SRM12M-1 PLANETARY MIXER
OPERATOR’S MANUAL
Persons under age 18 are not permitted to operate or have accessibility to
operate this equipment per U.S. Dept. Of Labor Employment Standards
Administration Fact Sheet No. ESA913.
SRM12M-1 REV A

Welcome to Univex
Thank you for purchasing this Univex Product.
Your new SRM12M-1 mixer has been designed with advanced performance and safety features that make it an
excellent addition to your food preparation equipment. Like all Univex mixers, slicers, meat grinders and
accessories, this mixer is engineered to provide years of reliable service.
If you have any questions concerning the operation of this unit, or if we can be of further assistance, please
call our Customer Service Department for the location of your nearest service representative.
Univex Customer Service:
USA & Canada 800-258-6358
International 603-893-6191
Or visit us on-line at www.univexcorp.com under service agents.
Safety is our top priority
READ AND MAKE SURE THAT YOU UNDERSTAND THE INSTRUCTIONS AND SAFETY
WARNINGS IN THIS BOOKLET BEFORE ATTEMPTING TO OPERATE THE MIXER OR
ATTACHMENTS.
NEVER PUT FINGERS OR HANDS IN THE BOWL WHILE THE MIXER IS OPERATING OR
SERIOUS INJURY COULD RESULT.
NEVER ATTEMPT TO CLEAR A JAMMED ATTACHMENT OR STALLED MIXER WITHOUT
SHUTTING THE POWER OFF AND DISCONNECTING THE ELECTRICAL POWER SUPPLY CORD.
DO NOT OPERATE THIS MIXER WITHOUT THE BOWL IN PLACE.
DO NOT OPERATE THIS MIXER WITHOUT THE SWING RING SAFETY GUARDS INPLACE.
Page 1

TABLE OF CONTENTS
DESCRIPTION PAGE
WELCOME TO UNIVEX..................................................................................................1
TABLE OF CONTENTS, LIST OF ILLUSTRATIONS...................................................2
CHOOSING THE RIGHT LOCATION FOR YOUR MIXER..........................................3
USER FRIENDLY SWING RING SAFETY GUARD…..................................................3
OPERATING THE SRM12M-1 MIXER...........................................................................4
CLEANING YOUR MIXER.............................................................................................5
OPERATOR’S PREVENTIVE MAINTENANCE...........................................................5-5.1
ELECTRICIAN'S WIRING DIAGRAM............................................................................6
WARRANTY...............................................................................................BACKCOVER
Page 2

CHOOSING THE RIGHT LOCATION FOR YOUR NEW MIXER
When selecting the best location for the mixer, it is helpful to consider the following:
Where is the best location for the operator, both for saving steps and easy viewing?
Is this a good location for product flow as in:
Easy to get ingredients to the mixer?
Destination of the mix after mixing?
Is there existing electrical service at this location?
Does this location provide easy access for cleaning and service?
Check to be sure that your mixer with attachments does not extend out into heavy traffic areas.
If stands and / or portable equipment are to be used along side of your mixer, can they be moved
easily to and from your mixer?
USER FRIENDLY SWING RING SAFETY GUARD
Your SRM12 mixer features a two part safety guard. The Swing Ring Safety Guard is easily removed
and installed, as well as dishwasher safe. It conveniently swings out of the way without having to be
removed to place or sample ingredients in the bowl. Only one side of the guard needs to be open when
adding ingredients. This two-piece design handles and fits conveniently in your sink or dishwasher. It
also provides a clear view of the product throughout the mixing cycle.
This mixer will not operate unless the Swing Ring Safety Guard is properly engaged.
The guards activate safety switches that enable the mixer to operate only when the guards are closed.
These switches protect against accidental operation of the mixer when the guards are open or
removed from the mixer. The mixer will automatically stop if the guard is opened. An additional
switch in the bowl lift automatically stops the mixer if the bowl is lowered from the “up” (mixing)
position.
To install the Swing Ring Safety Guard, insert the pointed end of the rod at the rear of the guard into
the lower mounting bracket on the mixer housing. Then insert the top end of the rod into the upper
bracket by aligning the groove in the rod with the slot in the bracket. Press the rod in and allow it to drop
down into position. Swing the two halves of the guard forward. Magnets located on the transmission will
hold the guards in position. When the guard is properly closed, the switches will be activated and the
mixer can be operated.
To remove the guard, simply reverse the installation procedure. Grip the two halves of the guard and
pull it open. Use an upward motion to release each half of the guard from the bracket on the machine
body.
To open the guard for access to the bowl, first turn the mixer off by pushing the red “Stop” push-
button. Pull open the two halves of the guard and swing one or both guards outward. It is not
necessary to remove the. Close the guards and press the green “Start” push-button to resume mixing
operations.
Page 3

SRM12M-1
OPERATING IN TRUCTION
The SRM12M-1 is a one speed 12 quart food mixer with a built in timer / alarm.
Read and make sure that you understand instructions and safety warnings before attempting to operate
the SRM12M-1 mixer.
1. To operate the mixer, mount the mixing bowl on the bowl support.
2. Slide the pastry knife onto the beater head shaft and rotate it 1/4 turn counter-clockwise to lock it
into place.
3. Add the ingredients to the mixing bowl (add liquid ingredients first).
4. Install the safety ring onto the mixer.
5. Raise the mixing bowl by rotating the bowl lift lever counter-clockwise.
NOTE: The mixer can only be started when the safety ring is in place and the bowl is in the
raised position. Do not operate the mixer without the bowl in place.
6. Start the mixer by pushing the green start push button. The SRM12M-1 has been set at the
factory for a 45 second mixing cycle. The mixer will stop and automatically reset to 45 seconds
when:
a. The mixer completes a full mixing cycle.
b. When the mixing cycle is manually stopped by pushing the red stop push button.
c. The mixer is stopped by a power outage.
7. An alarm will sound at the completion of the mixing cycle. Press the red stop push button to shut
off the alarm.
8. To remove the product after the mixer has stopped, lower the bowl, remove the safety ring,
remove the pastry knife and lift the bowl off the support.
9. Clean the bowl, pastry knife and mixer as soon as possible with warm water and mild soap and a
soft cloth or sponge. Do not hose the machine.
10. All operators should read the manual provided and understand all safety warnings before operat-
ing the mixer.
WARNING: DO OT PUT HA DS, SPOO S OR UTE SILS I THE BOWL WHILE THE
MIXER IS OPERATI G.
Page 4

CLEANING YOUR MIXER
Consistent use of the following procedures will ensure that your mixer is in optimum operating
condition.
•Warning: disconnect the power supply cord before cleaning.
xWash the body of the mixer, the bowl support, and the beater shaft with warm water and mild
soap.
xAvoidexcesswaterintheareaofthesafetyswitchesthatprotrudefromthehousingwherethe
xSwingRingSafety Guardis mounted.
xDo not rinse the mixer with a hose.
xDo not use abrasive pads to wash the mixer.
xDry the mixer thoroughly with a soft cloth.
xWashthebowlandbeaterimmediatelyafteruse.Ifaneggmixtureorflourbatterhavebeen
used,rinsethebowlandbeaterwithcoldwaterbeforewashingwithhotwater.
xWashtheSwingRing SafetyGuardinthesamemanner,orin a dishwasher.
xDry bowls and beaters and the Swing Ring Safety Guard thoroughly.
OPERATOR’S PREVENTIVE MAINTENANCE
For best long-term performance, operators should follow these simple practices:
xLightly lubricate the beater head shaft after washing with a food grade lubricant.
xDo not cover the mixer with a plastic bag, as this traps humidity inside the mixer.
xIf the electrical supply cord becomes damaged, it must be replaced with an approved cord or
assembly available from Univex directly or from a Univex service agent.
xDonotoverloadthemixer.
oOverloadingisthe#1causeofmixerfailure.
xKeep the mixer properly lubricated.
oLack of lubrication is the #2 cause of mixer failure.
Page 5

LUBRICATION
The lubrication instructions are in Figure 2. The motor has pre-lubricated bearings with a service
interval of ten years. The transmission and beater head gearing are packed with Nevastane 5P7 grease.
They must be repacked every 500 working hours of the mixer.
WARNING: NEVER WORK ON THE TRANSMISSION WITH THE MIXER RUNNIN .
IT IS RECOMMENDED THAT THE ELECTRICAL SERVICE POWER CORD BE DISCON-
NECTED TO PREVENT ACCIDENTAL START UP.
LUBRICATION INSTRUCTIONS
FIGURE 2
Molykote BR2 Plus
B
Internal Gear
C
machine oil.
B
Bowl Lift
Medium (3 weight)
Slide
A
Grease yearly with
Oil yearly
C
Grease every 5
hours of operation
with food grade
grease.
Bowl Lift
Bearing
Spur Gear
ASpeed Control
A
Bearing
B
B Bevel Gear
Page 5.1

WIRING DIAGRAM
115V, 60HZ, 1PH
Page 6

Warranty
The Univex SRM12M-1 mixer carries a two-Year, on-site, parts and
labor warranty against any defects in materials or workmanship. The
two-year period begins on the date of purchase by the end user and
remains in full effect provided the unit is used properly in accordance
with our instructions. Any Work to be performed under this warranty
must be performed between the hours of 8:00 a.m. and 5:00 p.m. local
time, Monday through Friday. Univex will not cover overtime charges
of any kind. Please call the Univex Warranty Service Department at
[phone] to report any warranty claims before arranging repair
or attempting to return the unit to Univex Corporation.
Damages incurred in transit or incurred because of installation error,
accident, alteration or misuse are not covered. Transit damages should
be reported to the carrier immediately.
Univex will not be liable for any consequential, compensatory,
incidental or special damages.
