67 cm. Weight (cart): 12,30 kg.
WARNINGS: Read Before Using!
• Do not drink the water produced by this system. Water produced by the
HydroPower DI system is too pure and will rob the body of vital minerals and nutrients
if imbibed in quantity.
• Prior to opening vessel housings, turn off water and relieve pressure in hose.
Press the yellow FastLock Opening lever on top to get pressure out of the
housings.
• If you use the QuickChange resin bags (recommended), pay attention on correct
position (be sure to seat bags with zip-tie facing up and sewing in parallel to vessel
ledge.
• If you use loose resin, pay attention on correct filling and prevent overfilling.
• After a longer non-usage period, flash the filter thoroughly so that only fresh water is
in.
TIPS:
• Clean highest windows first. Start at the top of each window and clean using vertical strokes with moderate speed.
• DI Systems eliminate spotting so when you are finished cleaning, let the surfaces air dry - no need to wipe.
(NOTE: First time cleaning with pure water may necessitate washing windows twice for maximum results.
Factor DI12T DI24T DI48T
Shipping weight incl resin* 11 kg 20 kg 35 kg
Max. recommended power (l/min.) 6 10 20
Height* 35 cm 59 cm 116 cm
Inner Diameter 20 20 20
Dimension of base 28 x 30cm 28 x 30cm 28 x 30cm
QuickChange Resin Bags 1 2 4
Max. fill with loose resin 6,25 l 12,5 l 25 l
Max. permanent pressure (bar) 8 8 8
Max. water temp. (°C) 30 30 30
Min. water temp. (°C) 2 2 2

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
Info
19038 4 casters for direct fix to
unit‘s base
18330
Info
DITDS
TDS-meter, TDS cover,
connections for units that are
not equipped with TDS
Info
DIB61 1 bag in air tight bucket
DIB64 4 bags in air tight bucket
Info
18503
hard, for female connector
18502 soft, for male connector
Info
DITCP complete with TDS-metre
18549 without TDS-metre
Info
DISKT 5 O-rings, care solution
19021 1x O-Ring
Info
DICRT Transportation Cart
ENGLISH
15
8. Spare Parts
NOTE: Due to safety reasons, unauthorised modifications are not allowed. Original parts
and accessories are specifically designed for this device. Any liability by the manufacturer
for damages resulting from modifications to the device or from using parts other than
original parts is excluded.
HydroPower DI
Spare Parts
All product images in this manual for illustration purpose only. Actual product may vary.
DIB64
HydroPower DI
WATER FLOW VALVE
Part #
HydroPower DI
TDS UPGRADE KIT
Part #
HydroPower DI
QUICK CHANGE RESIN BAGS
Part #
HydroPower DI
TRANSPORT PLUG
Part #
HydroPower DI
TOP CAP
Part #
HydroPower DI
SEALING KIT
Part #
HydroPower DI
SET OF CASTERS
Part #
HydroPower DI
CART
Part #
Info
DIPRE
Pre-Filter + Water Distribution
HydroPower DI
FLO WATER UNIT
Part #

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
16
HydroPower DI
Inhalt
Vorwort........................................................................................................... 17
1. Sicherheitsbestimmungen.......................................................................... 18
1.1 Allgemeines .................................................................................................... 18
1.2 Bestimmungsgemäße Verwendung ............................................................... 18
1.3 Betriebstemperaturen, Drücke und Anschlüsse............................................ 18
1.4 Umbauten und Veränderungen an dem Gerät ............................................... 18
1.5. Zu Beachten (Allgemeine Gefahren) ............................................................. 19
2. Transport und Verpackung.......................................................................... 20
2.1 Eingangskontrolle der QuickChange Harzbeutel........................................... 20
2.2 Eingangskontrolle der gesamten Einheit....................................................... 20
2.3 Beanstandungen............................................................................................. 20
3. Systemübersicht......................................................................................... 21
4. Installation und Inbetriebnahme ................................................................ 23
4.1 Installation eines neuen Gerätes.................................................................... 23
4.2 Inbetriebnahme............................................................................................... 23
4.3 Bedienung ....................................................................................................... 24
5. EcoFlo - Wasserflussoptimierer ................................................................. 25
6. Harzwechsel ............................................................................................... 26
6.1 Kapazität ......................................................................................................... 26
6.2 Harzwechsel: QuickChange Harzbeutel (empfohlen) .................................... 26
6.3 Harzwechsel: loser Harz ................................................................................ 27
7. Technische Daten........................................................................................ 28
7.1 Warnhinweise.................................................................................................. 28
7.2 Tipps................................................................................................................ 28
8. Ersatzteile .................................................................................................. 29

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
DEUTSCH
17
HydroPower DI
Vorwort
Vorwort
Mit der Wahl der Unger Vollentsalzung als Wasseraufbereitungssystem haben Sie sich für
ein hochwertiges Produkt entschieden.
Die Vollentsalzung arbeitet nach dem Prinzip des Ionenaustausches. Die gelösten
Mineralstoffe, die für Härtebildung und den Leitwert (TDS-Wert) verantwortlich sind,
werden dem Wasser entzogen.
Der Einsatz dieses Aufbereitungsfilters hat folgende Vorteile:
• Die Glasreinigung ist ohne weitere Mittel, nur mit einer Wasserstange und einer
Bürste möglich.
• Bevor Sie die Anlage installieren und in Betrieb nehmen, beachten Sie unbedingt die
Sicherheitsvorschriften und die Hinweise für die Installation und Wartung in dieser
Anleitung.
• Der Hersteller haftet nicht für die Funktion des Gerätes:
• Bei Handhabung, die nicht der üblichen Benutzung entspricht.
• Bei anderen Einsatzzwecken, die nicht in der Anleitung genannt sind (nicht bestim-
mungsgemäßem Gebrauch).
• Bei Missachtung der Sicherheitsvorschriften.
Schäden am Aufbereitungsfilter drohen bei:
• Bedienungs- und Installationsfehlern.
• Falsche Handhabung bei Verwendung von losem Harz (Überfüllung, Ausdehnung)
• Tauschen von Ersatzteilen, die nicht in der offiziellen Ersatzteilliste von Unger
aufgeführt sind.
• Selbständige Durchführung baulicher Veränderungen.
• Nicht einhalten der Sicherheitsbestimmungen (z.B. Frostschutz).
• Verwendung chemikalischer Zusätze.
• Mangelnder Wartung.
Sämtliche Wartungs- und Reparaturarbeiten sind von einem Fachmann auszuführen.
Wenden Sie sich diesbezüglich an Ihren Fachhändler.
Benutzen Sie nur Original Unger – Ersatzteile (gemäß Ersatzteilliste).
Wichtig für alle Rückfragen und Ersatzteilbestellungen ist die Angabe der genauen
Gerätebezeichnung.

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
18
1. Sicherheitsbestimmungen
1.1 Allgemeines
Beachten Sie die jeweils gültigen Verordnungen und Vorschriften, sowie die geltenden
Unfallverhütungsvorschriften.
Bei evtl. auftretenden Wasserschäden übernimmt Unger keine Haftung.
Stellen Sie sicher, dass im Anwendungsbereich ein ausreichender Wasserabfluss
vorhanden ist. Bei längeren Stillstandzeiten (z.B. am Wochenende) den Zulaufhahn schließen.
Transport: Stellen Sie sicher, dass nLite®HydroPowerDI Tank und Karre gut gesichert auf einem
Anhänger, Van oder Lastwagen transportiert werden.
Der Fensterreinigungs-Auftragnehmer muss alle geltenden lokalen, staatlichen / Landes-,
Bundes Erlaubnis-und Registrierungsanforderungen erfüllen. Er muss auch strikt alle
geltenden lokalen, staatlichen / Landes-und Bundesarbeitsgesetze und Sicherheitsvorschriften
und Normen einhalten.
1.2 Bestimmungsgemäße Verwendung
Von diesem Gerät können Gefahren ausgehen, wenn es unsachgemäß installiert wurde, nicht
regelmäßig gewartet wird oder zu nicht bestimmungsgemäßem Gebrauch eingesetzt wird. Die-
ses Gerät ist nur für die Wasseraufbereitung zum Erreichen einer optimalen Wasserqualität zur
Glasreinigung zu verwenden. Jeder andere Einsatz, insbesondere die Wasseraufbereitung zur
Nahrungsmittelherstellung (z.B. Getränke), gilt als nicht bestimmungsgemäß und ist verboten.
Bei der Arbeit an einer Trinkwasserleitung muss sichergestellt sein, dass der verwendete Was-
serhahn am Gebäude ein Rückstoßventil besitzt um zu vermeiden, dass Wasser zurück in die
Trinkwasserleitung läuft!
Sofern mit anderen Wasserquellen, z.B. mit Brunnenwasser, gearbeitet wird, muss zuvor eine
Wasseranalyse vorliegen um die Eignung des Wassers für dieses System festzustellen. Verun-
reinigungen des Wassers können das System schädigen und das Reinigungsergebnis ver-
schlechtern.
1.3 Betriebstemperaturen, Drücke und Anschlüsse
Die Anlage ist vor Frost zu schützen. Die Temperaturen im Betriebsraum muss mindestens 4°C
betragen. Die Wassertemperatur darf 30°C und der Betriebsdruck 8 Bar nicht überschreiten.
Das aufbereitete Wasser ist je nach Rohwasserzusammensetzung mehr oder weniger aggres-
siv. Deshalb müssen die Teile, die mit dem aufbereiteten Wasser in Berührung kommen, aus
geeignetem Material bestehen.
1.4 Umbauten und Veränderungen an dem Gerät
Eigenmächtige Veränderungen sind aus Sicherheitsgründen nicht gestattet. Originalteile und
Zubehör sind speziell für das Gerät konzipiert. Für Schäden, die durch Veränderungen am Gerät
oder durch die Verwendung nicht originaler Teile entstehen, ist jegliche Haftung des Herstellers
ausgeschlossen.
HydroPower DI
Sicherheitsbestimmungen

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower www.ungerglobal.com/hydropower
DEUTSCH
19
HydroPower DI
Allgemeine Gefahren
Inhalt unter Druck, kann zu schweren Verlet-
zungen oder zum Tod durch Tankriss führen.
Vor dem Start des Systems:
•BehälteraufRisseprüfen.
•PrüfenobDeckelrichtigverriegeltist.
•Arbeistdrucknichtüber116psi(8Bar).
•HaltenSiedieWasserleitungoffenund
drücken vor dem Öffnen des Behälters den
gelben Hebel, um Luft entweichen zu lassen.
•NurzumGebrauchmitTrinkwasser
Vor der Wartung des Systems:
•SchließenSiedieTrinkwasserzufuhrund
öffnen die Ventile am System.
•TrennenSiedieWasserversorgungund 
lassen den Behälter ablaufen.
GEFAHR
!
Verschütterter Harz ist eine Rutsch-
gefahr. Boden sofort reinigen.
WARNUNG
!
Harz kann zu Hautreizungen führen.
Hautkontakt vermeiden. Nach der
Anwendung gründlich die Hände
waschen. Kann Augenreizungen
verursachen. Augenkontakt
vermeiden. Schutzbrille tragen.
Bei Augenkontakt sofort die Augen
gründlich mit klarem Wasser
spülen. Arzt konsultieren wenn
Reizung nicht zurück geht.
ACHTUNG
!
LAGERUNG: Harz nicht in
offenen oder unbeschrif-
teten Behältern lagern.
Lagerung an kühlem,
trockenen Ort (10°C-40°C).
ENTSORGUNG: nach
anwendbaren Bundes-,
Landes-/ regionalen und
lokalen Vorschriften.
Alle nLite®HydroPower DI
Systeme erfordern den
Einsatz von Mischbett-Ion-
enaustauschharz. Dieses
Harz erfordert Austausch
bzw. Regeneration.
1.5 Zu beachten (Allgemeine Gefahren)
Das gefilterte, reine Wasser wird vom HydroPowerDI System durch einen flexiblen
Schlauch zur wasserführenden Stange geleitet. Das birgt die Gefahr von Stolperfallen
sowohl für den Anwender als auch für vorbeigehende Personen. Sichern Sie die Arbeits-
stätte entsprechend z.B. durch Warnschilder.
Jede nasse Oberfläche muss durch entsprechende Warnschilder für Anwender und Fuß-
gänger deutlich erkennbar sein. Gerade im Winter ist es wichtig, größere Wasserlachen
und somit Eisflächen, die zu Ausrutsch-Unfällen führen können, zu vermeiden.
Allgemeine Gefahren in Verbindung mit dem Einsatz von wasserführenden Stangen und
Entmineralisierungs-Ausstattung sind1:
•StolpergefahrfürdieÖffentlichkeitbeiderVerwendungvonlangenSchläuchen.
•RutschgefahrdurchnasseWege.
•RutschgefahrfürdieAnwender,beiKonzentrationaufdieArbeit.
•AbstürzebeimArbeitenaufFlachdächern.
•StromschlagausStangeninKontaktmitStromhochleitungen.
•VerletzungendurchherabfallendeTeilevonderStangeodervomGebäude.
•VerletzungendurchfalscheHandhabungvonStangenundanderenGeräten.
•VerbreitungvonLegionellen-ErkrankungendurchschlechteWartungdesSystems.
•Gefahren,dievonmitTanks,AnlagenundAusrüstungausgehen,dieüberladensind,
instabil, unsicher oder falsch in einem Fahrzeug installiert sind.
1. British Window Cleaning Academy (BWCA): Sicherheit bei der Glasreinigung durch Verwendung wasserführender Stangen

Quality Tools for Smart Cleaning
www.ungerglobal.com/hydropower
20
2. Transport & Verpackung
2.1 Eingangskontrolle der QuickChange Harzbeutel
Unger QuickChange Harzbeutel werden vor dem Versand sorgfältig geprüft und in luftdich-
ten Eimern verpackt. Versandschäden können jedoch nie ausgeschlossen werden.
Kontrollieren Sie im Beisein des Anlieferers die Verpackung auf äußere Schäden.
2.2 Eingangskontrolle der gesamten Einheit
• Vollständigkeit des Gerätes anhand der Abbildung (Seite 22) prüfen.
Je nachdem welche Artikelnummer Sie erworben haben, sind folgende Bestandteile
optional: TDS-Meter (5), Karre (9), Räder (10)
• Sichtprüfung des Gerätes auf Transportschäden.
2.3 Beanstandungen
Sollte die Verpackung beschädigt sein, lassen Sie sich dies vom Anlieferer bestätigen.
Bewahren Sie die Verpackung und den Versandkarton für eine evtl. Rücksendung auf.
Meldungen von Transportschäden, die nicht vom Transportunternehmen bestätigt wurden,
können nicht anerkannt werden.
Schäden die erst nach Inbetriebnahme festgestellt wurden müssen unverzüglich,
spätestens jedoch 6 Monate nach Kauf, dem Fachhändler gemeldet werden.
Zur Bestätigung des Kaufdatums ist die Rechnung des Händlers zwingend erforderlich.
Im Weiteren gelten die AGB der Firma Unger.
HydroPower DI
Transport & Verpackung
