Fiber OpticConnectorCassetteCleaningToolUser Manual
ForusewithUSConecLtd.partnumbers:
MTPMale–NolabelATC-RE-036339
SingleSlot –WithUSCLabelATC-RE-016227
TwoSlot(LCDuplex)–NoLabelATC-RE-026437
MTPMale–WithUSCLabelATC-RE-036226
MTRJMale–NoLabelATC-RE-046340
TwoSlot(LCDuplex)–WithUSCLabelATC-RE-026230
ATC-RE-03W
ATC-RE-04
ATC-RE-01
NTT-AT P/N
FTTHOptiTapPlugConnections–NoLabel8057
MTRJMale–WithUSCLabel6228
SingleSlot –Nolabel6338
DescriptionUSConecP/N
Lever
WindingReel
GuideRoller
Screw
Cover
Window
Wiping Board
GuideRoller
CassetteReel
Thankyou foryourpurchaseoftheOPTIPOPRcassette.Thisisthelatestgeneration ofthefiberoptic
cassettecleaningtoolsfromNTT-AdvancedTechnology,theworld’sleadingexpertonfiberoptic
connectorcleaningsolutions.
TheUsersManualincludestheinstructionson howtoproperlyuseOPTIPOPRcassetteandinstructions
on how toreplacethecleaningtape.Followingtheseinstructionswill helpyou getthebestcleaning
performance fromyourOPTIPOPRcassetteandthelongservicelife.

Step 3:
Releasethelevertocloseshutter
Step 2:
Depress theferruleonthecleaning
tapeusing samepressureasawriting
pen.Movetheconnectorfromleftto
right.
When cleaningangledpolished
connectors(APC), besuretoturnthe
ferrulesothat endfaceismaking
contact.
Step 1:
Opentheshutterbygrippingthe
lever. Theshutterwillopenand a
newsection ofcleaningtapewillbe
available.
Howto CleanConnectors
Step 6:
Engagethelevertwoorthreetimesto
verifythecleaningtapeismoving
smoothly.
Step 3:
Loadthenewcleaningtapeontothe
windingreel.Secureitusinga
bondingtape.
Step 5:
Re-hookthecoverontotheright sideof
thecassettehousing.
Re-snapthetab ontheleft sideofthe
cover
Step 2:
Pullthecleaningtapefromthe
windingreel
Step 4:
Reinsertthewindingreeland cassette
reel.
Routethecleaning tapeovertheguide
rollersand wipingboard.
Step 1:
Turnthescrewwithacoinorflat
headscrewdriver.
Removethecassettereeland
windingreel.
Howto Replace TheCassetteReel
Caution!
•OnlyuseOPTIPOPRrefillsmanufacturedbyNTT-AdvancedTechnology.FailuretouseNTT-AdvancedTechnology
manufacturedreplacement refillsmayvoid thewarranty.
•DoNOTreusecleaningtapeasthismaycausecross contaminationand causepermanentdamage.
•Anewrefillisneededwhentheleverbecomesdifficulttodepress.
•Donotleavethecassetteintemperaturesexceeding60 C/140 F forextendedperiods.
•OPTIPOPRcassettesarewarrantedformanufacturerand materialdefectsonly. Abusive, neglect oruseforunintended
purposesarenot coverednot coveredinthewarranty.
Fortechnical supportorre-orderinginformation,pleasecontactUSConecLtdat:
[e-mail] +1.828.323.8883(international)1.800.769.0944(USandCanada)
