Unimax U505TL User manual

U505TL
User Manual
Conventions used in this guide
In this user guide, we use the following symbols to
indicate useful and important information:
NOTE
Notes, usage tips, or additional information
Warning Situations that could cause injury
to yourself or others.
Caution Situations that could cause
damage to your device or other
equipment.

1
Specifications .........................................................................................................1
Basics........................................................................................................................2
In Box ...............................................................................................................2
Phone Overview.............................................................................................2
Battery..............................................................................................................2
Micro SD Card................................................................................................3
Turning Phone On or Off.............................................................................4
Touch screen Gestures..................................................................................4
Using the Onscreen Keyboard ....................................................................5
Editing Text.....................................................................................................6
Getting Started.......................................................................................................6
Google Account.............................................................................................. 6
Getting to Know the Home Screen ............................................................8
Customizing the Home Screen....................................................................8
Essential Display Icons.................................................................................9
Notifications Panel......................................................................................10
Opening & Switching Between Applications........................................10
Sleep Mode ...................................................................................................11
Adjusting Volume.......................................................................................11
Searching Your Phone and the Web ........................................................12
Connecting Your Phone to a Computer...................................................12
Phone Calls ...........................................................................................................12
Making Calls ................................................................................................12
Answering or Rejecting Calls....................................................................13
Using In-Call Options ................................................................................14
Using Call Log..............................................................................................14
Listening to Your Voicemail......................................................................15
Using Voice Dialer ......................................................................................16
Contacts .................................................................................................................16
About contacts..............................................................................................16
Opening Your contacts ...............................................................................16
Getting Started.............................................................................................16
Editing/Deleting Contacts..........................................................................18
Communicating............................................................................................19
Account Setting ............................................................................................19
About Messages ...........................................................................................19
Sending Messages .......................................................................................20
Reading Messages .......................................................................................21
Receiving Emergency Alerts Messages ...................................................22
Changing Messages Settings.....................................................................22
Google....................................................................................................................23
Gmail..............................................................................................................23
Maps...............................................................................................................24
Calendar.........................................................................................................26
Play Music.....................................................................................................26
Google Play Store ........................................................................................27
Web.........................................................................................................................29
Chrome...........................................................................................................29
YouTube ........................................................................................................31
Wi-Fi ...............................................................................................................33
Downloads ....................................................................................................34
Bluetooth ...............................................................................................................34
Using Bluetooth ...........................................................................................34
Disconnecting or Un-pairing from a Bluetooth Device........................35
Connecting to a Bluetooth Headset..........................................................35
Sending and Receiving Information Using Bluetooth.........................36
Camera/Camcorder ......................................................................................36
Sound Recorder............................................................................................37
Tools.......................................................................................................................38
Clock...............................................................................................................38
Calculator ......................................................................................................39
Settings ..................................................................................................................39
Settings on Your Phone ..............................................................................39
Firmware Upgrade.......................................................................................42
Safety and use.......................................................................................................42
Please read before proceeding...................................................................42
Limitation of damages ................................................................................43
Important health information and safety precautions .........................43

2
Regulatory agency identifications............................................................49
HEARING AID COMPATIBILITY HAC FOR WIRELESS
TELECOMMUNICATIONS DEVICES...................................................51

1
Specifications
1. Display
• 5 inch WVGA(854*480) Display.
• Capacitive Touch Screen.
2. Camera
• Front camera: 2.0MP.
• Rear camera: 5.0MP.
3. Dimensions and Weight
• Dimensions: 146.93 * 71.98 * 10.05mm.
• Weight: 160g.
4. Memory
• 16GB (ROM)/2GB (RAM).
• External memory card: Supports up to 128GB.
5. Operating System
• Android 9.0 Pie.
6. Connectivity
• WIFI(802.11 b/g/n), Bluetooth4.2.
7. Sensors
• Gsensor, Proximity sensor, Light Sensor.
8. Power Management (Performance)
Battery Cells
Capacity
Standby
Time
Talk
Time
Lithium-
Ion(Li-ion)
2400mAh
230h
9.5h

2
Basics
In Box
The U505TL comes with the following items included in the box:
1. Mobile phone.
2. Micro USB cable.
3. Battery cover.
4. Battery.
5. USB power adapter.
6 .QSG.
Phone Overview
Battery
Note that browsing the web frequently, extended data usage, being
in a poor signal area, or subjecting the device to extreme
temperatures will cause the battery to discharge quicker than
normal. To increase battery life, limit your data usage, or turn off
GPS and Bluetooth when not required.
1. Installing the battery
Please use only the original batteries and accessories you received
with your phone or UMX recommended replacements.
1. Remove the battery cover from the unit.
2. Align the battery’s exposed gold contacts with the battery
connectors inside the battery compartment.
3. Insert the battery with the contacts aligned to the connectors.
4. Gently push the battery into the battery compartment and
press down until you hear a click. Replace the battery door.
2. Removing the battery
1. Make sure that your device is turned off. To remove the battery
cover from your phone, open the back cover using your finger
at the small opening on the left of the phone.

3
2. Push the bottom of the battery upwards and remove the battery.
3. Charging your battery
Before you turn on your device and start using it, it is
recommended that you charge the battery.
1. Connect the USB cable to the USB power adapter.
2. Connect the power adapter to a standard outlet.
3. Locate the USB port located on the underneath of your device.
4. Plug the other end of the USB cable into the phone’s micro USB
port.
5. The USB icon on the cable should always face up when
connecting the cable to your device as shown.
NOTE
• It is more efficient to charge the battery with your device powered off.
• Battery operating time gradually decreases over time.
Micro SD Card
Use the micro SD card to store your photos, videos, music and
certain apps from Google Play Store. You can also move and copy
files to your computer from your device.
NOTE
When you insert or remove the micro SD card, you should remove the battery
cover.
1. Insert the micro SD card
1. Remove the battery cover and locate the micro SD card slot.
Insert the micro SD card into the slot with its gold contacts
facing left above battery until it clicks into place.

4
2. Removing the micro SD card
1.Remove the battery cover.
2. Slide the micro SD card out from the slot.
3. Removing the micro SD card while
the phone is on
If you need to remove the micro SD card while the phone is
on, unmount the micro SD card first to prevent corrupting or
damaging the files in the micro SD card.
1. From the Home screen, Up-slide screen into APP menu >
Settings.
2. Tap Storage >Tap to unmounts micro SD card.
3. Remove the micro SD card by following the steps in “Removing
the micro SD card”.
Turning Phone On or Off
1. Turning your phone on
1. Press and hold Power/Lock.
NOTE
The first time you use your phone you’ll need to set it up. See the Getting
Started chapter for details.
2. Turning your phone off
1. If the display is off, press Power/Lock to turn it back on.
2. Press and hold Power/Lock for a few seconds.
3. When Phone options menu appears, tap to power off.
Touch screen Gestures
Tap
To select onscreen items such as application and
settings icons or press onscreen buttons, simply
touch them with your finger.
Tap and hold
To open available options for the item, simply
touch and hold your finger on the screen over the
item.
Swipe or slide
Quickly drag your finger vertically or
horizontally across the screen.
Drag
Tap and hold your finger before you start to drag.
While dragging, do not release your finger until
the item reaches your desired location.
Flick
Flicking the screen is similar to swiping, but you
only need to swipe your finger in lighter and
quicker strokes. This finger gesture is always in a
vertical direction, such as flicking through the
contacts or the message lists.

5
Rotate
For most screens, you can automatically change
the screen orientation from portrait to landscape
by turning the phone sideways. When entering
text, you can turn the phone sideways to bring up
a bigger on-screen keyboard.
Using the Onscreen Keyboard
You can enter text using the onscreen keyboard. Some
applications open the keyboard automatically. In others,
tap anywhere in a text field to open the keyboard.
1. Tap each letter on the on-screen keypad.
2. Tap and hold a letter for additional key options (not all keys have
additional options). Additional key options include numbers and
letters with accent marks. If options are available, you will see a
box with all the options shown. Slide your finger to select the
character you want.
⚫Continue until you have finished the word.
◼You can also use the following icons:
•Tap 3while you type. When you release the key,
the lowercase letters reappear.
•Turn caps lock on. double-tap or touch & hold.
•Tap 3, so it changes to Touch shift key again
to return to lowercase.
•Tap 1 you can to delete words, tap 4you can change to the
number and sign keyboard.
•To hide the Android keyboard, press Back.
• When you write a new mail, you can tap 2 to skip from the
subject frame to text frame.
NOTE When you tap Settings > System > Languages & input > Virtual
keyboard > Manage keyboards, you can set the input methods.
Adding a word manually
1. From the Home screen, Up-slide screen into APP menu >
Settings.
2. Tap System > Language & input >Personal dictionary.
3. Press Add.
4. Type the word > tap Back.
1
2
3
4

6
Editing or deleting a word
1. From the Home screen, Up-slide screen into APP menu >
Settings.
2. Tap System > Language & input >Personal dictionary.
• To edit words from the dictionary, tap the word you want to
edit > Edit the word > tap Back.
• To delete words from the dictionary, tap the word you want to
delete >Delete.
Editing Text
You can select, copy or cut the text you’ve entered, then paste it in
another text field within the user interface.
NOTE Some applications may offer different text editing methods.
1. Selecting text
1. Tap the text field.
2. Move the cursor to the beginning or end of the desired text by
tapping in the location you want the cursor.
3. Tap and hold the text field.
4. Tap Select word in the pop-up menu.
•or tap Select all to select all the text in the text field.
5. Drag your finger to move the text cursor to a letter within the
text that you want to select. The selected text is highlighted in
blue.
2. Cutting and copying the text
1. Double-click to select the text to cut or copy it.
2. Tap and hold the selected text.
3. Tap Cut or Copy in the menu that opens.
•If you tap Cut, the selected text is removed from the text field. In
this case, the text is saved to the clipboard, so that you can paste it
into another text field.
3. Pasting the text
1. Cut or copy the text to paste.
2. Tap the text field where you want to paste the text and move the
cursor to your desired location.
•You can paste text that you copied from one application into the
text field in any other application.
3. Tap and hold then select Paste in the pop up menu.
•The text is inserted after the cursor. The text also remains in
the clipboard, so you can paste that same text into another
location.
Getting Started
Google Account
You must sign in to a Google account to use Gmail, Google
Calendar, and other Google applications; to download
applications from Google Play Store; to back up your settings to
Google servers; and to take advantage of other Google services on
your phone.

7
1. Registering a Google account
Gmail, Google Play Store, and other applications require a valid
Google account for use. You will be prompted to login into Google
the first time you use these applications.
1. Enter your Google account Email > Tap Next.
•If you don’t have a Google account, tap Create account instead.
See the next section for more details.
2. Enter your Google account Password > Tap Next.
