Univex GL50 User manual

Parts and Maintenance Manual for
GL50 Spiral Mixer

GL50 MIXER 2 of 29
WARRANTY TERMS
Validity: The warranty starts from the delivery date and lasts 12 months, if:
 The mixer was not damaged during transportation, and it was installed, commissioned,
used and serviced as prescribed in this manual.
 It was not tampered with, modified and no unintended tools were installed on it.
 It did not undergo modifications or repairs carried out by the customer or third parties in an
incompliant fashion or without the prior consent of the supplier.
The following conditions constitute improper use of the mixer:
• Loading more than what is allowed or use of unsuitable ingredients.
• Cleaning with unsuitable tools or instruments that can scratch the bowl or damage the
mixer or paint.
• Use of the mixer in unsuitable places.
Warranty
If the customer finds defects in the mixer, he must immediately inform the supplier, who will carry
out a quick analysis of the lack of compliance and will establish the next steps to be taken with the
customer.
The customer must provide the needed time and opportunity to carry out modifications,
improvements, repairs or the supply of spare parts which the supplier deems reasonably
necessary. If this does not occur, the supplier will not be held liable.
Parts subject to wear
Some components are made to last far longer than that of a normal mixers life expectancy.
Breakage or malfunctioning of these pieces depends on their use. They are therefore considered
parts subject to wear and are not included in the warranty, unless they manifest evident defects in
the parts or machinery.
The parts subject to wear are: transmission belts, motors, bearings and bowl.

3 of 29
CONDITIONS FOR USE:
Installation requirements: The mixer needs to be installed inside of a lit, ventilated building, on top of a
solid and level support. Operating temperature range from 5 to 40°C with humidity no greater than 90%.
Lighting: the light at disposal of the operator must comply with the type of work carried out, in relation to
general lighting, according to the Standards in force. It must on any account be sufficient to read the controls
and danger signs.
Vibrations: in correct working conditions, vibrations do not create dangerous situations.
Noise emissions: 70 dbA for normal use.
Electromagnetic environment: the machine has been built to work correctly in an industrial type of
electromagnetic environment.
Environments with risk of explosion: An atmosphere capable to being transformed into an
explosive atmosphere due to room and/or operating conditions is defined a potentially explosive
atmosphere.
The mixer was not built to work in environments with potentially explosive atmospheres.
MACHINE IDENTIFICATION:
There is a plate on the back of the mixer which carries indications concerning the manufacturer, the type of
machine, serial number, electrical features, and certifications.
Storage of packed mixer:
The mixer must be stored in a closed and covered place, on a smooth and solid surface protected from dust
and filth, sheltered from atmospheric agents and hygienically safe.
The temperatures must remain between –20 and +50°C, and humidity no greater than 90%.
Installation:
The mixer must stand in a vertical position, on a smooth surface sufficiently sturdy for the load (floor with
resistance over 20 km/cm2).
ATTENTION.
Do not make the mixer function only on wheels, always tighten the two supports until the wheels are fully lifted.
Connection to electrical mains:
The electrical connection must be carried out by a specialised electrician, according to the
standards in force in the country where it is installed. Make sure that the voltage and frequency of
the system are the same as those on the mixer identification plate. Incorrect connection makes the
warranty void.
Preservation of the machine: Storage before a long period out of service
Clean the mixer thoroughly.
Disconnect it from the electrical mains.
If possible, put it back into its original packing.
GL50 MIXER

4 of 29
GL50 MIXER
Dimensions:

GREENLINE 50 MIXER CAPACITY CHART
* Absorption Ratio (% AR) =water weight / Flour weight
Note:
Cold water causes dough to be stiff and hard to mix, increasing the load on
the mixer transmission and motor. Never use ICE as solid part, melt it before
add it into the mixer bowl. Pie Dough can be succesfully mixed in speed “1”
GREENLINE 50 KG (110 LB) OF MIXING DOUGH
PRODUCT FLOUR BATCH
LOW GLUTEN FLOUR 60% AR 65 LB. 110 LB.
BREAD, PIZZA DOUGH 60% AR 50 LB. 85 LB.
BREAD, PIZZA DOUGH 50% AR 45 LB. 70 LB.
BREAD ,PIZZA DOUGH 40% AR 35 LB. 50 LB.
PIE DOUGH 25 LB. 40 LB.
BAGEL DOUGH 40 LB. 60 LB.
5 of 29
GL50 MIXER

TROUBLE POSSIBLE CAUSE REMEDY
1. MIXER WILL NOT
OPERATE
1.1 ELECTRICAL SERVICE DOWN.
1.1 CHECK ELECTRICAL SERVICE. REPLACE
FUSE OR RESET CIRCUIT BREAKER AS
NECESSARY
1.2 SAFETY GUARD NOT CLOSED 1.2 CLOSE SAFETY GUARD
1.3 TIMER NOT TURNED ON 1.3 TURN TIMER ON
1.4 EMERGENCY STOP BUTTON PUSHED 1.4 TURN EMERGENCY STOP BUTTON
IN CLOCKWISE TO RELEASE
1.5 BURNED SWITCH CONTACTS 1.5 REPLACE OR CLEAN CONTACTS
1.6 BURNED OUT MOTOR 1.6 REMOVE, TEST, REPAIR OR REPLACE
2. MIXER RUNS BUT
SPIRAL WILL NOT
TURN.
2.1 BROKEN OR SLIPPING BELT 2.1 TIGHTEN OR REPLACE
2.2 BROKEN PULLEY 2.2 REPLACE
3. SPIRAL RUNS BUT
BOWL WILL NOT RUN
3.1 BROKEN OR SLIPPING BOWL CHAIN 3.1 TIGHTEN OR REPLACE
4. ALL THE LIGHTS ARE
ON BUT MIXER WILL
NOT OPERATE
4.1 THE THERMAL PROBE STOPPED THE
MOTORS BECAUSE THE DOUGH WAS TOO
STIFF, OR THE MIXING TIME TOO LONG
4.1 WAIT 20 MINUTES UNTIL THE MOTORS
TEMPERATURE GOES DOWN AND PRESS
START BUTTON TO FINISH THE MIXING
CYCLE
5. EXCESSIVE NOISE 5.1 GEARS NEED TO BE REPACKED WITH
GREASE OR OIL LEVEL IS LOW.
5.2 NOTIFY A SERVICE AGENT
5.2 BADLY WORN OR FRYED DRIVE BELTS 5.2 REPLACE BELT
5.3 OVERLOAD MIXING BOWL. 5.3 ADJUST CONTENTS OF BOWL PER
MIXING CAPACITIES TABLE
TROUBLE SHOOTING GUIDE
6 of 29
GL50 MIXER

CONTROL OF INSTALLED SAFETY SYSTEMS AND ELECTRICAL
SYSTEM:
The installed safety systems and t he electrical system are subject to periodical checks carried out by a
specialised electrician.
Key of control intervals:
(INTERVAL)
Key of how to carry out the controls:
(METHOD)
d = daily.
w = weekly.
m = monthly.
a = annually.
O = observation: requires simple eye check (i.e. alarm light)
F = Function: requires a phys
ical control of the action (i.e. pressing the
emergency button the mixer must stop)
M = Measurements: requires a c ontrol with an appropriate instrument (i.e.
control of earthing values).
Master switch.
Purpose: protection of power line.
Function: this equipment separates the machinery from the mains, it is placed on
the upright of the mixer, downstream the differential protection board.
Safety micro switch of grid.
Purpose: stop the machine temporarily. Function: by lifting the protection grid, the
motor power supply interrupts, temporarily stopping the machine. To reset the
machinery functioning, lower the grid and press the START button.
Stop Circuit (emergency).
Purpose: to stop the mixer immediately and unconditionally. Function: pressing
the STOP button cuts the power supply to the mixer, stopping it totally and not
systematically. To restore functioning of the machinery, the operator must release
the emergency button and start the cycle once again by pressing the START
button.
Controls of system
Periodically the mixer's automation functioning and earthing must be c hecked.
The operating modes, safety functions, terminal board contacts need t o be
controlled as well as the integrity of the cables, luminous LEDs and ear thing
system.
Control
Interval
Method
a
F
Control
Interval
Method
m
F
Control
Interval
Method
m
F
Control
Interval
Method
a
F
7 of 29
GL50 MIXER

DO NOT CARRY OUT ANY MAINTENANCE OR CLEANING WITH ELECTRICITY
CONNECTED
All bearings and transmission parts are lubricated for life. Keep the mixer clean to
avoid flour from depositing in the moving parts thus generating bothersome creaking
and abnormal wear.
To tension the belt,
remove the upper
casings, loosen the
motor bolts and act on
the appropriate register.
Fasten the motor bolts,
place the casings back
and test the machine.
*See Diagram below
Problems with the grid
micro switch: remove
the upper protection
casing, adjust the
micro switch position
close the casing again
and test the machine.
Should a power cable
be damaged, replace
it with a H07RN/F
cable with a 3x1.5
mm2 section
Cleaning: the mixer is not
water-proof. Do not wash it
with running water/hose. Clean
it with a moist cloth and neutral
detergents. Do not use excess
amounts of water as it is hard
to remove from the bowl.
To tension the chain
and the lower bowl
drive chain, remove
the lower casing (tilt
the machine) and act
on the appropriate
registers. Replace the
casing and test the
machine
*See Diagram below
Electrical issues must
be carried out by
qualified electrician,
with reference to the
layouts attached at the
end of the manual.
CLEANING AND MAINTENANCE OPERATIONS:
8 of 29
GL50 MIXER

GREENLINE 50 Recommended Spare Parts
Part Number
Quantity
Description
S12002901 1.35 ML Bowl Chain (Linear Meter)
S14002811 2 Black Feet
S13000601 1 Bearing 30306
S13000502 1 Bearing 30307
S01193094 1 Waterproof Seal
S13000306 1 Bearing 6006 2RS 2
S12003947 1 Belt Poly V J813 18 Rib
S13000317 1 Bearing 6206 2RS 3
S13000327 1 Bearing 6306 2RS 3
S13000328 1 Bearing 6307 2RS 3
S00003294 1 Main Power Switch Group
S03173098-2 1 Mobile Mixture Guard
S00003296 1 Grid Micro Switch
9 of 29
GL50 MIXER

CONTROL PANEL DESCRIPTIONS
Set the standard control panel (built up to October 2011)
-Turn Power switch on based on right side of Greenline Mixers.
-For some seconds you will see “SGM 01” blinking into the digital displays.
-After that you’ll find the last programmed times on 1st and 2nd displays.
-If you don’t need to change anything, you can press “start button” to start the mixing
cycle.
-The mixer will pass automatically from 1st to 2nd speed until the end of both times.
-If you need to set a new time configuration, please press “select” button.
The 1st speed light should be blinking. Use “+” or “-“ buttons to change 1st speed time ,
then press select to set the 2nd one use “+” or “-“ to regulate it and then press “select”
button again to set the timers.
-After that you can press “start” button and begin the mixing cycle.
-The Manual key selector is made only for emergency cases to overpass the electrical
chipboard and work manually in 1st or 2nd speed.
-Using the reverse Jog control, bowl and spiral will run counter clockwise but only until you
keep the selector pressed. It could be helpful at the start-up (for small quantities of dough)
or at the end of the mixing cycle for very wet dough. Do not use it for more than 60
seconds.
10 of 29
GL50 MIXER

SETTING THE NEW PROGRAMMABLE GREENLINE CONTROL PANEL
Programmable Control Panel – Greenline Version
Turn the main power switch on, you should see the on the first display the program number
blinking (ex. “P.01” or “P.02” etc…)
-Press “+” or “-“ buttons to choose the program number you would like to set.
-Press “select” button to see the timers for 1st and 2nd speed.
-Hold “select” button for a few seconds until you see the 1st speed light on.
-Use “+” or “-“ buttons to set the 1st speed time then press “select” to set the second one.
-You should see the second speed light on, set the timer for the second speed.
-Press select again to set the timer.
-Press “start” button to turn the mixer on.
-1st and 2nd speed have two different displays. The 1st one has only three numbers: 2 for the
minute and 1 for the ten second increments.
-The 2nd one has 4 numbers: 2 for the minutes and 2 for the seconds.
-When the timers countdown they pass automatically from 1st speed to 2nd speed and stop at
the end of the mixing cycle.
-You do not need to reset the programs every time you switch off and on the mixer.
11 of 29
GL50 MIXER

Number Part Number Description Quantity
1
S85193093-2 Control Panel Plate 1
2
S25001487 Electronic Timer
Chipboard
1
3
S25009061 Emergency Stop Button 1
4
S25004004 Manual Key Selector 1
5
S09193097 Panel Decal
1
6
S01167131 Waterproof Seal 1
7
S00003380
Reverse Direction Button
1
12 of 29
GL50 MIXER

Mixer Lid Part Listing
Illus Part No Description Qty
1S03173097-1 Fixed Mixture Guard 1
2S03173098-2 Mobile Mixture Guard 1
3S87173101-3 Stainless Steel Guard 1
4S85173102-2 Fixed Mixture Guard Pivot 4
5S85173076-6 Guard Pivot (Left) 1
6S85173092-4 Guard Pivot (Right) 1
7S15000002 Bushing Flange 2
8S1078048 Microswitch Cam 1
9S85173089-1 Eccentric Block 1
10 S85047046-4 Bracket 1
11 S85002511 Guard Bushing Plate 3
12 S14002510 Bushing Plate 3
13 S00003296 Guard Microswitch 1
14 S23010480 Snap Ring Ø 25 2
15 DIN 912 Screw TCEI M6 X 30 6
16 DIN 933 Screw TE M8 X 16 4
17 DIN 126 Washer M8 4
18 DIN 936 Low Nut M14 4
19 DIN 934 Nut M8 1
20 DIN 933 Screw TE M8 X 70 1
21 DIN 471 Elastic Ring Ø 17 2
22 DIN 913 Pin M6 X 8 3
23 DIN 912 Screw TCEI M8 X 35 2
13 of 29
GL50 MIXER

12
3
4
5
6
7 8
9
10
11
12
14 13
19
20
21
22
15
22
16 17 18
23
Mixer Lid
14 of 29
GL50 MIXER

1 S03173105 Upper Cover 1
2 S02173077-5 Electronic Panel Plate 1
3 S01173084 Carter Support Pivot 4
4 S86173010-2 Rear Cover 1
5 S86173009-2 Bottom Cover 1
6 S86173106 Front Bottom Cover 1
7 S02173008 Stainless Plate 1
8 S1173055 Countershaft 1
9 S1173079 Block 2
10 S85173086-1 Wheel Plate 2
11 S25001122 Cable Clamp 1
12 S00003294Main Power Switch 1
13 DIN 603 Carriage Bolt M5 X 20 10
14 DIN 126 Washer M5 34
15 UNI 8842 Serrated Lock Washer M5 10
16 DIN 934 Nut M5 10
17 DIN 438 Screw M8 X 30 4
18 DIN 912 Screw TCEI M5 X 10 18
19 ISO 7380 Screw TCBEI M5 X 16 6
20 DIN 933 Screw TE M10 X 40 4
21 DIN 126 Washer M10 4
22 ISO 7380 Screw TCBEI M6 X 10 8
23 DIN933 Screw TE M8 X 20 4
24 DIN 126 Washer M8 4
25 DIN 7991 Screw SPEI M10 X 20 4
Illus Part No Description Qty
Main Mixer Body Parts Listing
15 of 29
GL50 MIXER

1
2
6
5
4
8
7
3
9
10
11
12
13
16
15
14
13
14
14
14
14
14
15
16
21
20
23
24
22
19 18
18
17
19
25
Main Mixer Body
16 of 29
GL50 MIXER

Lower Mixer Body Parts Listing
1 S85173091 Foot Block 2
2 S14002811 Feet 2
3 S1173094 Wheels 4
4 S1173058 Wheel Shaft 2
5 DIN 933 Screw TE M10 X 16 8
6 DIN 126 Washer M10 8
5
6
1
2
5
63 4
17 of 29
GL50 MIXER

Spiral Transmission Parts Listing
Illus Part No Description Qty
1S14000004 AUTO-BLOCK RING-NUT 1
2S12003103 BELT SPAX 0857 SPIRALE 4
3S1173051 SPIRAL PULLEY 1
4S01173063 BEARING SPEACER 1
5S13000327 BEARING 6306 2RS 3 1
6S85173037-3 SPIRAL BUSHING PLATE 1
7S85173024-3 SPIRAL BUSHING 1
8S13000328 BEARING 6307 2RS 3 1
9S85173049-4 SPIRAL BUSHING PLATE 1
10 S87173041-3SPIRAL 1
11 S85173048-1 SPIRAL FLANGE 1
12 S86173021-2 MOTOR PLATE 1
13 S11001115 SPIRAL MOTOR 1
14 S23010151 STRETCHER 1
15 S1173029 MOTOR PULLEY 1
16 S1173087 TRANSMISSION BUSHING 1
17 S12003947 BELT POLYV 320J 180 SPIRALE 1
18 S13000317 BEARING 6206 2RS3 1
19 S1173050 NEUTRAL PULLEY 1
20 S13000306 BEARING 6006 2RS 2 1
21 S14000703 NILOS RING 3036 1
22 S19000025 MIM RING 45-80-10 1
23 S01173052-1 Return Shaft Pulley 1
24 S12003103 Belt Spa 857 1
25 DIN 912 Screw TCEI M6x15 1
26 DIN 8842 Teeth Washer M6 1
27 DIN 126 Washer M6 1
28 DIN 933 Screw TE M8x16 5
29 Washer 8x32 1
30 DIN 933 Screw TE M8x30 2
31 DIN 126 Washer M8 11
32 DIN 934 Nut M8 8
33 DIN 988 Spacer 35x45x0,5 1
34 DIN 7991 Screw SPEI M8x20 1
35 DIN 933 Screw TE M8x20 3
36 DIN 913 Pin M5x8 1
37 DIN 6885 A small plate 8x7x60 1
38 DIN 603 Squared screw M8x110 4
18 of 29
GL50 MIXER

1
2
3
4
21
5
6
7
9
8
10
11
22
13
12
14
15
16
18
17
19
20
23
24
25
26
27
32
38
37
31
35
34
33
36
28 29
30
31
32
28
31
Spiral Transmission'UDZLQJ
19 of 29
GL50 MIXER

Bowl Transmission Parts Listing
Illus Part No Description Qty
14173115 BOWL 1
285173124 BOWL SPACER 1
301173032-4 BOWL SHAFT 1
485173049-4 SPIRAL BUSHING PLATE 1
585173048-1 SPIRAL FLANGE 1
613000502 BEARING 30307 1
7S01173025 BOWL BUSH 1
813000601 BEARING 30306 1
985173037-3 SPIRAL BUSHING PLATE 1
10 01173046-2 CROWN BOWL HUB 1
11 1173047 BOWL CROWN 1
12 12002901 BOWL CHAIN 1
13 0173085-1 TENSION ROD PIVOT 1
14 01173070-2 BOWL TENSION PLATE 1
15 1173078 SMALL CROWN, CHAIN TRANSMISSION 1
16 13000315 BEARING 6204 2RS 3 1
17 1173071 PIVOT BOWL PLATE 1
18 01173033-1 BOWL PINION 1
19 13000316 BEARING 6205 2RS 3 1
20 02173081-1 TENSIONING PLATE 1
21 01173035-2 RETURN SHAFT 1
22 02173081-1 TENSIONING PLATE 1
23 19000025 MIM RING 45-80-10 1
24 DIN 934 Nut M8 11
25 DIN 8842 TEETH WASHER M8 7
26 DIN 126 Washer M8 10
27 DIN 7991 Screw SPEI M10x30 4
28 DIN 933 Screw TE M8x20 11
29 DIN 8842 TEETH WASHER M10 4
30 DIN 6885 A Small Plate 8x7x35 2
31 DIN 975 TENSION ROD M10 L=200 mm 2
32 DIN 1587 CLOSED NUT M10 3
33 DIN 975 TENSION ROD M10 L=500 mm 1
34 DIN 913 Pin M10x12 2
35 DIN 471 SNAP ring Ø 20 1
36 DIN 934 Nut M10 6
37 DIN 933 Screw TE M10x25 4
38 DIN 126 Washer M10 8
39 DIN 912 Screw TCEI M12x50 1
40 DIN 603 SQUARED SCREW M8x110 4
41 DIN 912 Screw TCEI M10x16 6
42 DIN 6885 A SMALL PLATE 8x7x50 1
43 DIN 988 SPACER 30x42x0,5 1
44 DIN 471 SNAP ring Ø30 1
20 of 29
GL50 MIXER
