Univex Swing Ring Series User manual

nivexExacting Standards, Just Like Yours, sirce 1948
SRM2O/SRMF2O
Swing Ring Series
SRM2O/SRMF2O PLANETARY MIXERS
Maintenance & Parts Manual
Persons under the age of 18 are not permitted to operate or have
accessibility to operate this equipment per U.S. Dept. of Labor Employment
Standards Administration Fact Sheet No. ESA91-3.
UNIVEX CORPORATION - 3 Old Rockingham Road - Salem, NH 03079-2140 - Tel [phone] - Fax [phone]
Int'l Tel [phone] - Int'l Fax [phone] - Website www.univexcorp.com - E-mail [email protected]
ED6 SRM2O/0203 Printed in USA
E
Ex xa ac ct ti in ng g S St ta an nd da ar rd ds s, , J Ju us st t L Li ik ke e Y Yo ou ur rs s, , s si in nc ce e 1 19 94 48 8
UNIVEX CORPORATION -3 Old Rockingham Road -Salem, NH 03079-2140 –Tel [phone] –Fax [phone]
Int’l Tel [phone] –Int’l Fax [phone] –Website www.univexcorp.com -E-mail [email protected]
ED6 SRM20/0203 Printed in USA
S
Sw wi in ng g R Ri in ng g S Se er ri ie es s
S
SR RM M2 20 0/ /S SR RM MF F2 20 0 P PL LA AN NE ET TA AR RY Y M MI IX XE ER RS S
Persons under the age of 18 are not permitted to operate or have
accessibility to operate this equipment per U.S. Dept. of Labor Employment
Standards Administration Fact Sheet No. ESA91-3.
SRM20/SRMF20
S
SR RM M2 20 0/ /S SR RM MF F2 20 0
Maintenance & Parts Manual
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
TABLE OF CONTENTS
LIST OF ILLUSTRATIONS
ILLUSTRATION PAGE
Page 1
FIGURE 1OVERALL VIEW OF MIXER 2
FIGURE 2 LUBRICATION INSTRUCTIONS 5
FIGURE 3TRANSMISSION 11
FIGURE 4 BEATER HEAD ASSEMBLY 12
FIGURE 5POWER TAKE OFF ASSEMBLY 13
FIGURE 6 INPUT ASSEMBLY 14
FIGURE 7 VERTICAL SHAFT ASSEMBLY 15
FIGURE 8BOWL LIFT ASSEMBLY 16
FIGURE 9 BOWL SUPPORT ASSEMBLY 17
FIGURE 10 SPEED CONTROL ASSEMBLY 18
FIGURE 11 VARI SPEED AND DRIVE SYSTEM 19 -20
FIGURE 12 HOUSING ASSEMBLY 21 - 22
FIGURE 13A WIRING DIAGRAM 115V, 208-230V 60HZ, 1PH,
220-240 V, 50HZ, 1PH, 100V, 50/60HZ, 1PH 23
FIGURE l3B WIRING DIAGRAM 115V, 60HZ, 1PH, CANADIAN ONLY
220-240 V, 50HZ, 1PH, EUROPE ONLY 24
FIGURE 13C WIRING DIAGRAM 380-400 V, 50HZ, 3PH EUROPE ONLY 25
DESCRIPTION PAGE
TROUBLE SHOOTING GUIDE 3
REMOVAL OF TOP COVER 4
MECHANICS MAINTENANCE 4- 5
REPAIR INSTRUCTIONS 6 - 10
REPLACEMENT PARTS, LISTS 11 - 22
WIRING DIAGRAMS 23 -25
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

11. CORD Page 2
SRM2O - SRMF2O
OVERALL VIEW OF FOOD MIXER
Figure 1
1. BEATER SHAFT 12. START BUTTON
2. CHUTE 13. STOP BUTTON
3. SAFETY RING ASSEMBLY 14. BOWL LIFT HANDLE
4. MAGNET 15. REAR ACCESS PANEL
5. NO. 12 HUB 16. SHIPPING BOLT FIOLE
6. THUMB SCREW 17. BOWL SUPPORT
7. UPPER MOUNTING BRACKET 18, BOWL
8. TIMER (OPTIONAL) 19. BOWL SUPPORT PIN
9. SPEED CONTROL LEVER 20. BOWL MOUNTING BRACKET
10. SPEED INDICATOR LABEL 21. LOWER MOUNTING BRACKET
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
SRM2O/SRMF2O TROUBLESHOOTING GUIDE
Page 3
TROUBLE POSSIBLE CAUSE REMEDY
1. Mixer will
not operate. 1.1 Electrical service down
1.2 Burned switch contacts
1.3 Timer not turned on
1.4 Motor capacitor defective
1.5 Burned out motor
1.6 SAFETY RING not
mounted and closed.
1.7 Bowl not raised
1.1 Check electrical service. Replace
fuse or reset circuit breaker as
necessary.
1.2 Replace.
1.3 Turn timer on.
1.4 Replace
1.5 Remove, test, repair or replace.
1.6 Install SAFETY RING ASSY
1.7 Raise bowl completely
2. Mixer runs
but beater
will not turn,
2.1 Speed changed while
mixer not running
2.2 Broken or slipping belt
2.3 Key or Pin sheared on
ìnput shaft' input gear,
bevel pinion, vertical
shaft or beater shaft.
2.1 While mixer running, move speed
control lever slowly forward then
back
2.2 Broken or slipping belt
2.3 Locate by step inspection and
replace defective part.
3. Slippage of
agitator
during
mixing.
3.1 Loose belts
3.2 Mixer bowl is over-loaded
3.3 Speed is set too high for
the mix
3.1 Tighten beltb.
3.2 Readjust contents of bowl per table
of contents.
3.3 Shift speed lower till action rotates
smoothly.
4. Speeds will
not change. 4.1 Loose belts
4.2 Van-speed pulley
inoperable,
4.1 Tighten or replace
4.2 Remove, clean and lubricate or
replace.
5. Attachments
contact
bottom of
bowl,
5.1 Dented bowl
5.2 Insufficient clearance
between bottom of bowl
and beater.
5.3 Misalignment of
transmission in relation
to bowl support.
5.1 Remove dent or replace bowl.
5.2 Readjust bowl lift
5.3 Realign transmission.
6. Excessive
noise. 6.1 Gears need tobe repacked
with grease.
6.2 Badly wons or frayed
drive belts.
6.3 Attachments hitting bowl
6.4 Overloaded mixing bowl.
6.1 Locate source by inspection and
repack with grease.
6.2 Replace belts.
6.3 Inspect for cause Ref: 5.1 and 5.2.
6.4 Readjust contents of bowl per table
of mixing capacities.
7. Difficulty in
raising or
lowering
bowl.
7.1 Lack of adequate
lubricant on bowl lift
slide assembly and
housing.
'7.1 Lubricate with grease per Figure 2.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
REMOVAL OF TOP COVER
The top cover (Fig. 12 [16]) must be removed in order to perform the maintenance
operations. It is secured by a spring clip at its front end and a screw at its
rearward end. First, DISCONNECT THE ELECTRICAL POWER FOR SAFETY.
Then, remove the screw in the rear (Fig. 12 [20]), lift rear of cover, push forward
about 3 inches and lift cover off.
Re-install in reverse procedure using care to insure that the cover sits squarely
and uniformly on the mixer housing.
MECHANICS MAINTENANCE
Every six months a mechanic should perform the following inspection and maintenance as
required:
1. BELTS
WARNING: Start mixer and adjust speed control (Fig. 1 [9)) to speed 4. Stop
mixer. FOR SAFETY' DISCONNECT POWER.
Remove top cover (Fig. 12 [16]) and rear access panel (Fig. 12 [23 J).
e. Check belts (Fig. ii [11 & 21]). If broken, glazed or worn, replace.
d Check belt (Fig. 11 [11]) for proper tension. The outer edge of the belt should be
flush with the outer diameter of the variable speed pulley (Fig. 11 [10)). If not,
adjust by loosening the Jam Nut (Fig. 10 [15 J) and turning the connecting rod
(Fig. 10 [14]) until the outer edge of belt is flush with the outer diameter of the
pulley. Retighten Jam Nut.
WARNING: Plug machine in, start mixer, and adjust speed control to speed 1.
Stop mixer. FOR SAFETY, DISCONNECT POWER.
Check belt (Fig. 11 [21)) for proper tension. The outer edge of the belt should he
flush with the outer diameter of the variable speed pulley (Fig. Il [10)). If not,
adjust by loosening nuts (Fig. 11 [13 J), holding motor (Fig. 11(30)), raise or
lower the motor until the outer edge of belt is flush with the outer diameter of
pulley. Retighten Nuts.
2. MOTOR
Check motor (Fig. 11(30]) for overheating, noise and excessive end play of shaft.
Replace if defective.
3. BOWL LIFT ADJUSTMENT (Fig. 8 and 9)
Place 20 qt. mixing bowl (Fig. 1 [18]) on bowl support and 20 qt. batter beater on
beater shaft (Fig. 1 [1]).
Raise bowl support to the high position.
e. Check clearance between bottom of bowl and lowest point of batter beater.
Clearance should be 3/16 inch, plus or minus 1/16 inch.
d. If adjustment is required, disconnect power, loosen lock nut (Fig. 8 [lO]) and (urn
linkage rod (Fig. 8 [9]) until desired clearance is obtained. Retighten lock nut.
Page 4
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Internal Gear
Bowl Lift
Slide
Bowl Lift
Bearing
Page 5
Speed Control
Bearin9
SRM2O - SRMF2O
4. LUBRICATION
The lubrication instructions are in Fig. 2. Motors have pre-lubricated bearings with a
service interval often years. The transmission and beater head gearing are packed with
Nevastane 5p7 grease. They must be repacked every 500 hours of operation.
WAINING: NEVER WORK ON THE TRANSMISSION WITH THE MIXER
RUNNING. IT IS RECOMMENDED THAT THE ELECTRICAL SERVICE BE
DISCONNECTED TO PREVENT ACCIDENTAL START UP.
LUBRICATION INSTRUCTIONS
FIGURE 2
OIL YEARLY.
MEDIUM (NO. 30)
MACHINE OIL.
GREASE EVERY 500
HOURS OF OPERATION
(KEYSTONE
NEVASTANE 5P7
GREASE YEARLY
MOLYKOTE BR2 PLUS.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
REPAIR INSTRUCTIONS
(Including disassembly, replacement and reassemble)
TRANSMISSION (Fig. 3)
Removal
WARNING: DISCONNECT POWER FOR SAFETY.
Remove housing top cover (Fig. 12 [16]).
Adjust speed control to low speed, then back to high speed, remove upper
retainer bracket (FIG. 11 [15]), and upper V-belt (Fig. 11 [11]) from
transmission driven pulley (Fig. 11 [12]). Remove driven pulley.
CAUTION: Transmission assembly is heavy and must he supported prior to
removing. Remove four cap screws (Fig. 3 [10]) securing transmission housing
to mixer housing. Remove transmission assembly and place on work bench.
Remove transmission cover (Fig. 3 [2]) by sliding toward the rear aiid lifting
up.
Rotate gear train by hand and inspect for worn or chipped gears, bent shafts.
worn bearings and excessive backlash. Backlash measured at gear teeth
exceeding 1/32" is considered excessive. After trouble has been isolated,
proceed to disassemble.
Disassembly
1. Beater Head Assembly (Fig. 4)
NOTE: If a gear requires replacement, always replace its mating
gear.
Remove cap screw, left hand thread, (Fig. 4 [12]) and remove heater
head assembly using jacking screws (Fig. 4 [9[) if necessary.
Remove drive pin (Fig. 4 [1]), top retaining ring (5), gear (6). key (3).
bottom retaining ring (5), retaining ring (7) and press shaft (2) and
bearing (4) from housing (10).
e. Press bearings (4) along with spacer (8) from shaft (2).
2. Power-Take-Off Assembly (Fig. 5)
Remove three cap screws (Fig. 5 [8]), washers (6 & 7), deflector (5).
retaining ring (3), gear (12), and withdraw assembly from housing (4).
Remove adapter (2), retaining ring (10) and press shaft (13) hearings
(9) and gear (11) assembly from housing (4).
Remove pin (17), gear (il), remaining retaining rings (3). key (14) and
press bearings (9) from shaft (13).
Page 6
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRIvÍF2O
3. Input Assembly (Fig. 6)
Remove two cap screws (Fig. 6 [10]) and withdraw assembly from
transmission.
Remove retaining ring (I), gear (2), keys (5, 7), retaining rings (1) and
press shaft (6) and bearing (4) from housing (8).
e. Remove retaining rings (3) and press bearing (5) from housing (6).
d. Remove retaining ring (1) and press shaft (6) from bearing (4).
4. Vertical Shaft Assembly (Fig. 7)
Remove key (4).
Invert housing on suitable support and press shaft (2) from
transmission housing (Fig. 3 El]).
Remove lower bearing (8) with puller and remove spacer (7).
Remove retaining ring (6) and pull or press upper bearing (5) from
transmission housing (Fig. 3 [1]).
Remove pin (3) and press shaft (2) from gear (1).
REASSEMBLE
Clean all components except bearings with safety approved cleaning
solvent. Inspect components for defects and replace those found to be
defective.
NOTE: All gears should be replaced as sets.
If shafts have become slightly scored during the disassembly process,
polish the shafts with fine machinist's crocus cloth. Use care to avoid
excessive removal of shaft surface or proper fit of components will be
lost.
e. Reassembly should be carried out in the reverse of the disassembly
procedures stated above. Successful reassembly is very dependent on
the cleanliness of all surfaces particularly the bores of housings, gears
and bearings as well as the outer surface of shafts. It is well to
recheck each component for cleanliness as it is picked up for
reassembly. New keys and roll pins should be used on reassembly.
d. Transmission should be progressively checked for smooth operation
while on the workbench by hand turning each assembly as it is
installed.
Page 7
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
e. Lubrication of the transmission should be done following its
installation on the mixer. Apply Keystone Nevastane 5P7 grease to
the spur gear and bevel gear meshes. This may be simplified by
feeding the grease into the rotating gear meshes. Caution should be
exercised to avoid entrapment of the application implement in the gear
teeth, Insure the deflector (Fig. 5 [5]) is positioned to dynamically
guide the lubrication into the bevel gear mesh.
BOWL SUPPORT ASSEMBLY (Fig. 9)
WARNING; Disconnect electrical power for safety.
Remove housing top cover (Fig. 12 [16]), and rear access panel (Fig. 12
[23 j).
Remove four cap screws (Fig. 9 [15]) and remove bowl support (Fig. 9 [1 J)
and slide cover (Fig. 9 [3]).
CAUTION: Bowl support must be held while screws are being removed in
order to prevent it from falling.
Reassembly is the reverse procedure.
SLIDE ASSEMBLY (See Fig. 9)
Carry out above disassembly procedure for removing bowl support.
Remove fixed slide cover (Fig. 12 [6]) by removing two nuts. (Fig. 12 [5])
Remove retaining ring (Fig. 9 [8]) from rod end pin (6). Withdraw pin (6)
from rod end (7).
Remove four kep nuts (Fig. 9 [13]) and withdraw slide frame (5) from
housing studs.
Remove four cap screws (Fig. 9 [14]) and lift off gibbs (Il). Remove slide
(IO).
Clean and inspect sliding surfaces for excessive wear
Replace parts showing excessive wear,
Lubricate sliding surfaces with grease.
Reassemble and reinstall in the reverse of the above procedure,
Check clearance between batter beater and bowl per Mechanics Maintenance
paragraph 3 a-d and readjust as necessary.
Page 8
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2O - SRMF2O
SPEED CONTROL ASSY. (Fig. 10)
.jumbly
Remove housing cover (Fig. 12 [16]) and rear access panel (Fig. 12 [23]).
Loosen screw on collar (Fig. 10 [17]). Remove collar rod end (16) and
o'ring (Fig II [8]) from cam assembly (lI). Loosen set screws (10) in cam
assembly (Il).
Drive roll pin (4) from hub (3) and pull hub (3), lever (2), and handle (1)
from cam assembly shaft (Il). Remove washer (5) from cam assembly
(Il)
Unscrew hub (3) and handle (1) from lever (2).
Remove nut (8) and washer (7) from studs holding speed control bearing (6)
to housing (Fig. 12 [3]).
6, Withdraw bearing (6) and remaining assembly from housing (Fig. 12 [31).
Pull cam assembly (11) from bearing (6).
Remove screws (20), lock washers (21), strap (22), and spring (19) from
bearing (6).
Remove screws (13) and detent disk (12).
Rc&ssernik
10 Reassemble in reverse of above procedure. Grease cam assembly shaft (Il)
and detent disk (12) during assembly with MolyKote BR2 Plus or general
purpose bearing grease. Adjust belt as described in Mechanics Maintenance
1 paragraph a,d-f.
11 1f speed control handle (I) moves while the mixer is running, tighten set
screws (10) against spring washer (9) until movement stops.
YARI-SPED ASSEMBLY (Fig Il)
PisisseJllWy
Remove housing cover (Fig. 12 [16]) and rear access panel (Fig. 12 [23]) as
described in the cover removal section.
Shift handle (Fig. 10 [I]) from fourth speed to first speed and back to fourth
speed with the mixer OFF. (Squeezing the belts (Fig. Il [Il & 21]) together
at midspan will help.)
Unscrew nut (13) and remove washer (14) and belt retainer (15).
Unwrap belt (Il) from pulley (12) and withdraw from van-speed pulley
(10).
Shift handle (Fig. 10 [1]) to first speed.
Unscrew nuts (13). Remove washers (14) and belt retainer (22) from mixer.
Page 9
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SRM2() - SRMF2O
Unwrap belt (21) fi-orn pulley (27). Withdraw belt (2 1) from van-speed
pulley (10).
Loosen screws on contactor (Fig. 12 [32]) which secure motor cord power
leads (34). Remove nut (38), lock washer (37) and motor cord ground lead
from weld stud. Remove nuts (38), washers (36) arid cord clamps (35).
Remove nuts securing motor (30) and lift motor from mixer. Loosen set
screw (28) and slide pulley (27) and key (29) off motor shaft.
Remove two screws securing connection box plate on rear end of motor.
Remove green grounding screw securing motor cord (33) ground lead. Pull
cord leads from motor terminals.
Loosen jam nut (Fig. 10 [15]). Loosen set screw on collar (Fig. 10 [17]).
Slide collar and rod end (Fig. lO [16]) off cani assy. (Fig. 10 [1 1]).
Unscrew rod end (Fig. 10 [16]) and jam nut (Fig. lO [15]) from connecting
rod (Fig. 11 [17]). Unscrew connecting rod from rod cud (Fig. il [7]).
Remove nuts (13) and washers (14). Withdraw varispeed pulley assy. from
mixer housing.
Loosen the two set screws on each van-speed pulley (10) and remove from
shaft (9). Remove woodruff keys (16) and retaining rings (1) from shaft.
Drive shaft (9) from pulley swivel bracket (4). Press remaining ball
bearings (2) from shaft (9) and from swivel bracket (4). Remove retaining
rings (3) from swivel bracket.
Remove retaining rings (6) from rod end pin (5) and bracket swivel pin (20).
Drive pins (20 & 5) from swivel bracket (4) aiid swivel bracket base (1 8).
Reassemble
Reassemble in reverse of above procedure. Adjust belts as described in
Mechanics Maintenance I paragraph a,d-f.
Adjust upper and lower belt retainers (15 & 22) 1/8" from outer belt surface.
HOUSING (Fig 12)
For the remaining parts which have not been discussed pertain to electrical
components and the housing, Figures 12, 13A, l3B, and 13G should provide
adequate guidance for the disassembling and reassembling of these parts.
Page 10
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Page 11
TRANSMISSION SRM2O - SRMF2O
FIGURE 3
ILLUS. PART NO. DESCRIPTION QTY.
1. 1024434 Transmission Housing
2. 1024117 Transmission Cover
3. 1200012 Phillips Hd. Screw 10-32 x 1/2 6
4. 1024041 Spring Clip 1
5. 1200076 Steel Flat Washer #10 2
6. 4400065 Split Lock Washer #10 6
78800022 Foam Strip
8. 1200084 Steel Flat Washer 1/2 4
9 . 1200085 Split Lock Washer 1/2 4
10 1200057 Socket, Hd. Cap Screw 1/2-20 x 1 4
11. 4400194 Dowel Pin 1/4" OD. x 1/2" LG 2
12. 1200440 Hex Hd. Cap Screw 10-32 x 1 4
13. 1020011 Internal Gear
14. 4400342 Label, Univex SRM2O) I
4400343 Label, Univex (SRMF2O)
15 1012438 Holder, Magnet 2
16 1012439 Magnet 2
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Page 12
BEATER HEAD ASSEMBLY SRM2O - SRMF2O
FiGURE 4
ILLUS. PART NO. DESCRIPTION QTY.
1023075 Beater Head Assembly
11200381 Drive Pin 3/8" x 1-1/4"
21023014 Beater Head Shaft
31200113 Woodruff Key #9
41030019 BaIl Bearing 6204LL 2
51200119 Retaining Ring, External 3
61012003 Beater Head Gear
71200117 Retaining Ring, Internal
81012012 Beater Head Spacer
98900038 Set Screw 2
10 1020106 Beater Head Casting
11 4400499 Washer 7/16" x 1-118" X5/64'
12 1200051 Hex. Hd. Cap Screw 3/8-24 x l-1/4" LU.
13 1020002 Splash Ring
14 4400269 Label, Rotation
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

* Not available - Part of PTO. Shaft Illus NO. 13
Page 13
POWER TAKE OFF ASSEMBLY SRM2O - SRMF2O
FIGURE 5
ILLUS. PART NO. DESCRIPTION QTY
1. 8800033 Cover, PTO. (With PTO )
2. 8800012 Adapter, Attachment (With PTO ) 1
3. 1200119 Retaining Ring, External 5
4. 4400030 Housing, PTO. (With PTO )
1012446 Housing, (Without PTO )
51024417 Deflector, Lubrication I
6. 4400005 Washer, Lock 1 4 3
7. 1200075 Washer, Flat 14 1
8. 1200025H Screw, Hex Hd. Cap 14-2O x 3/4 2
9. 1030019 Ball Bearing 6204 LL 2
10. 1200117 Retaining Ring, Internal
11. 1030031 Bevel Gear, Pinion Only 1
12 1020004 Spur Gear
13. 1021016 Shaft, PTO. ( With PTO )
1024420 Shaft, (Without PTO)
14. 1200113 Woodruff Key #9 1
15!' 4400006 Spring, PTO. Shaft ( With PTO )
16,* 4400016 BaIl, PTO. Shaft ( With PTO ) 1
17. 1200103 Roll Pin 5/16" x 1-1/4" 1
18. 4400229 Knob Assy, PTO. (With PTO ) 1
19. 4400210 Washer, PTO. 1
20. 8900019 Screw SFHD 6-32 x 3/8 2
21. 1200022H Screw, Hex Hd. Cap 1/4-20 x 1" 1
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Page 14
SRM2O - SRMF2O
INPUT ASSEMBLY
FIGURE 6
ILLUS. PART NO. DESCRIPTION QTY.
102 1036 Input Assembly 6
1. 1200119 Retaining Ring, External
21020010 Spur Gear, Input Pinion Only 2
3. 1200117 Retaining Ring, Internal 2
4. 1030019 Ball Bearing 6204LL
5. 1200113 Woodruff Key #9
61024186 Input Shaft
7. 4400230 Key 3/16" sq. x 1-1/2 1g.
8. 1030017 Input Housing 2
9. 4400003 Steel Flat Washer 14 ID. 2
10. 1200022H Hex. Hd. Cap Screw 1/4-20 x 1 2
11. 4400005 Lock Washer, 1/4
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Page 15
VERTICAL SHAFT ASSEMBLY SRM2O - SRMF2O
FIGURE 7
ILLUS. PART NO. DESCRIPTION QTY.
11020215 Bevel Gear
21012434 Vertical Shaft
34400022 Roll Pin 5/16" x 1-1/2
41200113 Woodruff Key #9
51030035 Ball Bearing 63204 ZZ
61200117 Retaining Ring, Internal
71020009 Vertical Spacer
81030019 Ball Bearing 6204 LL
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

* Part No, 1023053 is broken in half in Figure 9. lt is actually one piece and only one is
needed for bowl lift,
** Includes items 14 and 15.
'° Comes with Set Screw 10-32 x 3/4LG.
Page 16
SRM2O - SRN1F2()
BOWL LIFT ASSEMBLY
FIGURE 8
ILLUS. PART NO. DESCRIPTION QTY.
11024512 Lever, Bowl Lift (SRMF20 ONLY)
1025446 Lever, Bowl Lift (SRM2O ONLY)
2*** 1012350 Collar, Bowl Lift
34400118 RoIl Pin 1 x 3/16" 1
41200301 Nylon Washer 5/8
51012133 Bowl Lift Bearing 3
64400127 Steel Flat Washer 3/8 3
71200063 Kep Nut 5/16-18 1
8 ** 1024012 Cam Assembly (includes items 14 & 15)
9 * 1023053 Connecting Rod
10 1200155 Hex Nut 3/8-24
11 1012201 Rod End, 3/8-24 RH.
12 1020441 Collar & Set Screw
13 1030318 Spacer, Nylon 3/8
14 1200435 Reversible Lock nut 5/16-24
15 1200434 Set Screw 5/16-24 x 11/8
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

same part as ILLUS. NO. 9 in Figure 8.
Page 17
BOWL SUPPORT ASSEMBLY SRM2O - SRMF2O
FIGURE 9
LUS. PART NO. DESCRIPTION QTY.
11021028 Bowl Support
24400219 Pin, Bowl Support 2
31021019 Slide Cover, Movable
44400278 Gasket Strip 2
51012190 Frame, BL.
61012181 Pin, Rod End
71012202 Rod End 3/8-24 L.H.
81200311 Retaining Ring, External 2
9 * 1023053 Connecting Rod, BL.
10 1012189 Slide, BL.
11 1012191 Gibb, BL. 2
12 4400127 Steel Flat Washer 3/8 4
13 1200063 Kep Nut 5/16-18 4
14 1200039 Hex Hd. Cap Screw 5/16-18 x 3/4 4
15 4400178 Hex Hd. Cap Screw 5/16-18 x 1-1/2 4
16 1200077 Lock Washer 5/16 4
17 1020091 Bowl (Not Shown)
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

* Part No. 1030223 is also shown in Figure il. It is actually one piece and only one s
needed for speed control, van-speed assembly.
SRM2O - SRMF2O
SPEED CONTROL ASSEMBLY
FIGURE lo
Page 18
ILLUS.
1
2
34567
8
910II121314 *15.16171819202122
PART NO.
4400202
1020066
1012137
1200300
1200301
1020068
4400127
1200063
1200156
1200304
1020069
1023222
1200471
1030223
1200155
1012201
1020441
1030318
1023223
4400208
4400005
1023225
DESCRIPTION
Handle
Lever, S.C.
Hub, S.C.
Roll Pin 3/16' x 2"
Nylon Washer 5/8
Speed Control Bearing
Steel Flat Washer 3/8
Kep Nut 5/16-18
Spring Washer 5/8
Set Screw 10-32 x 3/4
Cani Assy, S.C.
Detent Disk
Screw Hex Soc Hd 10-32 x 1/2
Connecting Rod, S.C.
Hex Nut 3/8-24
Rod End 3/8-24 RH.
Collar & Set Screw
Spacer, Nylon 3/8' ID
Spring, S.C.
Phillips Pan Hd. Screw 1/4-20 x 1/2
Lock Washer 1/4
Strap, S.C.
QTY.
1
2
2
2
2
2
2
2
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

* Same part as ILLUS. NO. 4 in Figure 10.Page 19
ILLUS. PART NO.
SRM2O - SRMF2O
VARI-SPEED ASSEMBLY
FIGURE 11
DESCRIPTION QTY.
I12001 19 Retaining Ring, External 2
21030019 BalI Bearing 6204LL 2
312001 17 Retaining Ring, Internal 2
41030167 Pulley Swivel Bracket I
51012181 Rod End Pin i
612003 1 i Retaining Ring, External 4
71012202 Rod End 3/8-24 LU.
84400009 Rubber "O" Ring 3/16 x 4"
91021022 Van-Speed Shaft
10 1020061 Van-Speed Pulley (Cornes with (2) l/4-20x3/8 set screws) 2
11 1020501 Cog Belt
12 1020500 Pulley, Driven (Comes with 5/16-18x3/8 set srew)
13 1200063 Kep Nut 5/16-18 10
14 Reserved
15 1023240 Belt Retainer, Upper i
16 1200113 WoodruffKey#9 2
17 * 1030223 Connecting Rod, SC. i
18 1030216 Swivel Bracket Base i
19 1200083 Steel Flat Washer 3/8 4
20 1030191 Bracket Swivel Pin
21 1020502 Cog Belt
22 1023220 Bracket, Belt Retainer
23 4400127 Steel Flat Washer 3/8 8
24 1200413 Hex Hd. Cap Screw 1/4-20 X 1-1/2 1
25 1200075 Washer, Flat 1/4 1
26 1023219 Roller
27 1021030 Pulley, Drive (Comes with 5/16-18x1/4 set screw)
28 Reserved
29 4400230 Key, 3/16" sq. x l-1/2"
30 1025024 Motor, 1/21W, I l5V/230V, 60HZ, IPH (Includes item 29) 1
1020024A Motor, l/2HP, 220V-240V, 50HZ, 1PH, (Includes item 29)
100V, 50/60HZ, IPH
1020026 Motor, 1/2HP, 380 V,5OHZ,3PH (For Europe Only) (Includes
item 29) 1
31 1020218 Motor Mount SRM2O Only
32 7100107 Strain Relief
33 8800200 Cord, Electric 115V, 60HZ, IPH
100V, 50/60HZ, IPH i
8800201 Cord, Electric 230V, 60HZ, IPH
220-240 V, 50HZ, 1PH
8800102 Cord, Electric 230V, 50HZ, IPH (CE)
7100100 Cord, Electric 220/380V, 50HZ, 3PH
400V, 60 HZ, 3PM, 400V, 50HZ, 3PH, (British & CE)
8800101 Cord, Electric 230V, 50HZ, 1PM, (British) ¡
34 8800203 Cord, Motor 1PM
8800226 Cord, Motor 3PM
35 4400101 Clamp, Cord 3
36 1200076 Washer, Flat #10 2
37 4400065 Lock Washer #10 2
38 1200060 Hex Nut, 10-32 6
39 4400398 Tie Wrap (Not Shown) ¡
40 4400141 Nut, Kep 1/4-20 1
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor
