Unimax MAXAlpha User manual

Unimax MAXAlpha
User Manual
U675
www.umxmobile.com
GPUXU675

2
Conventions used in this guide
In this user guide, we use the following symbols to indicate useful and important information:
NOTE NOTE Notes, usage tips, or additional information
Warning Situations that could cause injury to yourself or others
Caution Situations that could cause damage to your device or other equipment

3
Contents
Specifications 6
Basics 7
In Box 7
Phone Overview 7
Battery 8
MicroSD Card 9
Turning Phone On or Off 10
Phone Options 11
Touchscreen Gestures 11
Using the Onscreen Keyboard 12
Editing Text 13
Getting Started 15
Getting to Know the Home Screen 16
Customizing the Home Screen 16
Essential Display Icons 18
Notifications Panel 19
Opening and Switching Between Applications 19
Sleep Mode 20
Adjusting Volume 22
Searching Your Phone and the Web 22
Connecting Your Phone to a Computer 23
Phone Calls 24
Making Calls 24
Answering or Rejecting Calls 25
Using In-Call Options 26
Using Call Log 26
Listening to Your Voicemail 28
Using Voice Dialer 28
People 29
About People 29
Opening Your People 29
Getting Started 29
Editing/ Deleting Contacts 31
Communicating 33
Account Setting 33

4
Messaging 34
About Messaging 34
Sending Messages 34
Reading Messages 36
Receiving Emergency Alerts Messages 37
Changing Messaging Settings 37
Google 39
Gmail 39
Google Talk 41
Maps 44
Local 46
Navigation 47
Latitude 48
Calendar 50
Play Music 53
Google Play Store 54
Play Books 56
Web 58
Email 58
Browser 61
YouTube 64
Wi-Fi 67
Downloads 68
Bluetooth 69
Using Bluetooth 69
Disconnecting or Un-pairing from a Bluetooth Device 69
Connecting to a Bluetooth Headset 70
Sending and Receiving Information Using Bluetooth 70
Entertainment 71
Camera/Camcorder 71
Gallery 73
Sound Recorder 76
Facebook 76
Twitter 76
Tools 76
Clock 76

5
Calculator 78
Settings 78
Settings on Your Phone 78
Firmware Upgrade using microSD Card 84
Safety and Use 85
Please read before proceeding 85
Limitation of damages 85
Important health information and safety precautions 86
Regulatory agency identifications 93
Accessories are available at www.umxmobile.com.

6
Specifications
Display
• 4.5”WVGA
• Capacitive Touch Screen
Camera
• Primary Camera：8.0MP
• Secondary Camera：0.3 MP
Dimensions and Weight
• Dimensions: 133x 66 x 9.9mm
• Weight: 4.2 oz.
Memory
• 4GB (ROM)/4GB (RAM)
• External memory: 2GB microSD™card included (supports up to 32GB)
Operating System
• Android 4.1
Connectivity
• BT 3.0 +EDR, Wi-Fi 802.11 b/g/n
Sensors
• Accelerometer, Proximity Sensor, Geomagnetic field sensor
Power Management (Performance)
Battery Type
Capacity
Standby Time
Talk Time
Lithium-Ion(Li-ion)
1650mAh
Up to 270Hours (11.3Days)
Up to 210minutes

7
Basics
In Box
The U675 comes with the following items included in the box:
• Mobile phone
• Micro USB cable
• Battery cover
• Battery
•USB power adapter
• QSG
•2GB Memory Card
Phone Overview

8
Battery
Note that browsing the web frequently, extended data usage, being in a poor signal area, or
subjecting the device to extreme temperatures will cause the battery to discharge quicker than
normal. To increase battery life, limit your data usage, or turn off GPS and Bluetooth when not
required.
Installing the battery
Please use only the original batteries and accessories you received with your phone or UMX recommended
replacements.
1. Remove the battery cover from the unit.
2. Align the battery’s exposed gold contacts with the battery connectors inside the battery
compartment.
3. Insert the battery with the contacts aligned to the connectors.
4. Gently push the battery into the battery compartment and press down until you hear a click.
Replace the battery door.

9
Removing the battery
1. Make sure that your device is turned off. To remove the battery cover from your phone, open
the back cover using your finger at the small opening on the left of the phone.
2. Push the bottom of the battery upwards and remove the battery.
Charging your battery
Before you turn on your device and start using it, it is recommended that you charge the battery.
1. Plug the USB cable into the USB power adapter.
2. Plug the power adapter into a standard outlet.
3. Locate the USB port located on the underneath of your device.
4. Plug the other end of the USB cable into the phone’s micro USB port.
5. The USB icon on the cable should always face up when connecting the cable to your device as
shown.
NOTE
• It is more efficient to charge the battery with your device powered off.
• Battery operating time gradually decreases over time.
microSD Card
Use the microSD card to store your photos, videos, music and certain apps from Google PlayTM Store.
You can also move and copy files to your computer from your device.
NOTE When you insert or remove the microSD card, you should remove the battery cover firstly then open the TF
cover.
Inserting the microSD card
1. Locate the microSD card slot and remove the cover.

10
Insert the microSD card into the slot with its gold contacts facing left above battery until it clicks
into place.
Removing the microSD card
1. Remove the microSD card cover.
2. Press the microSD card to eject it from the slot then slide it out the rest of the way.
Removing the microSD card while the phone is on
If you need to remove the microSD card while the phone is on, unmount the microSD card
first to prevent corrupting or damaging the files in the microSD card.
1. From the Home screen, tap Apps >Settings.
2. Tap Storage >Unmount SD card >OK.
3. Remove the microSD card by following the steps in “SD card safe to remove”.
Turning Phone On or Off
Turning your phone on
1. Press and hold Power/Lock.
NOTE The first time you use your phone you’ll need to set it up. See the Getting Started chapter for details.
Turning your phone off
1. If the display is off, press Power/Lock to turn it back on.
2. Press and hold Power/Lock for a few seconds.
3. When Phone options menu appears, tap Power off >OK.
Phone Options

11
Silent mode
1. Press and hold Power/Lock to display Phone Options.
2. Tap Silent mode.
• When you select Silent mode, is displayed in the Status bar. Ringtones, alerts, and all
audible sounds except media and alarms are silenced.
NOTE To turn silent mode off, press and hold Power/Lock and then tap .
Airplane mode
1. Press and hold Power/Lock to display Phone Options.
2. Tap Airplane mode.
• When you set Airplane mode, is displayed in the Status bar. Wi-Fi, Bluetooth, and mobile
network functions are all disabled.
NOTE To turn airplane mode off, press and hold Power/Lock and then tap Airplane mode again.
Touchscreen Gestures
Tap
To select onscreen items such as application and settings icons or press
onscreen buttons, simply touch them with your finger.
Tap and hold
To open available options for the item, simply touch and hold your finger on the
screen over the item.
Swipe or slide
Quickly drag your finger vertically or horizontally across the screen.
Drag
Tap and hold your finger before you start to drag. While dragging, do not
release your finger until the item reaches your desired location.
Flick
Flicking the screen is similar to swiping, but you only need to swipe your finger
in lighter and quicker strokes. This finger gesture is always in a vertical
direction, such as flicking through the contacts or the message lists.
Rotate
For most screens, you can automatically change the screen orientation from
portrait to landscape by turning the phone sideways. When entering text, you
can turn the phone sideways to bring up a bigger on-screen keyboard.
Using the Onscreen Keyboard
You can enter text using the onscreen keyboard. Some applications open the keyboard
automatically. In others, tap anywhere in a text field to open the keyboard.
1. Tap each letter on the on-screen keypad.
2. Tap and hold a letter for additional key options (not all keys have additional options).
Additional key options include numbers and letters with accent marks. If options are available,
you will see a box with all the options shown. Slide your finger to select the character you want.

12
3. Continue until you have finished the word.
You can also use the following icons:
Tap 3while you type. When you release the key, the lowercase letters reappear.
•Turn caps lock on. double-tap or touch & hold
Tap 3, so it changes to . Touch shift key again to return to lowercase.
•Tap 1 you can to delete words, tap 4you can change to the number and sign keyboard.
To hide the Android keyboard, press Back .
•When you write a new message, you can tap 2 to skip from the receiver frame to text frame.
NOTE When you type the notification panel will have a “select input method” you can set the input methods.
Adding, Editing or Deleting Words in the User Dictionary
Sometimes you may need to add a word to the predictive text dictionary, for example, a name or a
specialized technical word. If you want to add a word to your User dictionary while entering text,
double tap the word to highlight it, then tap and hold the word and select Add ** to dictionary.
Adding a word manually
1. From the Home screen, tap Apps >Settings.
2. Tap Language & input >Personal dictionary.
3. Press Add.
4. Type the word >tap OK.
Editing or deleting a word
1. From the Home screen, tap Apps >Settings.

13
2. Tap Language & input >Personal dictionary.
• To edit words from the dictionary, tap the word you want to edit >Edit > Edit the word > Tap
OK.
• To delete words from the dictionary, tap the word you want to delete >Delete.
Editing Text
You can select, copy or cut the text you’ve entered, then paste it in another text field within the user
interface.
NOTE Some applications may offer different text editing methods.
Selecting text
1. Tap the text field.
2. Move the cursor to the beginning or end of the desired text by tapping in the location you want
the cursor.
3. Tap and hold the text field.
4. Tap Select word in the pop up menu.
• Or tap Select all to select all the text in the text field.
5. Drag your finger to move the text cursor to a letter within the text that you want to select. The
selected text is highlighted in orange.
Cutting and copying the text
1. Double-click to select the text to cut or copy it.
2. Tap and hold the selected text.
3. Tap Cut or Copy in the menu that opens.
• If you tap Cut, the selected text is removed from the text field. In this case, the text is saved
to the clipboard, so that you can paste it into another text field.
Pasting the text
1. Cut or copy the text to paste.
2. Tap the text field where you want to paste the text and move the cursor to your desired location.

14
• You can paste text that you copied from one application into the text field in any other
application.
3. Tap and hold then select Paste in the pop up menu.
• The text is inserted after the cursor. The text also remains in the clipboard, so you can paste
that same text into another location.

15
Getting Started
Google Account
You must sign in to a Google account to use Gmail, Google Calendar, and other Google
applications; to download applications from Google Play Store; to back up your settings to Google
servers; and to take advantage of other Google services on your phone.
Registering a Google account
Gmail, Google Play Store, and other applications require a valid Google account for use. You will be
prompted to login into Google the first time you use these applications.
1. Tap Existing>Sign in to register your Google account.
• If you don’t have a Google account, tap New instead. See the next section for more details.
2. Enter your Google account Email and Password > Tap Sign in.
Creating a new Google account
1. Tap New > Enter First name, Last name and Email > Tap Next.
2. Enter a password in to the Type a password, Confirm password fields, then tap Next.
• Password tip: Your password must be a minimum of 8 characters in length.
3. Select Security question and enter the Answer, which will be needed if you forget your
password and then enter a Secondary Email >Create.
4. Read through Google Terms of Service > Tap I agree, Next.
5. Enter the letters shown on the screen > Tap Next > Tap Finish.
Adding a Google account
1. From the Home screen, tap Apps >Settings.
2. Tap Accounts & sync >Add account.
3. Tap Google > Tap Existing.
4. Tap Sign in to register your Google account.
5. Enter your Google account Email and Password > Tap Sign in >Finish.
• The U675 supports multiple Google accounts.
• If you have the same contact across multiple Google accounts, you can merge duplicates into a
single item in the contact list.
Add a Google account
1. From the Home screen, tap Apps >Settings.
2. Tap Add account.

16
Getting to Know the Home Screen
The Home screen is displayed when the device is in idle mode. You can add your favorite apps,
shortcuts, folders and widgets to the Home screen so they’re only a tap away.
The Home screen is actually five separate screens. Slide your finger the left or right and you’ll
discover more space to add icons, widgets, and more. Press Home to return to the center Home
screen.
Previewing the Home screens
1. From any Home screen, tap and hold Apps.
2. When you choose a desired Home screen, the display shifts to the selected Home screen.
Customizing the Home Screen
The Home screens and display wallpaper are customizable.
Home screen customization options
Open the Home screen you want to customize.
Moving an item on the Home screen
1. From the Home screen, tap and hold the item you want to move until it vibrates. Don’t lift your
finger.
2. Drag the item to a new location on the Home screen.
3. Lift your finger at the location where you want the item.
To add a shortcut for any application to a Home screen, tap Apps, tap and hold the item, then
drag it onto a Home screen.
Removing an item from the Home screen
1. From the Home screen, tap and hold an item until it vibrates. Don’t lift your finger. The

17
× Remove icon will appear at the top of the display.
2. Drag the item to × Remove.
3. When the item turns blue, lift your finger.
Changing the Wallpaper of the Home screen
1. From the Home screen, tap and hold any empty area on a Home screen long time.
2. Tap one of the following:
Gallery: Choose a photo from your camera gallery or memory card storage. You
can crop the image before setting it as the wallpaper.
Live wallpapers: Choose from pre-loaded animated wallpapers. Additional live wallpapers
can be downloaded from the Google Play Store.
Wallpapers: Choose from the pre-loaded animated or static wallpapers. Additional
wallpapers can be downloaded from the Google Play Store.
3. Tap Set wallpaper.

18
Essential Display Icons
Status icons
You can tell a lot about your phone when you understand the icons in the Status bar. Here’s what
each one means:
Signal strength
Synchronized with the web
No signal
GPS is active
3G network connected
Vibrate only mode
Wi-Fi signal strength
Speakerphone is on
Airplane mode
Silent mode-no audio or vibration
Data synchronizing
Microphone is muted
Bluetooth is on
~
It indicates that battery is remaining
(Empty to full charge states)
Bluetooth device connected
Connected to a computer via USB
cable
Notification icons
Notification icons in the Status bar alert you to items that may require your attention such as new
messages, calendar event reminders, missed call notifications, etc. Here’s what each one means:
Call in progress
Downloading data
Missed call
Uploading data (animated)
Call Diverted
General Warning Icon
More (not displayed) notifications
No microSD card installed
New Google Talk instant message
MicroSD card is being prepared
New voicemail
Upcoming event
New message
Alarm is set
New Gmail
Wi-Fi is on and wireless networks
are available
Connected to or disconnected from
VPN
Song is playing
New Email

19
Notifications Panel
When you receive a new notification, an icon will be displayed in your status bar at the top of your
screen.
Viewing and responding to Notifications
1. Tap and hold Status bar, and then slide your finger downward to open the Notifications panel.
2. If you have multiple notifications, you may need to scroll to see them all.
3. Tap a notification to respond to it.
Closing the Notifications panel
Drag the bottom bar of the panel up. Or just press Back.
Opening & Switching Between Applications
Opening and closing the Applications List
1. From the Home screen, tap Apps.
2. To close, press Home or Back.
Switching to a recently used application
1. From any screen, press and hold Recent apps. Scroll to see all recently used application.

20
2. Tap an icon to open the application or press Back to return to your previous screen.
Sleep Mode
Sleep mode saves battery power by turning off your display. You will still receive messages and calls
when the display is turned off.
Switching to Sleep mode
Press Power/Lock to switch your phone to Sleep mode.
Your phone automatically turns off the display after a period of inactivity. To customize the screen
timeout settings, from the Home screen, tap Apps >Settings >Display >Sleep.
Waking up from Sleep mode
Your phone automatically wakes up when you have an incoming call.
To wake it up manually, press Power/Lock. You’ll need to unlock the screen as described below.
Unlocking the screen
On the lock screen, tap the unlock icon and slide your finger in the direction of the arrows to
unlock the screen. The screen unlocks automatically when you answer an incoming call.
NOTE If you have set up a screen unlock pattern, pin, or password, you will be asked to draw the pattern on the
screen or enter the PIN or password to access the phone software.
