Unitron Quantum micro CIC Assembly instructions

Complete Quantum™
micro CIC fitting guide

1
Table of contents 1. Quantum micro CIC
The Quantum micro CIC is so small it’s hidden from sight -
only your client’s will know they’re wearing it. It provides
a discreet, ultra comfortable fit without the need for deep
impressions. And is completely hassle free, thanks to our
advanced automatic technologies.
The Quantum micro CIC is hardly noticeable - except when
it comes to delivering the highest fidelity, most natural
listening experience.
At Unitron, we care deeply about people with hearing loss.
We work closely with hearing healthcare professionals
to make advanced, purpose-driven solutions available to
everyone. Because hearing matters.
1. Quantum micro CIC ...................................................................................1
2. Components ...........................................................................................2
3. Identifying client candidacy ......................................................................2
4. Fitting ....................................................................................................... 3
5. Programming cables ................................................................................4

2
2. Components 3. Identifying client candidacy
Impression taking
For a Quantum micro CIC, only a standard
CIC ear impression reaching just past the
2nd ear canal bend is needed. No deep
impression techniques are required.
Hearing loss
Suitable for fitting mild to moderately
severe hearing losses.
Vent selection
Due to the deep fit of the micro CIC, venting is required
to prevent discomfort and possible injury to the client.
IntelliVent is the preferred venting option. IntelliVent has a
proven benefit in the reduction of occlusion and in turn, a
significant and positive impact on hearing aid returns and
remakes.
Client dexterity
Due to the small size of the Quantum micro CIC, client
dexterity should be taken into consideration.
1 Microphone protection
2 10A battery door
3 Vent
4 Removal handle
5 Waxguard
1
2
3
4
5
4
250 500 1000 2000 4000 8000
-10
0
10
20
30
40
50
60
70
80
90
100
110
120
Hz
Quantum micro CIC is suitable
for fitting mild to moderately
severe hearing losses.

3
4. Fitting
Orientation in the ear - removal handle
and vent towards the bottom of the ear.
Inserting the micro CIC
1. To insert the hearing aid, hold the
removal handle at the bottom of the
faceplate between the thumb and
index finger with the battery door
away from the ear.
2. Gently insert the canal portion of
the hearing aid into the ear, using
index finger to push the hearing aid
completely into place.
Extracting the micro CIC
1. To remove hearing aid, grasp the
removal handle between the thumb
and index finger. Gently pull on the
removal handle.
2. Move the jaw up and down or apply
pressure to the back of the ear to help
loosen the hearing aid.

4
5. Programming cables
Programming is done through the battery door. In order to
get the smallest size possible, the battery door on the micro
CIC is different from a standard 10A product. The Quantum
micro CIC requires specific programming cables that can
be identified by the white cord and the “MIC” label. These
cables should not be used with any other 10A products.
Warning! Using the incorrect programming cables with micro CIC’s can
damage the faceplate and programming contacts. Please only use the
specified programming cable listed.
058-1070 Programming Cable 10A 0.5m/R
058-1071 Programming Cable 10A 0.5m/L
Recommended for use with NoahLink
058-0098 Programming Cable 10A 2.0m/R
058-0099 Programming Cable 10A 2.0m/L
Recommended for use with HI-PRO
Optional
004-2311 Silicon Ear Guide for 10A programming cables (2pcs)

5
