Uniden BW610R User manual

1
BW610R
For more exciting new products please visit our website:
Australia: www.uniden.com.au
Additional/Standalone Camera
Baby Monitoring System

2
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important information about this product’s operation. If you
are installing this product for others, you must leave this manual or a copy with the
end user.
When using your equipment, always follow basic safety precautions to reduce the
risk of fire, electric shock and injury to persons, including the following:
• This equipment is NOT waterproof. DO NOT expose it to rain or moisture.
• DO NOT immerse any part of the product in water. Do not use this product near
water, e.g., near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
• To avoid any risk of electric shock from lightning, avoid handling any electronic
devices (except battery powered ones) during an electrical storm.
• Use only the power cord and/or batteries indicated in this manual.
• Never tug or pull on any power cord: be sure to leave some slack in the cord
when placing your equipment, and always use the plug to unplug cord from the
wall outlet.
• Never leave power cords where they can become crushed, cut, or frayed; when
running power cords, avoid letting them rub against any sharp edges or lie
across any high traffic areas where people might trip over them.
• Do not use the device if the adaptor cords or plugs have been damaged, the unit
has been exposed to liquids, or the unit has been dropped or is damaged.
When dust and grime builds up on the camera lens and glass, it affects the
camera’s “vision.” Use a microfiber cloth to regularly clean the cameras or when
night vision video is cloudy or unclear.
MAINTAINING YOUR SYSTEM

3
Failure to follow these warnings and the assembly instructions could result in
serious injury or death. This product is not designed or intended for use as a
medical monitor, nor should this product be used as a substitution for medical or
parental supervision. Always be sure that both the transmitter and receiver are
working properly, and are within range of each other.
STRANGULATION HAZARD. Keep the adaptor cords out of the reach of children.
WARNING: KEEP OUT OF THE REACH OF CHILDREN.
Allow for proper ventilation when units are in use. Do not cover the camera or
receiver with any object such as a blanket. Do not place it in a drawer or in any
location which would muffle the sound or interfere with the normal flow of air.
Warning to Parents and Other Users
To avoid damage to your equipment, follow these simple precautions:
• Do not drop, puncture or disassemble any part of the equipment. There are no
user-serviceable parts inside.
• Do not expose the equipment to high temperatures, and avoid leaving the
equipment in direct sunlight for more than a few minutes. Heat can damage the
case or electrical parts.
• Do not place heavy items on top of the equipment or expose the equipment to
heavy pressure.
• Remove the power adaptor during long periods between usages.
• Clean only with a dry cloth.
Failure to follow the instructions in this operating manual will void the
warranty. Uniden assumes no liability for damages to property or injury to
persons caused by improper handling or failure to comply with these safety
instructions.
SAVE THESE INSTRUCTIONS!
For best results

4
CONTENTS
WHAT’S IN THE BOX? .......................................................................................5
GETTING STARTED .............................................................................................6
INSTALLATION ..................................................................................................8
CAMERA INSTALLATION ...........................................................................................................................8
PAIRINGTOTHEMONITOR................................................................................10
USINGTHEBABYMONITOR...............................................................................11
CAMERA SELECTION............................................................................................................................... 11
BABY WATCH PLUS APP................................................................................... 12
REMOTE VIEWING VIA APP ................................................................................................................. 12
LIVE VIEW..................................................................................................................................................... 17
HISTORY ...................................................................................................................................................... 18
TROUBLESHOOTING ....................................................................................... 19
SPECIFICATION . ........................................................................................... 20
TWO-YEAR LIMITED WARRANTY .................................................................... 22

5
• If any item is missing or damaged, contact your place of purchase immediately.
Never use damaged products!
• Need help? Get answers at our website:
www.uniden.com.au for Australian model
WHAT’S IN THE BOX?
All trademarks are registered trademarks of their respective owners.
BW610R
Camera*
AC Adaptor USB-C Cable
Screws and
anchors Mounting
Template

6
GETTING STARTED
Camera
4
5
1
2
3
6
7
8
9
10
11
12
13
14

7
Item What it does
1LED night light bars.
2Status Light:
Solid Red: Camera is malfunction.
Slow Blinking Red: Waiting for network configuration.
Fast Blinking Red: Waiting for network connection/ Fail to connect to the
network.
Solid Blue: Camera connected to the network.
3Lens: Camera lens.
4Microphone: Receives sounds for the area near the camera, and
transmitssound from the camera to the monitor.
5Mouting Clip: This fastener can attach the camera to shelves or ledges.
6Temperature and humidity sensor: Detects the temperature and
humidity of the environment.
7Speaker: Produces the sound transmitted from the monitor.
8Power: Press and hold to turn the camera ON or OFF.
9Night Light: Press to turn the night light on or off.
10 Pair: Press and hold until the prompt tone is heard to start pairing.
Video: Press to activate video call feature through the app. Camera
requires internet connection.
11 Reset: Insert and hold the reset pin until the prompt tone is heard to reset
the camera.
12 MicroSD Card Slot: Insert microSD card (up to 128GB) to record video.
13 USB-C Port: Connects the USB cable to the camera.
14 Charging LED:
Orange = Charging
Green = Fully charged

8
INSTALLATION
CAMERA INSTALLATION
The camera and the mounting clip are a complete unit. The camera can be placed
on a shelf or the included mounting clip has two slots that t over screws to mount
or clip the camera on ledges and shelves the unit on the wall.
Placement Considerations
• The camera included is NOT weatherproof; it is an indoor camera.
• Avoid having a direct light source in view of the camera (ceiling or floor lamps).
• Carefully plan where and how the camera will be positioned, and where you will
route the cable that connects the camera to the power adaptor.
• If you are planning to pair it to a monitor, the clearest line-of-sight between the
camera and monitor is best. Walls, especially brick and concrete, can affect
reception quality.
• When pairing to a monitor, to positioning the camera, bring the monitor along; it’s
much easier to get the camera into the right position when you have the display
handy. Check the image on the monitor before you install the camera.
#You can install a maximum of 2 cameras to a BW61xx series monitor. When
pairing the additional camera, you will need to pair the cameras with the
monitor.

9
Powering the Camera
1. Insert one end of the USB-C cable to the USB-C port on the camera (at the
back of the camera).
2. Connect the other end of the USB cable into the USB power adaptor.
3. Connect the USB power adaptor into a 240 volt AC (standard indoor) power
outlet.
4. Switch on the plug and allow the camera to power up. The pairing indicator will
flash momentarily.
Wall Mount
The camera mounting clip has two slots that t over screws to mount the unit on the
wall.
1. Install the screws to the wall according to the position of the drill template. Do
not tighten the screws to the end, as you need to leave a gap for hanging the
camera.
2. Place the mounting clip over the installed screws and push it downwards,
locking it into place.
3. Adjust the camera as needed.
Clip Mount
Clip the camera on ledges and shelves.
1. Press the mounting clip as shown.
2. Place the unit over the mounting surface
and release.
3. Adjust the camera as needed.

10
Pairing the camera to the monitor:
1. Press the Menu button on the monitor, and select > Camera Management
> Camera icon that is greyed out .
2. Press and hold the pairing button on the camera until you hear the prompt tone.
3. Press OK button on the display screen to start pairing.
Unpair the camera from the monitor:
1. Press the Menu button on the monitor, and select > Camera Management.
2. Press and hold OK button on the monitor to unpair the camera.
The viewing range is limited to no more than 150m in line of sight. Other factors
such as house walls, layout and electronic devices will affect the transmission
range.
PAIRING TO THE MONITOR

11
USING THE BABY MONITOR
The BW61xxR series monitor supports up to two camera connections and able to
display two camera feeds at the same time.
To set parameters or enable functions of one of the cameras, you will need to select
the camera first.
Camera Selection:
Press the zoom key on the home page to enter the camera selection mode. The
camera icon will always appear on the live view screen. Press the zoom key to
select the camera to be controlled and press OK to select the camera.
To enjoy one camera view, please press OK again after selecting the camera.
The below interfaces are for reference only.
In addition, the battery level of the camera appearing on each camera view.

12
BABY WATCH PLUS APP
REMOTE VIEWING VIA APP
You can download Uniden Baby Watch Plus app to remotely view the camera.
To set up the baby monitor camera, please make sure it’s successfully installed and
powered on, and that the status indicator on the camera is flashing red slowly.
The flashing RED (slow) status means that your camera is ready to be paired to the
Baby Watch Plus App.
Prerequisites
• You must have an available Wi-Fi-enabled Smartphone (Android or iOS
smartphone).
• The BW610R camera and your smartphone must be within the same Wi-Fi
network range for initial setup (ideally within 3m from the router).
• Wi-Fi router connection is 2.4GHz and password if any.
1. Search and download the free Baby Watch Plus app from the App Store for iOS
devices or Play Store for Android devices. You will need to create an account
specifically for the Baby Watch Plus app. If you already have an account with
Baby Watch Plus app, log in account and skip to Step 5.
2. When the status indicator on the camera starts flashing red slowly, the camera
is ready to be paired with the Wi-Fi network. If the status indicator is not red or
flashing quickly, insert a pin to press and hold the reset button for 5 seconds,
wait for the status indicator to flashing red slowly.
* Please note that app screenshots are for reference only. User Interface for iPhone and
Android Phones might differ in terms of icons layout and functionality and may change
without notice.
As the Baby Watch Plus app is constantly under development to enrich user experience, the icons/
screens shown may vary slightly from the actual app.

13
2. When launch the Baby Watch app for the first time, you will see the login page.
Tap the “Sign Up” button to create a new Baby Watch Plus account.
3. Enter your email address you wish to register with and check the user
agreement privacy policies. Tap “Next” button to continue.
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD

14
4. Name your account and enter your password. Tap Done button and you’ll be all
set. Your Baby Watch App account has now been created.
5. On the devices tab, to add a device, tap the “+” button on the middle of the
screen or on the top right-hand side of the screen if you already have shared
access or a paired device.
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD

15
6. Please ensure the camera is powered on and is within the range of the router.
Tap “Next” to continue. If the indicator light on the camera is not flashing slowly,
press and hold the reset button with the reset pin for 5 seconds to reset the
camera and set it up within 2 minutes. When the camera is flashing slowly, the
camera is ready to set up tap “Next” to continue.
7. Enter the Wi-Fi password of the selected Wi-Fi network and tap “Next” to
confirm the Wi-Fi name and password. Tap “Ok” to continue. Please note that
the camera only supports 2.4GHz Wi-Fi connection and the Wi-Fi SSID and
password must not exceed 24 characters.

16
8. Please make sure that you’ve ripped the protection film off the camera’s lens.
Tap “Next” and a QR code will be generated on the screen. Please place the
QR code on screen towards the camera lens at a distance of about 15~20cm
to let the camera scan the QR code. After you hear the voice prompt from the
camera, please press “Next” to continue.
9. Please wait while the app is configuring your camera. Once completed, you’ll be
prompted to name your camera and tap “Done” to start the Live View.

17
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD
LIVE VIEW
2021-05-01 15:00:00
SD
2021-05-01 15:00:00
SD
Scroll to the right.
Back
Date & Time
Tap to switch streaming
resolution
Device Settings
Streaming rate &
Wi-Fi Strength
Full Screen Mode
Local Recording
Night Light
Motion Alert
Take Snapshot
Two-way talk
View and set the
temperature and
humidity alerts.
Play, repeat or
shufe lullabies
Access local gallery

18
HISTORY
2021-05-01 15:00:00
SD
Take a snapshot while
playback recorded video
Choose the date to
search for videos.
View alert event history
Record playback video
to local gallery Access local gallery
View playback
le timeline
#Please note that a SD Card is needed and inserted to the camera for the
lullabies to download and playback.
#Only the event recording and Full-Day recording are saved in the SD Card. Any
event history is saved in the SD Card.
#Local recording and snapshot are saved to the phone gallery.

19
If Try
There is no picture on
the monitor from the
camera
• checking all connections to the camera. Make sure
the adaptor is plugged in.
• making sure that the cameras and monitor are both
ON.
• making sure that the camera is in range of the
monitor.
The picture keeps
dropping on the
monitor
• moving the camera closer to the monitor.
• repositioning the camera, monitor or both to improve
the reception.
• adjusting the monitor antenna to vertical position.
There are audio
problems
• making sure that there is sound within range of the
camera microphone.
• moving the camera or monitor farther apart if the unit
emits a loud screeching noise.
There is an irregular
beeping coming from
the monitor
That is the Alert tone. Go to the Alert screen to turn the
alert volume down or off .
The picture has
become choppy
The picture may become choppy when experiencing a
lower frame rate. Try:
• moving the camera closer to the monitor.
• removing obstructions between the monitor and
camera.
• adjusting the monitor and antenna to vertical position.
The monitor picture
has frozen
Use the reset pin included to reset the monitor. The
monitor turns off. Press POWER to turn it back on again.
You can’t record video
or take a snapshot
Ensure a micro SD Card is inserted and format the SD
card through the app. The SD Card needs to be FAT32
format.
The camera is not
found when setting up
or could not connect to
the router.
Make sure the Wi-Fi router supports DHCP protocol and
the option is turned on.
Make sure the camera and your mobile device connect
to the same Wi-Fi router and selected the correct
2.4GHz Wi-Fi SSID and entered the correct password.
TROUBLESHOOTING
If you have problems with the system, there is often a quick and simple solution.
Please try the following:

20
SPECIFICATION
CAMERA
Image Sensor 1/2.8” Colour CMOS
Video Resolution 2304 x 1296
Viewing Angle 105°
Two-way Audio Yes
Night Vision Up to 10m
Temperature Sensor Yes
Humidity Sensor Yes
Wi-Fi 2.4G WIFI (IEEE802.11b/g/n)
Transmission Range Wi-Fi: up to 50m line of sight
Monitor: up to 150m Line of sight
Smart Home Google Assistant / Alexa
Storage Supports up to 128GB micro SD Card
Battery Capacity 3350mAh
Battery Life Up to 4 hours.(connected to monitor only)
Power Input 5V/1A
Operating Temperature Range –10°C ~ 40°C (14°F ~ 104°F)
Operating Humidity Range Within 80% Relative Humidity
