Owner's Manual
TKP-7000
Network Keypad

TKP-7000 Owner's Manual ©2012-2013 Universal Remote Control, Inc.
The information in this owner’s manual is copyright protected. No part of this
manual may be copied or reproduced in any form without prior written consent
from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPER-
ATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this owner’s manual may be subject to change without prior
notice.
URC - Control the Experience is a registered trademark of Universal Remote
Control, Inc.
Total Control is a registered trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
Universal Remote Control,Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: [phone] Fax: [phone]

TABLE OFCONTENTS
Introducing the TKP-7000 1
Installing the TKP-7000 3
Installation 4
Main Menu Navigation 5
Rooms Menu 12
Time & Weather Module 16
Shortcuts Pop-Up 17
Adjusting User Settings on the TKP-7000 19
Rebooting Your TKP-7000 28
Specifications 28
Limited Warranty Statement 29
End User Agreement 31
Federal Communication Commission
Interference Statement 32
Regulatory Information to the user 33

Page 1
TKP-7000
Introducing the TKP-7000
Thanks for purchasing URC's TKP-7000 in-wall touch-screen. Its easy,
intuitive use will help simplify your life while adding control of more
things than you thought possible.
Enjoy some key features like:
Rooms Menu
With the touch of a single button, take control of your domain.
Besides the ability to temporarily link the different rooms/areas of your
system for music listening, the Rooms Menu offers a snapshot of “what's
going on” in every room of your Total Control system. Better yet, tapping
on a room will convert your keypad into a controller for THAT room.
See how easy it is to keep track of what's happening in your world…
and control it!
Shortcuts Pop-Up
With all of the different options to choose from, the Shortcut Pop-
Up allows you to save some of the most common devices/activities
for easy selection. Keep up to 6 different activities at your fingertips
with the Shortcuts Pop-Up menu.

Page 2
TKP-7000
Capacitive Touch screen
Navigation just became easier; it's as simple as a “swipe” or “flick”.
By incorporating gesture control, every screen can be explored by
simple finger swipes while the on-board accelerometer supports
flicking.
Time & Weather Module
A simple button press opens the Time & Weather Module; a full
screen display keeping you “up to date” with today's time, date and
weather conditions.

TKP-7000
Installing the TKP-7000
The TKP-7000 is wall-mountable and fits easily into a dual-gang
opening. Prior to installation, make sure power is available at the
preferred location.
Power can be supplied to the TKP-7000 in any of the following
ways:
=An Ethernet cable connected to a PoE (power over ethernet)
router/switch
=An Ethernet cable connected to a PoE (power over ethernet)
injector
Power over Ethernet or PoE technology describes a system to pass
electrical power safely, along with data, on Ethernet cabling. The
IEEE standard for PoE requires Category 5 cable or higher for high
power levels.
Page 3

TKP-7000
Installation
Follow the diagram below for installation:
1. Make sure the dual-gang opening is fitted with a standard two-
gang trim box (available from the local electrical supplier/store)
2. Connect the Ethernet cable to the rear of the supplied TKP-7000
wall-plate.
3. Mount the wall-plate to the two-gang retro-box
4. The TKP-7000 easily snaps into place to the wall-plate.
Page 4

Page 5
TKP-7000
Main Menu Navigation
Although specific screen design and certain options will be dictated
by the custom integrator that programmed the Total Control System,
the general layout will remain the same. Actual navigation is performed
through screen swipes (Up/Down, Left/Right) while selecting any item
is as simple as pressing the icon/text to be selected.
The MAIN menu screen may be programmed any number of ways,
however, the general layout will remain the same
Reset button
Light Sensor

TKP-7000
Page 6
Title Bar
The Title Bar will be present on all TKP-7000 screens and contains
valuable information during normal use. Easily find out the time,
weather, now playing information and the room that the keypad is
controlling.
Time & Weather
This data, found on the left-hand side of the Title Bar will show the
current time, date and weather information. Pressing this area of the
Title Bar will open the Time & Weather Module. For more
information about this module, refer to the Time & Weather Module
section, later in this manual.
Current Room
The current room portion of the Title Bar shows the room that the
TKP-7000 is controlling. Remember, in a Total Control system,
although each room's keypad will default to control the room in
which it is placed, using the Rooms Menu will allow it to control
any other room in the your system.

TKP-7000
Page 7
Now Playing
Appearing on the right-hand side of the Title Bar, this displays the
source that is currently being used in the room that the keypad is
controlling.
• The Now Playing display will show the device that is being used
(in this case, William's iPod), associated artwork, and metadata
information is displayed since it is a URC media device.
The metadata will change, every 5 seconds, rotating
between song, artist and album.
• If an activity is being performed (like DVD or Cable) in the
selected room, the Now Playing section will display the activity.
If an activity is being performed in the selected room, the Now
Playing bar will describe the activity.

TKP-7000
Page 8
Categories/Devices Ribbon
This ribbon will show the various categories of control that are
available to the selected room. The quantity of categories is
determined by the system setup and can vary from one to however
many categories were programmed by the system designer.
Although only seven categories can fit on the screen at any moment,
navigate to other categories, if available, by swiping left or right.
Select a category by pressing the appropriate icon; this reveals the
devices/activities available for that category (submenus).
Device List
Submenus contain the devices/activities that were placed in the chosen
category by the system programmer.
Scroll up or down through the list by swiping upwards or downwards,
select a device/activity by pressing its icon.

Page 9
TKP-7000
Status Bar
The Status Bar, located directly above the Core Buttons, provides
valuable status and feedback of the Total Control system.
The four sections of the Status Bar are determined by the system
programmer, and are customizable per keypad,so it is not possible
to explain how your keypad looks; however, after reviewing the
following possibilities, there should be no need for further explanation.
Sunrise Time: Updated at midnight every day, this will show the
sunrise time for the next day.
Sunset Time: Updated at midnight every day, this will show the
sunset time for the next day.
URC Thermostat Temperature: If a THZ-100 (URC's thermostat) is
included in your home, this will show the current temperature status
based upon the internal sensor, additional sensor or the mean
temperature of both.
Alarm Clock: If the room being controlled has an Alarm that is set
to activate for that room the status bar will display an alarm clock
icon and the next scheduled time/day.
Surround Mode: When used with URC's DMS-AV Surround Processor
this will display the current surround mode of the processor.
Room Linked Status: Whenever the chosen room/area is “linked” to
other rooms, this will show a link
acknowledgment and icon.
Weather Alerts: Based on the current location entered by the system
programmer, the words “weather Alert” will appear
if an automatic alert is received via internet.
Vacation Mode: Whenever the Vacation Mode is activated for the
Total Control system, the status bar will display “Vacation Mode:
ON”.

Core Buttons
These key system navigation buttons will always be present at the
bottom of the screen.
Vol-, Vol+ & Mute
These audio controls will affect the volume for the room to which
the TKP-7000 is assigned. See the Rooms Menu section of this manual
for more details.
Main
Selecting this button will always return the user to the Main screen
Shortcuts
These user-configurable shortcuts allow the end-user to store up to 6
favorite activities. For more information about using shortcuts, refer
to the Using Shortcuts section of this manual.
Rooms
This selection will open the Rooms Menu and allow for monitoring
and/or control of other rooms in the project. See the Rooms Menu
section of this manual for more details.
Page 10
TKP-7000

Page 11
TKP-7000
Power
When pressed, this performs the Room Off function programmedby
the custom integrator.
If this button is pressed for greater than 3 seconds, the Power Menu
appears.
In this menu, it is possible to:
• Turn Off the ROOM (this is the same as tapping the Power button).
• Issue the House Off command, as programmed by the custom
integrator.
• Custom commands, programmed by the custom integrator, may
also appear in this menu.

Page 12
TKP-7000
Rooms Menu
The Rooms Menu is the “landing” screen for a TKP-7000. This menu
(see picture below) will be displayed whenever the keypad reboots,
loses/regains power or is reset. The most common choice would be
to select the room where the TKP-7000 is physically located,
however, as we will discover, this is up to the user.
The Rooms Menu is used to:
• Temporarily Link rooms in a Total Control DMS system. This
allows all of the linked rooms to listen to the same audio source
and join the volume commands into a single interface.
• Monitor the status of other rooms in the Total Control project
• Control any other room in a Total Control project as if it were a
keypad in that room. This is dependent upon the programming
done by the custom integrator.
Room List Buttons
• Each room listing will have an associated box and action buttons.
• The Exit button will return the user to the last screen used
• Selecting the room name will allow for control of that room (see
Selecting a Room)
Links
Rooms Options

Page 13
TKP-7000
Initial View (Room Monitoring)
When the Rooms Menu opens up, the room list populates with all
of the rooms in the Total Control project. Each room displays its
status so the user can visually see what is “going on” in that room.
The Exit button will return the user to the previous screen.
Selecting a Room (Room Control)
Selecting any room from the room list will allow the TKP-7000 to
control that room, as if it were physically in that room.
Returning the keypad to control the room where it is physically
located requires accessing the Rooms Menu and selecting the
appropriate room.

Page 14
TKP-7000
Linking Rooms (DMS Audio only)
Selecting the Link Rooms button will open up the Link Rooms
screen with the current room already selected. Only rooms/areas
that are part of the DMS family of products will appear.
=Select, using the check boxes, the rooms that you would like to
LINK. Pressing the check box will alternately “check” and
“uncheck” it.
=The Go Back button will cause the screen to revert to the Room
Menu without making any changes.
=The Done button will temporarily save the checked rooms as a
linked group that can be controlled from any of the linked
rooms.
Linked rooms are saved until the power is turned OFF, or the user
manually de-links the room(s).

Page 15
TKP-7000
Using Linked Rooms
Once a room is linked, pressing the volume or mute buttons for that
room will cause the Linked Rooms Volume Pop-Up to display
This menu will display the volume levels for all rooms in the
temporary group.
=Selecting All Linked Rooms results in the volume and mute
commands to operate ALL rooms (e.g. Volume Up will cause
the volume in all linked rooms to rise simultaneously, and at
the same rate).
=Selecting an individual room in the Linked Room List allows
the volume and mute buttons to adjust sound ONLY for the
room chosen.
Room Options
Selecting the Room Options button for a room will cause the menu
to expand and offer the user various options to control the room.
=Lights Off: If URC controlled lights are located in the selected
room, the Options menu will display a light bulb icon. Selecting
this icon will issue a “lights off” command for the chosen room.
=Power Off: Selecting the power icon will issue a “room off”
command for the selected room. The default for this command
is to turn off all audio and video device in that room, however
this may have been altered by the system programmer.
All Linked Rooms

Page 16
TKP-7000
Time & Weather Module
This module displays information about the time, date and local
weather.
Pressing on the Time, Date & Weather display in the Title Bar of the
TKP-7000 opens the Time & Weather Module.
=Selecting Exit will return to the previous screen
=Selecting Night Mode will place the TKP-7000 into a low light mode
to prevent it from overpowering a dark room. This mode will disable
any photo slideshow or screen time-out time andremain in this mode
until touched again.
=Once touched, the screen will revert to its normal mode of opera-
tion, including displaying a photo slide show and turning Off
after the amount of time determined in the Settings Menu.

Page 17
TKP-7000
Shortcuts Pop-Up
The Shortcuts Pop-Up menu is designed to give the user the ability
to select their most frequently used devices/activities and place
them within an easy to reach menu.
There are a maximum of six (6) shortcuts per room location.
Remember, regardless of the physical location of the TKP-7000, it
may still access, via the Rooms menu, any of the other rooms in the
Total Control system (dependent upon programming). Each room
can be assigned up to 6 shortcuts in this menu.
Only items that appear in the currently selected room are available
to be added to the Shortcuts Pop-Up.
Using the Shortcuts Pop-Up
Select the Shortcuts Pop-Up by pressing the Shortcuts icon in the
Core Menu.
If the screen is not touched, after 60 seconds the Shortcut Popup
will close and the TKP-7000 will revert to its previous screen.
Selecting a shortcut is the same as navigating to that same icon
(within the submenu) and selecting it.
Add devices/activities to this menu by selecting the Add/Edit button
in the Shortcut Popup.
This opens the Shortcuts Add/Edit screen, which will allow the user
to scroll through all of the devices/activities available to that room.
