Uni-ram UG2000D Series User manual

USER MANUAL
UG2000D SERIES
AUTOMATIC SPRAY GUN CLEANERS
REV 2019-02
WWW.UNIRAM.COM
CORPORATION
••381 Bentley Street, Markham ON L3R 9T2
• Tel. [phone]
• [email protected]

2
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
INTRODUCTION
Uni-ram holds many patents on designs used in its innovative products. Every machine is tested
for compliance with Quality Assurance standards. Follow the directions in this manual under Setup,
Operation and Maintenance in order to operate this machine safely and effectively. Not following these
instruction can lead to malfunction or damage to the machine. Ensure that the manual is readily avail-
able for the operator at all times. If you have any questions about the operation of this machine, call your
Distributor or Uni-Ram Service Engineer at 1-800-417- 9133.
COMMON FEATURES
• Automatic Wash
• Clean 2 Spray Guns and 2 Pots at the same time.
• 14 Cleaning Jets with swirl action.
• Shipping Size and Weight: 28" W x 17" D x 42" H, 91 LBS 41 KG.
CAUTIONS AND WARNINGS
• Always disconnect this machine from power sources before performing maintenance.
• Do not smoke or use near open flames, sparks or heat.
• Make sure all ground wires are connected and that unit itself is grounded properly.
SAFETY EQUIPMENT
• Wear safety eyeware, respiratory protection and protective clothing.
• Wear deluxe extended length neoprene gloves; SAS PN 6588 or Thicksters PN 6602-20 through
6605-20.
SETUP
DELIVERY INSPECTION
• Inspect the shipping carton for any sign of transport damage. Carefully remove the unit from the ship-
ping carton and check the unit for damage. Report any transport damage immediately to the carrier
and to Uni-ram Corporation. Initiate a freight claim with the carrier. The manufacturer is not respon-
sible for the freight damage.
Bag of accessories contains the following:
• Push on nozzle extension for disposable cup (110-430PPS).
• Push on nozzle extension for conventional cup system(110-430).
• Trigger lock spring and plug package (140-2340) (2 in a package).

3
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02
Diaphragm Pump
Drain Hose
(rear)
Suction hose for Wash
pail
Commercial Wash Pail
of solvent provided by
User.
Timer
Drain Valve
(inside)
UG2000D

4
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
LOCATION
Position the unit in a well-ventilated area away from sparks, heat and open flames, at least 6 " from the
back wall.
AIR SUPPLY
• Connect a male air supply adapter (not supplied) into the female Air Inlet on the unit. The male air
supply adapter is 1/4" NPT.
• Connect the female air supply hose to the adapter. The air supply hose must be at least 3/8"
inside diameter. The air supply pressure must be at least 85 PSI and the sup-
ply air must be free from contaminants such as water, dust, rust, tar and
grease. If the air supply is not clean and dry install a moisture filter. The
operation and longevity of the pump and other components depends on
clean dry supply air.
• To prevent damage to the Diaphragm Pump an internal Air Pressure Regulator has been
installed to limit the air pressure to 85 PSI. Do not install a second air pressure regulator or use a
pressure set below 85 PSI.
GROUNDING
• Connect the green ground wire at the back of the unit to a ground in the building.
Note: The pump and metal tube that inserts into each pail are grounded.
SOLVENT SELECTION
The adhesion quality of automotive paint has dramatically improved in recent years. The choice of sol-
vent is critical. Only use good quality solvent that is formulated for your paint and intended for use with
automatic spray guns cleaners. DO NOT USE CHLORINATED SOLVENT.
PAIL SETUP
• Place a 5 gallon pail of commercial solvent inside the cabinet. Place the suction hose and drain
valve in the solvent pail.
• Open the drain valve (vertical position).
Ring Terminal
DRAIN VALVE IS OPEN
(HANDLE IN VERTICAL POSITION).
DRAIN VALVE IS CLOSED
(HANDLE IN HORIZONTAL POSITION).

5
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02
Disposable
Cup
Pre clean Fluid
Passageway
PRE-CLEAN
• Disconnect the spray gun from the air hose. The method for the disposable cup is described rst followed by
the method for the conventional cup.
PRE-CLEAN - DISPOSABLE CUP
• Disconnect the dispsable cup as shown in photos to
the right and far ght.
• Squirt solvent into the disposable cup adapter, shown
in photo on far right.
• Pull the gun’s trigger to ush the solvent through the uid
channel and into the paint waste container (not supplied)
for later disposal.
.
PRE-CLEAN - CONVENTIONAL CUP
• Disconnect the cap and pour the paint waste into a paint waste container (not supplied).
CLEANING SPRAY GUNS AND CUPS
• Remove digital air gauge if so equipped.
• Loosen the air cap of the spray gun two full turns.
• Lock the trigger in the open position with the Trigger Lock Spring.
See photos below.
Remove
Gauge
Loosen
Cap
Trigger Lock Spring
On Spray Gun

6
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
SPRAY GUN PLACED IN TANK
INSTALLING SPRAY GUNS IN TANK
•Place the spray gun on the nozzle with the cap facing the corner.
Nozzle Extension
for disposable cups
Location for Push On
Nozzle Extension
Caps points to
the corner jets
Plastic Plug
Location for Conventional
Cup

7
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02

MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
Prevent Solvent From Entering the Air Passage of Spray Gun:
insert the plastic plug into the air tting of the spray gun
as in the photo below. Positive air will ow through the
passage way to the cap during cleaning. If the air passage
way has a a male tting attach the knurled female nut to
prevent sovlent from entering the air passage way.
This tting is located on the chain with the
trigger clamp.
• Close the lid of the spray tank
and turn the "Auto Wash Timer"
clockwise as in photo below
to initiate cleaning. The wash
cycle takes about 60 seconds.
REPLACING SOLVENT:
• Replace the solvent when the solvent has lost its cleaning
eectiveness or after approximately 100 cleanings.
• Close the drain valve (horizontal position).
• Remove the pail of used solvent and install a pail of new solvent.
Dispose of the used solvent in a manner compliant with the laws in
the municipality.
Return the suction hose and drain hose to the pail.
MAINTENANCE:
• Clean the tank of the gun cleaner daily.
Plastic Plug insterted into the air pas-
sage way of the spray gun
Drain Valve in
Closed Position

9
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02
TROUBLE SHOOTING
PROBLEM REASON CORRECTIVE ACTION
WASH PUMP MAKES
PUMPING SOUND BUT
SOLVENT DOES NOT FLOW
FROM THE JETS
Drain valve closed
Open drain valve (put in vertical position), if
not already open
Liquid level too low
Check wash liquid level. Add liquid if less
than1/2 full.
Fill to 3 gal (11 L).
Debris in pump or suction and
output hose
Follow Procedure 1, "Blocked Fluid
Passage in Diaphragm pump"
WASH PUMP MAKES
HISSING SOUND AND
SOLVENT DOES NOT FLOW
Water or contaminants are in
air line of pump.
Follow Procedure 2. "Blocked Air Passage
in Diaphragm Pump".
WASH PUMP DOES NOT
STOP UNLESS TIMER IS
TURNED BY HAND OR
Defective Timer Replace Timer, PN 115-200K.
AIR IS SHUT OFF. WASH
PUMP DOES NOTSTART.
TIMER KNOB SPINS BACK
WHEN TURNED
Defective Timer Replace Timer. PN 115-200K.

10
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
Trouble shooting continued
SYMPTOM REASON CORRECTIVE ACTION
INSIDE WALL OF TANK IS
COATED WITH PAINTEVEN
THOUGH OPERATOR
MAINTAINS TANK
Liquid lacks cleaning strength
Replace solvent / water and AQUA-
KLEEN in pail. Consider a solvent
that is formulated for type of paint
used and for use with automatic
spray gun cleaning.
Trigger not locked in open
position
Use Trigger Lock Spring PN 120-350
Spray gun is not properly
installed on to nozzle
Re-install with proper adapter
Incompatible solvent
pp
solvent formulated for type of paint
Low pressure in air supply
p
of 85 PSI
Plugged jets
yg
through the jets. If not successful,
SOLVENTAPPEARS RED or
ORANGE
Water in solvent is corroding
metal pail
Replace or recycle wash solvent
GUNS NOT CLEAN, WASH
SOLVENTIS MILKY WHITE
Wash solvent is contaminated
with water
Replace or recycle wash solvent
Not enough liquid in clean
rinse pail (right side)
Add liquid
Rinse Pump is leaking from a
crack caused by corrosion
due to acidic or chlorine
contaminated solvent
Replace rinse pump, PN URP-100SF
Faulty Valve
CLEAN RINSE IS DIRTY
Replace Combination Valve, PN
UVB-400KIT
GUNS NOT CLEAN, PUMP
WORKING, SOLVENTFLOW
NORMAL
CLEAN RINSE DOES NOT
WORK

11
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02
TROUBLESHOOTING PROCEDURES PROCEDURE 1
Blocked Fluid Passage In Diaphagm Pump
If the pump sounds like it is working but liquid does not flow,
clear the fluid passage as follows:
• Remove suction tube from the pail and blow air at 85 PSI
into the INLET Liquid Hose (see diagram). Step on foot
pedal to activate pump. This procedure may have to be
repeated several times. If this procedure does not help,
blow some water into the suction hose using a spray gun,
wait one minute and step on foot pedal to activate pump.
This procedure may have to be repeated several times. If
this procedure does not work, the pump must be replaced.
If you need to replace the pump call the Uni-ram Service
Engineer. The warranty on the diaphragm pump is two
years from date of purchase.
This procedure will also clear a blockage in the fluid line for the
brush. Follow the same procedure to clear a blockage in the automatic nozzle except turn the timer
instead of stepping on the foot pedal.
PROCEDURE 2
Blocked Air Passage In Diaphragm Pump
If there is a steady hissing sound and the pump is not
cycling, the spool valve has stalled due to a blocked air pas-
sage. Follow the procedure below to clear the blockage.
• Connect a blow gun to an 85 PSI source. Locate the
blue hose that extends from the air exhaust port of
the diaphragm pump. Use a blow gun to blow air into
the open end of this hose. Turn timer. If the procedure
is successful, the pump will start working. The proce-
dure may have to be repeated several times. If this
procedure does not work, replace the pump.
• Cause: Contaminants in the air supply (water, oil,
solid particles etc)
• Preventative Action: If necessary, install an Airline
(Moisture) Filter.
PROCEDURE 3
Blocked Passage in Air Line
The components in the air line are the diaphragm pump, air valve, foot pedal, 3-way ball valve
and regulator. See the Flow Diagram and the section: Replacement Parts.
To troubleshoot a component:
1) Disconnect the air line to the component using the quick disconnect.
2) Step on foot pedal and check for presence of positive air pressure in the air line. If there is ample
positive air pressure, replace the component.
If air pressure is absent, there is a faulty component upstream. Reconnect the air line and check the
operation of the next component upstream by following steps 1 and 2 above.

12
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
UG4000E FLOW DIAGRAM
Use the diagram to trace the flow of compressed air and solvent.

13
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-02
REPLACEMENT PARTS
Part No. Description
110-430 Nozzle Adapter, Push On, Conventional Systems Only
110-430PPS Nozzle Adapter, Push On, Disposable and Conventional Systems
780-3530 Nozzle Adapter, Disposable Cup Systems Only
100-413F Paint Cap Holder
115-200/K Mechanical Timer Assembly, 5 minutes
140-230 Air Passage Plug
140-2340 Trigger Clamp & Plug Kit
113-800 Flow-Through Brush Assembly
100-8335 GROUND WIRE,14G, GREEN, 36" L
100-835 GROUND WIRE,18AWG, GREEN, 4 FT
UDP4TA DUAL DIAPHRAGM PUMP, 4"

14
MANUAL - UG2000 SERIES SPRAY GUN CLEANERS REVISED 2019-03
Full Product Warranty
These Uni-ram products have been engineered and manufactured to high performance standards.
Each unit has been subjected to detailed factory testing before shipment.
This product comes with a one-year full warranty from the date of purchase. Uni-ram Corporation
reserves the right to repair or replace the unit, free of charge, to the original purchaser if a part is found
to be defective in material or workmanship as determined by factory service personnel. The items
listed below under "Conditions of Warranty" as consumables are not covered.
Uni-ram reserves the right to direct the customer to ship the unit collect to the Uni-ram factory or to an
approved Service Center for repair using the Uni-ram Return Goods Procedure or to repair the unit on-
site. To prevent damage in transport, the purchaser must ship the unit in the original packaging or use
alternate adequate packaging. All units must be shipped clean and free of liquid.
Diaphragm Pump:
We are pleased to advise that the warranty on the diaphragm pump, the heart of the spray gun
cleaner, comes with a 2 year replacement warranty. If, in the unlikely event your diaphragm pump fails
during the first two years of service, call Uni-ram Service at 1-800-417-9133. We will send you a new
pump free of charge and arrange for the return of your original pump.
Conditions of Warranty:
As Uni-ram Corporation has no control over the working conditions or circumstances under which the
purchaser stores, handles or uses the product, Uni-ram makes no warranty or claim, either expressed
or implied with respect to this product's fitness for any purpose or the result to be obtained from its
use. This condition applies to the sale of all products and no representative or distributor of Uni-ram
Corporation has the authority to waive or change these conditions.
This warranty applies only to the original purchaser and does not apply if the unit has been misused,
overloaded, neglected, altered or used for any purpose other than those specified in the operating and
installation instructions. Deterioration due to normal wear is not covered by this warranty. Damage due
to accident, transportation, fire, floods or acts of God is also not covered. Units whose serial numbers
have been altered or removed are not covered. The warranty is invalid if unauthorized chemicals as
noted in the manual or liquids with acid content are used in this unit. Unauthorized attempts at self-
repair or alterations by the owner also invalidate this warranty. Interior or exterior finishes are not cov-
ered by this warranty.
Consumable Items are not covered by this warranty (eg: gaskets, screens, bags, filters, nozzles and
air jets).
This warranty replaces all other warranties expressed or implied by statute or otherwise.
To make a claim, call Uni-ram Service at 1-800-417-9133 and quote the serial number of the unit.
