UPPAbaby 2010 VISTA User manual

Stroller System
Cochecito
Système de Pousette
USA
UPPAbaby
60 Sharp Street, Hingham, MA 02043
781.413.3000
www.uppababy.com
Model 0112 | Version 3.0
Canada
5514KM
19 Industrial Street Toronto, Ontario M4G 1Z2
416.422.2700 | toll free: 1.888.502.5514
www.uppababy.com
Model 0130 | Version 5.0
VISTA and UPPAbaby are trademarks and/or registered trademarks of Monahan Products LLC.
All other trademarks are the property of their respective owners.
VISTA et UPPAbaby sont des marques et/ou des marques déposées de Monahan Products LLC.
Toutes les autres marques sont la propriété de leurs propriétaires respectifs.
VISTA y UPPAbaby son marcas comerciales y/o marcas registradas de Monahan Products LLC.
Todas las demás marcas comerciales pertenecen a sus respectivos propietarios.
0112_Vista_US_Ins_V5.indd 2-1 7/15/13 1:05 PM

TABLE OF CONTENTS
ÍNDICE /TABLE DES MATIÈRES
Please read these instructions carefully prior to assembly and use.
Leer atentamente estas instrucciones antes del ensamblaje y uso.
Veuillez lire attentivement ces instructions avant d’assembler et d’utiliser la poussette.
ENGLISH
WARNINGS + SAFETY INFORMATION 2
CLEATHING + GENERAL MAINTENANCE 4
PARTS LIST 5
STROLLER ASSEMBLY 6
BASSINET ASSEMBLY 8
BASSINET OPERATION 9
STROLLER OPERATION 11
LIMITED WARRANTY 15
ESPAÑOL
ADVERTENCIAS E INFORMACIÓN SOBRE SEGURIDAD 16
LIMPIEZA Y MANTENIMIENTO GENERAL 18
LISTADO DE LAS PIEZAS 19
ENSAMBLAJE DEL COCHECITO 20
ENSAMBLAJE DEL CAPAZO 22
FUNCIONAMIENTO DEL CAPAZO 23
FUNCIONAMIENTO DEL COCHECITO 25
GARANTÍA LIMITADA 29
FRANÇAIS
MISES EN GARDE ET INFORMATIONS SUR LA SÉCURITÉ 30
NETTOYAGE ET CONSIGNES GÉNÉRALES D’ENTRETIEN 32
LISTE DES PIÈCES 33
ASSEMBLAGE DE LA POUSSETTE 34
ASSEMBLAGE DE LA NACELLE 36
UTILISATION DE LA NACELLE 37
POUR OPÉRER LA POUSSETTE 39
GARANTIE LIMITÉE 43
0112_Vista_US_Ins_V5.indd 2-3 7/15/13 1:05 PM

2UPPAbaby VISTA Instruction Manual ENGLISH
3
WARNINGS + GENERAL SAFETY
INFORMATION
WARNINGS + GENERAL SAFETY INFORMATION
WARNINGS + GENERAL SAFETY
INFORMATION
WARNINGS + GENERAL SAFETY INFORMATION
WARNINGS
NEVER LEAVE CHILD UNATTENDED. FAILURE TO FOLLOW THESE WARNINGS
AND INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH:
Keep these instructions for future reference.
STROLLER WARNINGS:
• This stroller is suitable for children from birth (with optional Infant SnugSeat
accessory) until child is 50 lbs (22.7 kg), and child height is 40" (101 cm).
• This stroller is intended to be used with one child only, unless equipped
with UPPAbaby accessories.
• Audible “click” must be heard to confirm that each attachment is
connected properly.
• Bumper bar must be attached at all times.
• The brake must be locked while taking the child in or out of the stroller,
and when parked.
• Maximum weight for the storage basket is 15 lbs (6.8 kg).
• Maximum weight for the seat pocket is 1 lb (.5 kg).
• NEVER leave child in the stroller while ascending or descending stairs,
or using an escalator.
• DO NOT make any alterations or modifications to the stroller with
products not supplied by the manufacturer as this may cause instability
or structural damage not covered under warranty.
WARNING: To avoid serious injury from sliding or falling out, always use
complete 5-point harness.
WARNING: Child may slip into leg openings and strangle. NEVER use in
a reclinded position unless child is secured in 5-point harness system.
WARNING: Unit may become unstable if manufacturer’s recommended
load is exceeded, or if parcel bag or accessory other than that
recommended by the manufacturer is used or hung from the unit.
WARNING: Children and adults should be clear of moving parts while
making stroller adjustments. Damage to fingers or extremities may occur
when opening or closing the frame.
WARNING: The canopy for the seat is not intended to retain the child.
• Canopy must be attached at all times.
This product is designed and manufactured to comply with ASTM F833 Standard Consumer Safety Performance
Specification for Carriages/Buggies and is JPMA certified. This product is designed and manufactured to comply
with Canadian standard SOR/91-350,s. 1(F) Carriages and Buggy Regulations.
WARNINGS
BASSINET WARNINGS:
• Audible “click” must be heard in order to determine that each lock is in the
proper position. To ensure proper locking engagement, check to see that
the bassinet handle cannot be disengaged from the stroller without unlocking
the device.
• Bassinet attaches ONLY in the rear-facing direction, so infant is facing the user.
• Bassinet must be removed to fold stroller.
• Maximum child weight 20 lbs (9 kg).
• Maximum child length 25" (63 cm).
WARNING: To prevent falls, do not use this product when the infant begins
to push up on hands and knees or has reached manufacturer’s recommended
maximum weight, whichever comes first.
WARNING: Child’s movement can slide carrier. NEVER place carrier near
edges of counter tops, tables or other elevated surfaces.
WARNING: NEVER use the bassinet carrier as a means to transport an infant
in a motor vehicle.
WARNING: Use of bassinet cover is recommended for added safety of your
child. See page 8 for installation instructions.
WARNING: The bassinet should only be placed on a low, dry, firm horizontal
surface when not in use with stroller or bassinet stand.
WARNING: NEVER place carrier on beds, sofas or other soft surfaces.
WARNING: Do not permit other children to play unsupervised next to the
bassinet.
WARNING: Unit may become unstable if a parcel bag other than that
recommended by the manufacturer is used.
WARNING: Open flames and other sources of heat, such as electric heaters,
gas ovens, etc. in the immediate vicinity of the bassinet are dangerous and
should be avoided.
WARNING: This bassinet is only designed to be used with the VISTA stroller
frame.
WARNING: DO NOT use the infant carrier if it is damaged or broken.
STRANGULATION WARNING: Strings can cause strangulation! DO NOT
place bassinets with strings around a child’s neck, such as hood strings or
pacifier cords. DO NOT suspend strings over a bassinet or cradle or attach
strings to toys.
0112_Vista_US_Ins_V5.indd 2-3 7/15/13 1:05 PM

4UPPAbaby VISTA Instruction Manual ENGLISH
5
PARTS LIST
MATTRESS +
MATTRESS COVER
BASSINET
COVER
BASSINET
SEAT
STROLLER
FRAME
CANOPY
FRONT
WHEELS
REAR
WHEELS
BUMPER
BAR
BASSINET CANOPY
TODDLER SEAT
RAIN SHIELD TODDLER SEAT BUG SHIELD BASSINET BUG SHIELD BASSINET STORAGE BAG
FRAME AND FABRIC CARE:
• Clean frame with a damp cloth and a mild detergent and dry thoroughly. Do not use abrasives.
• If the stroller chassis parts have been exposed to salt water we recommend that they be rinsed with fresh (tap)
water as soon as possible to avoid corrosion. Always dry frame if wet.
• All fabrics are removable except the outer bassinet base.
• Remove shoulder harness straps with microsuede harness pads before washing seat fabric.
• For removable fabrics, hand wash in cold water with mild detergent. Air dry completely and away from direct
sunlight before re-use or storage.
• The bassinet base fabric may be sponged lightly using a damp cloth and a mild detergent. Allow to dry completely
before re-use or storage.
• To extend the life of your VISTA’s fabric, keep it clean and do not leave it in direct sunlight for long periods of time.
• Do not fold or store the VISTA if it is damp or wet, nor store in a damp environment.
MAINTENANCE AND REPAIR:
• This stroller requires regular user maintenance. Regularly check all connecting hardware (rivets, screws, etc.) for
tightness and security.
• Inspect your VISTA periodically. Seek prompt repairs, replacing worn or broken parts as needed. Check all safety
devices, locks and harnesses, for correct and secure operation. Never continue to use a product that is structurally
unsound.
• Only UPPAbaby replacement parts should be used. It may be unsafe to use parts supplied by another manufacturer.
• Contact Customer Service with any repair questions.
CLEANING + GENERAL MAINTENANCE
WARNINGS
BASSINET WARNINGS:
SUFFOCATION HAZARD:
I nfants have suffocated:
• Infants can suffocate in gaps between an extra pad and side of bassinet,
or on soft bedding.
• NEVER add a mattress, pillow, comforter or padding. ONLY use the mattress
pad provided by the manufacturer.
• If a sheet is used with a bassinet pad, use only the one provided by the
bassinet manufacturer or one specifically designed to fit the dimension of
the bassinet pad.
• DO NOT allow any part of the bassinet storage bag to cover a child’s nose
or mouth.
• To reduce the risk of SIDS pediatricians recommend healthy infants be
placed on their backs to sleep, unless otherwise advised by physician.
WARNINGS + GENERAL SAFETY INFORMATION
UPPAbaby reserves the right to make design changes and improvements
to any of our products as part of our commitment to innovation.
0112_Vista_US_Ins_V5.indd 4-5 7/15/13 1:05 PM

6UPPAbaby VISTA Instruction Manual ENGLISH
7
BASSINET
STORAGE BAG
TO REMOVE THE FRONT WHEELS:
Slide plastic lever in direction
indicated on button and pull wheel
out from frame.
TO INSERT THE FRONT WHEELS:
Slide each front wheel into the
housing until it locks.
STROLLER ASSEMBLY
INSTALL/REMOVE WHEELS
UNFOLD STROLLER
TO INSTALL THE BACK WHEELS:
While pressing in the hubcap of
the wheel, slide the wheel into
the axle until it locks into place.
TO REMOVE THE BACK WHEELS:
Push the hubcap in and pull the
wheel out.
STEP 1 : Pull latch back with your thumb to release
locking mechanism.
STEP 2: Pull the handle upward until the frame locks
open as shown.
STROLLER ASSEMBLY
STEP 1: Insert metal posts into bumper bar
attachment slots found on both sides of seat.
STEP 1: Pull canopy fabric over seat back.
STEP 2: To remove, press button at bottom of plastic
housing and lift bumper bar out.
STEP 2: Snap each side of canopy attachment to seat
frame above plastic ring.
ATTACH/REMOVE
THE BUMPER BAR CANOPY INSTALLATION
ATTACH THE SEAT
STEP 1: Insert the posts on the sides of the seat into
the slots of the frame. Push until you hear it “click”
on both sides.
STEP 2: Pull up on seat to be sure it is properly
attached to the frame.
STEP 3: To remove, simultaneously push down both
release buttons and lift the seat from the frame .
NOTE: Seat can attach in either forward or rear-facing direction.
WARNING: Bumper bar must
be attached at all times! NOTE: Canopy height is adjustable.
0112_Vista_US_Ins_V5.indd 6-7 7/15/13 1:05 PM

8UPPAbaby VISTA Instruction Manual ENGLISH
9
STEP 3: To remove, (arrow 1) simultaneously push down
both release buttons and (arrow 2) lift the seat from
the frame.
BASSINET ASSEMBLY
SET-UP THE BASSINET
STEP 2: Fold back liner.
STEP 4: Replace bassinet liner and mattress.
STEP 1: Remove mattress.
STEP 3: Pull both steel braces firmly into their
respective sockets. Make sure that both braces
are properly locked in place.
STEP 5: Pull bassinet canopy upright and fasten
canopy to Velcro strips at top of liner.
STEP 6: ATTACH BASSINET COVER
1: Place the closed end of the cover over the bottom
of the bassinet, and pull the cover toward the top of
the bassinet.
2: Fasten the ends of the bassinet cover to
the outside of the canopy with the Velcro strips.
BASSINET OPERATION
STEP 1: Insert the posts on the sides of bassinet
into the slots on the frame. Push until you hear it
“click” on both sides.
STEP 2: Check carefully that the bassinet is properly
attached to the frame by pulling up on the bassinet
carry handle.
ATTACH BASSINET
TO STROLLER
Undo Velcro flap found on bottom exterior of
bassinet and adhere to lower Velcro strip.
STEP 1: Unzip the bottom zipper on the canopy
hood exterior.
STEP 2: Lift and line up seam half-way until
magnets connect.
FOR ADDITIONAL
VENTILATION
VENTILATED CANOPY
STEP 1: Lift rear lever firmly and completely (90˚).
STEP 2: Lift bassinet off of frame using
carrying handle.
TO REMOVE BASSINET
NOTE: Bassinet attaches only in the rear-facing
direction so infant is facing the user.
NOTE: Bassinet must be removed
from stroller to fold.
0112_Vista_US_Ins_V5.indd 8-9 7/15/13 1:05 PM

10UPPAbaby VISTA Instruction Manual ENGLISH
11
BASSINET OPERATION
STEP 1: Collapse bassinet canopy by simultaneously
pressing buttons on both sides and pushing back.
STEP 2: Lift fabric liner and mattress out of the
way. Disengage by pulling steel braces from their
respective sockets.
USING BASSINET STORAGE BAG: Slide collapsed
bassinet into bag and fasten Velcro tab.
PROPER INSTALLATION OF BASSINET BUG SHIELD
COLLAPSING BASSINET PROPER USE OF ACCESSORIES
REMOVING BASSINET FABRICS
STEP 1: Remove liner by pulling
elastic up and over sides of
bassinet. Release side Velcro strips.
STEP 2: Unzip canopy zippers
located on the underside of canopy
where fabric meets the carry handle.
Detach Velcro from liner at bottom.
STEP 3: Unzip fabric sheet at top
of bassinet pad and remove.
CLEANING Hand wash gently with
mild detergent.
Dry flat and away from direct
sunlight before re-use or storage.
DO NOT bleach, iron
or dry clean.
STROLLER OPERATION
TO LOCK WHEEL SWIVEL: Push button down to lock.
TO UNLOCK: Slide button up.
CLICK
1
2
2
1
STEP 2: Reattach clip to the desired harness loop.
Use loop location above child’s shoulder line, or
closest to child’s shoulder.
USE SUNSHADE: Pull
sunshade out for SPF
50 sun protection.
USE PEEK-A-BOO
WINDOW: Roll flap
and attach.
STEP 1: Detach silver adjustment clip from upper
or lower harness attachment loop. (Remove
microsuede harness pad if necessary to facilitate
harness adjustment.)
TO ADJUST CANOPY: Slide canopy attachment
simultaneously up or down the seat frame (in
between two plastic rings) for desired height.
SET SWIVEL/
LOCKING SYSTEM
TO LOCK THE BRAKE:
STEP 1: Brake is located on the right rear wheel.
Push down on the pedal with foot to lock.
STEP 2: Attempt to push stroller back and forth
to ensure brake is engaged.
TO RELEASE BRAKE: Push the pedal down again.
SET THE BRAKE
ADJUST SEAT HARNESS ADJUST CANOPY
NOTE: Lock wheel swivel if traveling through rough
terrain or sand.
0112_Vista_US_Ins_V5.indd 10-11 7/15/13 1:05 PM

12UPPAbaby VISTA Instruction Manual ENGLISH
13
TO ADJUST LEG REST: Push both buttons (left
and right side of leg rest). Rotate leg rest to one
of five preset positions.
TO ADJUST HANDLE: Push the button at the top
and slide handle to one of three handle positions
suited to user height and comfort.
ADJUST HANDLE + LEG REST PROPER INSTALLATION
OF RAIN AND BUG SHIELD
STROLLER OPERATION
TO LOCK: Slide both belt ends together until
it locks.
TO OPEN: Depress button at center and pull apart.
Pull the lever near the top of the seat and tilt seat
to desired position. Release the lever to lock in
one of five preset positions.
LOCK THE HARNESS TILT THE SEAT
WARNING: Use the 5-point harness
to restrain the child while in the
stroller at all times. Adjust harness
to fit child securely.
NOTE: Do not use upright position for infants less
than six months old. Use the most reclined position
and gradually re-position the seat more upright as
the child is able to support its head without assistance.
Always re-adjust harness after changing positions.
STROLLER OPERATION
STEP 1: Activate the brake to prevent stroller from
rolling forward while folding.
FOLD STROLLER
STEP 2: Place handle bar in lowest position.
STEP 4: Holding both buttons, push handle bar all the
way in firmly until indication line meets top of plastic
collar on right side of handle bar, then push down.
You can now release both buttons.
STEP 5: Continue to collapse until locking mechanism
engages on right side of stroller. Stroller will stand
when folded.
STEP 3: Simultaneously, push and hold black plastic
tab on left side of stroller in with your left thumb
and squeeze the handle height adjustment button
with your right hand.
CLICK
1
2
2
1
21
CLICK
1
2
2
1
2
1
NOTE: When folding frame with seat attached, seat must be in forward facing and upright position.
WARNING: Children and adults should be clear of moving parts while
making stroller adjustments. Damage to fingers or extremities may occur
when opening or closing the stroller frame.
0112_Vista_US_Ins_V5.indd 12-13 7/15/13 1:05 PM

14UPPAbaby VISTA Instruction Manual ENGLISH
15
REMOVE FABRIC FROM SEAT
STEP 1: Unfasten Velcro
from lower foot rest.
STEP 2: Disconnect
straps on side of seat
that are wrapped
around seat frame.
STEP 3: Release strap on the underside of seat and
slide fabric over and off of the top of seat frame.
Reverse process when putting fabric back on seat frame.
STROLLER OPERATION
REMOVE FABRIC FROM CANOPY
STEP 1: Unscrew hinge on one side of canopy.
STEP 3: Remove plastic frame from hinge by sliding
it upward.
STEP 2: Remove hinge from aluminum frame.
STEP 4: Remove frame from canopy by sliding fabric
off of both aluminum and plastic frames.
CLEANING Hand wash gently with
mild detergent.
Dry flat and away from direct
sunlight before re-use or storage.
DO NOT bleach, iron
or dry clean.
LIMITED WARRANTY
Your UPPAbaby stroller is warranted to be free from any manufacturing defects for a
period of 2 years from the date of purchase under normal use and in compliance with
the operating instructions.
This warranty cannot be extended and an extended warranty cannot be purchased.
This warranty is not transferable and extends only to the original retail purchaser and
is only valid when supplied with proof of purchase. PLEASE RETAIN PROOF OF
PURCHASE FOR THIS LIMITED WARRANTY.
The warranty is valid only in the original country of purchase. This warranty is subject
to the conditions set forth by country in which the items were purchased. Conditions
may vary. UPPAbaby will not ship replacement or repair parts out of the country
of purchase.
UPPAbaby will provide replacement parts or conduct repairs as determined fitting by
the company. UPPAbaby reserves the right to exchange item with a replacement part.
Some parts may be replaced with newer model parts as the stroller is improved over time.
Please note that a repair issue will NOT be covered by this warranty if:
• The issue is caused by misuse or poor maintenance. Please refer to this instruction
booklet for guidance on stroller use and maintenance.
• Damage is caused by improper installation of UPPAbaby parts and/or accessories.
Please refer to this instruction booklet for guidance on stroller assembly and use.
• Damage is corrosion, mold or rust caused by lack of maintenance or service.
• Damage is due to general wear and tear, which is the result of everyday use or negligence.
• Damage is caused by sun intensity, sweat, detergents, damp storage or frequent washings.
• Repairs or modifications are carried out by a third party.
• Stroller is purchased from an unauthorized retailer. Approved retailers are listed on our
website at www.uppababy.com.
• Stroller is second-hand.
• Stroller is damaged as a result of an accident, airline or freight damage.
UPPAbaby reserves the right to determine if warranty terms and conditions have been met.
Please contact your local distributor if you have any questions regarding warranty.
Register your stroller online at www.uppababy.com.
CUSTOMER SERVICE
COUNTRY CONTACT TELEPHONE WEBSITE
US 60 Sharp Street Hingham, MA 02043 781.413.3030 www.uppababy.com
CANADA
5514KM
19 Industrial Street
Toronto, Ontario M4G 1Z2
1.888.502.5514 www.uppababy.com
0112_Vista_US_Ins_V5.indd 14-15 7/15/13 1:05 PM

16Manual de Instrucciones UPPAbaby VISTA ESPAÑOL
17
WARNINGS + GENERAL SAFETY
INFORMATION
ADVERTENCIAS E INFORMACIÓN GENERAL DE SEGURIDAD WARNINGS + GENERAL SAFETY
INFORMATION
CARE
ADVERTENCIAS E INFORMACIÓN GENERAL DE SEGURIDAD
ADVERTENCIA
NUNCA DEJE AL NIÑO SIN SUPERVISIÓN. NO SEGUIR ESTAS INSTRUCCIONES
CORRECTAMENTE PODRÍA RESULTAR EN LESIONES GRAVES PARA SU HIJO:
Mantenga estas instrucciones para futura referencia.
ADVERTENCIAS SOBRE EL COCHECITO:
• Este cochecito es apto para niños a partir del nacimiento (con el reductor
de asiento opcional Infant SnugSeat) y hasta que alcancen los 22,7 kg
(50 lbs) de peso o los 101 cm (40") de estatura.
• Este cochecito está diseñado para su uso con un solo niño, a menos que
esté equipado con los accesorios adecuados de UPPAbaby.
• Debe oírse un “clic” para determinar que cada seguro haya sido encajado
en la posición correcta.
• La barra protectora debe estar colocada en todo momento.
• El freno debe estar puesto cuando se ponga al niño en el cochecito
o se saque de él y cuando el cochecito esté aparcado.
• El peso máximo para la cesta de almacenaje es de 6,8 kg.
• La capacidad máxima del bolsillo del asiento es .5 kg.
• NUNCA deje al niño en el cochecito cuando suba o baje escaleras o use
el ascensor.
• NO haga ninguna alteración o modificación al cochecito con productos
que no hayan sido suministrados por el fabricante, ya que esto podría causar
inestabilidad o daños estructurales que no están cubiertos por la garantía.
ADVERTENCIA: para evitar que se produzca una lesión grave por
deslizamientos o caídas, utilice siempre el arnés de 5 puntos de sujeción.
ADVERTENCIA: el niño podría deslizarse entre las aperturas de las piernas
y estrangularse. NUNCA lo utilice en una posición reclinada salvo que el
niño esté sujeto por un sistema de arnés de 5 puntos de sujeción.
ADVERTENCIA: la unidad podría perder estabilidad si se excede la carga
máxima recomendada por el fabricante o si se usa o se cuelga de la unidad una
bolsa portapaquetes o un accesorio distinto al recomendado por el fabricante.
ADVERTENCIA: los niños y adultos deberán permanecer alejados de las
piezas móviles al realizar ajustes en el cochecito. Podrían ocurrir lesiones
en dedos y extremidades al abrir o cerrar el chasis.
ADVERTENCIA: la capota del asiento no está diseñada para mantener
al niño en su sitio.
• La capota debe estar colocada en todo momento.
Este producto ha sido diseñado y fabricado para cumplir la Norma ASTM F833 sobre Seguridad del Consumidor
en materia de especificación del desempeño para coches cuna/coches de paseo, y está certificado por JPMA. Este
producto ha sido diseñado y fabricado para cumplir la Norma canadiense SOR/91-350,s 1(F) sobre Regulaciones
para Coches Cuna y Cochecitos.
ADVERTENCIA
ADVERTENCIAS SOBRE EL CAPAZO:
Debe oírse un “clic” para determinar que cada seguro ha sido ajustado en la
posición correcta. Para garantizar que el cierre de bloqueo se ha ajustado
de manera correcta, compruebe que el capazo/asa de transporte no pueda
soltarse del cochecito sin desbloquear el dispositivo.
• El capazo se acopla SOLO orientado hacia atrás, de modo que el bebé
quede de cara al usuario.
• Debe retirarse el capazo para plegar el cochecito.
• Peso máximo del niño 20 lbs (9 kg).
• Altura máxima del niño 25" (63 cm).
ADVERTENCIA: Para evitar caídas, no utilice este producto cuando el bebé
pueda gatear o haya alcanzado el peso máximo recomendado por el fabricante,
lo que ocurra primero.
ADVERTENCIA: Los movimientos del niño podrían deslizar el capazo. NUNCA
ponga el capazo cerca de los bordes de encimeras, mesas u otras superficies altas.
ADVERTENCIA: NUNCA utilice el capazo como medio de transporte para
un bebé en un vehículo motorizado.
ADVERTENCIA: Se recomienda el uso de la cubierta del capazo para mayor
seguridad de su hijo. Consulte la página 22 para ver las instrucciones de instalación.
ADVERTENCIA: El capazo solo debe ponerse en una superficie baja, seca,
firme y horizontal cuando no se utilice con el cochecito o el soporte de capazo.
ADVERTENCIA: NUNCA ponga el capazo sobre un a cama, un sofá u otro
tipo de superficies blandas.
ADVERTENCIA: No permita que otros niños jueguen junto al capazo sin
supervisión.
ADVERTENCIA: La unidad podría perder estabilidad si se usa una bolsa
portapaquetes distinta a la recomendada por el fabricante.
ADVERTENCIA: Las llamas y otras fuentes de calor como calentadores eléctricos,
hornos de gas, etc. próximos al capazo son peligrosos y deben evitarse.
ADVERTENCIA: Este capazo está diseñado solo para utilizarse con el armazón
de cochecito VISTA y el soporte de capazo VISTA.
ADVERTENCIA: NO utilice el capazo si está dañado o roto.
PELIGRO DE ESTRANGULACIÓN: ¡Los cordones pueden causar estrangulación!
NO ponga objetos con cordones alrededor del cuello del niño, como cordones
de capuchas o de chupetes. NO cuelgue cordones sobre un capazo ni lo use
como base de sujeción o ate cordones a los juguetes.
0112_Vista_US_Ins_V5.indd 16-17 7/15/13 1:05 PM
