Universal Electronics Millenium 4 User manual

MILLENNIUM™4
Universal Remote Control
User’s Guide
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 1

TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming TV Control . . . . . . . . . . . . . . . . . . . . . 8
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . 8
Programming VCR Control . . . . . . . . . . . . . . . . . . 12
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . 12
Programming TV/VCR Combo Control . . . . . . . . 16
Setup Codes for TV/VCRs . . . . . . . . . . . . . . . . . . . 17
Programming Cable Converter
(or DBS Receiver) Control . . . . . . . . . . . . . . . . . . . 18
To Unlock the Cable Key . . . . . . . . . . . . . . . . . . . . 18
To Program the Cable Key . . . . . . . . . . . . . . . . . . . 18
To Lock the Cable Key . . . . . . . . . . . . . . . . . . . . . . 19
Setup Codes for Cable Converters. . . . . . . . . . . . . 19
Setup Codes for DBS Receivers. . . . . . . . . . . . . . . 20
Programming Channel Control Lock . . . . . . . . . . 21
To Activate Channel Control Lock . . . . . . . . . . . . . 21
To De-Activate Channel Control Lock. . . . . . . . . . . 21
Programming Audio Control . . . . . . . . . . . . . . . . . 22
Setup Codes for CD Players. . . . . . . . . . . . . . . . . . 23
Setup Codes for DVD Players. . . . . . . . . . . . . . . . . 24
Setup Codes for Stereo Receivers . . . . . . . . . . . . . 24
Setup Codes for Stereo Amplifiers. . . . . . . . . . . . . 25
Setup Codes for DBS Audio Services . . . . . . . . . . . 25
Searching For Your Code . . . . . . . . . . . . . . . . . . . . 26
Checking The Codes . . . . . . . . . . . . . . . . . . . . . . . 27
Programming The Power Key . . . . . . . . . . . . . . . . 28
Programming The Tune-In Keys . . . . . . . . . . . . . 29
To Program a Tune-In Key . . . . . . . . . . . . . . . . . . . 29
To Clear a Tune-In Key . . . . . . . . . . . . . . . . . . . . . 29
Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . 30
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . 31
To Change Volume Lock to the CABLE Mode . . . . . 31
To Change Volume Lock to the TV Mode. . . . . . . . . 31
To Change Volume Lock to the VCR Mode . . . . . . . 31
To Change Volume Lock to the AUDIO Mode. . . . . . 32
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Additional Information . . . . . . . . . . . . . . . . . . . . . . 34
2
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 2

INTRODUCTION
The Universal Electronics Millennium™ 4 is our latest
generation universal remote control.It is designed with
sophisticated technology that will allow you to finally
consolidate the clutter of all of the original remote controls
in your home entertainment system.It’s packed with easy-
to-use features such as:
• Preprogrammed to operate the cable converter sup-
plied by your cable system provider
• Preprogrammed technology for easy setup
• Preprogrammable Power key for master on/off control
of all of your equipment with a single keystroke
• Instant“Tune-In”keys for assignment to your
favorite channels
• Convenient hide-away sliding door to conceal
less-used functions
• Color-coded keys to quickly locate popular functions
• Cable ID Lock to lock your remote control for use only
with the cable converter
• Channel Lock to lock channel selection only to the
cable converter
• Code library for video and audio components
• Code Search to help program control of older or
discontinued components
Before you can use your new remote control,you will
need to program it to operate the specific home enter-
tainment components you wish to control.Follow the
instructions detailed in this manual to set up your
Millennium 4 and enjoy your new remote control.
3
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 3

FEATURES AND FUNCTIONS
Use the illustration below to locate Millennium 4 features
and then study the Key Charts (on the next two pages) to
learn how they function.
4
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 4

Key Charts
The LED (red light) blinks to show that
the remote control is working and is
sending signals.
Press AUDIO,VCR,TV,orCBL once
to select a home entertainment
component to control.
Press POWER once to turn on or off
the selected home entertainment
component.
Use SETUP for all programming
sequences.
Use the keypad (0~ 9) to directly select
channels (e.g.,09 or 31).
Press MUTE once to turn sound off
or on.
Press ENTER once after entering channel
numbers on some TV models.
Use volume +(or volume - ) to raise (or
lower) the sound volume.
Use CH + (or CH - ) to select the next higher
(or lower) channel.
Press LAST once to recall the last channel
and to page back one screen in the
main menu.
Use FAV to cycle through your favorite
channels that are stored in your cable
converter.
Use GUIDE to display the program guide.
Press PPV/LOCK once to display the pay
per view menu or to lock out a specific
channel on your cable converter.
Use EXIT to exit out of your cable
converter’s menu and guide.
continued on next page...
5
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 5

Key Charts (continued)
Use cursor keys to move the cursor in
the program guide and menu screens.
Use SELECT/OK to choose options,PPV
events, and to tune programs from the
program guide.
Use INFO to display current channel and
program information.
Press MENU once to display your cable
converter’s screen menu.
Use PAGE ▲▲(or PAGE ▼▼) to page up
or down) through menu screens and the
program guide.
Reserved for use as“Tune-In”keys
(see page 29).
Slide the door open to reveal less-often
used keys such as VCR transport buttons
and cable converter features.
In the VCR and TV modes, use the REW,
PLAY,FF,REC,STOP,andPAUSE keys to
control yourVCR. To record a program,
press REC twice.
Reserved for cable converter features
(see your cable converter manual).
Press TV/VCR once to switch theVCR to
view TV channels or tape.This key will
also control the input select feature on
most TVs.
6
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 6

INSTALLING BATTERIES
1. On the back of the Millennium 4, push the tab
and lift off the battery cover.
2. Obtain two (2) fully-charged AA alkaline bat-
teries.Match the + and – marks on the batter-
ies to the + and – marks in the battery case,
then insert the new batteries.
3. Press the battery cover back into place.The tab
should click when the cover is locked.
4. Test the unit by pressing POWER and any mode
key (e.g.AUDIO,VCR,TV,orCBL). If the batteries
are inserted correctly,the LED will blink once.
NOTE: Whenever batteries need replacement, the Millennium 4
will blink twice with every key press. Simply replace the batteries
and the Millennium 4 will be restored to its full functionality,
complete with your favorite settings.
7
❶
❸
❷
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 7

PROGRAMMING TV CONTROL
NOTE: If you own a TV/VCR combination, skip this section and
perform “Programming TV/VCR Combo Control” on page 16.
Locate the brand name of your TV in the Setup Codes For
TVs section below, and write it in the following space.
TV Brand: __________________________________
The brands are listed in alphabetical order with the most
popular codes listed first.You will use one of these codes
to program the Millennium 4 to operate your TV:
1. Turn on the TV.
2. On the Millennium 4,press TV once. Press and
hold SETUP until the LED blinks twice,then
release SETUP.
3. Enter the first four-digit code for your TV. If
you perform this procedure correctly,the LED
will blink twice.
NOTE: If the LED did not blink twice after entering
the code’s last digit, then repeat steps 2 through 3 and
try entering the same code again.
4. Aim the Millennium 4 at your TV and press
POWER once.The TV should turn off. If it does
not respond,repeat steps 2-3,trying each code
for your brand until you find one that works.If
it still does not work,try searching for the code
(see Searching For Your Code on page 26).
5. Write your TV code in the boxes below for
future reference.
NOTE: Remember, to use the Millennium 4 to operate your TV,
press
TV first.
Setup Codes for TVs:
A-Mark 0003
AOC 0030, 0019,0003, 0052, 0185
Abex 0032
Admiral 0093
Adventura 0046
Aiko 0092
Akai 0030
Alaron 0179
Ambassador 0177
8
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 8

Anam 0180
Anam National 0055
Archer 0003
Audiovox 0451, 0180,0003, 0092,0623
Baysonic 0180
Belcor 0019
Bell & Howell 0154,0016
Bradford 0180
Brockwood 0019
Broksonic 0236,0463,0003
CXC 0180
Candle 0030,0056, 0046,0186
Carnivale 0030
Carver 0054
Celebrity 0000
Cineral 0451,0092
Citizen 0060,0030, 0056,0039, 0046, 0092,0186, 0280
Clairtone 0185
Concerto 0056
Contec 0180,0185
Craig 0180
Crosley 0054
Crown 0180,0039
Curtis Mathes 0047,0054, 0154,0051,0451, 0093,0060, 0030,0145,0056,
0016,0039, 0166,0466
Daewoo 0451,0019, 0039,0092, 0623, 0624
Daytron 0019
Denon 0145
Dumont 0017, 0019
Dwin 0720, 0774
Electroband 0000,0185
Emerson 0154,0236,0463, 0180, 0282, 0178, 0019,0179, 0039, 0038,
0177,0185, 0280, 0623, 0624
Envision 0030
Fisher 0154, 0159
Fujitsu 0179
Funai 0180, 0179, 0171
Futuretech 0180
GE 0047,0051, 0451, 0093, 0282, 0178, 0021, 0055, 0027, 0135
Gibralter 0017,0030, 0019
GoldStar 0030,0178, 0019,0056, 0001, 0032
Gradiente 0053, 0056
Grunpy 0180,0179
Hallmark 0178
Harley Davidson 0179
Harman/Kardon 0054
Harvard 0180
Hitachi 0145,0056,0032, 0038, 0151
Infinity 0054
Inteq 0017
JBL 0054
JCB 0000
continued on next page...
9
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 9

Setup Codes for TVs (continued):
JVC 0053
Janeil 0046
KEC 0180
KTV 0180, 0030, 0039, 0185, 0280
Kaypani 0052
Kenwood 0030, 0019
Kloss 0024,0046
LG 0056
LXI 0047,0054, 0154, 0156, 0178
Logik 0016
Luxman 0056
MEI 0185
MGA 0150,0030, 0178, 0019
MTC 0060,0030,0019, 0056, 0185
Magnavox 0054, 0030, 0179, 0020, 0024, 0096, 0186, 0187, 0386
Majestic 0016
Marantz 0054,0030
Matsushita 0250
Megatron 0178, 0145, 0003
Memorex 0154,0250, 0150, 0178, 0056, 0016
Midland 0047,0017, 0051, 0039, 0032, 0135
Minutz 0021
Mitsubishi 0093, 0150, 0178, 0019
Motorola 0093,0055
Multitech 0180
NAD 0156,0178, 0166
NEC 0030,0019, 0056, 0497
NTC 0092
Nikko 0030, 0178, 0092
Noshi 0018
Onwa 0180
Optimus 0154,0250, 0166
Optonica 0093,0165
Orion 0236, 0463, 0179
Panasonic 0051,0250, 0055
Penney 0047,0156, 0051, 0060, 0030, 0178, 0021, 0019, 0018, 0056,
0039,0003, 0027, 0032, 0135
Philco 0054,0463, 0030,0145, 0019, 0020, 0096
Philips 0054
Pilot 0030, 0019, 0039
Pioneer 0038, 0166
Portland 0019, 0039, 0092
Prism 0051
Proscan 0047
Proton 0178,0003, 0052, 0466
Pulsar 0017,0019
Quasar 0051,0250, 0165, 0055
RCA 0047, 0051, 0093, 0019, 0018, 0038, 0090, 0135
Radio Shack 0047,0154, 0165, 0180, 0030, 0178, 0019, 0056,0039,0032
Realistic 0154,0165,0180, 0030, 0178, 0019, 0056, 0039, 0032
10
Millennium 4 Mnl M4090 7/23/99 9:34 AM Page 10
