Unic UGC5005A User manual

105 - Grid ilter x 2
128 - Work Screen x 2
2050 - Quick Release Coupling x1
736 - Hook x 2
2030 - Extended Nozzle Kit includes x 4
UC 25- ilter Kit x 1
UC 25 ilter Kit includes:-
382 - Water Bucket
320 - Stainless steel filter basket
U B25 - ilter bags
UC100 - Uni-Clean, detergent booster
UP5 - Uni-Pure, bacterial agent
UC 40 - Uni-Coag, coagulant for cleaning
contaminated water
What it should come with
Also available:
Installation fittings:
We also recommend:
INTERNATIONAL
The professional’schoice
Water & Solvent Spray Gun Cleaner
Operating
Instructions
UGC5005A
786 - Air, Dirt & Water trap
783 - Nipple
RA3 3” Angle lange R3 3” Angle lange lat 6R5 6” to 5” Reducer 3 3” lange lat 5R3 5” to 3” Reducer
D3 3” lexi Ducting Gate Valve 803
Solvent Recycler Paint Can Crusher Paper Compactor

Warranty Conditions
UGC5005A - Water & Solvent Spray Gun Cleaner
1 Subject to the other Warranty Conditions the Company
1.1 Warrants that upon delivery, and for a period of 12 months from the date of delivery of the spray gun cleaning
machine (‘the Machine’), the Machine shall:
(a) Be of satisfactory quality within the meaning of the Sale of Goods Act 1979; and
(b) Be reasonably fit for the purpose of cleaning spray guns;
1.2 guarantees the pump forming part of the Machine against all mechanical defects arising from faulty workmanship or
materials for five years from the date of purchase.
2 Subject to the other Warranty Conditions if the Machine is used only in the United Kingdom and the Customer has on
purchase of the Machine entered into a 5 Year Service Agreement with the Company for the servicing of the Machine
then whilst that 5 Year Service Agreement remains in force the Company guarantees the Machine against all
mechanical defects arising from faulty workmanship or materials for five years from the date of purchase.
3 The guarantees in Warranty Conditions 1 and 2 do not extend to consumable components such as filters, jets and
flow-through brush as specified in the manual for the Machine. The Buyer acknowledges that in normal usage these
parts may from time to time require replacement.
4 The Company shall not be liable for a breach of any of the warranties in Warranty Conditions 1 and 2 if:
(a) the Buyer does not notify the defect to the Company and if so requested by the Company complete and send to the
Company the Company’s defect report form, and, if the defect is a result of damage in transit to the Buyer, within One
day of the time when the Buyer discovers or ought to have discovered the defect; or
(b) the Company is not given a reasonable opportunity after receiving the notice to examining the Machine at the Buyer’s
premises (if in the United Kingdom) or the Buyer (if asked to do so by the Company) fails to return the Machine to the
Company's place of business at the Buyer's cost for the examination to take place there, or
(c) the Buyer uses the Machine after giving notice of a defect; or
(c) the Buyer has failed to follow the Company's oral or written instructions as to the storage, installation, commissioning,
use or maintenance of the Machine or (if there are none) good trade practice; or
(d) the Buyer alters or repairs the Machine (other than by replacing consumable items such as filters, jets and flow-
through brush or such units as are intended to be replaced by the user as specified in the manual) without the written
consent of the Company, or (f) any parts not supplied by the Company have been installed on the Machine, or
(g) the Buyer has not paid all sums due from the Buyer to the Company.
5 The Company shall not be liable for a breach of the warranty in Warranty Condition 2 if the Buyer has not fully
complied with the provisions of the 5 Year Service Agreement
6 Subject to Warranty Conditions 4 and 5 if the Machine does not conform with the warranties in Warranty Conditions 1
and (if applicable) 2 the Company shall either send a replacement unit to the Buyer (where the unit to be replaced is
intended to be replaced by the user as specified in the manual) or repair the Machine (or repair or replace the
defective part). Any parts so replaced shall become the property of the Company and where a replacement unit is
sent to the Buyer to be fitted by the Buyer the Buyer shall at its own expense return the unit so replaced to the
Company. The Company may issue an invoice for any replacement units sent to the Buyer, which will be cancelled if
the unit replaced is returned to the Company and found by the Company to be defective.
7 If the Company complies with Warranty Conditions 6 it shall have no further liability for a breach of any of the
warranties in Warranty Conditions 4 and 5 in respect of the Machine.
8 Any repaired or replacement parts for the Machine shall be guaranteed on these Warranty Conditions for the
unexpired portion of the relevant period specified in Warranty Conditions 1 and 2.
9 These Warranty Conditions are in addition to and do not replace any statutory rights that the Buyer may have under
the Sale of Goods Act 1979 or otherwise.
or pump repair under warranty within the U.K.
CONTACT
UK. – Unic International - Tel +44(0)115 – 9474000 - ax: [phone] - Email: [email protected]
OUTSIDE UK
Contact your local lojet distributor. If unknown check their web site www.flojet.com for details.
Quote your date of purchase.
The machines are not user serviceab e and Unic Internationa or their authorised distributor shou d on y carry out repairs.

Setting the machine up
Installation of containers
PLEASE OTE: It is advised that an air, dirt and water trap filter is fitted (786
as shown on the front page). This will protect the valves and cylinder from dirt
and water contamination.
Air Supply Pressure: 40 to 90 PSI. 2.75-6.9 bar, 3-kg / cm2.
Thread size: 1/4” BSP
Position machine in a well ventilated area. The extraction outlet will accept 3” (75mm) hose and
should be connected to an existing system or taken to the external part of a building and vented to
atmosphere. Hose and a range of adaptors are available direct from Unic International.
Connect the machine to the air supply. All air connections are located on the right hand side of the
machine when viewed from the front.
Connect earth wire on rear of machine to suitable earthing point.
1
So vent Tank
The machine will take 20, 25 or 30 litre solvent containers. When installing 25 & 30
litre containers we advise that you raise the adjustable corner legs.
Take 1 x 25litre drum of clean solvent, remove 5 litres and fill an empty 5 litre
container.
Disconnect quick release coupling by lifting the locking ring and bring outside of
machine (See Diagram 1)
Insert hose with suction filter into drum of solvent and enter drain tube.
Push solvent container/s under machine aligning filler neck with male part of quick
release coupling.
Reconnect quick release coupling.
Place the full 5 litre container under the centre of the machine next to the 25 litre
drum of solvent.
Insert black 6mm nylon tube with wire clip in to the full 5 litre container.
Turn drain valve lever to the vertical position (see diagram 2).
Underneath the machine at the rear are the earthing wire(s), the crocodile clip(s)
must be attached to any metal solvent container(s) if used (these are not supplied
by Unic international).
1
Water Tank
ill large white bucket with water (120mm from top of container).
it Cloth ilter to Stainless Steel filter unit.
Place filter on top of water bucket and push under the right hand side of machine
aligning drain hole with filter assembly.
Insert hose with suction filter into the water bucket.
Pour into the water bucket 1 x 100ml bottle of “UNI-CLEAN” and 1 x 5ml bottle of
“UNI-PURE”.
ill 5 litre plastic container with clean water.
Place the 5 Litre container under the centre of the machine next to the water
bucket located on the right.
Insert black 6mm nylon tube with wire clip in to the full 5 litre container
2
a
b
c
d
e
f
g
h
a
b
c
d
e
f
g
h
i
2
3

Using the machine
WAR I G: D N T SM KE R USE PEN FLAME NEAR CABINET.
Please ote: For best results spray guns should be cleaned as soon as
possible after use.
WAR I G:
• THE LID IS L CKED DURING PERATI N F R Y UR SAFETY
• THE L CK MUST N T BE REM VED
• T UNL CK SWITCH FF THE MACHINE
Any paint left in cup/pot should be emptied into a waste container or stored for future use.
Place paint cup/pot into machine over the top pair of square nozzle jets.
The air cap of the spray gun can either be loosened or removed completely and put into machine.
it the trigger clip to trigger of spray gun. See Diagram 3.
Put spray gun into machine. See Diagram 4.
If using a suction spray gun fit directly onto taper nozzle
If using a gravity or pressure spray gun use a nozzle extension.
1
Close lid.
Ensure mode valve control lever is in the automatic position (horizontal).
Turn timer knob clockwise (The machine will run automatically for approximately 4 minutes).
Upon completion open the lid and remove the spray guns from the machine. We advise that you
DO OT store the spray guns in the machine.
MANUAL WASH/ CLEAN RINSE
MANUAL WASH
Turn Mode Control Valve on the front of machine to Manual Mode.
Open lid of machine. Air extraction will come on automatically (Solvent side Only).
Turn Manual Wash lever to the ON Position and washing solvent will flow from central wash block
and brush.
Proceed to wash spray gun manually.
CLEAN RINSE
Repeat steps one and two listed above
Turn Clean Rinse lever to the ‘ON’ Position and clean water will flow from central block.
Rinse the spray gun.
6
7
8
9
1
2
3
4
1
2
3
2
3
4
5
a
b

To Clean/ Change Contaminated Water
Remove large water bucket and filter assembly from under the machine.
Sprink e into water one bottle of “UNI-COAG”. Stir in the powder using the mixing paddle provided
for at least 2 minutes. It is very important that the powder is thoroughly stirred into the contaminated
water for coagulation to take place.
Leave to stand and within 5 minutes the water will clear.
When the water is clear place the ilter Assembly over a foul water drain and pour away the water
collecting the paint residue in the ilter Cloth Bag. (providing permission from the Local Water
Authority has been granted. Otherwise the water can be reused or disposed of in accordance with
the local regulations).
Remove the ilter Cloth Bag and place in paint oven to assist the drying, or leave to dry outside. The
residue reduces by approximately two thirds and reverts to a powder from which can be disposed of
with your solid waste.
1
2
3
4
5
MAI TE A CE CHECK:
Grid Filter:
It is recommended that the Green Grid Filter inside the tank under the Work Screen is
changed once a month.
Suction Filter:
It is recommended that the Suction Filter be cleared thoroughly every time the cleaning
fluid is replaced.
Please note:
If the Suction Filter is damaged or removed, the Pump Warranty is void.
Lubrication:
The air valve is lubricated at the factory and designed to operate without additional
lubrication. If added lubrication is desired, every 500 hours of operation (or monthly)
Remove the hose from the pump air inlet and add two drops of machine oil to the air
inlet.
The Unic range of Gun Cleaning Machines are Category 2 equipment that is suitable for
Apparatus Groups (Gas groups) IIA, IIB and IIC, with a temperature class of T6.

Unic International (UK)
Health & Safety Data Sheet
Information supplied in accordance with section 6 of the health and safety at work etc. Act 1974
PRODUCT NAME UNIC POWERCLEAN SPRAY GUN CLEANING UNIT.
USES Removal of paint from Spray guns, cups and hoses.
GENERAL Before operating Powerclean Spray Gun Cleaning System, operators must be
PRECAUTIONS familiar with the correct operating procedures as detailed in the manufacturer’s
Operating Manual.
Do not tamper with the safety lid switch, which prevents the unit operating in the
cleaning mode when the lid is open.
Close drain valve and close lid when the unit is not in use. All solvent should be
drained from the cleaning tank before closing the drain valve.
Inspect solvent storage compartment daily to ensure there is no leaks from the
solvent containers.
Replace solvent filter pad frequently (bimonthly replacement of the filter pad is
recommended)
Always disconnect the air source before performing maintenance tasks.
IRE HAZARDS Do not smoke or use other ignition sources near the cabinet.
E.g. no hot work, such as welding.
HEALTH HAZARDS The cleaning solvent used will contain substances hazardous to health, typically
acetone, methanol, white spirit, xylene and toluene. Air monitoring carried out
with a recommended cleaning thinner has shown that concentrations do not
exceed exposure limits published by the Health and Safety Executive. Levels
were less than 50% of the mixed short-term exposure limit when the lid was
open for removal of the spray gun, cups and hoses and just 6% of the limit
during the cleaning cycle. Substances in the solvent however can be absorbed
through the skin, see personal protection equipment.
VENTILATION A local exhaust ventilation system as supplied with the machines, should be
installed so that vapours are safely vented to atmosphere away from windows
and other air inlets. In accordance with the Control of Substances Hazardous to
Health regulations 1988 the system should be maintained and undergo a
thorough examination.
PERSONAL Suitable gloves must be worn when replacing and removing spray guns from the
PROTECTION cleaning machine. Most glove manufacturers recommend Nitrile gloves for the
EQUIPMENT solvent xylene and toluene, which can be absorbed through the skin.
WASTE DISPOSAL Waste solvent must be removed by a registered carrier to a disposal or recovery
facility licensed to receive waste solvent.
EMERGENCY IRE
ACTION In case of fire, use a form of dry powder extinguishing agent. Cool solvent drums
exposed to fire with water spray.
IRST AID
Eye contact with solvent- irrigate with clean water. Skin contact with solvent-
remove contaminated clothing, wash skin thoroughly with soap and water.
Excess inhalation of solvent vapours – Remove to fresh air, seek medical
attention
Accidental Ingestion – Do not induce vomiting, seek medical attention.
SPILLAGE O SOLVENT
Contain and collect with non-combustible materials E.g. sand and earth. Do not
allow to enter drains. Exclude sources of ignition. Ventilate area.
SUPPLIER Unic International (UK)
IN ORMATION Colwick Road, Nottingham NG2 4BG
Tel [phone]
ax [phone]

Test Report
on emissions from Powerclean Spray Gun Cleaners
Tab e 3 - Solvent concentrations measured during the operation of a Unic Powerclean Automatic Spray
Gun Cleaning Machines.
*a This monitoring position was outside the operator’s breathing zone. Measurements were taken
to establish the effectiveness of the ventilated enclosure.
*b Exposure limits are generally for single compounds. Where there is reason to believe that
effects are additive a mixed exposure is assessed using the formula: C1/L1+ C2/L2...< 1
where C1 etc. are the measured concentrations and L1 etc are the corresponding exposure
limits.
Solvent
Acetone 1500 ppm Less than limit of 50ppm 50ppm
(10 min. TWA) detection
Propan - 2 - OL 500 ppm Less than limit of Less than limit of Not measured
(10 min. TWA) detection detection
Propyl Acetate 250 ppm Less than limit of Less than limit of Not measured
(10 min. TWA) detection detection
Butyl Acetate 200 ppm Less than limit of 30ppm 10ppm
(10 min. TWA) detection
Xylene 150 ppm Less than limit of 20ppm 150ppm
(10 min. TWA) detection
Toluene 150 ppm 3ppm 10ppm 60ppm
(10 min. TWA)
White Spirit 720mg/m3 30mg/m3 75mg/m3 100mg/m3
(10 min. TWA)
% of mixed exposure 100% 6% 49% 156%
limit *b (10 min. TWA)
Short Term
Exposure Limit
Ref: EH 40 1992
Monitoring
Position 1
10cm above the
unit during normal
operation.
Lid closed.
Ventilation off.
Monitoring
Position 2
10cm above the
unit when the cycle
had finished.
Lid open.
Ventilation on.
Monitoring
Position 3
*a
inside the enclosure
when the cycle had
finished.
Lid open.
Ventilation on.

Health & Safety Data Sheet
Uni-Pure - UP5
Biocide for use in Water Spray Gun Cleaning Machines
PHYSICAL & MECHA ICAL PROPERTIES
Appearance: Clear Liquid Ph value, conc. solution: 2.0-4.0
Colour: Green yellow lash Point: Is not flammable
Odour Mild Relative Density: 1.030 – 1.042 @ 20ºC
Specific Gravity: 1.2 Solubility in Water: Miscible with water
COMPOSITIO / I FORMATIO O I GREDIE TS
Name CAS No Content Classification
2 -METHYL -2H- ISOTHIAZOL-ONE 2682-20-4 < 1% Xn;R20/21/22. C;R34. N;R50. R43.
5–CHLORO-2-METHYL–ISOTHIAZOLIN-3-ONE 26172 55-4 1-5 % T;R23/24/25. C;R34. N;R50. R43
COPPER NITRATE 10031 43 - 3 1-5% Xn; R20/21/22. C;R34. O;R8
HAZARDS IDE TIFICATIO
May cause sensitisation by skin contact. Irritating to eyes and skin.
CLASSI ICATION Xi;R36/38. R43
STABILITY A D REACTIVITY
Stability: No particular stability concerns
Conditions to avoid: Avoid contact with: Strong oxidising agents. Strong alkalis. Reducing agents.
Materials to avoid: Strong oxidising substances. Strong reducing agents. Strong alkalise.
Hazardous ire or high temperatures create : Carbon dioxide (CO2).
Carbon monoxide (CO). Nitrous gases
Decomposition Products: (NOx). Hydrogen chloride (HCI). Sulphurous gases (SOx).
HA DLI G A D STORAGE
Usage Precautions: Read and follow manufacturer’s recommendations. Avoid spilling, skin and eye contact. Wear full
protective clothing for prolonged exposure and/or high concentrations. Wear full protective clothing
when handling concentrate; changing drums etc. Protect from frost.
Storage Precautions: Store in tightly closed original container in a cool, dry well-ventilated place.
Keep in original container. Keep above the chemical’s freezing point to avoid rupturing the container.
Storage Class: Corrosive storage.
EXPOSURE CO TROL/PERSO AL PROTECTIO
Engineering Measures: Provide adequate general and local exhaust ventilation.
Hand Protection: Protective gloves must be used if there is a risk of direct contact or splash.
Eye Protection: Wear splash-proof eye goggles to prevent any possibility of eye contact.
Respiratory Equipment: Respiratory protection may be required.
Other Protection: Provide eyewash station. Wear appropriate clothing to prevent repeated or prolonged
skin contact.
FIRST AID MEASURES
Inhalation: Move the exposed person to fresh air at once. Get medical attention if any discomfort continues.
Skin Contact: Wash the affected area with soap or mild detergent and water. Promptly remove clothing if soaked
through and wash as above. Get medical attention if irritation persists after washing.
Ingestion: DO NOT induce vomiting. Get medical attention immediately. Promptly get affected
person to drink large volumes of water to dilute the swallowed chemical. Give milk instead of water if
readily available.
Eye Contact: Promptly wash eyes with plenty of water while lifting the eyelids. Get medical attention immediately.
Continue to rinse.
FIRE FIGHTI G MEASURES
Extinguishing Media: This product is not flammable. Use fire-extinguishing media appropriate for surrounding materials.
Special ire ighting Use supplied air respirator if product is involved in a fire. Move container from fire area if it can be done
Procedures: without risk. Use water to keep fire exposed containers cool and disperse vapours.
Unusual ire & Explosion
Hazards: No unusual fire or explosion hazards noted.
Specific Hazards: ire or high temperatures create: Carbon dioxide (CO2). Carbon monoxide (CO).
Nitrous gases (NOx). Hydrogen chloride (HCI). Sulphurous gases (SOx).
Protective Measures in ire: Self contained breathing apparatus and full protective clothing must be worn in case of fire.
DISPOSAL CO SIDERATIO S
Dispose of waste and residues in accordance with local authority requirements. Contact specialist disposal companies.
TOXICOLIGCAL I FORMATIO
Inhalation: Gas or vapour may irritate respiratory system.
Ingestion: Liquid irritates mucous membranes and may cause abdominal pain if swallowed. Swallowing
concentrated chemical may cause severe internal injury.
Skin Contact: Irritating skin. May cause sensitisation by skin contact. Prolonged or repeated exposure may cause
severe irritation.
Eye Contact: Irritating to eyes. Extreme irritation of eyes and mucous membranes, including burning and tearing.
ECOLOGICAL I FORMATIO
Not regarded as dangerous for the environment.
The above information is correct to the best of our knowledge. The conditions or methods of handling, storage, use or disposal are beyond
our control. Attention is drawn to the users of the need too satisfy themselves of the suitability of use and their compliance with COSHH
regulations 1988.
TRA SPORT I FORMATIO
NOT CLASSI IED

Health & Safety Data Sheet
Uni-Aqua Wash UAW-100/ Uni-Clean UC100
PHYSICAL A D CHEMICAL PROPERTIES
Appearance Bright yellow, clear liquid
Odour Slight detergent odour.
Ph Neat : 13.0 10% : 12.2 1% : 11.2
Density@20°C 1.02 g/ml
lash point Non-flammable
Solubility in Water Soluble in all proportions.
COMPOSITIO /I FORMATIO O I GREDIE TS
A blend of surfactants and solvents, alkali builders and chelating agents
Substances Concentrations Risk Phrases/Symbols
Sodium metasilicate 1-5% Corrosive R34 CAS No: 6834-92-0 EINECS No: 229-912-9
Non-ionic surfactants 5-10% Harmful R22,41 CAS No: 68439-46-3
2-(2-butoxyethoxy) ethanol 1-5% Irritant R36 CAS No : 112-34-5 EINECS No :203-961-6
HAZARDS IDE TIFICATIO
The product is classified as being IRRITANT; those materials listed above as Harmful or Corrosive are present at levels low enough to ensure
that the formulated product is classed as ‘Irritant’.
STABILITY A D REACTIVITY
Stable under normal conditions of use and storage. If involved in a fire, will generate sooty deposits plus the oxides of carbon and nitrogen.
HA DLI G A D STORAGE
Store between 0 and 30° C in the containers provided and replace closure after use. Do not mix with other chemicals. Wear safety glasses
and gloves when handling neat or dilutes product. If the diluted product is sprayed in significant quantities or used through a high pressure
washer, then also wear a waterproof suit and rubber boots.
FIRST AID MEASURES
Eye Protection Wear splash-proof eye goggles to prevent any possibility of eye contact.
Skin Protection No specific hand protection noted, but gloves may still be advisable.
Respiratory Protection Not Required. Normal room ventilation is adequate.
EXPOSURE CO TROLS/PERSO AL PROTECTIO
Wear rubber gloves and safety glasses when handling the neat or diluted product.
Workplace Exposure Limits (WELs):
Sodium metasilicate as a dry powder has been allocated an STEL of 2mg/cubic metre.
The product contains ~2%w/w of this material in aqueous solution.
FIRE FIGHTI G MEASURES
Non-flammable and will not support combustion. If drums are involved in a fire, then spray with water to cool.
ACCIDE TAL RELEASE MEASURES
Contain spillage and absorb onto dry earth, sand or granules. Scrape up and place into suitable plastic containers. lush the affected area
with water.
DISPOSAL CO SIDERATIO S
or the disposal of large quantities, consult the local authority for advice; Small amounts may be disposed of via the foul sewer where it will
be successfully treated by the local water treatment plant. Do not allow product to enter the surface drainage system.
TOXICOLIGICAL I FORMATIO
Contact with eyes Causes irritation, redness and watering.
Contact with skin Prolonged contact causes dryness and irritation due to loss of natural skin oils.
Ingested Will cause soreness to mouth and throat. May cause an upset stomach.
Inhaled If mist or spray is inhaled, will cause irritation of mouth, nose and throat.
REGULATORY I FORMATIO
The preparation requires a formal COSHH assessment which should ensure that employees are aware of hazards/precautions detailed in this
date sheet. The COSHH assessment should also ensure that recommended safety equipment is available and, where applicable, the
exposure limits detailed under exposure controls are not being exceeded.
Label for supply:
Risk Phrases R36/38 Irritating to eyes and skin
Safety Phrases S24/25 Avoid contact with skin and eyes. S26 In case of contact with the eyes, rinse immediately with
plenty of water and seek medical advice.
S37/39 Wear suitable gloves and eye/face protection.
U.K.Regulatory References: The Chemicals (Hazard Information and Packaging for Supply) Regulations 2009. The carriage of
Dangerous Goods and Use of Transportable Pressure Equipment Regulations 2007 aligned with ADR.
Workplace Exposure Limits EH40.2005 and subsequent amendments.
REACH Regulation 1907/2006/EC effective June 1st, 2007. The raw materials used in this preparation have
been pre-registered in accord with the requirements of REACH.
OTHER I FORMATIO
It is the responsibility of the user to ensure safe working conditions. The health hazards and general information contained within this Material
Safety Data Sheet are given as a guide to the precautions required to maintain a safe working environment.
ull details of the Risk Phrases used in information on ingredients and not subsequently covered are given below:
R22 Harmful if swallowed. R34 Causes burns. R41 Risk of serious damage to eyes.
This is a safe, general purpose hard surface cleaner with a wide area of applications. Used at between 1 – 10% w/w depending upon degree
of soiling.

Health & Safety Data Sheet
Uni-Coag UC 40
CHEMICAL CHARACTERISTICS
CHEMICAL NAME: CAS No. Polyclay 622
30-80% Bentonite Clays : 1302-78-9
<30% Al2 (SO4)3 : 16828-11-8
<15% Ca(OH)2 : 1305-62-0
<60% Activated Carbon : 1333-86-4
HAZARDS
Description of Hazards: The product may generate a nuisance dust, which can have a drying effect on the skin and irritate the
respiratory tract.
FIRST AID MEASURES
Ingestion: Seek medial attention if large amounts ingested.
Skin Contact: Wash immediately with plenty of water and soap if available.
Eye Contact: Gross inhalation of dust – remove to fresh air, get medical attention.
Inhalation: Gross inhalation of dust – remove to fresh air; get medical attention.
FIRE FIGHTI G MEASURES
Extinguishing media: Water or powder
ACCIDE TAL RELEASE MEASURES
Personal Precautions: Avoid contact with skin and eyes. Wear protective clothing against nuisance dust.
Spills can be slippery when wet.
Environmental Precautions : None required
Methods for cleaning up : Sweep into containers for disposal.
lush spill area with water.
Slippery when wet.
If slipperiness remains apply more dry-sweeping compound.
HA DLI G A D STORAGE
Handling Avoid dust build – up or collection.
Storage Protect from moisture.
EXPOSURE CO TROL/PERSO AL PROTECTIO
Control limits for workplace.
Components OEL for Respirable Dust
Bentonite 5mg/m’
Al2 (SO4)3 2mg/m’
Ca (OH)2 5mg/m’
General protection/hygiene Before breaks and finishing work wash hands.
Respiratory protection Wear dust mask.
Eye protection Wear safety spectacles.
Hand protection Wear protective gloves.
Body protection None required.
PHYSICAL A D CHEMICAL PROPERTIES
Material state Powder % Volatile by weight Not applicable
Colour Grey pH Not available
Odour Odourless Evaporation Not applicable
Boiling Point Not applicable Solubility in water Not available
Melting Point Over 1000ºC lash Point Not applicable
Vapour Pressure Not available lammable Limits Not available
Bulk Density 800-900kg/cmb Autoignition Temperature Not available
Vapour Density Not applicable Decomposition Temperature Not available
STABILITY A D REACTIVITY
Stability Stable
Condition to avoid None known
Materials to avoid None known
TOXIXOLOGICAL I FORMATIO
Potential Health Effects None known
Hazardous Ingredient Toxicity Data No hazardous Ingredients
ECOLOGICAL I FORMATIO
Ecological Information Not known environmental damage
DISPOSAL CO SIDERATIO
All local and national regulations should be followed. Can be co-disposed of with household solid waste given local authority approvals.
TRA SPORT I FORMATIO
Land Transport ADR/RID and GGVS/GGVE Not applicable/regulated
Inland Water Shipping AND/ADR Not applicable/regulated
International Shipping IMO Not applicable/regulated
Air Transport ICAO/IATA Not applicable/regulated
REGULATORY I FORMATIO
EC Marking and Regulation None required
Symbol None
Risk Phrases S24/25 Avoid contact with skin and eyes
Safety Phrases S82 Spills are very slippery when wet
I VE TORY I FORMATIO All components of this product are included.
EEC EINECS Chemical Substances (EINECS) in compliance with Council Directive
67/548/EEC, Amended 79/831/ECC.

Model:
This product complies with the following
European Community Directives:
2006/42/EC Machinery Directive
The following standard was used to verify compliance with the
directives:
E 13463-1:2009
Note: Checked requirements of harmonized standards
Certified to Atex standards.
Certificate number: SIRA 03ATEX5252
EC Notified Body: not applicable
Approved By: Date:
Director (Signed)
Date:
Director (Printed)
INTERNATIONAL
The professional’s choice
Unic International, Colwick Road, Nottingham NG2 4BG England
Tel: [phone] Fax: [phone] Email: [email protected] Web: www.unic.co.uk
Declaration of
Conformity
UGC5005A

Unic International, Colwick Road, Nottingham NG2 4BG England
Tel: [phone] Fax: [phone]
Email: [e-mail] Web: www.unic.co.uk
Mode : UGC5005A
Air Input: 40/90 PSI - 2.75/6 Bar
Air Consumption: 1/2 C M: 28/56 L/min
Air Input Connection: 1/4” B.S.P
Year of manufacturing: 2013/14
Height: 1020mm
Width: 845mm
Depth: 445mm
Weight: 57kg
Directive 94/9/EC.Marking: Ex II 2G T6
Certificate Number: SIRA 03ATEX5252
Manufactured By: Unic International UK
Colwick Rd
Nottingham
NG2 4BG

Unic International, Colwick Road, Nottingham NG2 4BG England
Tel: [phone] Fax: [phone] Email: [email protected] Web: www.unic.co.uk
INTERNATIONAL
The professional’s choice
Information Request
orm
FAX BACK: [phone]
Please send information on:
(please tick appropriate box)
Mini Spray Gun Cleaners Can Crushers
Paint Can Washers Paint Can Shakers
Brake Washer Parts Washer
Solvent Recycler
Spares Service Information
Other Comments:
Please send this information to:
Name:
Address:
Email:
Telephone:
ax:
