US Robotics 5412 User manual

Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card and PCI Adapter
●Home
●Installation
●Configuration
●Help
The USRobotics Wireless Nd1PC Card and PCI Adapter are the solution to your home and small business
wireless connectivity needs. Nd1technology provides the maximum 802.11g range in the industry,
delivering optimal wireless connections to your PCs, laptops, and other wireless devices. Nd1also provides
the maximum speed – up to 270 Mbps – delivering large files like MP3s, digital photos, and digital video
through your network fast and efficiently. And with Nd1, your network will be protected with a maximum
security suite of capabilities, including Wi-Fi Protected Access (WPA), WPA2/802.11i (Windows 2000 and XP
only), MAC address filtering, and more.
And to assure a simple, straight-forward installation, U.S. Robotics developed the SureStart installation
wizard. SureStart walks you through the installation of any Nd1PC Cards, PCI Adapters, USB Adapters, or
Routers in a seamless fashion. In addition, SureStart provides easy-to-understand guidance to set up
security for your wireless network. Sharing Internet access securely, wirelessly or wired, has never been
easier.
System Requirements
●Windows™ XP SP1 or Windows 2000 SP4
●Available PCI or PC slot
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/index.html (1 of 2)9/7/2006 9:29:38 AM

Wireless Nd1 PC Card and PCI Adapter
●CD-ROM drive
●A functioning Ethernet-based cable or DSL modem or other WAN connection for Internet access
●A browser that supports HTML 4.01 specification with Javascript enabled
© 2005-2006 U.S. Robotics Corporation
R46.1334.00
rev 1.2
9/06
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/index.html (2 of 2)9/7/2006 9:29:38 AM

Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card and PCI Adapter
●Home
●Installation
●Configuration
●Help
Product Specifications
(note to reviewers - except for SecureEasySetup, this is pulled directly out of MAXg)
Wireless Nd1PC Card
●Complies with IEEE 802.11g 54 Mbps wireless radio standard
●Note to reviewers: Is there a Pre-N standard compliance that should be noted
here?
●100mW power output
●Supports Windows 2000 and Windows XP
●SecureEasySetup™ for automatic Wireless LAN configuration with Wireless Nd1
routers and access points.
Wireless Nd1PCI Adapter
●Complies with IEEE 802.11g 54 Mbps wireless radio standard
●Note to reviewers: Is there a Pre-N standard compliance that should be noted
here?
●100mW power output
●2 dBi Detachable Reverse SMA Antennas
●Supports Windows 2000 and Windows XP
●SecureEasySetup for automatic Wireless LAN configuration with Wireless Nd1
routers and access points.
Security Features
9 AMfile:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/features.html (1 of 2)9/7/2006 9:29:3

Wireless Nd1 PC Card and PCI Adapter
●WPA (Wi-Fi Protected Access)
●WPA2 (Wi-Fi Protected Access)
●802.1x (RADIUS) authentication
●CCX 1.0 and 2.0
●CCKM
●64/128-bit WEP (Wired Equivalent Privacy) data encryption
●Ability to disable wireless radio
●AES
●TKIP
Acknowledgements
Note to reviewers: Does this apply to the 5412 and 5419?
This product includes software developed by MDC and its licensors. This product
includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit
(http://www.openssl.org/). This product includes cryptographic software written by
Eric Young ([email protected]). This product includes software written by Tim
Hudson ([email protected]).
9 AMfile:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/features.html (2 of 2)9/7/2006 9:29:3

Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card and PCI Adapter
●Home
●Installation
●Configuration
●Help
Installation
Depending on the product that you purchased, choose one of the following
installation instructions:
Click here if you are installing a Wireless Nd1PC Card.
Click here if you are installing a Wireless Nd1PCI Adapter.
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/install.html9/7/2006 9:29:39 AM

Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card and PCI Adapter
●Home
●Installation
●Configuration
●Help
Install Your USRobotics Wireless Nd1PC Card
1. Insert the USRobotics Installation CD-ROM into your computer’s CD or DVD ROM
drive.
If the CD does not start automatically, start it manually as follows:
A. Windows XP: Click Windows Start > My Computer.
Windows 2000: On the desktop, double-click My Computer.
B. Double-click the CD drive.
2. Click Wireless Nd1PC Card, click Install, and follow the on-screen instructions.
3. If a window appears warning that the software has not passed Windows testing,
continue with the installation. USRobotics has thoroughly tested the operation of
the software with Windows to ensure its safe operation.
Windows XP: Click Continue Anyway.
Windows 2000: Click Yes.
4. When you are prompted, insert the PC Card.
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/pc-install.html (1 of 3)9/7/2006 9:29:39 AM

Wireless Nd1 PC Card and PCI Adapter
5. Windows XP only:
A. If the Found New Hardware Wizard asks to connect to the Windows update
Web site to search for software, select No, not this time and click Next.
B. With Install the software automatically selected, click Next.
6. If a window appears warning that the software has not passed Windows testing,
continue with the installation. USRobotics has thoroughly tested the operation of
the software with Windows to ensure its safe operation.
Windows XP only: Click Continue Anyway.
Windows 2000 only: Click Yes.
7. Windows XP only: Click Finish.
8. Select the option that matches your wireless network and follow the on-screen
instructions.
You can connect your PC Card to an Nd1or other SecureEasySetup certified router or
access point using the SecureEasySetup button. SecureEasySetup configures the
wireless security settings to creates a secure connection. If your wireless router or
access point is SecureEasySetup certified, one of the following logos should appear on
the device:
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/pc-install.html (2 of 3)9/7/2006 9:29:39 AM

Wireless Nd1 PC Card and PCI Adapter
You can also manually enter the wireless security settings to connect your PC Card to
any router or access point.
If you choose not to connect to a wireless network at this time, you can connect later by
following the instructions in Connect to a Wireless Router or Access Point After
Installation.
You have successfully completed the installation procedure. Please register your
USRobotics Wireless Nd1PC Card at www.usr.com/productreg/.
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/pc-install.html (3 of 3)9/7/2006 9:29:39 AM

Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card and PCI Adapter
●Home
●Installation
●Configuration
●Help
Install Your USRobotics Wireless Nd1PCI Adapter
1.
Insert the USRobotics Installation CD-ROM into your computer’s CD-ROM or
DVD drive.
If the CD does not start automatically, start it manually as follows:
A. Windows XP: Click Windows Start > My Computer.
Windows 2000: On the desktop, double-click My Computer.
B. Double-click the CD drive.
2. Click Wireless Nd1PCI Adapter, click Install, and follow the on-screen
instructions.
3. If a window appears warning that the software has not passed Windows testing,
continue with the installation. USRobotics has thoroughly tested the operation
of the software with Windows to ensure its safe operation.
Windows XP: Click Continue Anyway.
Windows 2000: Click Yes.
4. When you are prompted to Power Off your computer, click Power Off (with
Windows 2000 you must also manually power off the computer) and unplug
your computer.
5. Open your computer’s case and remove the screw and metal filler bracket for
an available PCI slot.
6. Hold the wireless adapter by its edges. Do not touch the contacts on the
connector. Insert the wireless adapter into the available PCI slot and press it
firmly to seat it in the connector.
file:///G|/CSO/T-Writer%20Repository/Networking/5419%20Mach-1%20PCI%20Adapter/User%20Guide/pci-install.html (1 of 3)9/7/2006 9:29:40 AM

Wireless Nd1 PC Card and PCI Adapter
7. Use the screw removed in Step 5 to secure the PCI Adapter.
8. Attach the antennas to the wireless card.
9. Close your computer, plug it in, and turn it on.
10. Windows XP only:
A. If the Found New Hardware Wizard asks to connect to the Windows
update Web site to search for software, select No, not this time and
click Next.
B. With Install the software automatically selected, click Next.
11. If a window appears warning that the software has not passed Windows testing,
continue with the installation. USRobotics has thoroughly tested the operation
of the software with Windows to ensure its safe operation.
Windows XP only: Click Continue Anyway.
Windows 2000 only: Click Yes.
12. Windows XP only: Click Finish.
13. Select the option that matches your wireless network and follow the on-screen
instructions.
You can connect your PCI Adapter to an Nd1or other SecureEasySetup certified
router or access point using the SecureEasySetup button. SecureEasySetup configures
the wireless security settings to creates a secure connection. If your wireless router or
access point is SecureEasySetup certified, one of the following logos should appear on
the device:
