Universal Furniture Storage Unit User manual

General Single Ped. Table: 1 leaf, 1 bag, 4 bun feet, no leveler
Version 20081118
GOOD, AFFORDABLE, SMART DESIGN
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material.
The manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for
packaging carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use everyday, bolts and nuts may loosen up. They should be periodically inspected
and re-tightened to prevent damage to the furniture and (or) personal property or cause injury. Always check
to be sure all hardware on this list is attached to the furniture and kept tightened at all times.
Assembly Procedure: (Please follow the sketches below.)
For All beds:
Step 1: Unpack, inspect, and read assembly instruction carefully. Lay out the parts and hardware.
Make sure the quantity of each is correct.
Step 2: Position the storage unit in the approximate desired location.
Step 3: Align the holes in the headboard post with the inserts in the end of the front frame of the
storage unit. Loosely attach the headboard with bolts and wrench. Repeat this step with
footboard.
Step 4: Position the side rail to align with the second hole and the last hole in the other headboard
post and loosely attach with brackets, lock washers, nuts and use spanner to tighten them.
Repeat this step with footboard.
Step 5: Tighten all bolts by wrench and all nuts by spanner.
Step 6: Screw slat roll between side rail and front frame of storage unit with wood screws by using
Phillip head screw driver (not provided). Unpack the divider package from drawer and attach
divider to magic wire in place.
Note: If you purchased the extension kit, please assemble the extension kit first, and then assemble
this storage. (Follow the sketch)
Assembly is now complete.
HARDWARE LIST:
2
1
3
4
4 PCS
6
51 PC
5/16"*3-1/2"
22*1.5
5/16" 70*30*5mm 1 PC
5/16"*3-1/2"
5/16"
7
8PCS
4 PCS
4 PCS
4 PCS
4 PCS
8
D o w e l
B ra c k e t
L o c k W a s h e r
N u t
Spanner
B o lt
W re n c h
W o o d s c re w
INSTRUCTION SHEET
Storage Unit

General Single Ped. Table: 1 leaf, 1 bag, 4 bun feet, no leveler
Version 20081118
7
1
2
345
6

General Single Ped. Table: 1 leaf, 1 bag, 4 bun feet, no leveler
Version 20081118
2
1
3
4
8 PCS
8 PCS
51 PC
F e m a le C o n n e c to r
A lle n W re n c h
Connector B o lt
L o c k W a s h e r
F la t W a s h e r
8 PCS
8 PCS
H a rd w a re p a c k a g e f o r e x te n s io n k it a s s e m b ly
