Universal Electronics Potenza ST User manual

Potenza ST
Universal Remote Control
Users Guide
PREPROGRAMMED FOR YOUR SET-TOP BOX
Nebula Potenza ST.fm Page 1 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
2
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Device Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting Up a Combo Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Searching for Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Checking the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Learning Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Programming a Learned Key . . . . . . . . . . . . . . . . . . . . . . . . . 14
Deleting a Single Learning Key. . . . . . . . . . . . . . . . . . . . . . . . 15
Deleting All Learned Keys in a Specific Mode . . . . . . . . . . . . 16
Programming Channel Control Lock . . . . . . . . . . . . . . . . . . . . . . . . 16
Unlocking Channel Control. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Locking Channel Control to STB. . . . . . . . . . . . . . . . . . . . . . . 17
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Unlocking Volume Control for a Single Device (Individual
Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Unlocking All Volume Control (Global Volume Unlock) . . . . . 18
Locking Volume Control To One Mode (Global Volume Lock) 19
Programming ID Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programming Macro Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Programming a Macro Key. . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Clearing a Macro Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Programming the Master Power Key . . . . . . . . . . . . . . . . . . . 21
Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . . 22
Clearing the Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 22
Re-Assigning Device Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Clearing Custom Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Manufacturer’s Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 27
Setup Codes for Audio Receivers. . . . . . . . . . . . . . . . . . . . . . 27
Setup Codes for Audio Accessories . . . . . . . . . . . . . . . . . . . . 30
Setup Codes for Cable Boxes/Converters . . . . . . . . . . . . . . . 30
Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setup Codes for DVD Recorders. . . . . . . . . . . . . . . . . . . . . . . 37
Setup Codes for DVD Combos. . . . . . . . . . . . . . . . . . . . . . . . . 37
Satellite Receivers and DVR/PVR Systems. . . . . . . . . . . . . . . 37
Setup Codes for Satellite Receivers . . . . . . . . . . . . . . . . . . . 37
Nebula Potenza ST.fm Page 2 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
3
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Setup Codes for TVs (DLP) . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setup Codes for TVs (HDTV) . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setup Codes for TVs (LCD) . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . . 50
Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 52
Setup Codes for TV/VCR/DVD Combos . . . . . . . . . . . . . . . . . . 53
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Nebula Potenza ST.fm Page 3 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
4
INTRODUCTION
The Potenza ST Universal Remote Control by Universal
Electronics is our latest generation universal remote
control. Its sophisticated technology allows you to
consolidate up to five of your original home
entertainment remote controls into one easy-to-use
product. Moreover, its packed with advanced features
such as:
• Preprogrammed control to operate the set-top box
supplied by your service provider
• Dedicated keys to control popular functions on your
DVR/PVR (Digital/Personal Video Recorder)
• Programmable Master Power key for master on/off
control of your home entertainment equipment with
a single keystroke
• Programmable Macro Keys to allow you to activate
certain keys in a specific order
• Channel Lock to lock channel selection only to the
cable converter
• Volume Lock to lock volume controls to one mode or
individual modes
• Device Key Re-Assignment to remotely control a
second (duplicate) device
• Code Search to help program control of older or
discontinued components
• Color-coded keys to quickly locate popular
functions
• Code library for popular video and audio devices
Before using the product, you will need to install the
enclosed batteries and also perform some programming
to operate the specific home entertainment devices you
wish to control.
Please follow the instructions detailed in this manual to
set up the unit and then start enjoying your new remote
control.
Nebula Potenza ST.fm Page 4 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
5
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the
Potenza ST Universal Remote Control and then study the
Key Charts (on the next three pages) to learn how they
function.
To find out what type of devices can be controlled by
each device key after programming, see “Device Table”
on page 8 .
Nebula Potenza ST.fm Page 5 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
6
Key Charts
Key Function
Use SETUP for all programming
sequences.
Press POWER once to turn on or off a
home entertainment device. For
MASTER POWER control, see “Using the
Master Power Key” on page 21.
Press VCR, DVD, AUD, TV, or STB once to
select a home entertainment device to
control. Also see “Device Table” on
page 8.
Each device key has an embedded LED
(red light) that blinks upon selection
and indicates the remote control is
working and (after programming) is
sending signals.
Use GUIDE to display the program
guide.
Use INFO to display the current channel
and program information.
Use DAY+ (or DAY-) to move a day
forward (or back) on your set-top box’s
program guide.
Use the Cursor keys to move the cursor
in the program guide and menu screens
and to navigate within the interactive
service.
Use OK to choose options, PPV events,
and to tune to programs from the
program guide.
Use PAGE+ (or PAGE-) to page up (or
page down) through menu screens and
the program guide.
Use EXIT to exit out of your set-top box’s
menu and guide.
Use VOL+ (or VOL-) to raise (or lower)
the audio volume.
Use FAV to cycle through your favorite
channels stored in your set-top box.
Nebula Potenza ST.fm Page 6 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
7
Use CH+ (or CH-) to select the next
higher (or lower) channel.
For DVD players, use these keys to skip
forward (or reverse) through chapters.
For amplifiers/receivers, use these keys
to select the next higher (or lower)
preset station.
Press MUTE once to turn the sound off
or on.
Press LAST once to recall the last
channel.
Press ON DEMAND to access Video on
Demand services.
Use A, B, C, and Dto access additional
features on your set-top box (see set-top
box manual for details).
Use to command your PVR/DVR
set-top box to instantly replay the last 7
seconds of a program you are watching.
Press LIVE to command your PVR/DVR
set-top box to return to watching live
TV.
Press LIST once to display a list of
recorded shows on your PVR/DVR set-
top box.
In all modes except STB, use REW, PLAY,
FFWD, STOP, and PAUSE to control a
VCR, DVD player, or a PVR (after
selecting a desired device). To record in
the VCR mode, press REC twice.
In the STB mode, use these keys to
control the DVR/PVR functions of the
set-top box.
Use the keypad numbers (1-9, and 0) to
directly tune channels (e.g., 09).
For amplifiers/receivers, use the keypad
numbers to select inputs 1 through 10.
P ress ASPECT once to change the aspect
ratio of the show you are watching. (Not
available on all set-top boxes)
.
Key Function
Nebula Potenza ST.fm Page 7 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
8
Device Table
NOTE: Please refer to the table below when
performing the instructions in
“Programming Device Control” on page 9 or
“Setting Up a Combo Unit” on page 11.
After programming, the Potenza ST Universal Remote
Control will be able to control the following types of
devices:
Press SHIFT to access additional set-top
box features (see your set-top box’s
manual).
PIP turns the Picture-In-Picture feature
on or off (if available on your TV or set-
top box).
SWAP is used to switch PIP images and
sound between the main and window
pictures.
MOVE moves the PIP window to
different positions on your TV screen.
PIP CH+ and CH- are used to select the
next higher or lower channel and is
displayed on your PIP window.
INPUT in STB mode is used to view other
video sources (Aor B). In other modes,
use INPUT to switch between the source
inputs on the device you are controlling.
MACRO 1 and MACRO 2 are reserved for
use as macro keys (See “Programming
Macro Keys” on page 20.).
Device Key Controls these types of devices
VCR, TV/VCR Combo, PVR (Personal
Video Recorder), or extra DVD Player
DVD Player, or extra VCR, TV/VCR
Combo or PVR
Audio Amplifier, Tuner, or Receiver
Te l e v i s i on
Set-top box
Key Function
Nebula Potenza ST.fm Page 8 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
9
INSTALLING BATTERIES
1. On the back of the remote control, push the
tab and lift off the battery cover.
2. Locate the two (2) enclosed AA batteries.
Match the + and - marks with those in the
battery case, then insert them.
3. Align the covers keys with the cases holes and
press the cover back into place. The tab should
click when the cover is locked.
NOTE: When batteries need replacement, the remote
control will cease to operate. Replace the
batteries and the unit will be restored to its
full functionality, complete with your favorite
settings.
PROGRAMMING DEVICE CONTROL
The Potenza ST Universal Remote Control is
preprogrammed to operate the set-top box provided by
your television service provider, an RCA TV, a Toshiba
DVD player, an RCA VCR, and a Pioneer audio receiver.
To control devices other than the default brands,
perform the following steps; otherwise skip this section.
4. Test the remote control by pressing any mode
key (e.g., TV). If the batteries are inserted
correctly, the LED (red light) will blink once.
1
3
2
Nebula Potenza ST.fm Page 9 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
10
NOTES: For control of a Combo device (for example, a
TV/VCR combo), skip this section and per-
form the instructions on “Setting Up a Combo
Unit” on page 11. Also refer to “Device Table”
on page 8 to find out which devices can be
programmed onto each device key.
If you have another brand of set-top box you
would like to control, you’ll need to unlock the
STB ID Lock before changing the set-top box
code (see “Programming ID Lock” on
page 19).
1. Turn on a device and, if applicable, insert
video media, (e.g., cassette or disc).
NOTE: Please read steps 2 through 5 completely
before proceeding. Highlight or write down
the codes and device you wish to program
before moving on to step 2.
4. Use the “Manufacturer’s Codes” starting on
page 27) to locate the type of device and
brand name and then enter the first four-digit
code for your device. If performed correctly,
the selected mode key will blink twice.
NOTE: If the selected mode key emits a long blink,
the entry is invalid. Repeat steps 2 through 4
and try entering the same code again.
NOTE: If the device does not have a POWER key (e.g.,
DVD and VCR), press the(Play) key.
6. Repeat steps 1 through 5 for each device you
want the remote control to operate. For future
reference, write down each working device
code in the boxes on the following page.
VCR Code
2. On the remote control, press a device key once
(i.e., VCR, DVD, AUD, TV, or STB); it will blink
once.
3. Press and hold SETUP until the selected mode
key blinks twice, then release SETUP.
5. Aim the remote control at the device and
press POWER once. The device should turn
off. If it does not, repeat steps 2 through 4,
trying each code for your brand until you find
one that works. If it still does not respond, try
searching for the code (see “Searching for
Your Code” on page 12).
Nebula Potenza ST.fm Page 10 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
11
Device Type:___________________
DVD Code
Device Type:___________________
AUD Code
Device Type:___________________
STB Code
Device Type:___________________
TV Code
Device Type:___________________
SETTING UP A COMBO UNIT
If you own a combo unit such as a TV/VCR Combo or a
TV/DVD Combo, you need to follow special steps to set
it up. Perform the following instructions to control
combo device:
1. For a TV/VCR Combo, turn on your TV/VCR
Combo and insert a video cassette. (For a TV/
DVD Combo, insert a DVD).
3. Use the “Manufacturer’s Codes” starting on
page 27 to locate the brand name and enter
the first four-digit code for your combo device
(for example, TV/VCR). If you perform this
procedure correctly, the VCR key will blink
twice.
NOTE: If the VCR key did not blink twice after enter-
ing the codes last digit, repeat steps 2 through
3 and try entering the same code again.
If you’ve located a setup code that works for
your combo device (for example, a TV/VCR
2. On the remote control, press VCR once; it will
blink once. Then press and hold SETUP until
the VCR key blinks twice.
Nebula Potenza ST.fm Page 11 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
12
Combo) and a separate TV code is also listed,
you’ll need to program this code into the
remote control to access volume control (see
“Programming Device Control” starting on
page 9).
5. For future reference, write down each working
device code in the boxes below:
TV/VCR or TV/DVD Code
TV Code (if used)
SEARCHING FOR YOUR CODE
If your home entertainment device does not respond to
the Potenza ST Universal Remote Control after trying all
of the codes listed for your brand, or if your brand is not
listed at all, try searching for your code.
For example, to search for a code for your TV:
1. Turn on your TV.
4. Aim the remote control at your combo device
(for example, TV/VCR Combo) and press
POWER once. The device should turn off. If it
does not respond, repeat steps 2 through 3,
trying each code listed for your brand until
you find one that works. If it still does not
respond, try searching for the code
(“Searching for Your Code” starting on
page 12).
2. On the remote control, press TV once; it will
blink once. Then press and hold SETUP until
the TV key blinks twice.
3. Type 9 9 1. The TV key will blink twice.
4. Aim the remote control at the TV and press
POWER once.
5. Press and release the CH+ key continuously,
then stop when the TV turns off.
Nebula Potenza ST.fm Page 12 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
13
7. To search for the codes of your other devices,
repeat steps 1 through 6, but substitute the
appropriate key (e.g., VCR, DVD, AUD, or STB)
for the device you are searching for.
CHECKING THE CODES
If you have set up your remote control by searching for
your device code (on the previous page), you may need
to find out which four-digit code is operating your
equipment.
F
or example, to find out which code is operating your TV :
5. To check for other device codes, repeat steps 1
through 4, but substitute the appropriate key
(e.g., VCR, DVD, AUD, or STB) for the device
you are checking. Write down the codes in the
appropriate boxes on page 11.
NOTE: In the search mode, the remote control will
send IR codes from its library to the selected
device, starting with the most popular code
first.
6. Press POWER. The TV should turn on, then
press SETUP once to lock in the code. The LED
will blink twice to indicate that the code is
saved.
NOTE: If the TV does not turn on during step 6, then
slowly press and release CH- to go back
through the codes, then press SETUP when the
TV turns on.
1. On the remote control, press TV once; it will
blink once. Then press and hold SETUP until
the TV key blinks twice.
2. Enter 9 9 0. The TV key will blink twice.
3. To view the code for the first digit, press 1
once. Count the number of times the TV key
blinks (e.g., 3 blinks = 3) and write down the
number in the leftmost TV Code box on
page 11.
NOTE: If a code digit is 0, the selected mode key will
not blink.
4. Repeat step 3 three more times for the
remaining digits. Use 2for the second digit, 3
for the third digit, and 4for the fourth digit.
Finish writing down the code in the TV Code
boxes on page 11.
Nebula Potenza ST.fm Page 13 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
14
USING LEARNING
The Potenza ST Universal Remote Control includes a
Learning feature (not available on all models) so you
can add functions that are unique to your home
entertainment devices (e.g.,VCR T
racking Up or Down).
However, there are some considerations .
Learning Precautions
• Your original remote controls must be in working
order for learning to work properly.
• Learned keys are mode-specific, so each one can
store a unique function for each mode.
• Do not use the following keys for learning: Device
Keys, SETUP, Record (•), Tune-In Keys.
• Learning capacity is approximately 16 to 25 keys,
depending on the code being learned.
• Certain device functions are not learnable including
multi-frequency types, some high frequency ones,
and other unusual formats.
• For optimum learning, avoid high levels of ambient
light such as natural sunlight or energy-efficient
fluorescent lights.
NOTE: Please have your original remote controls
handy before programming learning.
Programming a Learned Key
NOTE: If more than 15 seconds pass between key
presses, the remote exits programming.
3. Press the desired key on the Potenza ST once
to store the feature to be learned.
1. Press and hold SETUP until the last-selected
mode key blinks twice, then press 9 7 5.
NOTE: If the LED displays one long flash instead,
either your batteries are low, or the Potenza ST
Universal Remote Control has a memory fault.
2. Press a mode key once (i.e., VCR, DVD, AUD,
TV, or STB) to assign a mode for learning.
Nebula Potenza ST.fm Page 14 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
15
4. Place the Potenza ST Remote Control head-to-
head (about 2" apart) from your original
remote control. Also locate the key (on your
original remote control) that you want the
Potenza ST Universal Remote Control to learn.
5. On the original remote, press and hold the key
to be learned. The Potenza ST Remote
Control’s LED will blink rapidly, then turn off.
Continue holding the key on the original
remote until the LED blinks twice.
NOTE: If the LED displays one long blink, a learning
error has occurred. Try repeating this step
again until a successful capture occurs. If the
function is still not captured, press and hold
SETUP to exit programming and review the
“Learning Precautions” on the previous page.
If needed, also see “Troubleshooting” on
page 24. After review, start programming
again at step 1.
Deleting a Single Learning Key
T
his process returns the key to its original programmin g
for the mode you select. You can also delete learned
programming by teaching a different function to the key
(see “Programming a Learned Key” on page 14)
NOTE: If more than 15 seconds pass between key
presses, the remote exits programming.
6. Repeat steps 2 through 5 for another mode
and/or key or press and hold SETUP until the
active mode key LED blinks twice to exit
programming.
1. Press and hold SETUP until the last-selected
mode key blinks twice, then press 9 7 6.
2. Press a mode key once (i.e., VCR, DVD, AUD,
TV, or STB). The LED on the selected mode
key will blink once.
2"
Nebula Potenza ST.fm Page 15 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
16
3. Press the key containing the learned function
to be deleted twice. The active MODE key will
blink twice.
Deleting All Learned Keys in a Specific Mode
NOTE: If more than 15 seconds pass between key
presses, the remote exits programming.
PROGRAMMING CHANNEL CONTROL LOCK
By default, the remote control’s channel-control
capabilities are locked to the set-top box. The affected
keys*are 1through 0, CH+, CH-, and LAST. This will
guarantee that you do not inadvertently change a
channel on your TV or VCR. However, you can de-
activate this feature to allow full access to these keys in
the TV and VCR modes.
*NOTE: This feature does not affect the AUD mode.
4. Repeat steps 2 through 3 for another key or
press and hold SETUP to exit programming.
1. Press and hold SETUP until the last-selected
mode key blinks twice, then press 9 7 6.
2. Press a mode key twice (i.e., VCR, DVD, AUD,
TV, or STB) to clear all the learned keys for that
mode. The mode key LED blinks twice.
3. Repeat step 2 for another mode or press and
hold SETUP to exit programming.
Nebula Potenza ST.fm Page 16 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
17
Unlocking Channel Control
Now the remote control will provide TV and VCR
channel-control capabilities while in the TV or VCR
mode.
Locking Channel Control to STB
Now, regardless of what mode you select (except AUD),
the channel keys will only change channels on your set-
top box.
CHANGING VOLUME LOCK
Volume Lock allows you to control the volume through
the device identified as having your primary speaker(s),
regardless of which mode you are using. On the Potenza
ST Remote Control, Global Volume Lock is set to TV, so
you can control TV volume while in the VCR, DVD, TV or
STB mode. You can perform Individual Volume Unlock
on a selected device to set its volume control for
independent operation.
1. On the remote control, press STB once; it will
blink once. Press and hold SETUP until the
STB key blinks twice.
2. Enter 9 7 3. The STB key will blink twice.
3. Press CH- once. The STB key will blink four
times.
1. On the remote control, press STB once; it will
blink once. Press and hold SETUP until the
STB key blinks twice.
2. Enter 9 7 3.The STB key will blink twice.
3. Press CH+ once. The STB key will blink twice.
Nebula Potenza ST.fm Page 17 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
18
NOTE: The audio mode’s (AUD) volume controls are
active regardless of Volume Lock settings.
However, if you lock the volume controls to
the AUD mode, you will have control of the
audio device’s volume in all other modes (i.e.,
VCR, DVD, TV, and STB). This can be an advan-
tage if, for example, you always listen to home
entertainment devices through your receiver’s
speakers.
Unlocking Volume Control for a Single Device
(Individual Volume Unlock)
4. Repeat steps 1 through 3 for each device you
want volume to be unlocked.
Now, after you select a device that has volume unlocked
(e.g., STB), pressing VOL+, VOL-,or MUTE, will control
only that device’s volume.
Unlocking All Volume Control (Global Volume Unlock)
NOTE: Performing these instructions will set inde-
pendent volume control for all programmed
devices.
1. Assuming Global Volume Lock is active, select
a mode on the remote control that you want to
unlock (e.g., STB) and press it once. Next,
press and hold SETUP until the device key
blinks twice.
2. Enter 9 9 3. The last-selected device key will
blink twice.
3. Press VOL- once. The last-selected device key
will blink four times.
1. On the remote control, press and hold SETUP
until the last-selected device key blinks twice.
2. Enter 9 9 3. The last-selected device key will
blink twice.
3. Press VOL+ once. The last-selected device key
will blink four times.
Nebula Potenza ST.fm Page 18 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
19
Locking Volume Control To One Mode (Global
Volume Lock)
NOTE: The audio mode’s volume controls are active
regardless of Volume Lock settings. However,
if you lock the volume controls to the AUD
mode, you will control the audio device’s vol-
ume in all other modes (i.e., VCR, DVD, TV, or
CBL). This can be an advantage if, for exam-
ple, you always listen to home entertainment
devices through your receiver’s speakers.
Now, when you press VOL+, VOL-,or MUTE, the volume of
the selected device (e.g., TV) is controlled regardless of
mode.
PROGRAMMING ID LOCK
The Potenza ST Universal Remote Control is locked at
the factory to operate your service provider’s set-top
box. However, if you have another brand or model of set-
top box or satellite service that you would like to control,
then you’ll need to perform the following steps to unlock
the ID Lock, enter a new manufacturer’s code, and lock
the ID Lock again.
1. Turn on the set-top box.
1. On the remote control, press and hold SETUP
until the last-selected device key blinks twice.
2. Enter 9 9 3. The last-selected device key will
blink twice.
3. Select a mode (e.g., TV or AUD) which you
want to use to control the volume. The
selected device key will blink twice.
2. On the remote control, press STB once; it will
blink once. Then press and hold SETUP until
the STB key blinks twice.
3. Enter 9 8 2. The STB key will blink four
times, indicating ID Lock is unlocked.
Nebula Potenza ST.fm Page 19 Monday, October 15, 2007 4:55 PM

www.urcsupport.com
20
4. Perform the instructions under
“Programming Device Control” on page 9 to
program device control for the desired cable
converter or satellite receiver.
When you are done, perform steps 5 and 6 on
this page to again lock the ID Lock.
PROGRAMMING MACRO KEYS
The Potenza ST Universal Remote Control includes two
macro keys (located directly below the MUTE and LAST
keys). Macro keys allow you to set up key macros to
activate certain keys in a specific order. For example, you
can set up a key macro to change the channels on your
TV, raise or lower the volume, and start recording on
your VCR, all with the touch of one key. If you want to
change the macros stored in a previously-programmed
macro key, you’ll need to clear the key first (see
“Clearing a Macro Key” on page 21).
Programming a Macro Key
3. Select a macro key (for example, F1) and
press it once.
5. On the remote control, press STB once; it will
blink once. Then press and hold SETUP until
the STB key blinks twice.
6. Enter 9 8 2. The STB key will blink twice,
indicating ID Lock is again locked.
1. On the remote control, press and hold SETUP
until it blinks twice.
2. Enter 9 9 5. The SETUP key blinks twice.
4. Press the key sequence you want to program
into the macro. For example, to turn on your
TV and raise its volume, press the TV mode
key once, followed by pressing the VOL+ key
once.
Nebula Potenza ST.fm Page 20 Monday, October 15, 2007 4:55 PM
