UniFocus Time Clock
Installation & Mounting Guide

Position the PC face down on a
protected/padded surface.
Tabs
Place the Mount Plate as you see
above. Be sure the TABS are pointed
up. Install screws in the 4 positions
noted.
Run cables through the
cut-outs in the Mount Plate
before installing Cord Guard.
Place the Cord Guard over the
cords and align with the holes
on the Mount Plate.
Secure the Cord Guard by
installing two screws on the
back side of the Mount Plate.
Screws
Wall/Angle Mount Assembly Instructions
Begin with the Base Mount
securely fastened to the wall.
(fasteners not included)
Lift the PC/Mount Plate as
shown. Insert the TABS into
the slots at the top of the Base
Mount attached to the wall.
Once both TABS are fully
inserted, lower the PC at an
angle. For safety, do not leave
the PC “hanging” on the
Mount Plate TABS.
Install the Perforated Adjust-
ment Plate (part #5) to the
Mount Plate as shown.
Install the Studded Adjust-
ment Plate (part #4) to the
Base Mount. Select 1 of 3
angles by inserting the stud
into one of the 3 holes.
Secure the two plates using
the Tension Knob. These
plates are designed to be a
tight fit, you may need
assistance.
3
1
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY
1 PT81000A BASE MOUNT 1
2
PT81000B MOUNT PLATE 1
3
PT81000C CORD GUARD 1
4
PT81000D STUDDED ADJUSTMENT PLATE 1
5
PT81000E PERFORATED ADJUSTMENT PLATE 1
6
PT81000F TENSION KNOB 1
7
14” ZIP TIE 2
8
M4 X 0.7 X 8 PAN HEAD MACHINE
SCREW, PHILLIPS, ZINC, STEEL
8
8
2
45
67
Note: There are three sets of instructions for alternate mount installation.
Please read instructions thoroughly before you begin.
Please be sure your mount kit has the following parts:
See: Optional Power Brick installation (page 4)
Wall
1

3
1
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY
1 PT81000A BASE MOUNT 1
2
PT81000B MOUNT PLATE 1
3
PT81000C CORD GUARD 1
4
PT81000D STUDDED ADJUSTMENT PLATE 1
5
PT81000E PERFORATED ADJUSTMENT PLATE 1
6
PT81000F TENSION KNOB 1
7
14” ZIP TIE 2
8
M4 X 0.7 X 8 PAN HEAD MACHINE
SCREW, PHILLIPS, ZINC, STEEL
8
8
2
45
67
Wall/Flat Mount Assembly Instructions
Please be sure your mount kit has the following parts:
Place the PC face down on a
protected/padded surface.
Tabs
Run cables through the
cut-outs in the Mount Plate
before installing Cord Guard.
Place the Cord Guard over the
cords and align with the holes
on the Mount Plate.
Secure the Cord Guard by
installing two screws on the
back side of the Mount Plate.
Screws
Lower the PC flat against the
Mount Plate. Install two screws on the
front through the access
holes in the Cord Guard. A
magnetic tip screwdriver may
be helpful.
Place the Mount Plate as you see
above. Be sure the TABS are pointed
up. Install screws in the 4 positions
noted.
Begin with the Base Mount
securely fastened to the wall.
(fasteners not included)
Lift the PC/Mount Plate as
shown. Insert the TABS into
the slots at the top of the
Base Mount attached to the
wall.
Once both TABS are fully
inserted, lower the PC at an
angle. For safety, do not
leave the PC “hanging” on
the Mount Plate TABS.
Wall
2

Insert the Base Mount: Align the two
tabs with the two slots in the Base
Mount.
Insert the tabs from both Studded (part
#4) and Perforated (part #5) Adjustment
Plates into the large slots in position
A&B above. Be sure to keep the stud
facing inward.
Depending on the preferred angle, insert
the stud into one of the three holes on the
Perforated Adjustment Plate. These Plates
are designed to be a tight fit, you may
need assistance.
Holding the plates firmly, attach the
Tension Knob and tighten. The Procare
Touch 8 Mount should now be tight and
firm.
A
B
PRESS FIRMLY
3
1
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY
1 PT81000A BASE MOUNT 1
2
PT81000B MOUNT PLATE 1
3
PT81000C CORD GUARD 1
4
PT81000D STUDDED ADJUSTMENT PLATE 1
5
PT81000E PERFORATED ADJUSTMENT PLATE 1
6
PT81000F TENSION KNOB 1
7
14” ZIP TIE 2
8
M4 X 0.7 X 8 PAN HEAD MACHINE
SCREW, PHILLIPS, ZINC, STEEL
8
8
2
45
67
Please be sure your mount kit has the following parts:
Desktop Mount Assembly Instructions
Place the PC face down on a
protected/padded surface.
Tabs
Place the Mount Plate as you see above. Be
sure the TABS are pointed up. Install screws
in the 4 positions noted.
Screws
Run cables through the cut-outs in
the Mount Plate before installing
Cord Guard.
Place the Cord Guard over the
cords and align with the holes on
the Mount Plate.
Secure the Cord Guard by installing two
screws on the back side of the Mount Plate.
See: Optional Power Brick installation (page 4)
3

Optional Power Brick Installation
With PC face down on a padded/protected surface, insert the (2)
14” zip ties through the holes provided in the tabs as shown. Place power brick between the two tabs.
Bundle as much power cord as needed on top of the Power Brick –
hold in place while securing/tightening the two zip ties. You may choose to snip off any excess Zip-Tie after tightening. Warning: Do not cut any wiring/cables.
The mount was designed to stow the power brick and power cord for a cleaner installation.
This method is for both Desktop and Wall Mount installations. It will not work with Flat Mount installations.
4

Cash
drawer
jack
(Not used)
4 USB 2.0 ports
(Use one port for biometric
reader. May also connect
an external card scanner.)
LAN port
(Connect to your
network cable–
not supplied*)
3 COM
ports
(Not used)
External
monitor port
(Not used)
Power
on/off
push-button
USB 3.0
port
(Not used)
Power cable
connection
(Connect to
power brick)
Ports & Connections
Biometric reader
(Cable connects to
USB 2.0 port below)
