ALIGNMENT PROCEDURE FOR GMR1048‑2CK(UT016ZH)
TRANSMITTER
STEP MODE CHANNEL FREQUENCY CONDITION ADJUST METHOD
1 TX 1 462.5625MHz CONNECT RF WATTMETER TO THE RT201 KEY THE TRANSMITTER WITH PTT, AND
ANTENNA PATTERN ON THE PCB. ADJUST THE OUTPUT POWER AT 1.2W±0.05W
2 TX 1 462.5625MHz CONNECT FREQUENCY COUNTER TO RT401 KEY THE TRANSMITTER WITHOUT ANY
THE ANTENNA PATTERN ON THE PCB MODULATION. ADJUST TRANSMISSION
WITH AN APPROPRIATE ATTENUATOR. FREQUENCY TO 462.562500MHz±100Hz
3 TX 1 462.5625MHz CONNECT MODULATION ANALYZER TO RT402 KEY THE TRANSMITTER, AND ADJUST RT402
THE ANTENNA PATTERN ON THE PCB. AS THE WAVEFORM ON THE OSCILLOSCOPE
HPF:OFF LPF:3KHz DE‑EMP:OFF COMES TO BE A CERTAIN SQUARE WAVE
CONNECT OSCILLOSCOPE TO
MODULATION OUTPUT OF THE
MODULATION ANALYZER.
CONNECT AUDIO GENERATOR TO TP3
WAVEFORM:20Hz SQUARE WAVE
MAGNITUDE:1.5Vp‑p
4 TX 1 462.5625MHz CONNECT MODULATION ANALYZER TO RT403 KEY THE TRANSMITTER, AND ADJUST RT201
+CTCSS THE ANTENNA PATTERN ON THE PCB. AS THE MODULATION ANALYZER INDICATES
No.27 HPF:OFF LPF:15KHz DE‑EMP:OFF ±2.2KHz ±0.1KHz DEVIATION.
INJECT 1KHz 60mVp‑p SINE WAVE TO
MICROPHONE JACK FROM AUDIO
GENERATOR.
RECEIVER
STEP MODE CHANNEL FREQUENCY CONDITION ADJUST METHOD
1 RX 1 462.5625MHz CONNECT DC VOLTMETER TO TP2 L403 ADJUST L403 AS THE VOLTMETER
INDICATES 1.3V±0.05V
INJECT ‑47dBm RF SIGNAL WITHOUT
MODULATION FROM SSG TO THE ANTENNA
PATTERN ON THE PCB.
2 RX 1 462.5625MHz CONNECT SINAD METER TO SPEAKER JACK RT404 TURN RT401 FULLY C.C.W., THEN
WITH 16Ω DUMMY LOAD. TURN SLOWLY TO C.W. AND SET IT
AT THE POINT WHERE WAVEFORM
INJECT RF SIGNAL FROM SSG AS FOLLOWING APPEARS AT THE SPEAKER OUT.
CONDITION.
MAGNITUDE:AS LARGE AS THE RECEIVER OBTAINS
10dB SINAD SENSITIVITY.
DEVIATION:±1.5KHz
AF FREQUENCY:1KHz

FORM-4 REFERENCE DIAGRAM NO. PAGE
MODEL UNIT BLOCK ISSUE DATE ISSUED
2005/10/24
TITLE ADJUST POINT SUB TITLE REF DIAGRAM
1. MAIN PCB B101 (TOP VIEW) 2. MAIN PCB B101 (BOTTOM VIEW)
TP1 : VCONT +6V:DC 6V L182 : VCONT ADJ.
TP2 : DISC OUT(De_Em
)
LOCAL OUT L401 : DISC.ADJ.
TP3 : BAL RF IN/OUT RT201 : TX POWER ADJ.
TP4 : AF OUT UP RT401 : FREQ. ADJ.
TP5 : MIC IN DWN RT402 : MOD. BALANCE ADJ
TP6 : PTT RT403 : MAX DEV. ADJ.
TP7 : MONI RT404 : SQ ADJ.
TP8 : BATT SEL
REV. CODE △△△△△△△△△△△△△△
DATE
LOT # / RN #
REVISED BY
CHECKED BY
ENGLISH VERSION 02.09 JQD818ZF011 R0
UT016ZH
REVISIONS:
ALIGNMENT
PROCEDURE
RT403 RT402
L401
RT404
RT401
L182
RT201
TP1
TP2
TP4
TP5
LOCAL
OUT +6V
GND
GND RF IN/OUT
GND
TP3
GND
TP6 UP
DWN
TP7 TP8
